Günter & Hauer
EN Instruction manual
BUILT-IN MICROWAVE OVEN
EOK
20 BL / 20 X
28 X
25 WH/ 25 IVR

Thank you for your trust and choosing
GÜNTER & HAUER products!
Operating instructions are also available on our website:
www.gunter-hauer.eu
This manual was developed to facilitate
the use of the product.
It will help you familiarize yourself with
new appliance quickly.
Make sure you have received the product
without any damage.
If damage is detected, please contact the purchasing
organization where you have bought appliance.

3
CONTENT
1) Precautions...........................................................................4
2) Important safety instructions.................................................8
3) Cleaning................................................................................9
4) Microwave oven installation.................................................11
6) Assembly instructions..........................................................13
7) Instructions for choosing cookware.....................................17
8) Operation instructions:
Model EOK 25 WH / 25 IVR..............................................21
Model EOK 28 X................................................................27
Model EOK 20 BL / 20 X.................................................33
9) Troubleshooting..................................................................38
10) Specifications....................................................................40

PRECAUTIONS
Please read carefully and
keep for future use!
To prevent the possible impact
of electromagnetic radiation:
1) Do not turn on the
microwave oven when the door
is opened, do not break
microwave door latches or insert
any objects into the holes of the
door latch.
2) Do not allow foreign objects to
fall between the door and the
front surface of the microwave, as
well as the accumulation of food
particles or detergent residue on
the sealing surfaces.
ATTENTION: Do not use the
microwave if the door is
damaged and/or its parts
(hinges, locks) or seals. All
repair works and adjustments
in the microwave oven should
be carried out only by a
qualified specialist.
4
SAFETY INSTRUCTIONS
To avoid fire, electric shock,
injury or exposure to
electromagnetic radiation, follow
the basic safety requirements
described below when using the
appliance:
ATTENTION: Liquids and
other products should not be
heated in hermetically closed
containers, as they may
explode.
ATTENTION: Any
modifications and repairs to
the microwave oven that
involve removing the shield
against electromagnetic
radiation should be performed
by qualified personnel only.

5
3) This appliance can be used by
children aged 8 and over and
adults with physical disabilities,
sensory or cognitive impairments,
or lack of experience and
knowledge, if they are supervised
or have been instructed in the safe
use of the appliance and are aware
of the possible risks. Children
should not play with the appliance.
Cleaning and maintenance of the
appliance may be performed by
children only under supervision.
4) Keep the appliance and its
power cable out of the reach of
children under 8 years old.
5) Use only microwave safe
dishes.
6) It is necessary to clean the
microwave regularly, as well as
remove food residues from it.
7) When heating food in a
plastic or paper container, keep an
eye on it, as ignition is possible.
8) If smoke is emitted, turn off or
unplug the appliance and leave the
microwave door closed to contain
the flames.
9) Do not allow food to overheat.
This is especially relevant when
heating a small amount of food.
10) Do not use the microwave
cavity for storage. Do not store
various items inside, including
bread, cookies, etc.
11) It is not allowed to use metal
containers for food and drinks
when cooking in the microwave
oven. Remove any metal handles
from the cookware before placing
it in the microwave.
Cause: an electrical arcing or
spark may occur, which might
damage the furnace.
12) Install this microwave oven
only according to the installation
instructions supplied with the
appliance.
13) Hard-boiled eggs should not
be reheated in the microwave as
they may explode even after the
microwave is finished. It is also not
possible to reheat hermetically
closed bottles, cans, containers,
nuts in their shells, tomatoes, etc.
14) This microwave is intended for
domestic or similar use, such a s:

6
- in the kitchen for staff in
stores, offices and other
working spaces;
- for guests in hotels, motels,
and other residential spaces;
- in farm houses;
- in "bed and breakfast" house
type.
15) To avoid a hazardous
situation, a service representative,
or another qualified technician
must perform replacement of a
damaged power cable.
16) Do not use or store the
appliance outside.
17) Do not use near water, in a
wet area (eg. basement) or near a
swimming pool.
18) The appliance and its parts
can get very hot during use. Be
careful, avoid contact with
heating elements. Keep the cable
away from heated parts and heat
sources. Do not cover the
ventilation openings with cloth or
paper. These materials can ignite
if they come into contact with the
hot air coming out of the
microwave.
19) Do not leave the cable hanging
over the edge of a table or a
countertop.
20) If the microwave is not kept
clean, damage to the surface may
occur, which carries the risk of
shortening the life of the appliance,
as well as creating a dangerous
situation.
21) To prevent burns, the contents
of feeding bottles and baby food
cans should be stirred or shaken,
and the temperature should be
checked before consumption.
22) Heating containers with drinks
in a microwave oven may result in
slow boiling, so precautions should
be taken when handling such
containers to prevent this situation.
ALWAYS wait 20 seconds after the
microwave shuts off to allow
temperature to equalize.
23) The appliance cannot be
controlled using a separate timer or
remote control.
24) The external parts of the
appliance can become very hot
during use. To avoid burns, do not
leave children unattended near the
appliance.

7
25) The appliance must not be
cleaned with a steam cleaner.
26) Use only the temperature
sensor recommended for this
microwave oven (the appliance is
equipped with a temperature
sensor slot).
27) This microwave oven is
designed for heating food and
drinks. To avoid burns, sparks and
flashes, do not heat fabrics and
bags, rugs, slippers, sponges, raw
clothes, package filled with grains,
etc.
UNPACKING
The appliance was
protected from damage
during transportation.
After unpacking the microwave,
please remove the packaging
elements in an environmentally
safe way.
All materials used for
packaging are safe for the
environment and 100%
recyclable, which is marked with
the corresponding symbol.
WARNING! Packaging
materials (polyethylene bags,
pieces of foam, etc.) during the
unpacking process must be
inaccessible to children.
For more detailed information
on the recycling of this product,
please contact your local or
regional authorities, cleaning
service or the store where you
have purchased the appliance.
AFTER DECOMMISSIONING
This product conforms
to EU Directive
2002/96/CE. This
appliance is marked
with the symbol on
the selective sorting of waste
electronic equipment. This
means that this product must not
be disposed of with household
waste but must be supported by
a system of selective collection.
It will be recycled or dismantled
to minimize the impact on the
environment.

8
Electrical and electronic
products are potentially
dangerous for the environment
and human health due to the
presence of hazardous
substances.
Disposal of the appliance must
be carried out in accordance with
current environmental legislation
and waste disposal regulations.
IMPORTANT SAFETY
INSTRUCTIONS
Touching some internal parts
and components can cause
serious injury or death.
Do not disassemble this
appliance.
DANGER OF ELECTRIC SHOCK!
Improper grounding can cause
electric shock.
Do not insert the plug into the
socket until the appliance is
properly connected and
grounded.
This product must be grounded.
In the case of a short circuit, it
reduces the risk of electric shock
by allowing current to flow.
This product is equipped with
a cable that has a ground wire
and a suitable plug.
The plug must be connected to a
properly installed, grounded
socket.
If you do not fully understand the
grounding instructions or if you
have any doubts about whether
the appliance is properly
grounded, you should contact a
qualified electrician or technician.
If it is necessary to use an
extension cord, then only a
three-wire cable with a socket
for electrical grounding should
be used.
The manufacturer is not
responsible for damage or injury
as a result of connecting the
microwave oven to a power
source without grounding
protection or with faulty
grounding protection.
The microwave oven is
equipped with a short power
cable to avoid the risk of flash of
fire or sudden shutdown of the
microwave oven in case someone
tripped over a long cable.

9
If an extension cord is used:
1) The nominal electrical data on
the extension cord must
correspond (be of the same value)
to the nominal electrical data of
the appliance.
2) The extension cord must be
with a three-wire cable with
grounding.
3) The long cable should be run
in such a way that it does not hang
over the table or countertop, so
that children cannot pull on it, and
someone does not get caught on it
and accidentally disconnect the
microwave.
CLEANING
To avoid the accumulation of fat
and food particles, the following
parts of the microwave oven
should be cleaned regularly:
1) Remove all splashes and stains
from the interior surfaces or the
turntable ring using a soapy water
and a cloth. Clean and wipe dry.
2) To clean the external surfaces
and accessories of the microwave,
use a soft cloth and warm soapy
water. Clean and wipe dry.
3) ALWAYS keep door seals clean
and keep doors closed securely.
4) Do not use abrasive materials,
chemically active substances and
sharp metal scrapers to clean the
glass door of the microwave oven,
as this can cause scratches and
cracks in the glass.
5) TIP: To soften hardened food
particles and eliminate odors,
place a cup of water (300 ml) with
diluted lemon juice (half a lemon)
on the tray and heat it for ten
minutes at full power. After
finishing, wipe the surfaces with a
soft and dry cloth.
• Internal and external surfaces.
• Doors and door seals.
• Glass tray and turntable ring
assembly.
Before cleaning, make sure that
the appliance is disconnected from
the power supply.

10
PRODUCT OVERVIEW
EOK 25 WH
EOK 25 IVR
EOK 28 X
EOK 20 BL EOK 20 X

11
MICROWAVE OVEN
INSTALLATION
Your microwave comes with
the following accessories:
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
F
G
A
ED
CB
E) Observation window
F) Door
G) Safety interlock system
WARNING: The grill rack should only
be used when using the «GRILL»
function by placing it on the glass tray.

12
TURNTABLE INSTALLATION
1. Never place the glass tray upside
down.
2. Glass tray and turntable ring
assembly must always be used
during cooking.
3. For cooking or reheating, always
place dishes on the turntable.
4. If glass tray or turntable ring
assembly is cracked or damaged,
contact your the nearest service
center.
INSTALLATION
AND CONNECTION
1. This appliance is intended for
domestic use only.
2. This microwave is intended for
built-in use only. It is not intended
for countertop use or for use inside a
cupboard.
3. Please observe the special
installation instructions.
4. The appliance can be installed in
cabinet with a width of 60 cm, at a
height of 85 cm from the floor).
5. The appliance is fitted with a
plug and must only be connected
to a properly installed grounded
socket.
6. The mains voltage must
correspond to the voltage specified
on the rating plate.
7. The socket must be installed
and power cable must only be
replaced by a qualified electrician. If
a permanent connection is to be
made, ensure that the power line
has a multi-pole switch with a
contact distance of at least 3mm.
8. Connection through adapters
and extension cords is allowed, if
they fully meet the technical
requirements and standards, as well
as the power cable that comes with
the microwave. In all other cases,
overloading may cause a fire.
ATTENTION: The manufacturer is
not responsible for injuries and
damage to appliance and property,
as a result of non-compliance with
the described conditions.
ATTENTION: Accessible surfaces
may be hot during microwave
operation.

13
ASSEMBLY INSTRUCTIONS
EOK 20 BL
EOK 25 WH / EOK 25 IVR
EOK 28 X
EOK 20 X
ATTENTION: A cabinet for
installation of the product should
not have a back wall.
Do not block the ventilation
openings.
The power cable must not be
run so that it does not hang over a
table or countertop, it cannot be
pulled by children, or someone
does not trip over it and
accidentally turn off the appliance.
Dimensions may vary. Check the
manufacturer's official website for up-to-
date information.
388
401
386
344
388
388 388
324

Mounting plate.
В. PREPARE THE CABINET
1. Read the instructions on the
microwave bottom template
(hereafter «TEMPLATE»). Put the
«TEMPLATE» on the bottom
plane of cabinet, taking into
account all gaps.
2. Make marks on the bottom
plane of cabinet according to
marks «A» in the template.
14
"a""seloH
PN:261800316968
内容
成品尺寸：303*427mm

15
3. Remove the bottom cabinet
template and fix the mounting
plate with screw «A».
С. INSTALL THE MICROWAVE OVEN
4. Install the microwave to the cabinet.
-Make sure the back of the appliance is locked by mounting plate.
-Do not pinch the power cable.
SCREW «А»
MOUNTING
PLATE
MOUNTING
PLATE

16
5. Open the door, fix the microwave to the cabinet with Screw «B»,
at the installation hole.
INSTALLATION
HOLE
SCREW «B»

17
TYPE OF
COOKWARE
SUITABILITY
FOR MWO REMARKS
Aluminum foil
✓Х
It can be used in small quantities to
protect certain areas of food from
burning. Placing the foil close to the
microwave walls or using a large
amount of foil can cause an
electrical arcing.
Crust pan
✓
Do not preheat for more than eight
minutes. Follow the manufacturer's
instructions. The bottom of the
cookware should be at least 5 mm
thick. Improper use may damage the
turntable.
Porcelain and
ceramics✓
Porcelain, ceramic, glazed ceramic
and thin-walled porcelain can usually
be used as long as they do not have a
metal finish.
Cookware made
of polyester fiber ✓Such cookware are usually used for
packaging frozen products.
Waxed or
greaseproof paper ✓
Can be used to preserve moisture
and prevent splashing.
Bags for cooking
✓Х
Follow the manufacturer's instructions.
Do not tie up with metallic twist tie.
Make cuts for steam to escape.
INSTRUCTIONS FOR CHOOSING COOKWARE

18
Packaging of quick-
cooking products:
•Polystyrene cups
and containers
•Paper bags or
newspapers
•Recycled paper
or cookware with
metal finish
✓Х
Х
Х
Can be used to heat up food.
Polystyrene can melt when it is
overheated.
Ignition hazard.
May cause an electrical arcing.
Glassware:
•For cooking
•Thin-walled
•Glass jars
✓
✓
✓
It can be used when there is no
metal finish.
It can be used to heat up food
and liquids. When heated sharply,
fragile glass can break or burst.
The lid should be removed.
Suitable only for warming up.

19
Metal:
•Cookware
•Freezer bags
with metallic
twist tie
ХMay cause arcing or ignition.
Plastic:
•Containers
•Food wrap
film
•Freezing and/
or cooking
packages
•Plastic foam
✓Х
✓Х
✓Х
Х
In particular, heat-resistant
thermoplastic. Some other types of
plastic can deform or discolor at
high temperatures. Do not use
melamine plastic.
Can be used to preserve moisture.
Should not touch products. Be
careful not to get burned by the
hot steam when removing the film.
Only if they are suitable for boiling
or use in the microwave. Follow
the manufacturer's instructions.
Do not use metallic twist tie. Must
not be closed hermetically. Poke
some fork holes in it if necessary.
At high temperatures, plastic foam
can melt or release harmful
substances that get into food or
liquids.

20
Paper and wood
•Plates, cups,
napkins made of
textiles or paper
•Recycled
paper
•Wood
✓
✓Х
For cooking for a short time and
warming up. For absorption of
excess moisture.
May cause electrical arcing.
The wood will constantly lose
moisture and dry out, which will
lead to its further destruction.
Thermometers
✓Х
Only intended for use in
microwave ovens (for meat and
sweets / caramel).
✓: Recommended
✓Х: Use with caution
Х: Not recommended
✓Х
