GZ LEAHUA LIGHT LH-C039 User manual

LH-C039 Led Spider Beam Light
User Manual
This manual contains important information.
Please read before operating fixture.

1
1 SECURITY TIPS
WARNING!!! To reduce the risk of fire, electric shock, or
injury to persons, follow these important safety instructions:
non-professionals, not to disassemble the light arbitrarily and
lighting accessories inside.
rated voltage range: AC110V-120V/60Hz or AC200V-240V / 50HZ
(to be selected).
not beam irradiate the flammable materials, flammable materials
and the lamp should be maintained at least 1M over the distance.
lamps used in ambient temperature: -15 ℃-40 ℃, the highest
temperature of the surface of the lamp: 60 ℃.
to keep away from the liquid substance and humid environment.
before using the lights must ensure the good grounding, can not
install charging and remove any parts.
the installation of lamps, must be fixed screw fasteners with
additional security cable and regular inspection.
lamps consecutive working hours is not recommended more than
10 hours.
should stop using the lights in time when happens unusual
conditions during the process
lamp parts of the rotation, external accessories and paste parts
should be regular inspected, such as the emergence of loose and
rock, should be reinforced in a timely manner to prevent the
accident.
lamps adopt strong winds to refrigerate, it is easy to accumulate the
dust, so you have to clean it weekly especially the cooling air
opening, otherwise the dust will plug leading to poor light

2
2 TECHNOLOGY REFERENCE
Input Voltage: AC90-240V 50-60Hz
Power consumption: 150w
Light source :8PCS 10W led RGBW
Channel: 16CH,/18CH/42CH
Color: RGBW
Control: DMX, master slave, sound active, auto mode.
Dimmer:0-100%dimmer
Scan Angle: Vertical 180
Beam Angle: 45degree
Motor:2motors
.Pan : 540°16 bit
Tilt : 270°16 bit
Net weight: 4.4kg
Carton case:460*300*220mm(put single)
Gross weight:5.7kg
Function:
1.Lighting, an innovative, versatile pixel multi‐beam effects,
delivering outstanding, sharp and long‐throw beams
2.Featuring 2 movable LED bars, each with 4 pixel controlled 8W
LEDs for the best lighting performance you can ever except
3.3 Operation Modes: DMX, Mater/Slave mode, Sound Activation.
4.DMX Channel modes: 1,6,12 channels
5.Optional easy controller CA‐8 for instant lighting show.
6.Great built‐in programs under master/slave operation triggered by
music.
7.Electronic dimming and various strobe effects.
8.Ideal for pubs, clubs, bars, parties, Mobile DJs and more.

3
3 Board Instruction
Main menu:
1. POWER IN: Used to connect to supply power;
2. POWER OUT: Used to connect to supply power to the next unit;
3. Fuse (T 3.15A): Used to protect the unit from the damage of the
over‐current;
4. DMX IN/OUT: For DMX512 links, use 3‐pin XLR plug cable
to link the unit together;

4
5. Only for remote control: Used to connect to the CA‐8 to
control the unit for Stand by, Function and Mode function;
6. Microphone: Used to receive music for the sound activation;
7. LED:
DMX
On
DMX input present
MASTER
On
Master Mode
SLAVE
On
Slave Mode
SOUND
Flashing
Sound activation
8. Button:
MENU
To select the programming functions
DOWN
To go backward in the selected functions
UP
To go forward in the selected functions
ENTER
To confirm the selected functions
9. Function Display: Used to show the various menus and the
selected functions.

5
10 . Board Instruction
d001
001--512
512 Address
Chxx
16Channel
18 Channel
DMX Mode
Mode
Sens
ON
Sound Mode
Fast Mode
Slow Mode
OFF
X2Motor Forward
Console mode
Sound operating Mode
Fast operation mode
Slow run mode
0--99
Sound sensitivity
Tilt1
OFF
X1Motor Forward
Tilt2
ON
X1Motor reversal
X2Motor reversal
rdon
Reverse Display
42 Channel
16
18
42
rdoF
Forward Display
rdoF

6
4 DMX CHANNEL SHEET
16 Channel Mode:
CH
Function
Explanation
1
M1 Level of
functioning
0-255 forward adjust upward, downward
adjustment reversal
2
M1 Vertical
0-255 M1Motor speed adjustment
3
Strobe
0-255 flicker adjustment, from slow to fast
4
Total dimmer
0-255 overall brightness adjustment
5
R1 dimmer
0-255 Red brightness adjustment
6
G1 dimmer
0-255 Green brightness adjustment
7
B1 dimmer
0-255 Blue brightness adjustment
8
W1 dimmer
0-255 White brightness adjustment
9
M2 Level of
functioning
0-255 forward adjust upward, downward
adjustment reversal
10
M2 Vertical
0-255 M1Motor speed adjustment
11
Strobe
0-255 flicker adjustment, from slow to fast
12
Total dimmer
0-255 overall brightness adjustment
13
R2 dimmer
0-255 Red brightness adjustment
14
G2 dimmer
0-255 Green brightness adjustment
15
B2 dimmer
0-255 Blue brightness adjustment
YES
Initialization
Deft
CdoF
Display does not
CdoF
Cdon
Display off
YES
System Reset
RESET

7
16
W2 dimmer
0-255 White brightness adjustment
18 Channel Mode:
CH
Function
Explanation
1
0-10
The role of other channels
11-120
Effect1
121-243
Effect2
245-255
Sound effect
2
Built-effect
speed
Built-effect speed adjustment
3
0-10
Other channels work
11-127
Changes color combinations
128-160
Color transitions
161-200
Color gradient1
201-255
Color gradient2
4
Adjustment
The first 10CH speed adjustment function
5
Level
operation
0-255 forward adjust upward , downward
adjustment reversal
6
Vertical
operation
0-255 forward adjust upward , downward
adjustment reversal
7
Motor
running
0-255 Horizontal , vertical motor speed
8
Total dimmer
0-255 overall brightness adjustment
9
Strobe
0-255 strobe adjustment ,from slow to fast
10
R1 dimmer
0-255 Red brightness adjustment
11
G1 dimmer
0-255 Green brightness adjustment
12
B1 dimmer
0-255 Blue brightness adjustment
13
W1 dimmer
0-255 White brightness adjustment
14
R2 dimmer
0-255 Red brightness adjustment

8
15
G2 dimmer
0-255 Green brightness adjustment
16
B2 dimmer
0-255 Blue brightness adjustment
17
W2 dimmer
0-255 White brightness adjustment
18
Reset
150-200 Reset
42ChannelMode:
CH
Function
Explanation
1
0-10
The role of other channels
11-120
Effect1
121-243
Effect2
245-255
Sound effect
2
Built-effect
speed
Built-effect speed adjustment
3
0-10
Other channels work
11-127
Changes color combinations
128-160
Color transitions
161-200
Color gradient1
201-255
Color gradient2
4
Adjustment
The first 10CH speed adjustment function
5
Level
operation
0-255 forward adjust upward , downward
adjustment reversal
6
Vertical
operation
0-255 forward adjust upward , downward
adjustment reversal
7
Motor
running
0-255 Horizontal , vertical motor speed
8
Total dimmer
0-255 overall brightness adjustment
9
Strobe
0-255 strobe adjustment ,from slow to fast
10
R1 dimmer
0-255 Red brightness adjustment

9
11
G1 dimmer
0-255 Green brightness adjustment
12
B1 dimmer
0-255 Blue brightness adjustment
13
W1 dimmer
0-255 White brightness adjustment
14
R2 dimmer
0-255 Red brightness adjustment
15
G2 dimmer
0-255 Green brightness adjustment
16
B2 dimmer
0-255 Blue brightness adjustment
17
W2 dimmer
0-255 White brightness adjustment
18
R3 dimmer
0-255 Red brightness adjustment
19
G3dimmer
0-255 Green brightness adjustment
20
B3dimmer
0-255 Blue brightness adjustment
21
W3 dimmer
0-255 White brightness adjustment
22
R4dimmer
0-255 Red brightness adjustment
23
G4 dimmer
0-255 Green brightness adjustment
24
B4 dimmer
0-255 Blue brightness adjustment
25
W4 dimmer
0-255 White brightness adjustment
…
…
…..
38
R8dimmer
0-255 Red brightness adjustment
39
G8 dimmer
0-255 Green brightness adjustment
40
B8 dimmer
0-255 Blue brightness adjustment
41
W8dimmer
0-255 White brightness adjustment
42
Reset
150-200 Reset
5 DIFFICULTY RESOLUTION
The following is a list of problems and resolution, and other
malfunction preparing work should be professionally qualified staff to
deal with.
1. Bulb not working
a) Check whether approaching the service life of light bulbs, then
change it

10
b) Check whether bulbs circuitry leak, loss or connect poorly
2. Beam appears bleak
a) The bulbs maybe approach the service life, then change it, or
the optical components are unclean.
b) Bulbs have accumulation of dust, so the bulbs and other parts
inside the lamp should be cleaned and maintained in regular
period.
3. Computer lamp work intermittently
a) Check whether the fan process naturally and become dirty
b) Check inner temperature-response control plug is off
c) Check whether the circuitry is good
4. The computer lamp not controlled by controller during lighting
a) Check numeral starting address and the connection of
communication control circuit
b) The corresponding channel button of controller is open or not
c) Check whether the fuse on power supply input jack is broken
off
6 AFTER SERVICE
1. Our company offer technical consultation to customers for ever.
2. If the machine is wrong and need repairmen, please truthfully fill in
the related content and feedback us the problems timely, as well as
we have to improve the product.
3. In addition to the lamp, also matching accessories are as follows：
accessories：Power line 1 piece Optional parts：(customers）

11

Warranty Card
Name Model Production Purchase
Description: These must be truthfully fill, seal by the end-user and point-of-sale, or else the
warranty will not work (warranty period and terms, see the following)
warranty period：one year since purchase warranty terms：1、If fail when using the product
in normal state, you can made under the provisions of the warranty, show the warranty card
and purchase bills(copy), and enjoy free maintenance service in a specific service center or
the manufacturer.
2. The following will be the implementation of paid service:
(1)Without the effective warranty card
(2)There’s blank, alter and no point-of-sale name
(3)Fail caused by unresistance
(4)Fail caused by transportation or unloading
(5)Fail caused by not operate by manual
(6)Fail caused by disassemble without unauthorized
(7)Fail caused by using the unauthorized control system
Note:
Based on our company continue to improve the product, the statement
containing data may have changed, and will not notice the change any
more. Company retains its right to change specifications related when
product is improved. Thanks for your understanding.
