Grundig PHDQ 2002 BC User manual

A
A
CLASS
CLASS
KLASSE
KLASSE
GSS
Grundig SAT Systems GmbH
Beuthener Straße 43
D-90471 Nuremberg
Phone: +49 (0) 911 / 703 8877
Fax: +49 (0) 911 / 703 9210
Email: [e-mail]
Internet: http://www.gss.tv
Grundig SAT SystEms
Assembly Instructions
Assembly Instructions
English
PHDQ 2002 BC
PHDQ 3002 BC
PHDQ 4002 BC
PHDQ 5002 BC
A
A
CLASS
CLASS
KLASSE
KLASSE
HDTV Digital QAM

- 2 -
- 2 -
Contents
1 Safety regulations ...............................................................................................3
2 General information ............................................................................................3
2.1 Packing contents.................................................................................... 3
2.2 Technical data....................................................................................... 4
2.3 Description ........................................................................................... 5
2.3.1 Manual display of the software version.......................................... 6
2.3.2 How the TP module works ............................................................ 6
2.3.3 Explanation of the term “symbol rate”............................................ 7
3 Assembly ............................................................................................................8
3.1 Installing the Cassette............................................................................. 8
3.2 Connecting the Cassette ......................................................................... 8
4 The operator control panel at a glance.................................................................9
4.1 Menu items ........................................................................................... 9
4.2 Operator control panel........................................................................... 9
5 Programming .................................................................................................... 10
5.1 Preparation..........................................................................................10
5.2 The menus at a glance ..........................................................................11
5.2.1 The menu of channel strip B.........................................................12
5.3 Cassette programming ..........................................................................13
Selecting the Cassette ...........................................................................13
Switching the channel strip.....................................................................13
To query software versions: ...................................................................14
Setting the output channel (only Bx…A)...................................................14
Modulator settings (only Bx…A) .............................................................16
Setting output level of the channel strips (only Bx…A)................................16
Producing a QAM signal for testing (only Bx…A) .....................................17
Inverting the user signal (only Bx…A) ......................................................17
QAM monitoring (only Bx…A) ...............................................................18
Setting the LNB oscillator frequency........................................................18
Setting the input symbol rate and the DVB mode ......................................19
Setting the input frequency (transponder frequency)................................. 20
Setting the QAM modulation value (only Bx…A) ......................................21
Setting the stuffing (only Bx…A)............................................................. 22
Saving settings .................................................................................... 23

- 3 -
- 3 -
1 Safety regulations
Important
• Assembly, installation and servicing must be carried out by an authorised
electrician.
• Switch off operating voltage before the start of assembly or service work or
pull out the mains plug.
• Install the system …
- in a dust-free, dry environment
- so that it is protected from moisture, vapours, splashing water and damp
- somewhere protected from direct sunlight
- away from the immediate vicinity of heat sources
- at an ambient temperature of < 50 °C.
• Make sure the device is adequately ventilated.
Do not cover the ventilation slots.
• Beware of short circuits!
• No liability is accepted for damage caused by faulty connection or inexpert
handling.
• Observe the relevant norms, regulations and guidelines on the installation and
operation of antenna systems.
• Earth the SAT receiver using the equipotential bonding rail in accordance with
DIN EN 50083 and VDE 0855.
• Do not perform installation and service work during thunderstorms.
Take action to prevent static discharge when working on the device.
2 General information
2.1 Packing contents
1 Cassette PHDQ 2002 BC or PHDQ 3002 BC or PHDQ 4002 BC or
PHDQ 5002 BC
2 HF connection cables
1 Assembly instructions (on CD)
1 Measuring log

- 4 -
- 4 -
2.2 Technical data
The devices meet the following EU directives:
73/23/EEC, 89/336/EEC
The product fulfils the guidelines and standards for CE labelling.
HF input:
Frequency range: 950 … 2150 MHz
Frequency raster: 1 MHz
Level range: 35 dBµV … 80 dBµV
DVB-S modes: DVB-S
1/2 , 2/3 , 3/4 , 5/6 , 7
/8
DVB-S2 modes: QPSK
1/2 , 3/5 , 2/3 , 3/4 , 4/5 , 5/6 , 8/9 , 9/10 ,
8PSK
3/5 , 2/3 , 3/4 , 5/6 , 8/9 , 9/10
Symbol rate DVB-S: QPSK: 2 … 45 MSymb/s
Symbol rate DVB-S2: QPSK: 10 … 30 MSymb/s
8PSK: 10 … 31 MSymb/s
HF output:
PHDQ 2002 BC
Frequency range: 60 MHz … 86 MHz
PHDQ 3002 BC
Frequency range: 112 MHz … 306 MHz
PHDQ 4002 BC
Channels: S21 … S41
Frequency range: 306 MHz … 466 MHz
Channel raster: 8 MHz
PHDQ 5002 BC
Channels: C21 … C69
Frequency range: 474 MHz … 858 MHz
Channel raster: 8 MHz
Output level: Typ. 90 dBµV
Output impedance: 75 Ω, nominal

- 5 -
- 5 -
Connections:
SAT inputs: 2 F-connectors
HF output: 1 IEC socket, female
Connection strip (10-pin): For supply voltages and control circuits
Socket RS 232: Update interface
2.3 Description
The Cassettes convert two QPSK -modulated data flows into one QAM-modu-
lated data flow. The Cassettes are controlled via the head end. Each Cassette
has two inputs and one HF output, as well as an integrated multi-transport flow
processor for stuffing, PID pass, drop and service filtering.
For these Cassettes, information from a barker channel can be added or ex-
changed with a transport flow (MTP function, Drop- and service filter). For this
purpose, there are two autonomous reception tuners and one modulator on
which the modified transport flow can be transmitted as a QAM-modulated
signal.
The SDT and PAT tables are automatically generated. All data relevant to the
operation of the Cassette is registered in a logbook with a maximum of 500
entries.
The operating software of the Cassette can be actualised via an external 9-pin
SUB-D-socket, using a PC or notebook, (software “ BE-Flash ”) or settings in the
channel strips “ A ” (service channel) and “ B ” (barker channel) of the Cassette
(PC software “ MTP ”, component of software PSW 1000). You can find the cur-
rent operating software of the Cassettes on the website “ http://www.gss.tv ”.
The prepared input signals are transmitted to the HF output collector of the head
end via the HF output socket. The output level of the Cassettes can be set with the
level regulator (max. –20 dB) at the output collector of the head end.
After the head end has been switched on, the software version of the control
unit is displayed briefly in the two-line LC display and afterwards the type of
Cassette of the first slot.
Approximately five minutes after the last button has been pressed, the software
version of the control unit is displayed.
The Cassettes are designed for use in the following head ends:
– PSU 12
– PSU 8
– PGT 8

- 6 -
- 6 -
2.3.1 Manual display of the software version
If necessary, you can call up the display of the software version of the control
unit manually:
• Hold down any two keys of the control unit simultaneously until the display
goes dark and
the software version, e.g. “ V.3 4 ”, is displayed.
2.3.2 How the TP module works
When converting the QPSK-modulated signal to a QAM-modulated cable signal,
the demodulated data stream can be accessed via the integrated TP module. This
data stream, also called transport stream, contains several stations with all their
components (video, audio, data and service information), which can be changed
using the TP module.
The individual functions
Station filter
Individual stations can be deleted. This reduces the data rate and, consequently,
the output symbol rate.
Stuffing
The transport stream is padded out using what is known as zero data. This
increases the data rate and, consequently, the output symbol rate. Changing
the output symbol rate suitably alters the bandwidth used (halving the output
symbol rate roughly halves the bandwidth at the output).
Changing service information
The transport stream contains data in the form of tables which the receivers eval-
uate and require for convenient use. The TP module can change the “Network
Information Table” (NIT). The NIT contains data which the set-top box needs for
the automatic search function.

- 7 -
- 7 -
2.3.3 Explanation of the term “symbol rate”
High-quality modulation methods like QPSK and QAM can encrypt several
bits as a single transferred and received symbol. The user data stream contains
the audio and video signals of a station and is thus permanently assigned. If
the value of the modulation and therefore the number of bits per symbol is in-
creased, the symbol rate falls compared to the user bit rate.
Formulae for calculating the output symbol rate “SR (A)” at a fixed input symbol
rate “SR (E)” and “FEC”.
256-QAM: SR (A) = FEC x 1/4x SR (E)
128 - Q A M: SR (A) = FEC x 2/7x SR (E)
64-QAM: SR (A) = FEC x 1/3x SR (E)
32-QAM: SR (A) = FEC x 2/5x SR (E)
16-QAM: SR (A) = FEC x 1/2x SR (E)
4-QAM: SR (A) = FEC x 1/1x SR (E)
Example:
Output symbol rate 64-QAM, FEC= 3/4,
Input symbol rate SR (E) = 27,500 kilosymbols per second
SR (A) = 3/4x 1/3x 27,500 kilosymbols/s
SR (A) = 6,875 kilosymbols/s
Note:
If no “FEC” is stated in the station lists, it can be assumed to be
“FEC =
3/4
”.
Reception from a transponder with a very low symbol rate
(SCPC station)
The extremely low data rate means that the output symbol rate is very low. If
there are reception problems with different digital receivers, set QAM modula-
tion with stuffing to a higher value.
Defined symbol rates
Some cable operators specify a fixed symbol rate (e.g. 6,900 kilosymbols per
second).

- 8 -
- 8 -
3 Assembly
3.1 Installing the Cassette
Warning
Before inserting or changing Cassettes, pull the mains plug of the head end
out of the mains socket.
•
Unscrew the fastening screws from the bracket in the head end.
• Insert the Cassette into a free slot and push it into the housing.
• Align the Cassette and gently make it contact with the connections of the
circuit board and the HF bus bar.
• Fasten the Cassette with the 1screws.
3.2 Connecting the Cassette
• Connect the HF input cable with the input sockets “ INPUT A ” 2
(channel strip A) and “ INPUT B ” 1(channel strip B).
• Connect the head end to the mains power supply.
—> The Cassette is now ready for operation.
+24
BREITBA
C101
L104
L100
L101
L103
C100
LNC-
+18V
ROT
+18V
Anschl.
GRUEN
INPUT OUTPUT OUTPUT INPUT


CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE CASSETTE
 *1/Ê

 *1/Ê

,-ÓÎÓ


- 9 -
- 9 -
Note:
The operating software of the Cassette can be updated via the socket
“RS 232” 3(9-Pin-Sub-D) by means of a PC or notebook.
Use the “BE-Flash” software as the update software. You can make drop
and pass filter settings in the channel strip “B” using the “MTP” PC software.
You can find the current operating software of the Cassettes on the website
“ http://www.gss.tv ”.
4 The operator control panel at a glance
4.1 Menu items
Program the Cassette using the keys on the head end control unit. The two-line
display of the control unit then shows the menus.
You can select the following main menu items
with the button:
– Cassette and channel strip
– Output channel
– LNB oscillator frequency
– Symbol rate
– Input frequency
– QAM modulation
– Stuffing
4.2 Operator control panel
You can individually select the menus and menu items step-by-step using the
key pad of the head end:
scrolls forward through the menu
AUDIO scrolls backward through the menu
▶
◀/
select parameters in the menus
set values, initiate actions
selects sub-menus
Msaves all entries
The parameters to be set are displayed underlined (cursor).
BE–Remote
PROFESSIONAL
V. 34

- 10 -
- 10 -
5 Programming
The following examples show how the PHDQ 4002 BC Cassette is programmed;
the output channels can be set from S21 … S41. Set the other Cassettes listed
in the same way.
5.1 Preparation
Notes:
Using the menu
“ LEVEL CONTROL ” the Cassette generates an equally powerful
HF carrier on the video carrier frequency of the channel. In this way, the Cas-
sette‘s level can also be set with an analogue TV test receiver set to the video
carrier frequency of the channel. In order to prevent interference within the
head end and the cable system, the output level of the digital Cassettes must
be lowered by approx. 10 dB at 64 QAM and by approx. 4 dB at 256 QAM
compared to analogue Cassettes.
• Connect the test receiver to the “TEST OUTPUT” 1of the
head end.
• Set the output channel of the Cassette (see page 14) and
adjust the TV test receiver to this channel.
• Switch on the modulator if necessary.
• Measure the output level of the analogue Cassettes and, if
necessary, tune them to a uniform output level.
• Check the output level of the digital DVB-MTP Cassettes.
Lower the output level of the appropriate Cassette in re-
lation to the analogue Cassettes at 64 QAM by approx.
10 dB and at 256 QAM by approx. 4 dB with the level
adjuster to the right of the Cassette.
• After programming the Cassette check the output level of
the Cassette again and if necessary set it again.
.
+24
BREITBA
L100
L101
L103
C100
LNC-
+18V
ROT
+18V
Anschl.
GRUEN
CASSETTE CASSETTE CASSETTE
1
+24
BREITBA
L100
L101
L103
C100
LNC-
+18V
ROT
+18V
Anschl.
GRUEN
CASSETTE CASSETTE CASSETTE
1
