GVision P15BX-O User manual

M
ultimedia A
pp
licatio
n
1
5
" TFT L
C
D Bathroom T
V
Where
Versatility
Meets
Flexibility
Where Versatility Meets Flexibility
GVision Incorporated TEL: [phone] / FAX : [phone] / www.gvision.com.twGVision Incorporated TEL: [phone] / FAX : [phone] / www.gvision.com.tw
* Specifications are subject to change without notice.
Mechanical drawing
I/O Ports
Front Side Back Side
Configuration
LCD Display
Pixel Pitch
Max. Resolution
Contrast Ratio
Brightness
Response Time ( Tr+ Tf )
Display Color
Effective Display Area
Viewing Angle (CR ꇙ 10)
Backlight
Lamp Life
Input Signal
Signal connector Analog
Digital
Video in
Scan Frequency
Tuner Type
TV Channel Selections
(Audio systems)
Video System
Key Control
Speakers Out (watts)(R/L)
Operating Condition Temperature
Humidity
Altitude
Storage Condition Temperature
Humidity
Power (Internal)
Power Consumption
Dimensions
Dimensions (Carton)
Weight (Net)
Certification
Features :
* Support NTSC-M and Multi-PAL TV tuner system
and Video-in Auto-detection function.
* Nicam Audio system supported
* IP53 (Front bezel) Spilling proof available
* Anti-Glare Tempered Glass
* High contrast color TFT LCD display support resolution
up to XGA 1024x768.
* Universal power adapter.
* Advanced OSD control for picture quality adjustment.
* Various embedded multimedia providing audio system,
earphone jack, and audio-out jack.
Ordering Information :
* P15BX-OQ VGA, DVI-D,
Video, S-Video,
Audio, TV Tuner
P15BX-OQ
15" TFT active matrix panel
0.297(H) x 0.297 (V) mm
XGA 1024 x 768
400:1 (Typical )
450 Cd/m2(Typical )
25 (5+20) ms
16,777,216 colors
304.1 (H) x 228.1 (V)
140 (H) x 125 (V)
4 CCFTs
25,000 hrs
Analoge VGA, Dogoya, Composite
Video (NTSC/PAL)
D-sub 15 pin (VGA)
DVI-D
RCA, S-Video, TV antenna
56/60/70/72/75 Hz
TV-Tuner
NTSC-M(Mono) ꅁ PAL-B/G ꅂ D/K ꅂ
L ꅂ I ( Multi PAL ) ( NICAM )
NTSC/PAL
Power on/off with LED, Menu,
Select, Adjustment (+, - )
2W / per channel driver
5oC-35oC (41oF-95oF)
20%-80% (no condensation)
To 10,000 feet
-20oC-60oC ( -4oF-140oF )
10%-90% ( no condensation )
Input AC 100~240V, 50~60Hz;
Output DC 12V / 3A
36 watts
280(H) x 351(W) x 54.1(D) mm
340(H) x 450(W) x 160(D) mm
5 Kg
C-UL, FCC, CE
UNiT : mm
Audio RCA S-Video TV Line-in DVI-D VGA DC in
Q
P15BX
-
OQ
P15BX OQ
P15BX OQ
