Gunter & Hauer CER 320 User manual

Günter & Hauer
EN USER MANUAL
GLASS CERAMIC ELECTRIC HOB
CER 320 / 321
CER 640

Thank you for your trust and choosing
GÜNTER & HAUER products!
Operating instructions are also available on our website:
www.gunter-hauer.eu
This manual was developed
to facilitate the use of the product.
It will help you familiarize yourself with new
appliance quickly.
Make sure you have received it without any damage.
If damage is detected, please contact the purchasing
organization where you have bought appliance.

 Safety instructions........................................................4
 Installation of the Hob..................................................7
 Connection to the Power Supply................................11
 Product Overview.......................................................13
 Use of the Electric Hob........
 &RRNLQJ7LSV
 &OHDQLQJDQG0DLQWHQDQFH
 7URXEOHVKRRWLQJ
 Specifications..............................................................27
CONTENT
3

4
SAFETY INSTRUCTIONS
Please read these instructions carefully. Only after that you will be able to
use the appliance correctly.
Keep the operating and installation instructions. If you transport the
appliance to another person, transfer the manual with it.
Check the condition of the electrical appliance after unpacking it.
If it was damaged during transportation, do not connect the hob, but contact
the service center or the organization where you have purchased the product.
This appliance is intended for domestic use only. Use the hob only for
cooking. Do not leave the working appliance unattended.
SAFE USE
For the safe use of this appliance, adults and children who, due to physical,
sensory or mental limitations, lack of experience or knowledge are unable to
use it, should not do so without the supervision of a responsible adult.
Do not allow children to play with electrical appliances.
OVERHEATED OIL AND FAT
There is a fire hazard! Overheated oil and fat easily catch fire. Never leave
fat or oil heating unattended. In case of ignition of oil or fat, never pour
water on a grease fire. Extinguish it by covering the cookware with a lid or a
plate. Switch off the cooking zone.
COOKING FOOD IN A WATER BATH
When cooking in a water bath, the ingredients are placed in a cookware,
which in turn is placed in a pan of a larger diameter with water. Thus, the
food is cooked under the influence of even and gentle heat of hot water, and
not directly on the cooking zone. When cooking in a water bath, other
cookware should not come into direct contact with the bottom of the pan
containing the water. This will help to avoid damage to the glass surface of
the hob and cookware due to overheating of the cooking zone.

5
THE HOB IS HEATING UP
Do not touch hot cooking zones. Keep children away from the hob. Never
place flammable objects on the hob. Do not store flammable objects and
aerosols in drawers under the hob.
WET BOTTOM OF COOKWARE AND WET COOKING ZONE
There is a danger of injuries! If there is any liquid between the bottom of
the pan and the cooking zone when it heated, the steam pressure will
increase. Due to it, cookware can suddenly jump up. Always make sure that
the bottom of the cookware and the cooking zones are dry.
CRACKS ON THE HOB
There is a danger of electric shock! If the hob is broken or cracked,
disconnect the appliance from the power supply. Contact the service center.
If the indicator does not work, turn off the cooking zone. Contact the service
center.
THE HOB TURNS OFF
There is a fire hazard! If the hob automatically turns off and cannot be
used, it may suddenly switch on later. To avoid this, disconnect the
appliance from the electrical network. Contact the service center.
DO NOT PLACE METAL OBJECTS ON THE HOB
There is a risk of burns! Do not leave knives, forks, spoons, lids and other
metal objects on the hob - they can heat up very quickly.
FAN MAINTENANCE
There is a risk of damage! In the lower part of the hob there is a cooling
fan. If there is a drawer under the hob, do not store small objects and paper
there. They can be drawn in by the fan, which will lead to its breakdown or
to the cooling failure.
WARNING! There should be a distance of at least 20 mm between the
contents of the drawer and the fan inlet.

6
ATTENTION!
This appliance complies with the standards of safety and electromagnetic
compatibility. However, persons with pacemakers are not recommended to
approach the working appliance. It is also possible that people who use
other types of electronic devices, such as hearing aids, may have unpleasant
sensations near the hob.
SWITCHING OFF THE HOB
Every time after using the hob, it must be turned off using the main switch.
You should not wait for the automatic shutdown of the hob due to the
absence of cookware on the cooking zone.
CAUSES OF DAMAGE
•The rough bottom of the cookware can scratch the hob.
•Never place empty cookware on the cooking zones. This may damage
the hob.
•Never place hot cookware on the control panel, display panel and hob
frame. This may damage the hob.
•Dropping hard or sharp objects on the hob can damage it.
•Foil and plastic cookware melt when they come into contact with hot
cooking zones. The use of auxiliary coatings to protect the hob from
dirt is not recommended.
DISPOSAL OF PACKAGING MATERIAL
Packaging material (film, foam, etc.) can be dangerous for children! All
materials used in the packaging of the hob are fully recyclable. Cardboard
and foam plastic are marked accordingly. Please dispose of the packaging
materials in order not to cause harm to the environment.

7
INSTALLATION OF THE HOB
1. SAFETY INSTALLATION RULES
The electrical installation must be carried out so that a device is
available to disconnect the product from the AC network, which discon-
nects all poles with a distance between contacts of at least 3 mm.
Devices such as overcurrent protection circuit breakers, fuses (plug-type
fuses must be removed), earth leakage circuit breakers, and contactors
are suitable for disconnection.
Electrical appliances of this type can be installed in such a way that
there is a high cabinet or wall on one side. The hob must be installed in
such a way as to provide protection against impacts. The item of kitchen
furniture into which the hob is built in must meet the existing durability
requirements.
To prevent damage to the kitchen set, the installation of furniture
in which the hob will be built in must be carried out by a qualified
technician.
The countertop of the kitchen set should be flat and horizontal. All
cut surfaces must be properly sealed to protect against moisture and dirt.
Make sure the sealant is spread around the countertop without gaps. It is
not recommended to additionally use silicone sealants, as this can make
it difficult to disassemble the hob during maintenance.
When disassembling the hob, it must be pushed out from
below. Kitchen furniture in which the hob will be built in, as well as
all furniture located near it, must be made of heat-resistant
materials. In addition, all decorative elements must be fixed with
heat-resistant glue.
Ensure that your new product is properly installed and grounded
by a qualified technician. Make sure to follow these instructions!

8
2. BEFORE INSTALLATION
Write down the serial number of the product, which is on the
technical data plate. You may need this number when contacting the
service center or organization where you have purchased the product.
After installation, access to it will not be possible, because the plate with
technical data is located on the underside of the electrical appliance.
Place the hob so that the glass surface is facing down. The glass
surface must be protected from damage.
3. PRODUCT AND COUNTERTOP CUTOUT DIMENSIONS
(MM)
L(mm)W(mm)H(mm)D(mm)A(mm)B(mm)X(mm)
CER 320/321 290 520 50 46 270 490 50 min.
CER 640 590 520 50 46 560 490 50 min.
4. HOB INSTALLATION PARAMETERS
•The hob is designed to be installed into the countertop above the
kitchen cabinet, the width of which is 600 mm or more.
•The hob can be installed into the countertop with a thickness of
30-50 mm.
•The minimum distance between the hob and the wall behind is 50
mm.
•The distance between the hob and the hood should not be less than
specified in the hood installation instructions.

9
In any case, make sure that the appliance is well ventilated
and that no vents are blocked.
NOTE: The safe distance between the hob and cupboard is at least 760
mm.
If there is a drawer under the lower part of the hob, you should
leave at least 65 mm of free space to avoid overheating of the furniture
surface. And also, at least 20 mm, between the cabinet and the kitchen
wall for free air circulation.
A(mm)B(mm)C(mm)DE
760 50 min. 20 min. air inlet
opening
air outlet
opening (5 mm)
•Furniture for installation must have covering, as well as adhesives,
resistant to a temperature of 100 °C. Failure to meet this
requirement may result in deformation of the surface or peeling of
the covering.
•The distance between the hob and the vertical walls of kitchen
furniture located next to it should be at least 50 mm.

10
Countertop
Hob
Mounting bracket
Screw ST 3.5*8
The lower part
C
B
DA
5.HOB FIXING
After installation, secure the hob to the countertop by screwing the
brackets to the sides of the appliance. Adjust the position of the brackets
to suit the thickness of the countertop.

11
Before connecting, make sure that the operating voltage of the hob
power supply, marked on the technical data plate, corresponds to the
voltage of the existing AC network. The plate with technical data is
located on the lower part of the hob.
Before connecting the cables to the power circuit, disconnect the
voltage supply!
The power supply voltage of the heating elements is 220~240 V
AC. The hob must be connected to the AC network in such a way that
there is a device which disconnects all poles with a distance between
contacts of at least 3 mm., for example, an overcurrent protection circuit
breaker, fuses (plug-type fuses must be removed), an earth leakage
disconnecting device or a contactor.
Before connecting to the electrical network, make sure that
the connection is protected by a suitable fuse and that the cross-sectional
area of the wiring corresponds to the power consumption of the
appliance. The connection must be made taking into account the
capabilities of the fuses and the current load of the electrical network.
CONNECTION TO THE POWER
SUPPLY

12
After installation, it is necessary to provide full protection against
contact with conductive and insulated parts.
•During installation make sure that the cable is not pinched and
does not come into contact with sharp edges.
•Cables of nearby connected electrical appliances must not touch
hot cooking zones.
•After the hob is connected to the power supply, make sure that all
cooking zones are working by turning each of them to maximum
power for a short time.
•A damaged cable should only be replaced by a qualified specialist.

1. TURNING THE HOB ON FOR THE FIRST TIME
Traces of glue applied to the gaskets may be visible on the glass surface of
the hob.
Before turning on the glass-ceramic surface for the first time, clean it with
a damp cloth and a small amount of manual dishwashing liquid. Do not use
aggressive and abrasive cleaning agents, coarse dishwashing sponges, rust
removers, stain removers. Remove all protective films and warning
stickers.
After connecting to the power supply, all indicators will light up for a
few seconds.
2. GENERAL OVERVIEW
Top view
CER 320
PRODUCT OVERVIEW
CER 321
1. max. 1000/2000 W zone
2. max. 1200 W zone
3. Control panel
1. max. 1800 W zone
2. max. 1200W zone
3. Control panel
13

CER 640
CER 640
3. TOUCH CONTROL PANEL
The hob is equipped with a touch control panel. Touch the corresponding
symbol to turn on the button.
•Buttons and sliders respond to touch, so no effort is required.
•Use pads, not your fingertips.
•Every tap on the sensor is confirmed by a sound signal.
1. On/off button
2. Heat level slider / buttons
3. Timer
4. Child lock
5. Cooking zone selection
button
6. Dual zone
1. max. 1800 W zone
2. max. 1200 W zone
3. max. 1800 W zone
4. max. 1200 W zone
5. Control panel
Control panel
CER 320
14
CER 321

Do not place any objects on the touch control panel (error messages may
appear).
Make sure that the control panel is always clean. If the control panel is
dirty or has spilled liquid on it, error messages may appear, and it may be
difficult for the panel to respond to the touch of your fingers.
Make sure the bottom of your cookware is smooth, fits tightly to the glass
surface, and matches the size of the cooking zone. Always place the
cookware in the center of the cooking zone.
Do not move cookware on the surface, this will save the hob from unwanted
scratches on the glass ceramic surface. Always lift pans off the hob.
15
4. SUITABLE COOKWARE
Do not use cookware with uneven edges or curved bottom.

16
2. AFTER COOKING IS COMPLETED
1. Touch the control button of the corresponding
cooking zone that you want to turn off.
USE OF THE ELECTRIC HOB
1. START OF COOKING
After connecting the hob, you will hear a single beep and all the indicators
on the panel will light up for 1 second and then go off. This means that the
hob has entered a standby mode.
1. Tap ON/OFF button . All indicators will
display "–".
2. Place the appropriate cookware on the desired
cooking zone. Make sure that the surfaces of the
cookware and the cooking zone are clean and dry.
3. Touch the button that controls the selected
cooking zone.
4. Set the desired heat level using the appropriate sensors.
•If the heat level is not set within 1 minute, the hob will switch off
automatically. To continue cooking, you will have to repeat step 1.
•You can adjust the cooking temperature at any time during
cooking.

17
3. Switch off the hob by tapping the ON/OFF button.
4. The hot surface indicator informs you that the cooking zone is still
too hot to touch. It will disappear when the cooking zone is cooled
to a safe temperature level. This feature can also be used to save
power if you need to continue cooking for a while - use the
cooking zones that are still hot.
3. CHILD LOCK
•This function allows you to lock the control panel of the hob to
prevent accidental touches (for example, when children can
accidentally turn on one or more cooking zones).
•When the lock is active, all control sensors except ON/OFF are
inactive.
To lock the control panel, do the following:
. The timer indicator will display Touch the lock button on the panel
"Lo" symbol.
To unlock the control panel, do the following:
1. Make sure the hob is switched on.
2. Tap and hold the lock button on the panel for 3 seconds.
3. Now you can use the appliance in normal mode.
When the lock is activated, all sliders and buttons except ON/
OFF are inactive. You can always turn off the hob in case of an
emergency. However, in order to continue using the hob, it
should be unlocked.
2. Turn off the cooking zone using the corresponding slider or button.
Set the heat level to 0. Make sure the display shows "0".

18
Heat level 1 2 3 4 5 6 7 8 9
Working time before shutdown
(hours) 8 8 8 4 4 4 2 2 2
5. ALARM CLOCK AND TIMER
The timer function can be used in 2 modes:
•The timer can be used as an alarm clock. In this case, after the
countdown ends, none of the working cooking zones will be
switched off.
•You can also set a timer when one or more cooking zones are
automatically turned off after the timer is expired.
*The maximum duration of the timer is 99 minutes.
5.1. Alarm clock
1. Make sure that the hob is switched on and the
cooking zone selection is not activated (the
cooking zone indicator "–" does not flash).
2. Touch the timer button; the display will show
"00" and the right zero "0" will start flashing.
3. Adjust the time using the slider or buttons: (eg 5).
NOTE: You can set the alarm before or after you have finished setting
the heat level of the selected cooking zone.
4. AUTO SHUTDOWN
It is a safety function and is activated if you forget to turn off the cooking
zone. The basic auto shutdown time is shown in the table below:

19
4. Touch the timer button again - another "0" will
start flashing.
5. Use the corresponding sensor to set the desired time (eg - 2).
The alarm is now set for 25 minutes.
6. After setting the alarm time, it will start counting down immediately.
The display will show the remaining time.
7. When the set time is reached, a beep will sound for 30 seconds and
the time indicator will display "- -" symbol.
5.2. Timer with auto shutdown
1. Select the cooking zone for which you want
to activate the auto shutdown timer.
2. Tap the timer button - the display will show
"00" and the right zero will flash.
3. Select the time using the sensor (eg, 5).
4. Touch the timer button again - zero will begin
to flash.
5. Use the sensor to set the desired time (e.g., 2). The alarm is now
set for 25 minutes.

20
6. Once the alarm time is set, it will start counting down immediately.
The display will show the remaining time.
NOTE: The indicator of the active cooking zone will be indicated by
a red dot in the lower right corner of the heat level indicator.
7. After the timer has finished, the corresponding cooking zone
will switch off automatically.
(timer for 15 minutes)
(timer for 25 minutes)
NOTE: Other cooking zones will continue to operate according to
your settings if they have been set previously.
5.3. Auto shutdown for several cooking zones
1. When you set a timer for several cooking zones, the red dots will
indicate for which of the zones the timer is set. The timer display
shows the minimum timer. The dot of corresponding zone will flash.
2. At the end of the timer, the corresponding cooking zone will turn off.
The display will then show the time until the end of another
minimum timer and the corresponding red dot will flash.
