GTS®humidifier LX Series
FIGURE 1-1: GTS HUMIDIFIER
Gas connection
Gas valve Electrical field connection
Primary heat exchanger
Blower
Steam outlet
Control components
Flue gas
vent
Duct dispersion option shown: Ultra-sorb Model LV
OM-7942
Drain
Secondary
heat
exchanger
Combustion air
intake
Air gap
Open drain
Supply
water
connection
Flue gas condensate

DRISTEEM SUBMITTAL • PAGE 2 OF 12
REV. 0620
Models, capacities, electrical specifications, and weights
LP GAS
All models operate at rated input
HIGH ALTITUDE
The input shown in Table 2-2 is derate when operating units at a high
altitude.
Table 2-1:
GTS models, capacities, electrical specifications, turndown, and weights
GTS
model
Maximum
steam
capacity
Input
Water usage
at maximum
capacity
Tank
volume
GTS humidifier
LX series*
Burner
quantity
Turndown Full load
amps*
Operating
weight
Shipping
(empty)
weight**
lbs/hr kg/h MBh kW m3/h gals/
hr
litres/
hr gals litres lbs kg lbs kg ratio lbs/hr 120V 60 Hz
230V
50 Hz
LX-50 50 23 61 17.8 1.7 6 23 14 53 304 138 187 85 1 5:1 10 2.0 1.5
LX-75 75 34 91.5 26.8 2.5 9 34 14 53 304 138 187 85 1 6:1 12.5 2.0 1.5
LX-100 100 45 122 35.8 3.4 12 45 13 49 300 136 192 87 1 8:1 12.5 2.0 1.5
LX-150 150 68 183 53.6 5.1 18 68 25 95 450 204 242 110 1 6:1 25 2.5 2.0
LX-200 200 91 244 71.5 6.8 24 91 42 159 706 320 356 161 1 6.7:1 30 4.0 2.5
LX-250 250 113 305 89.4 8.5 30 114 42 159 706 320 356 161 1 8.3:1 30 4.0 2.5
LX-300 300 136 360 105.5 10 36 136 41 155 709 321 367 166 1 10:1 30 4.0 2.5
LX-400 400 181 488 143 13.5 48 182 80 303 1259 571 593 269 2 13.3:1 30 6.5 3.5
LX-500 500 227 610 178.8 16.9 60 227 80 303 1259 571 593 269 2 16.7:1 30 6.5 3.5
LX-600 600 272 720 211 20 72 273 78 295 1265 574 615 279 2 20:1 30 6.5 3.5
* For outdoor enclosures, see Table 10-1.
** Add approximately 60-90 lbs (27-41 kg) for packaging material.
Table 2-2:
High altitude derate
Altitude Input
derate %
feet meters
0–2000 0–610 0
2001–2500 610–765 2
2501–3000 765–915 4
3001–3500 915–1065 6
3501–4000 1065–1220 8
4001–4500 1220–1370 10
4501–5000 1370–1525 12
5001–5500 1525–1675 14
5501–6000 1675–1830 16
6001–6500 1830–1980 18
6501–7000 1980–2135 20
7001–7500 2135–2285 22
7501–8000 2285–2440 24

DRISTEEM SUBMITTAL • PAGE 3 OF 12
REV. 0620
Dimensions
K
E
F
D
G
C
L
A
B
Side view Front view Top view
OM-7946
H
M
O
J
FIGURE 3-1: LX MODELS 50 - 150 INDOOR UNIT DIMENSIONS
P
Q
J
T
S
R
N
FIGURE 3-2: LX MODELS 200 - 300 INDOOR UNIT DIMENSIONS
See "Indoor unit dimensions" on page 4-1.
See "Indoor unit dimensions" on page 4-1.
K
E
F
G
C
L
B
Side view Front view Top view
OM-8014
M
D
P
Q
T
S
R
NA
H
J
O

DRISTEEM SUBMITTAL • PAGE 4 OF 12
REV. 0620
Dimensions
K
E
F
G
C
L
B
Side view Front view Top view
OM-7998
M
D
J
FIGURE 4-1: LX MODELS 400 - 600 INDOOR UNIT DIMENSIONS
P
Q
T
S
R
NA
H
Table 4-1:
Indoor unit dimensions
Description LX-50, LX-75, LX-100 LX-150 LX-200, LX-250, LX-300 LX-400, LX-500, LX-600
inches mm inches mm inches mm inches mm
A Overall length 23.25 590 32.25 819 56 1422 56 1422
B Overall width 23.25 590 23.25 590 22 559 34 864
C Overall height 42.75 1085 42.75 1085 47 1194 53 1346
DFlue position 4.3 109 4.3 109 8.7 221 14.5 368
E 4.4 112 4.4 112 5.61 143 5.6 142
F Flue diameter 3 76 3 76 4 102 6 152
GSteam outlet position 3.8 97 3.8 97 7.1 180 7 178
H 5.3 135 5.3 135 6.9 175 7.4 188
J Steam outlet diameter 2 51 2 51 3 76 4 102
KGas inlet position 9.2 234 9.2 234 16.6 4022 16.6 422
L 4.6 119 4.6 119 14.3 363 14.3 363
MDrain position 3.5 89 3.5 89 11 279 11 279
N 4.5 114 4.5 114 8 203 8 203
OCombustion air 8.92 227 8.92 227 6.5 165 14.5 368
P 2.7 69 2.7 69 14 363 14.5 368
Q Combustion air diameter 3 76 3 76 4 102 6 152
R Flue and combustion air height 5.5 140 5.5 140 5.6 142 7.1 180
SFill valve connection position 6.59 167 6.59 167 22.4 569 22.4 569
T 5.60 142 5.60 142 12.4 315 12.4 315

DRISTEEM SUBMITTAL • PAGE 5 OF 12
REV. 0620
Location and clearance recommendations
FINDING A LOCATION
• Provide a level, solid foundation for the humidifier.
• The GTS humidifier LX series vent and air piping can be installed through
the roof or through a sidewall. Use only vent/air piping methods described
in the IOM. Locate the humidifier as near as possible to an outside wall
or accessible roof space so that the flue pipe from the humidifier is short,
direct, and limited to wind exposure.
• Locate the unit so it and its electrical components are protected from water
during humidifier operation and service.
• Install the humidifier in a location away (and protected) from drafts. Follow
the instructions concerning combustion and ventilation air.
• Locate the humidifier in an area where leakage from the tank or its
connections will not result in damage to the adjacent structure or to lower
floors of the structure. When such locations cannot be avoided, install a
suitable drain pan (adequately drained) under the humidifier. The pan must
not restrict combustion airflow.
• If located in an insulated space, keep the humidifier free and clear of
insulating materials. Insulating material can be combustible. Inspect the
humidifier area when the humidifier is installed or when insulation is added.
• See the combustion air and flue gas venting section in the Installation and
Operation Manual for pipe termination locations and instructions.
WARNING
Installation requirements
The humidifier must be installed by
a qualified technician and meet the
requirements of all governing codes.
Failure to follow these instructions could
cause severe bodily injury or death.
18" (457 mm)
1" (25 mm)
30" (762 mm)
for
LX-50 through
LX-150
54" (1372 mm)
for
LX-200 through
LX-600
FIGURE 5-1: LX SERIES CLEARANCE
RECOMMENDATIONS (INDOOR UNITS)
OM-7947
36" (914 mm)
1" (25 mm)
Indoor Unit
FIGURE 5-2: LX SERIES CLEARANCE RECOMMENDATIONS
(OUTDOOR UNITS)
Outdoor Unit External steam outlet:
application dependant
Internal steam outlet:
6" (152 mm)
36"
(914 mm)
6" (152 mm)
18" (457 mm)
30" (762 mm) for
LX-50 through LX-150
54" (1372 mm) for
LX-200 through LX-600
OM-8012

DRISTEEM SUBMITTAL • PAGE 6 OF 12
REV. 0620
Optional floor stand mount (Models 50, 75,100, and 150 only)
FIGURE 6-1: LX SERIES FLOOR STAND MOUNT ASSEMBLY FLOOR STAND MOUNTING INSTRUCTIONS
1. Refer to Figure 7-1 for assembly of the floor stand.
2. Use the hardware provided by DriSteem to assemble.
3. Arrange appropriate lifting mechanism and personnel
to mount the GTS humidifier LX series on the floor
stand. See Warning below.
4. Use the lifting hole on the base of humidifier to
carefully lift it off the ground. See Warning below.
5. Slowly lower the humidifier on the floor stand.
6. Secure the base of the humidifier to the floor stand
using sheet metal screws.
OM-7972
OM-7971
Notes:
• Weight of floor stand:
Models LX-50 - LX-100: 24 lbs (11 kg),
Model LX-150: 30 lbs (14 kg)
• Allows for condensate piping/pump
• Bottom supply water connection is located underneath the side
water connection. See fill valve connection position on page 4.
WARNING
HEAVY OBJECT
To avoid muscle strain or back injury, use lifting aids and
proper lifting techniques when removing or replacing.
Model LX-150
Models LX-50 - LX-100

DRISTEEM SUBMITTAL • PAGE 7 OF 12
REV. 0620
C
OM-7962
A
21.125" (537mm)
FIGURE 7-1: LX SERIES WITH FLOOR STAND MOUNT (MODELS 50, 75, AND 100)
See "Indoor unit dimensions" on page 4-1.
B
OM-7970
Optional floor stand mount (Models 50, 75,100, and 150 only)
C
OM-8021
A
21.125" (537mm)
FIGURE 7-2: LX SERIES WITH FLOOR STAND MOUNT (MODEL 150)
See "Indoor unit dimensions" on page 4-1.
B
OM-8022

DRISTEEM SUBMITTAL • PAGE 8 OF 12
REV. 0620
Optional wall mount (Models 50, 75 and 100 only)
OM-7993
22.88" (581 mm)
FIGURE 8-1: LX SERIES WITH WALL MOUNT
See "Indoor unit dimensions" on page 4-1.
OM-7992
24.63" (626 mm)
23.13" (587 mm)
42.75"
(1086 mm)
20.13"
(511 mm)

DRISTEEM SUBMITTAL • PAGE 9 OF 12
REV. 0620
Outdoor enclosure: Location
• The following information is not intended to supersede any requirements of
federal, state, or governing codes having jurisdiction; prior to locating the
unit, authorities having jurisdiction should be consulted.
• The GTS must be level and located so there is enough clearance for
opening the access panels (see recommended clearances on Page 5).
• Do not locate unit in areas where the surrounding air has high levels of
particulates, such as some industrial parks or areas near highways. In
situations such as these, you will need to filter the air inlets.
• The unit should be located so prevailing winds do not blow into the air
intakes.
• When located on the roof, the air intakes must be a minimum of 14”
(360mm) off the roof to prevent intake of snow or splashed rain.
• Locate unit so air intakes are not too close to other exhaust fan outlets,
gasoline storage, or other contaminants that could potentially cause
dangerous situations. Using and storing gasoline or other flammable vapors
and liquids in open containers near this appliance is hazardous.
Table 9-1:
Outdoor unit amps and weights
Model
Full Load Amps**
(Heater Package)
Full Load Amps**
(No Heater Package) Operating weight Shipping (empty) weight*
120V 60 Hz 230V 50Hz 120V 60Hz 230V 50Hz lbs kg lbs kg
LX-50 7.0 4.5 3.0 2.5 479 217 362 164
LX-75 7.0 4.5 3.0 2.5 479 217 362 164
LX-100 7.0 4.5 3.0 2.5 475 216 367 166
LX-150 7.5 5.0 3.5 3.0 629 285 421 191
LX-200 9.0 5.5 5.0 3.5 914 415 564 256
LX-250 9.0 5.5 5.0 3.5 914 415 564 256
LX-300 9.0 5.5 5.0 3.5 916 415 574 260
LX-400 16.5 8.5 7.5 4.5 1606 729 940 426
LX-500 16.5 8.5 7.5 4.5 1606 729 940 426
LX-600 16.5 8.5 7.5 4.5 1612 731 962 436
* Add approximately 60-90 lbs (27-41 kg) for packaging material.
** Full load amps listed are for the humidifier and the enclosure.

DRISTEEM SUBMITTAL • PAGE 10 OF 12
REV. 0620
Outdoor enclosure: Dimensions
DIMENSIONS
• For outdoor unit weights, see Table 9-1.
• For clearances, see Figure 5-1.
H
B
Control cabinet
Pipe chase
Exit for standard steam outlet
GTS humidifier LX series
Exit for optional steam outlet
(through pipe chase)
G
J
F D
E
Access panel door
Ventilation fans
Heater
Flue gas vent
OM-8010
FIGURE 10-1: OUTDOOR ENCLOSURE TOP VIEW
Access panel door
Table 10-1:
Outdoor unit dimensions
Description LX-50, LX-75, LX-100 LX-150 LX-200, LX-250, LX-300 LX-400, LX-500, LX-600
inches mm inches mm inches mm inches mm
A Enclosure length 36 914.4 45 1143 57.35 1456.59 57.35 1456.59
B Enclosure width 27.35 694.7 27.35 694.7 27.35 694.69 39.10 993.04
C Enclosure height 57 1447.8 57 1447.8 62 1574.8 62 1574.8
DPipe chase position 2.05 52.02 2.05 52.02 2.05 52.0 2.05 52.02
E 6.51 165.28 6.51 165.3 3.05 77.4 2.05 52.04
FPipe chase size 7 177.8 7 177.8 7 177.8 10 254
G 11 279.4 11 279.4 14 355.6 16 406.4
HSteam pipe position 6.46 164.1 6.46 164.1 9.17 233 8.965 227.61
J 22.77 578.3 20.83 529.1 22.16 562.84 31.48 799.36
K Curb height 14.0 - 36.0 356 - 914 14.0 - 36.0 356 - 914 14.0 - 36.0 356 - 914 14.0 - 36.0 356 - 914
L Height to bottom of flue outlet 48.35 1228.1 48.35 1228.1 49.49 1257 46.65 1184.9
Air intake

DRISTEEM SUBMITTAL • PAGE 11 OF 12
REV. 0620
B
FIGURE 11-1: OUTDOOR ENCLOSURE MOUNTED ON A CURB
B
FIGURE 11-2: OUTDOOR ENCLOSURE MOUNTED FLUSH
OM-8008 OM-8009
C
A
A
K
Outdoor enclosure: Dimensions
L
FIGURE 11-3: GTS OUTDOOR ENCLOSURE STEAM OUTLET OPTIONS
External steam outlet Internal steam outlet
Ventilation
fans
1½" (38 mm)
knockouts 4"
(102 mm) o.c.
Steam outlet
GTS LX
humidifier
Steam outlet
Ventilation
fans
1½" (38 mm)
knockouts 4"
(102 mm) o.c.
Emergency
drain
Pipe chase
OM-8006
Emergency drain
Pipe chase
GTS LX
humidifier
OM-8007

DRISTEEM SUBMITTAL • PAGE 12 OF 12
REV. 0620
3/8" typical clearance
Unit base
Weather stripping
Wood nailer
(by installer)
Insulation and cant (by installer)
B
D
A
C
1"x 2"
(25
mm x
50 mm)
wood
nailer
3" (76 mm)
typical
Cross section view
DM-7496
Table 12-1:
Outdoor enclosure curb dimensions
Outdoor enclosure model
A B C D
inches mm inches mm inches mm inches mm
LX 50 - 100 35.38 898.65 33.23 844.04 26.73 678.94 24.73 628.14
LX 150 44.38 1127.25 42.23 1072.64 26.73 678.94 24.73 628.14
LX 200 - 300 56.73 1440.94 54.58 1386.33 26.73 678.94 24.73 628.14
LX 400 - 600 56.73 1440.94 54.58 1386.33 37.45 951.23 35.45 900.43
Outdoor enclosure curb details and dimensions
FIGURE 12-1: LX SERIES OUTDOOR ENCLOSURE CURB DETAILS AND DIMENSIONS
