Grundig GRVPO 090 User manual

Split type air conditioner
User Manual
10M-8508723600-4422-01
EN
GRVPO 090/GRVPO 091
GRVPO 120/GRVPO 121
GRVPO 180/GRVPO 181
GRVPO 240/GRVPO 241
GRFPO 070/GRFPO 071
GRFPO 090/GRFPO 091
GRFPO 120/GRFPO 121
GRFPO 180/GRFPO 181

CONTENTS
ENGLISH 1-62
V2210003

Please read this user manual rst!
Dear Customer,
Thank you for preferring a Grundig product. We hope that you get the best results
from your product which has been manufactured with high quality and state-of-the-art
technology. Therefore, please read this entire user manual and all other accompanying
documents carefully before using the product and keep it as a reference for future use.
If you handover the product to someone else, give the user manual as well. Follow all
warnings and information in the user manual.
Meanings of the symbols
Following symbols are used in the various section of this manual:
C
Important information or
useful hints about usage.
A
Warning for hazardous
situations with regard to life
and property.
Warning to actions that
must never perform.
B
Warning for electric shock.
This symbol shows that
information is available such
as the operating manual or
installation manual.
Do not cover it.
This symbol shows that the
operation manual should be
read carefully.
This symbol shows that a
service personnel should be
handling this equipment with
reference to the installation
manual.
(For R32/R290 gas
type)
This symbol
shows that this
appliance used
a flammable
refrigerant. If
the refrigerant
is leaked and
exposed to an
external ignition
source, there is a
risk of fire.

CONTENTS
1 Safety precautions 7
2 Name of parts 13
3 Remote controller 15
4 Remote control 20
4.1 Cooling mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.2 Fan mode (not fan button) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.3 Dry mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.4 Auto mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.5 Heating mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
4.6 Fan speed function (Fan button) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.7 Child-Lock function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.8 Timer function ---- Timer On. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.9 Timer function ---- Timer Off. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 21
4.10 Swing function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.11 Turbo function. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.12 Mute function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.13 Sleep function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.14 ZoneFollow function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.15 ECO function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.16 Display function (Indoor display). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.17 GEN function (For Inverter Only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.18 Soft Breeze function (For Inverter Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.19 8°C heating function (For Inverter Only). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.20 Go Clean function (For Heat Pump Inverter only) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4.21 Self Clean+ function (Optional) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
4 / 62 EN Split type air conditioner / User Manual

CONTENTS
5 Operation instructions 25
6 Instructions for servicing (R32) 27
7 Installation precautions (R32) 34
7.1 Important considerations . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.2 The maximum charge and the required minimum floor area . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
7.3 Installation safety principles . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
7.4 Suggested tools . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
8 Installation precautions 37
8.1 Pipe length and additional refrigerant . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.2 Torque parameters. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37
8.3 Dedicated distribution device and wire for air conditioner. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 38
9 Indoor unit installation 39
9.1 Step 1: Select installation location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
9.2 Step 2: Install mounting plate . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
9.3 Step 3: Drill wall hole . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
9.4 Step 4: Connecting refrigerant pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
9.5 Step 5: Connect drainage hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
9.6 Step 6: Connect wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
9.7 Step 7: Wrap piping and cable . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
9.8 Step 8: Mount indoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
10 Outdoor unit installation 45
10.1 Step 1: Select installation location . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
10.2 Step 2: Install drainage hose . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
10.3 Step 3: Fix outdoor unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
10.4 Step 4: Install wiring. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Split type air conditioner / User Manual 5 / 62 EN

CONTENTS
10.5 Step 5: Connecting refrigerant pipe . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
10.6 Step 6: Vacuum pumping . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
11 Test operation 49
11.1 Inspections before test run . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
11.2 Test run instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
12 Maintenance 51
13 Troubleshooting 53
13.1 Error code on the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
14 European disposal guideline 55
15 Installation instructions 56
15.1 F-Gas instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
16 Specification 57

Split type air conditioner / User Manual 7 / 62 EN
Safety rules and
recommendations for the
installer
1. Read this guide before
installing and using the
appliance.
2. During the installation of
the indoor and outdoor
units, access to the working
area should be forbidden
to children. Unforeseeable
accidents could happen.
3. Make sure that the base of the
outdoor unit is firmly fixed.
4. Check that air cannot enter the
refrigerant system and check
for refrigerant leaks when
moving the air conditioner.
5. Carry out a test cycle after
installing the air conditioner
and record the operating data.
6. Protect the indoor unit with a
fuse of suitable capacity for
the maximum input current
or with another overload
protection device.
7. Ensure that the mains voltage
corresponds to that stamped
on the rating plate. Keep the
switch or power plug clean.
Insert the power plug correctly
and firmly into the socket,
thereby avoiding the risk of
electric shock or fire due to
insufficient contact.
8. Check that the socket is
suitable for the plug, otherwise
have the socket changed.
9. The appliance must be fitted
with means for disconnection
from the supply mains
having a contact separation
in all poles that provide full
disconnection under over
voltage category Ill conditions,
and these means must be
incorporated in the fixed wiring
in accordance with the wiring
rules.
10.The air conditioner must be
installed by professional or
qualified persons.
1 Safety precautions

8 / 62 EN Split type air conditioner / User Manual
1 Safety precautions
11.Do not install the appliance
at a distance of less than
50 cm from inflammable
substances (alcohol, etc.) Or
from pressurized containers
(e.g. spray cans).
12.If the appliance is used in
areas without the possibility
of ventilation, precautions
must be taken to prevent any
leaks of refrigerant gas from
remaining in the environment
and creating a danger of fire.
13.The packaging materials are
recyclable and should be
disposed of in the separate
waste bins. Take the air
conditioner at the end of its
useful life to a special waste
collection center for disposal.
14.Only use the air conditioner
as instructed in this booklet.
These instructions are
not intended to cover
every possible condition
and situation. As with
any electrical household
appliance, common sense and
caution are therefore always
recommended for installation,
operation and maintenance.
15.The appliance must be
installed in accordance
with applicable national
regulations.
16.Before accessing the
terminals, all the power
circuits must be disconnected
from the power supply.
17.The appliance shall be
installed in accordance with
national wiring regulations.
18.This appliance can be used
by children aged from 8 years
and above and persons with
reduced physical, sensory
or mental capabilities or
lack of experience and
knowledge if they have
been given supervision or
instruction concerning use
of the appliance in a safe
way and understand the
hazards involved. Children

Split type air conditioner / User Manual 9 / 62 EN
shall not play with the
appliance. Cleaning and user
maintenance shall not be
made by children without
supervision.
19.Do not try to install the
conditioner alone, always
contact specialized technical
personnel.
20.Cleaning and maintenance
must be carried out by
specialized technical
personnel. In any case
disconnect the appliance
from the mains electricity
supply before carrying out any
cleaning or maintenance.
21.Ensure that the mains voltage
corresponds to that stamped
on the rating plate. Keep the
switch or power plug clean.
Insert the power plug correctly
and firmly into the socket,
thereby avoiding the risk of
electric shock or fire due to
insufficient contact.
22.Do not pull out the plug to
switch off the appliance
when it is in operation, since
this could create a spark and
cause a fire, etc.
23.This appliance has been made
for air conditioning domestic
environments and must not
be used for any other purpose,
such as for drying clothes,
cooling food, etc.
24.Always use the appliance with
the air filter mounted. The use
of the conditioner without air
filter could cause an excessive
accumulation of dust or
waste on the inner parts
of the device with possible
subsequent failures.
25.The user is responsible for
having the appliance installed
by a qualified technician,
who must check that it is
earth in accordance with
current legislation and insert
a thermos magnetic circuit
breaker.
1 Safety precautions

10 / 62 EN Split type air conditioner / User Manual
26.The batteries in the remote
controller must be recycled
or disposed of properly. For
disposal of scrap batteries,
please discard the batteries as
sorted municipal waste at the
accessible collection point.
27.Never remain directly exposed
to the flow of cold air for a
long time. The direct and
prolonged exposition to cold
air could be dangerous for
your health. Particular care
should be taken in the rooms
where there are children, old or
sick people.
28.If the appliance gives off
smoke or there is a smell of
burning, immediately cut off
the power supply and contact
the Service Center.
29.The prolonged use of the
device in such conditions
could cause fire or
electrocution.
30.Have repairs carried out only
by an authorised Service
Centre of the manufacturer.
Incorrect repair could expose
the user to the risk of electric
shock, etc.
31.Unhook the automatic switch
if you foresee not to use the
device for a long time. The
airflow direction must be
properly adjusted.
32.The flaps must be directed
downwards in the heating
mode and upwards in the
cooling mode.
33.Ensure that the appliance is
disconnected from the power
supply when it will remain
inoperative for a long period
and before carrying out any
cleaning or maintenance.
34.Selecting the most suitable
temperature can prevent
damage to the appliance.
1 Safety precautions

Split type air conditioner / User Manual 11 / 62 EN
Safety rules and
prohibitions
1. Do not bend, tug or compress
the power cord since this
could damage it. Electrical
shocks or fire are probably
due to a damaged power
cord. Specialized technical
personnel only must replace a
damaged power cord.
2. Do not use extensions or gang
modules.
3. Do not touch the appliance
when barefoot or parts of the
body are wet or damp.
4. Do not obstruct the air inlet
or outlet of the indoor or the
outdoor unit. The obstruction
of these openings causes
a reduction in the operative
efficiency of the conditioner
with possible consequent
failures or damages.
5. In no way alter the
characteristics of the
appliance.
6. Do not install the appliance
in environments where the
air could contain gas, oil or
sulphur or near sources of
heat.
7. This appliance is not
intended for use by persons
(including children) with
reduced physical, sensory
or mental capabilities, or
lack of experience and
knowledge, unless they have
been given supervision or
instruction concerning use
of the appliance by a person
responsible for their safety.
8. Do not climb onto or place any
heavy or hot objects on top of
the appliance.
9. Do not leave windows or
doors open for long when the
air conditioner is operating.
10.Do not direct the airflow onto
plants or animals.
1 Safety precautions

12 / 62 EN Split type air conditioner / User Manual
11.A long direct exposition
to the flow of cold air of
the conditioner could have
negative effects on plants and
animals.
12.Do not put the conditioner
in contact with water. The
electrical insulation could be
damaged and thus causing
electrocution.
13.Do not climb onto or place any
objects on the outdoor unit.
14.Never insert a stick or similar
object into the appliance. It
could cause injury.
15.Children should be supervised
to ensure that they do not
play with the appliance. If
the supply cord is damaged,
it must be replaced by the
manufacturer, its service
agent or similarly qualified
persons in order to avoid a
hazard.
Package information
Packaging materials of the
product are manufactured
from recyclable materials in
accordance with our National
Environment Regulations. Do
not dispose of the packaging
materials together with the
domestic or other wastes. Take
them to the packaging material
collection points designated by
the local authorities.
Compliance with RoHS
Directive
The product you have purchased
complies with EU RoHS Directive
(2011/65/EU). It does not
contain harmful and prohibited
materials specified in the
Directive.
1 Safety precautions

Split type air conditioner / User Manual 13 / 62 EN
Indoor unit
Outdoor unit
Air outlet
Air outlet
Air deflector and flap
Mounting plate
Air filter
Air inlet
Front panel
Emergency button
Refrigerant connecting pipe
Air inlet
Wiring cover
Drainage pipe
Connection wiring
Valve protective cover
Gas valve
(Low pressure valve)
Liquid valve
(High pressure valve)
With the protective cover removed
2 Name of parts

14 / 62 EN Split type air conditioner / User Manual
2 Name of parts
C
Note:
This figure shown may be
different from the actual object.
Please take the latter as the
standard.
Indoor display
1
2
3
No. LED Function
1 Indicator for Timer, temperature and Error codes.
2 Lights up during Timer operation.
3 Sleep mode
A
Warning:
The shape and position of
switches and indicators may be
different according to the model,
but their function is the same.

Split type air conditioner / User Manual 15 / 62 EN
Inverter RC
3 Remote controller

16 / 62 EN Split type air conditioner / User Manual
On/Off RC
3 Remote controller

Split type air conditioner / User Manual 17 / 62 EN
Remote controller buttons
No. Buttons Function
1To turn on/off the air conditioner
2SOFT BREEZE To activate the function of soft breeze.
3MODE To select the operation mode: AUTO, COOL, DRY, FAN, HEAT.
4(TEMP UP) To increase the setting temperature, lengthen the time in TIMER
setting.
5(TEMP DN) To decrease the setting temperature, reduce the time in TIMER setting.
6To adjust the air flow direction vertically.
7To adjust the air flow direction horizontally.
8FAN To adjust the fan speed: auto, mute, low, mid-low, mid, mid-high, high.
Turbo
9ZONE FOLLOW To activate the function of ZoneFollow
10 TURBO To switch on/off the TURBO mode
11 ECO/GEN To switch on/off the ECO function and GENERATOR mode
12 TIMER/DISPLAY To switch on/off the TIMER function and LED display light
13 SLEEP/MUTE To switch on/off the SLEEP function and MUTE mode
14 Go Clean/Self Clean+ To switch Go Clean or Self Clean+ function
15
( + )
To activate the function of Child Lock, press and buttons
together for more than 3 seconds.
A
Warning:
• The display and some functions of the remote control may vary according to the
model.
• The shape and position of buttons and indicators may vary according to the model,
but their function is the same.
• The unit confirms the correct reception of each button with a beep.
• There might some functions not fit for your air conditioner, you will hear a beep
when you press these buttons, but air conditioner do not response, we express our
apologies.
3 Remote controller

18 / 62 EN Split type air conditioner / User Manual
Remote controller DISPLAY, meaning of symbols on the liquid crystal display
No. Symbols Meaning
1AUTO MODE indicator
2COOLING MODE indicator
3DRY MODE indicator
4FAN MODE indicator
5HEATING MODE indicator
6BATTERY indicator
7TEMPERATURE/CLOCK indicator
8or FLAP SWING (Air flow) indicator
9MUTE indicator
10 FAN SPEED indicator
11
(FLASH)
(FLASH) AUTO FAN indicator
12 TURBO indicator
13 CHILD LOCK indicator
14 ZoneFollow indicator
15 SOFT BREEZE indicator
16 ECO indicator
17 GENERATOR MODE indicator
18 TIMER indicator
19 SLEEP MODE indicator
20 DISPLAY LIGHT indicator
21 Go Clean/Self Clean+ function indicator
22 8° C heating function indicator
3 Remote controller

Split type air conditioner / User Manual 19 / 62 EN
Replacement of batteries
Remove the battery cover plate from the rear of
the remote controller, by sliding it in the direction
of the arrow.
Install the batteries according the direction
(+ and -) shown on the Remote Controller.
Reinstall the battery cover by sliding it into place.
A
Warning:
Use 2 LRO 3 AAA (1.5V) batteries.
Do not use rechargeable batteries.
Replace the old batteries with new
ones of the same type when the
display is no longer legible.
Do not dispose batteries as
unsorted municipal waste.
Collection of such waste
separately for special treatment is
necessary.
Recommendations for locating and using the
remote controller holder (if present). The remote
controller be kept in a wall-mounted holder.
3 Remote controller

20 / 62 EN Split type air conditioner / User Manual
4.1 Cooling mode
COOL
The cooling function allows the air
conditioner to cool the room and
reduce Air humidity at the same
time.
To activate the cooling function (COOL), press the
MODE
button until the symbol appears on
the display.
With the button or set a temperature lower
than that of the room.
4.2 Fan mode (not fan button)
FAN
Fan mode, air ventilation only.
To set the FAN mode, press
MODE
until
appears on the display.
4.3 Dry mode
DRY
This function reduces the humidity
of the air to make the room more
comfortable.
To set the DRY mode, Press
MODE
until
appears in the display. An automatic function of
pre-setting is activated.
4.4 Auto mode
AUTO
Automatic mode.
To set the AUTO mode, press
MODE
until
appears on the display.
In AUTO mode the run mode will be set
automatically according to the room temperature.
4.5 Heating mode
HEAT
The heating function allows the air
conditioner to heat the room.
To activate the heating function (HEAT), press the
MODE
button until the symbol appears on the
display.
With the button or set a temperature higher
than that of the room.
A
Warning:
• In HEATING operation, the
appliance can automatically
activate a defrost cycle, which
is essential to clean the frost
on the condenser so as to
recover its heat exchange
function. This procedure
usually lasts for 2-10 minutes.
During defrosting, indoor
unit fan stop operation. After
defrosting, it resumes to
HEATING mode automatically.
4 Remote control
