Guardian H3010 Quick reference guide

Ultrasonic Digital
Humidier
Remanufactured
Model No. R3010
30-Day Limited Warranty
www.guardiantechnologies.com
1.866.603.5900
English E - 1
Spanish S - 1
Date Purchased
month ________
year _________
USE & CARE INSTRUCTIONS
Start
E-1

Model Number: R3010
Humidifying Mode: Combination
Power Supply: AC120V, 60Hz
Power Consumption: 140W (40W at cool humidication)
Humidity Capacity: About 350 cc/hr. (at highest setting and warm humidication)
Tank Capacity: 1.4 gallons
Successive Humidity Hours: Up to approximately 72-hours depending on
environmental conditions
Dimensions: Width 14.5 inches - Height 12 inches - Depth 9 inches
Weight: 8.8 pounds (not including packaging)
ADDITIONAL FEATURES
Small silver particles have been added to the water tank to help ght the growth of mold and mildew on
the surface of the water tank.
PRODUCT SPECIFICATIONS AND PARTS CONTROL PANEL BUTTON FUNCTIONS
Tank Lid
Cleaning Brush
Power Plug
Night Lamp
Body
Spout
Handle
Tank
Air-Cleaning Filter
Spout Guide
Silver Clean Technology
Uses ultrasonic technology for quiet operation while you sleep.
Silent Operation
Lamp
Select/Set
Hour
Minute
Power
Cool/Warm
Spray
C ontrol
Display
Start
Stop
Time
Provides a soft ring of blue light
with ON/OFF switch.
Night Light/Lamp
Change between programming
mode and normal mode.
Select/Set
Select the hour for timer start/off
or clock (actual time).
Hour
Select the minute for timer start/
off or clock (actual time).
Minute
Turns humidier on/off for normal
usage and programming mode.
Power
Select humidifying temperature based on need. Warm humidity
will use more power but will humidify your room quicker.
Warm or Cool Mist Selection
Adjusts spray between low, medium, high and turbo.
Spray Control
Turns off display lights.
Display On/Off
When the unit is low on water the Rell LED on the front panel will light
up, and the unit will shut off. Simply add more water to continue use.
Water Shortage Indicator
Night Light/Lamp
Select/Set
Hour
Minute
Power Warm or Cool
Mist Selection
Spray
Control
Display
On/Off
*To access
cleaning brush,
pull up on lid.
E-3
E-2

WARNINGS
This product should be used only in accordance with the specications outlined in this manual.
Usage other than what has been specied here may result in serious injury.
• Disassembly, repair or remodeling by an unauthorized person may result in serious harm.
• Do not use if plug is damaged or loose.
• Keep this product out of the reach of children and away from pets.
• Be careful not to put water in the humidity spout.
• Before lling or cleaning the unit, make sure it is unplugged.
• Once the humidier has been turned on, do not move it.
• Do not move when in operation.
• Do not remove the water tank from the unit while it is on.
• Do not handle the adapter plug with wet hands.
• Do not excessively bend, twist or pull the power cord.
• Avoid placing this product where the humidity is pointed directly at an electrical object.
• Do not directly inhale the humidity.
• Do not place this product on a sloped or unstable surface.
• When not in use, unplug the unit.
• Do not ll the water tank with hot or boiling water.
• Do not use this product in direct sunlight, or near a gas stove or heater.
• Do not use if the water tank becomes cracked or damaged.
• Do not keep this product running for an extended period of time.
• Do not clean the unit or water tank with detergents or chemicals of any kind.
• Do not use this product near any other electronic device.
• Do not cover the humidity opening at any time during use.
• Do not use this product near a sink.
• Do not drink water from the water tank.
• Do not place this product on an absorbent surface.
• Do not pour anything but water into the water tank.
Failure to comply with the warnings listed above may result in electric shock or serious injury.
Make sure the unit is unplugged.
1. Separate the tank from the body
of the unit.
2. Open the tank lid, turning it to
the left.
3. Pour cool, clean water directly
into the tank. Do not pour anything
but water into the water tank.
4. Close the tank lid, turning it to
the right.
5. Attach the tank to the body of
the unit.
Spray
Control
Display
On/Off
E-5E-4

1. Power Button
Before turning on make sure there is water in the unit.
Press the Power Button.
2. Warm or Cool Mist Button
Press to select warm or cool mist. Water
temperature is maintained at room temperature for cool
setting and 80 degrees for warm.
3. Spray Control Button
When you press the Spray Control Button
there are four options to choose from:
Press once for WEAK
Press twice for MIDDLE
Press three times for STRONG
Press four times for TURBO
*You will notice the lights get higher as the spray increases.
4A. Light Options - Display Button
Press the Display Button to turn the display lights ON or OFF.
5. Water Rell Button
When the Water Rell Button lights up it is time to rell
the water tank.
Program Start
1. Push Select/Set Button until "START" is blinking on display.
2. While "START" is blinking, select the desired start time using Hour and
Minute buttons (AM or PM as indicated).
3. Select Cool/Warm preference.
4. Select Spray Control preference.
5. "START" indicator will remain lit once programmed.
Power
Cool/Warm
S
p
C
Spray
Control
Dim
Display
Lamp
4B. Light Options - Night Light Feature
Press the Lamp Button at the top of the unit to illuminate
the night light feature.
Select/Set
Start
Stop
Time
D
one
set
Hour
r
Minute
Program Stop
1. Push Select/Set Button until "STOP" is blinking on display.
2. While "STOP" is blinking, select the desired end time using Hour and
Minute buttons (AM or PM as indicated).
3. "STOP" indicator will remain lit once programmed.
4. To cancel program, press and hold select/set button for two seconds
(START and STOP buttons will not be lit).
Clock Set
1. Clock must be set in order for timer to work properly.
2. Push Select/Set Button until "TIME" is blinking on display.
3. Select actual time using Hour and Minute Buttons (AM or PM as indicated).
The programmable mode allows you to set the timer to turn the humidier both on/off
at a daily predetermined time. This mode also allows the clock to be programmed.
FIRST TURN POWER BUTTON ON.
E-7
E-6

PROBLEM SOLUTION
Water vapor & humidity are
not produced.
Power Plug: Unplug and then try again.
Power Failure: When the power is returned, try again.
Tank Installation: Make sure the water tank is
correctly attached. Make sure spring on tank
cap moves freely when pushed.
Air blows but water vapor is
not produced.
Excessive Water: Remove a certain amount of water
from the tank.
The desired humidity is lower than the current tem-
perature: Increase the desired humidity.
Detergent residue in the tank: Wash the tank out and
try again.
Humidity level is low.
The surface of the ultrasonic metal disk may be dirty:
Wipe it off with a dry, soft cloth. Clean with diluted
vinegar.
The water in the unit is too cold: Replace with cool,
but not cold water.
Warm humidity is not produced. It may take 10-15 minutes before warm
humidity is created. The mist may not feel
warm to the touch.
Check to see if base of unit feels warm to the touch.
If so then warm mist is being produced.
The humidity has a bad smell. Poor maintenance or dirty water: Clean the product
thoroughly, and ll it with fresh water.
White dust is forming on
nearby furniture.
Hard water will deposit a certain amount of
dust. Dust in the air settles because of the
added humidity in the room.
*Use distilled water if this becomes a nuisance.
• Always unplug the unit before servicing it in any way.
• The temperature of the water remaining in the unit after use may be HIGH.
• Do not submerse the unit in water, or allow water to enter anywhere on the unit
except the designated water tank.
INSIDE THE BODY OF THE UNIT
Pour excess water out of the unit, but do not allow it to enter the hole where the water
vapor comes out. Wash out the unit with fresh water, using the cleaning brush and a
soft cloth as needed.
OUTER SURFACE OF THE UNIT
Wipe the surface of the unit with a soft, damp cloth if needed.
WATER TANK
If water spots remain in the water tank, wipe the inside with a soft cloth.
DO NOT use soap or detergents.
AIR FILTER
Gently wipe away debris from the lter with a soft cloth.
This lter does NOT need to be replaced.
ULTRASONIC DISK
Remove spray spout (Fig. 1) and use the enclosed cleaning brush to regularly remove build up
and deposits from this area (Fig. 2). Diluted vinegar will help to prevent this build up.
Fig. 1 Fig. 2
• Fully dry the inside and outside of the unit before storing it.
• DO NOT leave water in the unit.
• Store in a cool, dry place.
E-9
