COREMAX M1 PROJECT
GM CHASSIS
SERVICE MANUAL

ENGLISH
2
CONTENTS---------------------------------------------------------------------------------------------------------------
5 REVISION LIST
7 PRODUCT SPECIFICATIONS
7 Technical specifications
10 Unique features of your TV set
10 Receiving digital stations
11 GRUNDIG SCR System
11 Things to do for energy saving
11 Notes on still images
11 Notes on still images
13 PRODUCT INSTALLATION
13 Package Content
13 Standard accessories
13 Optional accessories
14 Connection/Preparation
15 Setting up or hanging
16 Connections of the television
17 Control elements on the television
17 Starting and switching the television to
standby mode
17 Adjusting the volume or changing the
channel
17 Source selection
17 Inserting batteries into the remote control
19 SETTINGS
19 Tuning television channels
20 Initial set-up
22 Channel Editor for Digital channels
24 PICTURE / SOUND SETTINGS
25 Picture settings
27 Sound settings
27 Sound settings
28 Switching on and off
28 Selecting channels
28 Selecting a favorites list
28 Pinning a favorite channel to the main
menu
28 Selecting a signal source
28 Adjusting the volume
28 Muting
29 Displaying information
29 Audio language
29 Subtitles
29 Zap function
28 FUNCTIONING OF THE TV - BASIC
FUNCTIONS
30 In the »Tools« menu, you can find the
features below.
30 Sleep timer
30 Zoom function
30 Changing the picture format
31 ELECTRONIC TV GUIDE
32 TELETEXT MODE
32 TOP text or FLOF text mode
32 Normal text mode
32 Additional functions
33 Information on recording and playing
television programs
33 Possible restrictions when using external
data medium
34 Connecting external data medium
35 USB recording settings
36 "Pausing" time shift programs
37 Recording Programs
38 Program setting for recording
40 Editing the timer
40 Deleting the timer
40 Playback
Deleting broadcasts from the recorded
files menu
41 USB
41 File formats
42 Connecting external data medium
42 Before removing the external data me-
dium, disconnect the data medium.
43 File browser
43 Settings in the USB set-up menu
44 Basic playback functions
45 Additional playback functions
47 USING AN EXTERNAL DEVICE
47 DIGI LINK
47 Digi Link connection functions of the TV
48 Device Control
49 High resolution – HD ready
49 Connection options
50 Connecting an external device
51 Using a DVD recorder, DVD player, video
recorder or set-top box

3
ENGLISH
CONTENTS---------------------------------------------------------------------------------------------------------------
51 Headphones
51 Hi-Fi system
52 Playing audio signal with the Hi-Fi system
53 WIRED SCREEN SHARE (MHL)
53 What is MHL?
53 Connecting a mobile device
53 Choosing the channel position for the
mobile device
54 OPERATION WITH COMMON IN-
TERFACE
54 What is common interface?
54 Inserting the CA module
54 Access control for CA module and smart
cards
55 DETAILED CHANNEL SET-
TINGS
55 Searching for all satellite-connected digi-
tal television stations automatically
56 Searching for satellite-connected digital
television stations manually
57 Antenna settings for digital satellite chan-
nels and searching for channels automati-
cally
Antenna settings for digital satellite chan-
nels and searching for channels automati-
cally with SCR system
58 Antenna settings for digital satellite chan-
nels and searching for channels automati-
cally with SCR system
59 Antenna settings for digital satellite chan-
nels and searching for channels automati-
cally with DiSEqC 1.0/1.1
61 Searching for television channels from the
cable provider automatically
Searching for television channels from the
cable provider manually
Motor antenna setup
(DiSEqC 1.2)
Searching for television channels from the
cable provider automatically
62 Searching for television channels from the
cable provider manually
62 Searching for digital terrestrial TV chan-
nels automatically
63 Searching for digital terrestrial TV chan-
nels manually
64 Auto service update
64 Tuning analog television
channels
Changing stored analog
channels
66 GENERAL OPERATING PRINCIPLE
OF THE TV
66 Block Diagram
67 General Operating Principle of the Chas-
sis
67 DC Power Stage
69 OPERATING PRINCIPLES OF CIR-
CUIT COMPONENTS
69 IC200 Main integrated circuit (IC-SMD
MSD92LBSW2 BGA)
69 IC700 Nand flash (IC-SMD K9F-
2G08U0D)
69 IC400 Audio and headphone amplifier
(IC-SMD TAS5753MD)
70 IC104 Step-Down converter (IC-SMD
XC6222D151ER-G)
70 I
70 IC102 Step-down DC/DC converter
70 IC100 Current limited power distribution
switch (IC-SMD XC8107AC10MR-GW)
71 IC1000 LED Backlight Driver integrated
circuit (IC-SMD AP3064FNTR-G1)
71 IC201 System reset integrated circuit (IC-
SMD APX812-29UG-7)
72 IC900 Analog-digital tuner integrated
circuit (IC-SMD Si2151-A10-GMR)
72 IC902 Satellite tuner integrated circuit
(IC-SMD AV2018-S85QFG)
72 IC903 LNB regulator
73 SERVICE MENU SETTINGS
73 System configuration
73 Source configuration
73 TV configuration
75 Cloner configuration
76 Approved logos
76 Acoustic management
76 Software version
77 CUSTOMER SETTINGS
81 CHASSIS DIAGRAMMATIC IMAG-

ENGLISH
4
CONTENTS---------------------------------------------------------------------------------------------------------------
ES
81 Chassis DC socket
81 DC voltages
83 Satellite tuner
84 USB
85 FAILURE/ERROR ANALYSES
85 Sound available but no picture, and back
lights illuminated
87 Sound available but no picture, and back
lights not illuminated
89 No audio
91 SOFTWARE UPDATE
91 Updating TV Software by using USB
memory
91 Updating software and boot from the user
menu
92 Updating panel file
92 Locations where required keys are stored
93 TeraTerm usage
94 HOTEL TV SETUP
95 GLOSSARY

5
ENGLISH
REVISION LİST ---------------------------------------------------------------------------------------------------
Version Amendment Date Responsible Department
1 SEK draft published 27.07.2017 TV Design Application

ENGLISH
6
SAFETY -------------------------------------------------------------------------------------------------------------------------
WARNING
Risk of electrical accident
7 Do not open the TV set. Safety risk may arise
and also the guarantee of the product can be
void if the television set is opened.
7 The TV set can only be operated with the
power cable or the AC/DC adapter supplied
with the product.
7 Do not operate the TV set with a damaged
power cable/AC/DC adaptor (if supplied).
7
on products with 32" external adapter option:
If you use a 12 V battery to supply the TV, you must
use a suitable cable with 6A support.
If you use it with an external adaptor, you need to
use a 12 V (min. 6A) adaptor.
7 If the plug on the TV set has an earthing con-
tact, only insert the plug into a socket with an
earthing contact.
7 Plug the TV set into the mains socket only after
you have connected the external devices and
the antenna.
7 Protect the TV set from moisture. Do not place
any vessels filled with water (such as vases)
on the TV.
Fire hazard
7 To prevent the spread of fire,
keep candles or other open
flames away from this product at
all times.
7 Do not cover the ventilation slots on the TV
set.
7 Always unplug the power plug and an-
tenna plug during thunderstorms and stormy
weather.
7 Keep candles or other open flames away from
the TV set.
7 Do not expose the batteries to extreme heat
such as sunshine, fire or the like.
7 Only use batteries of the same type (brand,
size, properties). Do not use used and new
batteries together.
Injuries caused by falling TV set
Never place the TV set on an unstable surface.
The TV set may fall, causing serious injury, possi-
bly leading to death in isolated cases. Observe
the following precautions especially to protect
the children from such negative incidents:
7
Only use furniture that can safely support the
TV set.
7
Sides of the TV must not extend beyond the
on which the television is placed.
7
Do not place the television on furniture such
as cupboard, sideboard, bookshelf that tends
to tip over. In obligatory cases, such bearers
must be fixed onto the wall or suchlike struc-
tures so that the television does not tip over.
7
There must be no cover, lace, cloth, tulle or
similar items between the television and the
stand/furniture you have placed the television
on.
7
Instruct children that there is danger associ-
ated with climbing on furniture when the TV
set is to be reached.
7
Observe the aforementioned warnings when
you displace the television.
WARNING
Shortened service life due to high oper-
ating temperature
7 Do not place the TV set next to heating units
or in direct sunlight.
7 To ensure adequate ventilation, maintain
clearance of at least 10 cm around the TV set.
Discolouration of furniture due to rub-
ber feet
7 Some furniture surfaces may discolour when
they come in contact with rubber. To protect
furniture, you can place a sheet made of glass
or plastic under the stand. Do not use textile
underlays or mats such as doilies.

ENGLISH
7
Technical specifications
Specification Crystal LUNA Ledart
Energy Class A/A+ A/A+
Display Size 32((HD), 32" 40"
43"(FHD)
24" 32" (HD), 40"
43" (FHD)
32(HD), 43"
49"(FHD)
PPR 500/600/800/850 200/600/800 600/800
HD Ready YES YES YES
Full HD YES YES YES
Ultra HD NO NO NO
Full HD 50 Hz YES YES YES
Full HD 100Hz NO NO NO
Audio output "7W@8ohm 12.5V"
must be selected on 32"
products, "10W@8ohm
13.5V" must be selected
on 40" products, and
"10W@8ohm 24V" must
be selected on 43" prod-
ucts.
"3W@6ohm 12V"
must be selected
on 24" products,
"6W@6ohm 12.5V"
must be selected
on 32" products,
"8W@6ohm 12.5V"
must be selected
on 40" and 43"
products, and
"8W@6ohm 24V"
must be selected on
50" products.
"7W@8ohm 12.5V"
must be selected on
32" products, and
"10W@8ohm 24V"
must be selected on
43", 49" and 55"
products.
On board Subwoofer NO NO NO
Standby power consumption <0.5W
Power input (V/Hz.) 220-240V ~ 50-60Hz
Rosh Limits Pb (Lead) / Hg (Mercury) Pb, complies with RoHS Directive / 0 mg
Scart OUT NO
Scart input Standard
Audio/Video RCA input Via Scart
S-Video input Via Scart
HDMI input 1-2-3 HDMI 1.4
YPBPR input Via Scart
VGA input NO
PC audio input NO
PRODUCT SPECIFICATIONS --------------------------------------------------------------

ENGLISH
8
Line Out Via Headphones
Headphone Socket Standard
Optics Out YES
Languages Support for 27 different languages
Diseqc Standard Diseqc 1.2
Broadcasting Systems DVB-T2/C/S2
(Analog/DVB-T2/DVB-C/DVB-S2)
100 / 1000 / 1000 / 6000
.3gp, .mp3, .m4a, .aac, .mov, divx (4/5/6.x), .mpg, .vob, .dat, .ts, .avi,
.mp4, .mkv, .trp, .div, H264 (L4.0), H264 (L4.1), HEVC
Digital Program memory TV/
Radio
USB Film formats
USB Subtitle formats SRT, SSA, ASS, SMI, .txt
.jpg, .jpe, .bmp, .png,
USB Picture formats
MEMC NO NO NO
Integrated WiFi & Bluetooth NO NO NO
WiFi Ready NO NO NO
Appstore (download-remove-
update, move, add favorite)
NO NO NO
Inter@ctive Cloud (Dropbox) NO NO NO
DLNA NO NO NO
ROVI Smart TV Guide (Web
EPG)
NO NO NO
Web Browser NO NO NO
AppPip NO NO NO
HBB TV 1.2.1 (1.5 ) NO NO NO
HEVC YES (Tuner, USB) YES (Tuner, USB) YES (Tuner, USB)
Wi-di (other than Widi ready
products)
NO NO NO
Live Share (Widi & Miracast) NO NO NO
Interactive Hotel TV NO NO NO
VoD - Maxdome/Netflix/
Amazon Prime*
NO NO NO
Online Software Update NO NO NO
OSD Type Grundig/Beko/Arçelik/
OEM
Grundig/Beko/
Arçelik/OEM
Grundig/Beko/
Arçelik/OEM
Easy-to-Use User Interface YES YES YES
PRODUCT SPECIFICATIONS --------------------------------------------------------------

ENGLISH
9
Remote Control TP6-P1 TP6-P1 TP6-P1
Easy-to-Use Remote Control NO NO NO
W8, IPhone/IPad, Android
remote control
NO NO NO
CI+ CI+ 1.3 (Single) CI+ 1.3 (Single) CI+ 1.3 (Single)
DTS NO NO NO
Dolby MS11 YES YES YES
PVR OPTION OPTION OPTION
MHL NO NO NO
Dual Watch NO NO NO
Panel stand-by during music NO NO NO
PIP NO NO NO
Capture & Share NO NO NO
Gesture Control NO NO NO
Voice Recognition NO NO NO
Baby Watch NO NO NO
Easy sign-in NO NO NO
Simple Hotel TV YES YES YES
Front Time Display NO NO NO
PRODUCT SPECIFICATIONS --------------------------------------------------------------

ENGLISH
10
PRODUCT SPECIFICATIONS --------------------------------------------------------------
Unique features of your TV set
7
Your television set enables you to receive and
watch digital stations (via
DVB-S, DVB-T and DVB-
C), including the High
Definition (HD) ones.
Today, High Resolution
programs can be viewed
in many countries.
7
Although this television
meets the current DVB-S, DVB-T and DVB-C
standards as of August 2012 its compatibility
with future DVB-S digital satellite broadcasts,
DVB-T digital terrestrial broadcasts and DVB-C
digital cable broadcasts is not guaranteed.
7
This television can receive and process all
analogue and all unencrypted digital stations.
This television set has an integrated digital
and analogue receiver. The digital receiver
unit converts the signals from digital stations to
provide outstanding audio and picture quality.
7
The TV guide (only for digital stations) tells
you of any schedule changes at short notice,
and provides an overview of all the stations’
schedules for the next few days.
7
You can connect various data media, for
example, an external hard drive, a USB
memory stick or a digital camera to the USB
socket. Using the file browser, you can then
select and play the file formats you want (for
example, MP4, MP3 or JPEG data).
7With the Time Shift function, you can easily
stop and resume a program with the remote
control in a fast and simple way. Program is
recorded to the external data medium.
7You can save any digital TV channel you have
chosen, if no limitation has been imposed by the
broadcaster.
7 7
TV channel is transformed by the TV
and saved to a USB external data
medium.
You can recall and play saved programs from
the archive.
While a recording is in progress, you can
select a another recording from the archive
and watch that.
For saving and playing TV programs, please
see page 37.
7TV and radio division in programme menu/
channel list
7Faster opening time compared to KY-KT
7Compatible with TS1-TS2-TS3-TS4, iPhone/
iPad RC, Android RC and new RC design
7Unicable solution in DVB-S/S2 broadcasts
7Using different sources during recording
7More user-friendly USB menu (such as viewing
all files, deleting all files in bulk)
7Compatible with new 2015 designs
7DTS support
7Sub-woofer option
7Sub-woofer analog output (Line-out)
7Dolby 2+1/5+1
Receiving digital stations
7
To receive digital satellite stations (DVB-S) you
need a satellite antenna.
7
To receive digital stations (DVB-T) you need a
digital rooftop or indoor antenna.
7
The antenna cable of the cable TV network
that broadcast in DVB-C must be plugged into
TV in order to receive the DVB-C broadcasts.
7
Unlike analog broadcasting, not every station
has its own transmission frequency. Instead,
several stations are grouped into what are
known as bouquets on a regional or national
level.
7
You can find the current transmission informa-
tion on teletext from various broadcasters, or
look in a TV guide or on the Internet.
7
Various digital television stations from private
broadcasters are encrypted (DVB-S, DVB-T
HEVC: It is the video
compression algorithm.
It can compress the im-
age 36%-44% more in
comparison to previous
standard H264 with
the same quality.

11
ENGLISH
PRODUCT SPECIFICATIONS --------------------------------------------------------------
and DVB-C). Watching these stations and the
recording and playback functions are only
possible with the appropriate CI module and
a SmartCard. Consult your specialist dealer.
GRUNDIG SCR System
Your TV supports SCR system (Single Channel
Router). With SCR satellite system, several us-
ers can individually receive all signals from the
satellite simultaneously.7
Things to do for energy saving
Those items mentioned below will help you
reduce the consumption of natural resources as
well as save your money by reducing electricity
bills.
7
If you will not be using the TV set for several
days, it should be disconnected from the
mains for environmental and safety reasons.
TV will not consume energy in this condition.
7
If the TV set has main switch, it will be enough
to turn the TV off via main switch. TV will
reduce energy consumption almost to Zero
Watt.
7
TV consumes less energy on stand-by mode.
However, some TV sets may have features
such as on timer, that require the TV set to be
left in stand-by to work correctly.
7
TV consumes less energy when brightness is
reduced.
Notes on still images
Watching the same image for a long time on
the screen may cause a still image remains
feebly on the background. Feeble image(s) on
the background is originated from LCD/LED
technology and does not require any action
under guarantee. To avoid such cases and/or
minimize the impact, you may observe the tips
below.
7
Do not allow the same TV channel to stay on
the screen for a very long time. Channel logos
may cause this situation.
7
Do not allow the images, which are not full
screen, to constantly stay on the screen; if not
streamed in full screen format by the broad-
caster, you can convert the images to full
screen by changing picture formats.
Notes on still images
Watching the same image for a long time on
the screen may cause a still image remains
feebly on the background. Feeble image(s) on
the background is originated from LCD/LED
technology and does not require any action
under guarantee. To avoid such cases and/or
minimize the impact, you may observe the tips
below.
7
Do not allow the same TV channel to stay on
the screen for a very long time. Channel logos
may cause this situation.
7
Do not allow the images, which are not full
screen, to constantly stay on the screen; if not
streamed in full screen format by the broad-
caster, you can convert the images to full
screen by changing picture formats.

ENGLISH
12
PRODUCT SPECIFICATIONS --------------------------------------------------------------
Full HD, User Friendly Menu Structure
The user-friendly new UI structure provided with
KP chassis has been kept in the new GM chassis
as well.
The aims of this structure are;
7Impressiveness: To create a quality experience
with animations and design,
7Themeability: To create special designs for
our brands and to create distinctiveness among
them,
7Accessibility: To create designs that can easily
be used by everyone of all age groups as well
as offering ease of use in our all interfaces.
High Efficiency Video Coding (HEVC)
It is a video compression
standard created as a result
of a mutual study by ISO/IEC
MPEG (Moving Picture Ex-
perts Group) and ITU-T VCEG (Video Coding
Experts Group). It is a coding technology offer-
ing the same quality image with a higher com-
pression rate and a lower bandwidth in com-
parison to H264/avc, which is the previous
standard.
HEVC standard is mostly used for UHD videos
and it supports videos up to 8K. However
since it is an efficient method and it particularly
allows using the bandwidth effectively in DVB-
T2 broadcasts, it is started to be used in FHD
broadcasts as well. With G7 chassis, for the first
time HEVC will be supported for FHD on one of
our non-UHD televisions.
Web Browser (Open Web Browser)
Open web browser software enables users to
open HTML or more developed pages on the
network providers. G7 chassis incorporates a
"Web Browser". Thus, as in computers or mobile
phones, all internet pages can be accessed by
entering URL address. Browser does not support
Flash. For this reason, on some web pages, ap-
plications requiring flash player will not function.
Electronic TV Guide
The Electronic TV guide
(RoviGuideTM) has two operation
modes, namely online and offline.
In the offline mode, you can only see
channel data which the station provider has
made available.
A lot of content such as program information,
channel logos, information about actors/
actresses, pictures, fragments, etc. can be
received via the Internet connection in the online
mode. Additionally, through using artist, series
or film names, it is possible to perform search
among TV programs.

13
ENGLISH
PRODUCT INSTALLATION -------------------------------------------------------------------
Standard accessories
1 Television
2 Stand
3 Remote control
4 Battery for remote control
5 Screws and installation instructions for the
stand
6 User manual
Optional accessories
Easy-to-Use Remote Control
Battery for Easy-to-Use Remote Control
Cleaning cloth
Package Content

ENGLISH
14
PRODUCT INSTALLATION -------------------------------------------------------------------
Connection/Preparation
Connecting the antenna and the power cable
1 To receive digital satellite channels (DVB-S),
connect the satellite antenna cable to the
SATELLITE antenna socket on the television
set;
and/or
2a For terrestrial digital stations (DVB-T), con-
nect the rooftop or indoor antenna to the
ANT IN antenna socket on the television
set;
or
2b For digital stations of the cable TV network
(DVB-C), plug the antenna cable into ANT
IN socket on the television set;
or
2c For analog stations, plug the antenna cable
into ANT IN socket on the television set.
Note:
7
When connecting an indoor antenna you
may have to try it out at different positions
until you get the best reception.
3 Plug the power cable into the wall socket.
Note:
7
Only plug the device into the mains socket
after you have connected the external
devices and the antenna.
7
Do not use an adapter plug or an extension
cable which does not meet the applicable
safety standards. Do not make changes on
the power cable.
12
3

15
ENGLISH
Setting up or hanging
7 Select a location so that no direct sunlight falls
on the screen.
Setting up with stand
7 To mount the stand, refer to the installation
instructions included.
7 Place the TV set on a hard, level surface.
Preparing for mounting on the VESA
bracket
Contact authorised dealer to purchase the
bracket.
You will need:
7 A pair of scissors,
7 A cross-tip screwdriver.
Follow the installation instructions for the VESA
bracket.
1 Place the TV set in the film on a smooth
surface with the screen facing down.
2 Cut open the film on the back side using the
scissors.
3 Connect the required cables to the connec-
tors of television. See the "Connections"
section in this manual.
4 Tie the cables so they do not hang down
onto the floor.
5 Screw the VESA bracket onto the TV set
and mount it according to its installation
instructions.
VESA

ENGLISH
16
PRODUCT INSTALLATION -------------------------------------------------------------------
Connections of the television
AV / S-VHS / COMPONENT
Scart audio / video input
(CVBS signal, RGB signal);
S-Video audio / video
input (with Scart-S-VHS
converter);
Component, audio / video
input (with Scart - YPbPr
converter.
Service is for service purposes.
Optic Out Optics sound output.
USB(HDD) USB Hard disk socket for
external data medium and
PVR function.
HDMI3 (ARC) HDMI socket, audio/video
signal input (HDMI).
HDMI2 HDMI socket, audio/video
signal input (HDMI).
SATELLITE Satellite antenna socket.
ANT IN Antenna socket.
U Headphone connection
(3.5 mm jack);
External audio output (with
headphone-RCA converter)
USB1 USB socket for external
data media and PVR func-
tion.
HDMI1 HDMI socket, audio/video
signal input (HDMI).
CI Common interface slot.

17
ENGLISH
PRODUCT INSTALLATION -------------------------------------------------------------------
Control elements on the televi-
sion
Buttons of the remote control
Starting and switching the tele-
vision to standby mode
1 To start the television from standby mode
press 8/I.
2 To switch the television to standby mode
press 8/I.
Adjusting the volume or chang-
ing the channel
1 Press V/P and use + or – to select volume
or channel, confirm with V/P.
2 Increase volume/channel with + .
3 Decrease volume/channel with –.
Source selection
1 Press V/P, use + or – to select »Open
Input Source Menu« and confirm with V/P.
– »Select source« menu will be displayed.
2 Use + or – to select the soure and confirm
with V/P.
– Selected source will be displayed.
Inserting Batteries into the Re-
mote Control
1 Open the battery compartment by removing
the lid.
2 Insert the batteries (2 x 1.5 V micro; for
example R03 or AAA). Observe the polarity
(marked on the base of the battery compart-
ment).
3 Close the battery compartment.
Note:
7
If the television no longer reacts properly
to remote control commands, the batter-
ies may be flat. Be sure to remove used
batteries.
7
The manufacturer accepts no liability for
damage resulting from used batteries.

ENGLISH
18
PRODUCT INSTALLATION -------------------------------------------------------------------
Remote control - Main functions
Cursor Control
Moves the cursor up and down
in menus.
Moves the cursor to the left/
right in menus.
Opens the channel list;
activates various functions.
Previous, Next,
Forward, Backward;
Double Character in Teletext
Mode, Update, Freeze, Re-
sponds.
Chooses subtitles.
Chooses audio channel.
Turns on/off the television
set (stand-by).
Signal source.
Turns audio on/off (mute).
Zapping function
switches the menus back one
menu level.
Opens the menu.
Displays information.
Opens Tools menu.
Switches between teletext
and TV modes.
Opens the electronic TV
guide
Switches the television on
from standby mode;
selects the stations step by
step
Adjusts the volume.
Exits the menu.
Opens the channel list.
Switches the television on
from standby mode; selects
channels directly.
Selects the channel list
(»ALL«, »FAV1« to
»FAV4«).
Opens »HDMI CEC Device
List«.
Record, playback,
pause or
stop (digital
television channels only).
Selects picture format.
Opens Media Player menu.
Switches between TV chan-
nels and Radio channels.

19
ENGLISH
SETTINGS ------------------------------------------------------------------------------------------------------------------
The television is fitted with an "installation assis-
tant", which guides you step by step through the
basic settings.
The user can use the dialogue window on the
screen to perform settings that seem complex
and data inputs in a simple way that will be
understood by anybody.
Pages and dialogue items appear on the screen,
which identify the subsequent and likely operat-
ing steps.
To support this, you will also see the required
button symbols of the remote control.
Detailed basic settings:
– language selection
– country selection;
– user mode selection;
– Station settings (DVB-S, DVB-T, DVB-C and
analog channels).
Tuning television channels
Depending on the type of the antenna connect-
ed, you can determine which television channels
you would like to search.
DVB-S – Tunes digital satellite television chan-
nels.
You have two options for this search:
– basic installation which pre-sets a standard
selection, e.g. The satellite Astra 19.2°
East; you only need to start the scanning;
– professional installation, which allows you
to make all required settings and set param-
eters for your receiver's system.
DVB-C – Tunes digital cable television chan-
nels.
DVB-T – Tunes digital terrestrial television chan-
nels.

ENGLISH
20
Initial set-up
1 Switch the television set to standby using the
power switch O/I.
2 Switch on the television set from standby
with »8«, »1…0«, »P+« or »P–«.
– The Menu Language selection menu ap-
pears when the television is switched on
for the first time.
Smart Inter@ctive 4.0
Select
Menu Language
Please select your desired menu language.
Česky Dansk Deutsch English Español Eλληvıκά Français
Hrvatski Italiano Magyar Nederlands Norsk Polski Português
Pyccкий Româneşte Slovenščina Eesti Suomi Svenska Бългaрски
Slovenčina Lietuviu Türkçe
3 Select the menu language with »
<
«, »
>
«,
» V « or » Λ « and press »OK« to confirm.
– »Welcome« menu appears.
4 Gradual set-up will be performed to use the
television. Press »OK« to start the set-up.
5 Use »
<
«, »
>
«, » V « or » Λ « to select the
country in which the television is going to be
used and press »OK« to confirm.
– When »User Mode« appears, select
»Home Mode«.
6 Confirm »Home Mode« option with »OK«;
or
Select »Enhanced« with » V « or » Λ « and
confirm with »OK«.
– »Home Mode« contains preconfigured
TV settings that provide energy savings
conforming EUP.
– »Enhanced« – if you will use the televi-
sion for a demo presentation, enhanced
picture and sound settings are used in this
mode. Enhanced mode consumes more
energy.
Select »Stand« or »Wall-mounted« with » V « or
» Λ «.
Note:
7 Choosing the location of the television is
important for sound setting.
7 Press »OK« to confirm »Next«.
– »Summary« menu will be displayed.
8 Press »« (blue) to proceed to the next
step.
Note:
7 Continue to search TV channels as shown
for the following:
– For DVB-S reception, article 9;
– For DVB-C reception, article 14;
– For DVB-T reception, article 19;
Searching television channels with sat-
ellite signal (DVB-S/S2)
9 Select »Satellite« with » V « or » Λ « and
confirm with »OK«.
– Türksat Satellite is preset to 42 ° East.
10 Select »Standard Mode« with » V « or » Λ «
and confirm with »OK«.
11 Press »« (blue) for the next page.
Notes:
7 Select »Channel Type«.
Press » V « or » Λ « to select whether you
want to search for only digital channels
(Digital) or only radio channels (Radio) or
both (Digital + Radio) and press »OK« to
select and mark or unmark the »Digital«
and/or »Radio« items.
7 Select Scan Mode.
To select whether you want to scan free digi-
tal television channels (Free), only encrypted
digital television channels (Scrambled) or
both (Free + Scrambled), press » V « or
» Λ « and press »OK« to select and mark
or unmark the »Free« and/or »Scrambled«
elements.
SETTINGS ------------------------------------------------------------------------------------------------------------------
