Grundig Scenos UMS 6400 DVD User manual

ǵ
DEUTSCH
ENGLISH
FRANÇAIS
ITALIANO
PORTUGUÊS
DVD HOME
CINEMA MICRO
SYSTEM
Scenos
UMS 6400 DVD

2
CONTENTS________________________________________________________________________
4 Scenos UMS 6400 DVD
4 Special features of your DVD Micro System
4 Packing contents
4 Dolby Pro Logic, Dolby Digital and DTS
5 Set-up and safety
6-14 Overview
6-7 The front of the DVD Micro System
8-9 The displays of the DVD Micro System
10 The back of the DVD Micro System
11 Operating controls and connections of the subwoofer
12-14 The remote control
15-18 Connection and preparation
15 Connection diagram for the loudspeakers
15 Setting up the loudspeakers
16 Connecting the loudspeakers
16-17 Connecting a television, a flat screen or a projector
17 Connecting external devices digitally
18 Connecting the antennas
18 Connecting the power cord
18 Inserting batteries in the remote control
19 Additional information for units sold in the UK.
20-26 Settings
20 Setting the time
20 General information
21-22 Setting the video functions
22-23 Setting the loudspeaker configuration
24-25 Setting the audio functions
26 Tuning and storing radio stations
27-28 General functions
27 Switching on and off
27 Selecting the input source
27 Inserting a disc
27 Removing discs
27 Adjusting the volume
28 Muting
28 Selecting sound settings
28 Setting the surround mode
28 General information on disc playback
29-30 Disc features
29 Disc formats
29 DVD features
29 VCD/S-VCD features
30 MP3 CD features
30 Audio CD features
30 JPEG Picture CD features

CONTENTS__________________________________________________________________________________
ENGLISH
3
31-37 Disc mode
31 Playback functions
31 Selecting titles or chapters
32 Selecting titles or chapters (in DVD mode)
32 Playback with PBC (playback control) (in Video CD mode)
33 Playback with progressive scan (in DVD mode)
33 Displaying information
34-35 Additional playback functions
35-36 Zero setting (GO TO)
36 Selecting and playing scenes
36 Playing back tracks or titles in random order
37 Repeat functions
37 Creating a track memory – playing back titles or tracks in selected order
38-39 Tuner mode
38 Selecting the tuner input source
38 Selecting the waveband
38 Calling up stored radio stations
38-39 RDS station service
40-41 Timer mode
40-41 Switch-on timer
41 Sleep timer
42 Child lock
42 Changing the child lock settings
42 Changing the parental lock access code
43-44 Additional settings
43 Setting the picture mode
43 Displaying the multi-angle symbol
43 Activating and deactivating the status line
44 Language settings
44 Restoring all default settings
45-47 Information
45-46 Technical data
46 General instructions for laser devices
46 Cleaning discs
47 Rectifying minor problems

4
SCENOS UMS 6400 DVD _________________________________
Special features of your DVD Micro System
Your DVD Micro System provides you with perfect digital video playback in
studio quality.
It also provides superb cinema-quality audio playback – in stereo or with digital
multi-channel sound – depending on the type of DVD or CD used.
In addition to DVDs, you can also play S-Video CDs, MP3 CDs or WMA CDs,
audio CDs and JPEG picture CDs. In addition to this the DVD Micro System
reads home-made DVD Rs and DVD RWs with video data or CD-Rs and CD-
RWs with Audio data.
Packing contents
1DVD Micro System Scenos UMS 6400
2Operating manual
3Remote control
4Two batteries, 1.5 V, Mignon type,
UM 3/R 6/AA
5Two front loudspeakers
6Two surround loudspeakers
7Central loudspeaker
8Active subwoofer
9Five loudspeaker cables (3 x 5 m,
2 x 15 m)
10 Subwoofer cable
11 Euro/AV (Scart) cable
12 FM wire antenna
13 AM frame antenna
Dolby Pro Logic, Dolby Digital and DTS
With Dolby Pro Logic, the surround sound is obtained from the stereo signal.
This system carries the three front audio channels and a rear channel. However,
this method has the drawback that, for technical reasons, the rear channel
consists of a mono channel and must be limited in its frequency range and
dynamic range, which means the trebles of the rear channel are reduced.
Dolby Pro Logic II operates in much the same way as Dolby Pro Logic. However,
here the rear channel consists of two separate stereo channels, whose frequency
range is not restricted.
Dolby Digital, on the other hand, is a digital sound system designed for
completely independent multi-channel audio playback. Five full audio channels
and a low frequency effects (LFE) channel are carried. In general, Dolby Digital
signals can also consist of fewer than 5 channels (for example 2.0 or 3.0).
DTS Digital Surround is a digital sound system for differentiated 5.1 multi-chan-
nel audio reproduction which creates three-dimensional surround sound effects.
AM
LOOP ANTENNA
POWER
VOLUME
SUPER-BASS
POWER SUBWOOFER
DVD MICRO
SYSTEM WITH
DIGITAL TUNER
Scenos
DVD MICRO SYSTEM WITH DIGITALTUNER
SKIP/PRESET TUNER
AM/FM
TV
DVD VOLUME
SURROUND
ON/OFF
ECO
/UP
/DOWN
DISC/
RANDOM TV AM/FM
213
546
879
0GOTO MENU
SETUP
DEMO/OK
PRESET TUNING
SLOWPLAY/PAUSE STOP
PROGRAM
PBC/
BOOKMARK TITLE SUBTITLE
TIMER
RDS/
P.SCAN DISPLAY/DIM REPEAT
CLOCK/SLEEP
MUTE EQ/BBS LEVEL
VOLUME
ON/OFF
ECO
DOWN UP
6
SURROUND
3
4
67
5
12
18
9
10
11
12
2
13

ENGLISH
5
SET-UP AND SAFETY ______________________________________________
Please note the following information when setting up the home cinema system:
The DVD Micro System and loudspeakers are designed for playing back video
and audio signals at use. Any other use is expressly prohibited.
If you want to set up the DVD Micro System on wall shelves or in cupboards,
please ensure that it is adequately ventilated. There must be at least 10 cm
space at the side, above and at the back of the device. When setting up the
subwoofer, make sure that there is at least 20 cm of space at the side, above
and at the back of the device. Wherever possible the subwoofer should be set
up so that it stands freely.
If the DVD Micro System and loudspeakers are subjected to sudden changes in
temperature, for example if they are brought in from the cold to a warm room,
let them stand for at least two hours. Do not connect them to the mains supply
during this time.
The DVD Micro System and loudspeakers are designed for use in dry rooms.
If you do use them in the open, please ensure that they are protected from mois-
ture, such as rain or water splashes.
Place the DVD Micro System on a hard, level surface. Do not place any objects
such as newspapers on the DVD Micro System or cloth or similar items beneath it.
The laser lens is sensitive to temperature. Therefore, do not place the DVD Micro
System near heating units or in direct sunlight, as this will impair cooling.
Do not insert foreign objects in the disc compartment of the DVD Micro System.
Never open the casing of the DVD Micro System and loudspeakers. No
warranty claims are accepted for damage resulting from improper handling.
Do not place any vessels such as vases containing fluid on the DVD Micro
System and loudspeakers. These may be knocked over and spill fluid on the
electrical components, thus presenting a safety risk. Do not place any objects
such as burning candles on the DVD Micro System or loudspeakers.
Thunderstorms are a danger to all electrical devices. Even if the DVD Micro
System is switched off, it can be damaged by a lightning strike to the mains.
Always disconnect the mains and antenna plugs from the DVD Micro System
and the mains cable from the subwoofer during a storm.
If the DVD Micro System cannot scan DVDs or CDs perfectly, use a commercially
available cleaning-CD to clean the laser optics. Other cleaning methods may
damage the laser optics. Always keep the disc compartment closed to prevent
dust from collecting on the laser optics.
This DVD Micro System successfully combines technology and environmental
friendliness in its overall design. Only environmentally-friendly, high-quality
materials have been used. The batteries included contain no mercury or
cadmium. The range of materials used has been deliberately restricted and all
the larger plastic parts have been labelled. This means that the DVD Micro
System is easily disassembled to make servicing easier and optimise recycling.
°C2h
°C
Scenos
GITALTUNER
VD VOLUME
Scenos
DVDMICRO SYSTEM WITH DIGITAL TUNER
SKIP/PRESET TUNER
AM/FM
TV
DVD VOLUME
SURROUND
ON/OFF
ECO
/UP
/DOWN
Scenos
DVD MICRO SYSTEM WITH DIGITALTUNER
SKIP/PRESET TUNER
AM/FM
TV
DVD VOLUME
SURROUND
ON/OFF
ECO
/UP
/DOWN
EURO AV TV
230 V~
50/60 Hz
AUDIO OUT
L
R
COAXIAL OUT VIDEO OUT
TO SUBWOOFER
FR SR CL
S VIDEO OUT Y Pb/Cb Pr/Cr
FM ANT
FL SL SUB
AM ANT
! SERVICE !! SERVICE !! SERVICE !
Scenos
DVD MICRO SYSTEM WITH DIGITAL TUNER
SKIP/PRESET TUNER
AM/FM
TV
DVD VOLUME
SURROUND
ON/OFF
ECO
/UP
/DOWN
10
cm 10
cm
10
cm
1 0
c
m
Scenos
DVD MICRO SYSTEM WITH DIGITAL TUNER
SKIP/PRESET TUNER
AM/FM
TV
DVD VOLUME
SURROUND
ON/OFF
ECO
/UP
/DOWN
EURO AV TV
230 V~
50/60 Hz
AUDIO OUT
L
R
COAXIAL OUT VIDEO OUT
TO SUBWOOFER
FR SR CL
S VIDEO OUT Y Pb/Cb Pr/Cr
FM ANT
FL SL SUB
AM ANT
