Haden HWDI1480 User manual

www.haden.com 1
8KG Integrated Washer Dyer
HWDI1480
INSTRUCTION MANUAL

2www.haden.com
CONTENTS
Safety Instructions 3
Moving and Installing 7
Unpacking 7
Disposal of Packaging Materials 7
Removing Transit Bolts 8
Select Location 8
Adjusting Legs 9
Connecting water Inlet pipe 9
Transit Hole Plugs 10
Positioning the Water Drainage Hose 11
Electrical Connection 12
Product Overview 13
The Unit 13
Control Panel 14
Preparation 15
Preparing Laundry 15
Adding Detergent and Softener 17
Operation 19
Before First Use 19
Standard Washing 19
Options 20
Programmes 23
Washing Programmes Tables 24
Maintenance 25
Cleaning 25
Troubleshooting 27
Technical Specifications 29
Product Fiches 31
Guarantee 32

www.haden.com 3
SAFETY INSTRUCTIONS
When using electrical appliances, the following basic safety
precautions should always be taken.
•The appliance can be used by children aged 8 years and above and
persons with reduced physical, sensory or mental capability or a lack of
experience and knowledge if they are under supervision or have received
instruction on the safe use of the appliance and understand the hazards
involved.
•Children must not play with the appliance.
•Children younger than 3 should be kept away from the appliance unless
continuously supervised.
•Cleaning and user maintenance should not be undertaken by children
without supervision.
•If the supply cord is damaged, do not use the machine. The cable must
be replaced by the manufacturer, service agent or similarly qualified
technician to avoid a hazard.
•Only the new hose sets supplied with the appliance are to be used; old
hose sets should not be reused.
•The washing machine is for indoor use only.
•Your machine must only be installed by a competent service engineer.
•Before operating the washing machine, you must remove the transit
bolts from the rear of the machine. If the bolts are not removed, they
may cause heavy vibration, noise and malfunction of the machine which
will invalidate the guarantee.
•Install your machine in a location that is well ventilated and preferably
has constant air circulation. The openings and ventilation points of the
appliance must not be obstructed by carpet.
•Make sure that the door of your Washing Machine is not restricted and
can be opened fully.
•Ensure that the voltage and frequency of the power source are identical
to those of the washing machine.

4www.haden.com
•Do not use a plug socket with a current rating that is lower than that of
the washing machine. Never remove the power plug with wet hands.
•To ensure your safety, the plug to the power cord must be inserted into
an earthed socket.
•Do not connect your Washing Machine to the mains electricity supply
using an extension lead.
•Make sure that the water supply and electrical supply are connected by
a qualified technician in accordance with the manufacturer’s
instructions and local safety regulations.
•Please check the machine before installation. Check the outer surface
of the machine once the packaging has been removed. Do not operate
the machine if it appears damaged.
•The necessary ambient temperature for operation of your Washing
Machine is between 10 - 25 °C.
•The washing machine should not be installed in a bathroom.
•Should the ambient temperature fall below 0 °C, hoses may split or the
electronic card may not operate correctly.
•Make sure hoses and cables do not cause a trip hazard.
•Before starting any cleaning or maintenance remove the plug from the
power socket.
•A washing machine with a single inlet valve can be connected only to a
cold-water supply. A washing machine with two inlet valves can be
connected to either a hot-water or a cold-water supply.
•Make sure that all pockets are emptied before placing clothing in the
appliance.
•Sharp and rigid items such as coins, brooches, nails, coins and stones
may cause serious damage to the machine.
•Check that the water inside the drum has drained before opening the
door of the washing machine. Do not open the door if any water is
visible.
•Keep pets away from your machine.
•Pets and children may climb into the machine. Check the machine
before each use!!
•The glass door can become very hot during use. Keep children and pets
far away from the machine during use.

www.haden.com 5
•Packaging materials may be dangerous to children. Keep all packaging
(plastic bags, foam etc.) away from children.
•Only use your machine for laundry that is labelled as suitable for
washing by the manufacturer.
•Before washing clothes for the first time, it is recommended that for
your first wash you select a hot 90˚C wash cycle (without laundry) and
half fill the detergent drawer with a suitable detergent. The washing
machine should be run for the full cycle with an empty drum.
•Flammable, explosive or toxic solvents must not be used. Substances
such as gasoline and alcohol must not be used as detergents. Select
only detergents suitable for machine washing, especially drum-based
washing.
•The appliance must not be used to wash carpets.
•Be careful to avoid being burnt when the washing machine is draining
hot water.
•Never refill the water by hand during use.
•Washing laundry containing flour may damage your machine.
•Please follow the manufacturers’ instructions regarding the use of
fabric conditioner or any similar products that you intend to use in your
Washing Machine.
•After a program is complete, wait for 2 minutes to open the door.
•Remember to disconnect the water and power supply immediately after
the clothes are washed.
•Do not climb or sit on top of the machine.
•Do not lean against the door of the machine.
•Do not close the door with excessive force. If it is difficult to close the
door, reduce the amount of clothes in the drum or distribute them more
evenly.
•Never open the detergent drawer while the machine is running.
•In the event of a breakdown, unplug the machine from the mains supply
and turn the water supply off. Do not attempt to carry out any repairs.
Always contact an authorised service agent.

6www.haden.com
•Do not exceed the maximum load for the washing programme you
have chosen.
•Never force the door open when your Washing Machine is running.
•During manufacture your Washing Machine will under-go several
quality checks which may leave some water residue within the
machine. This will not affect the operation of your Washing
Machine.
•If your Washing Machine is left unused for a long time, unplug the
machine and switch off the water supply. We also recommend that
you leave the door open to prevent build-up of humidity inside.
If you need to relocate the machine:
1. Transport bolts must be reinstalled by a service engineer.
2. Accumulated water must be drained out of the machine before
relocation.
3. Handle the machine carefully. Never use protruding parts to lift the
machine. The machine door must not be used as a handle during
transportation.
4. The machine must be carried by at least 2 people.
Your machine is for domestic use only. Using it for commercial
purposes will cause your warranty to become void

www.haden.com 7
Moving and Installing
Unpack the Washing Machine
Unpack your washing machine and check that no damage has occurred
during transportation.
1.Remove the cardboard box and Styrofoam packing.
2.Lift the washing machine and remove the base
packing. Make sure that the small triangle foam
block from the base has been removed. If not, lay
the unit down on the side surface, then remove the
block from the unit bottom manually.
3.Remove the tape securing the power supply cord and drain hose.
4.Remove the accessories bag from the drum.
If the washing machine has been damaged during transportation or any
item is missing, please contact us immediately.
Dispose of Packaging Materials
The materials used to package the machine may be dangerous to children.
Please ensure that these materials cannot be accessed by children, and
dispose of them according to local regulations. Please do not throw the
packaging materials away with household waste

8www.haden.com
Remove the Transport Bolts
Before using the washing machine, the
transport bolts must
be removed from the back of the appliance.
Please remove and store the bolts as follows.
1. Loosen all bolts with a spanner before
removing them.
2. Fill the bolt holes using the with transit hole
covers
3. Store the transport bolts appropriately for
future use
Select Location
Before installing the washing machine, a location with the following
characteristics must be selected.
- A rigid, dry and level surface (if the surface is not level, please use the
guidance in the following figure, ‘Adjust Legs’, to level the appliance)
- Not in direct sunlight
- Sufficient ventilation
- Room temperature above 10℃
- Away from heat sources such as coal or gas fires.
- Leave a 20mm gap at least between the side and back of the unit.
Make sure that the power cord is not trapped beneath the washing
machine.
Do not install the washing machine on a carpeted floor.

www.haden.com 9
Adjusting Legs
For your machine to work silently and without any vibration, it should be
placed on a flat, stable surface.
There are adjustable feet under the bottom of the washing
machine. Before use, they should be adjusted so that the
washing machine is level. This will minimize vibrations and noise during
operation.
1. Check if the legs are closely attached to the cabinet. If not, please
turn them to their original positions tighten the nuts.
2. Loosen the lock nut and turn the feet until they closely contact the
floor.
3. Adjust the legs and lock them with a spanner, make sure the machine
is steady.
Connecting water inlet hose
Connect the inlet pipe as indicated.
1) Connect the straight end of the hose to
the cold water outlet at the installation
location. The outlet must be fitted with
a ¾” threaded connection.
Ensure it is tightened adequately so
that it does not leak.
1
2
3
4
Raise
Lower

10 www.haden.com
2) Connect the curved end of the hose to
the water inlet valve located at the rear
right hand top corner of the machine.
Ensure the connection is tightened
adequately so that it will not leak.
3) Make sure there a no kinks or bends in the hose.
4) Turn on the tap and check that there are no leaks from either
connection.
NOTE:
Your Washing Machine must only be connected to your water supply
using the supplied new fill hose. Old hoses must not be reused.
Transit Hole Plugs
Hole plugs can be used to plug up the
holes at the back of the machine after the
transit bolts have been removed.

www.haden.com 11
Positioning the Water Drainage Hose
The drain hose is located on the rear of the machine.
•The drainage outlet must be located between 60 and 100 cm in
height from the floor.
•Connect the drain hose to the drainage outlet.
•Ensure the hose is not kinked or bent.
Connecting to the branch drain pipe of the basin / sink
Position the outlet hose properly to ensure there is no water leakage.
Do not attempt to lengthen the drain hose.
When installing the outlet hose
over the sink, ensure that it is
tightly bound to the sink and
that the end is not underwater.
If the outlet hose is too long, do
not force it into the washing
machine, as this will cause
abnormal noises and damage
to the hose.

12 www.haden.com
Electrical Connection
IMPORTANT – This is a Class I Electrical Product. It requires an Earth
connection.
•Connect the appliance to a power socket that is correctly installed
and properly earthed.
•Make sure that the voltage of the power supply is the same as that
indicated on the machine's rating label.
•Do not use a multi-purpose plug or socket as an extension cord.
•Do not connect or remove the plug with wet hands.
•When connecting and removing the plug, hold the plug tightly. Do
not use excessive force to remove the power cord.
•If the power cord is damaged, it must be replaced by a qualified
electrician to avoid hazard.
The machine must be earthed properly.
If a short circuit occurs, earthing can reduce the risk of electrical shock.
DO NOT DISASSEMBLE THIS APPLIANCE. TOUCHING SOME OF THE
INTERNAL COMPONENTS CAN BE EXTREMELY HAZARDOUS.

www.haden.com 13
Product Overview
Detergent dispenser
Door
Control Panel
Power supply cord
Drain hose
Accessories

14 www.haden.com
Control Panel
1. On/Off
Turn the product on or off
2. Start/Pause
Press this button to start or pause the washing cycle
3. Option
This allows you to select an additional function and will light when
selected.
4. Programmes
Available programmes according to laundry type.
5. Display
The display shows the setting, estimated time remaining, options,
and status messages for your washer. The display will remain on
through the cycle.

www.haden.com 15
Preparation
Preparing Laundry
Please read these operating instructions carefully to avoid damaging the
washing machine or your clothing.
1. Follow the instructions given in the care labels on the clothing.
Separate your laundry according to type (cotton, synthetic, sensitive,
wool etc.), washing temperature (cold, 30°, 40°, 60°, 90°) and the
degree of dirtiness (slightly stained, stained, highly stained).
2. Never wash coloured and white laundry together.
Dark textiles may contain excess dye and should be washed
separately several times.
3. Ensure that there are no metallic materials on your laundry or in
the pockets; if so, remove them.
CAUTION: Any malfunctions which occur due to foreign
materials damaging your machine are not covered by the
warranty.
4. Close zips and fasten any hooks and eyes.
5. Remove the metallic or plastic hooks of curtains or place them in a
washing net or bag.
6. Reverse textiles such as pants, knitwear, t-shirts and sweat
shirts.
7. Wash socks, handkerchiefs and other small items in a washing net.
Check the label
Take all items out of the
pockets
Knot long strips, close zips and
buttons

16 www.haden.com
Check colourfastness before washing
Use a white towel to apply a small amount of
liquid detergent to an unseen section of
clothing. If the clothing stains the towel, it is
not colourfast.
Please wash scarves and other non-colourfast
clothes separately.
To maximise the effectiveness of washing,
apply liquid detergent to stains on sleeves,
collars and pockets and rub gently with a brush before washing.
Please take washed clothes out of the machine in a timely manner, as
laundry which is left in the machine for a long time may smell and become
mouldy.
It is recommended that brassieres are washed
inside a pillowcase with their zips or buttons sealed
to ensure that their internal steel wires do not
damage the washing-machine drum.
Particularly delicate textiles (such as lace curtains
and jackets) and small articles (such as short socks,
handkerchiefs and ties) should be put into a string
bag for washing.
Heavy single items such as towels, jeans and bulky
jackets may cause an imbalance in the motion of
the drum.
Separate clothes with
different textures
Put small clothes into
pillowcases
Turn easy-pilling and
long pile fabrics inside

www.haden.com 17
It is recommended that two or more such items are washed together to
ensure that draining occurs smoothly.
Clean any dust, soil and pet hair from clothes before washing
Ensure that babies’ skin is protected
Baby articles (clothes, towels and other fabrics) should be washed
separately. Rinsing time should be increased to ensure thorough rinsing
and cleaning
Do not exceed the maximum load! See the washing programme table
for the maximum load for the programme you require.
Adding Detergent and Softener
•Add detergent into the appropriate dispenser
•Apply softener before the you start the washing cycle
•Apply detergent and softener according to the washing amount, soiling
level, the water hardness in your area and the manufacturers
instructions of these products.
•For slightly dirty clothes, put a small amount of detergent into
compartment II of the drawer.
Pull out the dispenser
І
Prewash detergent
ІІ Main wash detergent
Softener

18 www.haden.com
•For excessively dirty clothes, put ¼ of the detergent to be used into
compartment I of the drawer and the remaining amount into
compartment II.
•Do not use the washing machine when the detergent drawer is
removed. It may cause a water leak or it may not work normally.
•If you forget to add detergent, you can drain the washing machine by
running a drain only programme. Then you can add detergent and start
the programme again. Detergent only reaches the drum when water
flushes through the detergent drawer.
•To prevent powder detergent staying in the drawer, dry the inside of
the drawer with a cloth. Make sure the powder isn’t lumpy when you
add it into the drawer.
•If the rinse cycle isn’t removing all the detergent from your wash, use
less detergent.
•Softener should not exceed the MAX level in the compartment.
•Wash out unused softener with a splash of water or a damp cloth after
the programme has finished.
•You can use liquid detergents in all programmes.
Dilute viscous fabric softener and fabric conditioner with water to
prevent blockage of the overflow. Maximum level is 40ml.

www.haden.com 19
Operation
Before First Use
Before washing your clothes for the first time, run a full wash programme
first:
1. Connect the machine to the mains power supply and the water supply.
2. Put a small amount of detergent into the detergent drawer. Close the
drawer.
3. Press the ON/OFF.
4. Select COTTON programme.
5. Press the START/PAUSE button
Standard Washing
1. Pull the door handle and place the laundry in the drum. (Refer to
Preparation to sort your laundry before it goes into the drum.)
Make sure no washing gets caught in the door.
2. Close the door.
3. Add the desired amount of detergent and softener to the detergent
drawer and close.
4. Press the ON/OFF
5. Select a wash programme.
6. Select any extra options if required.
7. Press the START/PAUSE button to start the washing.
8. The washing machine will beep when the programme has completed
If the door is locked and you switched the washing machine off and then
on - or if there’s a power cut - it will stay locked for 1 minute.

20 www.haden.com
Removing Washing (Once programme is finished)
•Once the washing machine beeps the door will remain closed for 1
minute before unlocking.
•Open the washing machine door and remove your washing.
•Remove any foreign objects to avoid risk of rusting.
•Leave the door and detergent drawer open so that residual water can
evaporate.
Options
Delay
Set the Delay function:
1. Select a programme
2. Press the Delay button to choose the time (delaying time 0-24 H)
3. Press [Start/Pause] to commence the delay operation
Cancel the Delay function:
Press the [Delay] button until the display be 0H. It should be pressed
before starting the programme. If the programme already started, should
press the [On/Off] button to reset the programme.
If there is any break in the power supply while the machine is
operating, a special memory stores the selected programme and
when the power is restarted, press the [Start/Pause] button the
program will continues.
My Cycle
Add your most frequently used programmes to memory
Press the Speed for 3 secs to add the selected running programme to
memory. The default is Cotton.
