Hahnel modus 600rt User manual

GB
Modus 600RT - English 1
Instruction
Manual
Wireless Speedlight
for Canon
English

GB
GB
2 Modus 600RT - English Modus 600RT - English 3
Foreword
Thank you for purchasing the Modus 600RT.
The Modus 600RT is a Speedlight for Canon EOS
series cameras and is compatible with the E-TTL
II Auto ash system. Older generation E-TTL/TTL
Autoash system and (Type-B camera) will work
also with some features not available.
• Before starting to shoot, be sure to read this
manual
• When reading this manual also refer to the
camera’s Instruction Manual
Conventions &
assumptions
• The manual is based on the assumption that all
devices including camera are turned on
• Reference page numbers are indicated by
(page **)
• The caution symbol indicates a warning to
prevent shooting problems
• The Note symbol gives supplemental
information

GB
GB
4 Modus 600RT - English Modus 600RT - English 5
Contents
1 Introduction
• Safety precaution - Warnings & Cautions 6
• Nomenclature
• Body 8
• Control Panel 9
• LCD Panel in ve modes 9
• Nomenclature - Viper TTL Transmitter 12
2 Getting started
• Wireless Kit - Whats in the box 14
• Wireless Pro Kit - Whats in the box 14
• Battery and charger 14
• Attaching to camera 17
• Power Management 17
• Flash Mode - E-TTL Autoash
• FEC (Flash Exposure Compensation) 18
• FEB (Flash Exposure Bracketing) 19
• FEL (Flash Exposure Lock) 20
• HSS (High Speed Sync) 20
• 2nd Curtain Sync 21
• Flash Mode - Manual Flash 22
• Flash output power range 22
• Optical O1 Secondary unit setting 22
• Optical O2 Secondary unit setting 23
• Flash Mode - Multi: Stroboscopic Flash 23
• Calcualting the shuter speed 23
• Number of ashes / ash frequency
= shutter speed 24
3 Wireless Flash Photography: (2.4GHz)
Control
• Master/Slave wireless ash lighting 25
• Wireless multiple ash shooting 26
• Wireless settings
• Master unit Setting 27
• Slave unit Setting 27
• Master unit ash ON/OFF 27
• DCM (Digital channel matching) 28
• Master - Viper TTL or Modus 600RT 28
• Slave - Modus 600RT 28
• Modus 600RT Reset 29
• ETTL - Fully automatic wireless
ash shooting 29
• Using Automatic wireless ash with multiple
slave units 31
• Adavnced setting with fully automatic
wireless ash 31
• Multiple master unit 32
• ETTL shooting Flash Ratio A:B 32
• ETTL shooting Flash Ratio A:B:C 33
• M: Wireless Flash Shooting with
Manual Flash 34
• MULTI: Wireless Flash Shooting with
Multi Flash 35
• GR - Shooting with a Different Flash
Mode for Each Group 35
4 Wireless Flash Photography: Optical
Transmission
• Wireless settings 38
• Master unit setting 39
• Slave unit setting 39
• Master unit ash ON/OFF 39
• Setting the optical communication
channel 39
• ETTL - Fully automatic wireless
ash shooting 40
• Using Automatic wireless ash with multiple
slave units 40
• ETTL shooting Flash Ratio A:B 40
• ETTL shooting Flash Ratio A:B:C 40
• M: Wireless Flash Shooting with
Manual Flash 41
• MULTI: Wireless Flash Shooting with
Multi Flash 41
5 Wireless Flash Photography: (2.4GHz) using
Viper TTL Transmitter
• Wireless setting 42
• Group Power Control setting for Manual
and TTL FEC 42
• Multi Mode 43
• Sync Modes 43
6 Other Applications
• Sync Triggering 44
• Auto Focus Asist Beam 44
• Bounce Flash 44
• Catchlight Panel 45
• Zoom – Setting the Flash Coverage and using
Wide Panel 45
• C.Fn – Setting Custom Functions 46
• Setting Camera Flash Functions 47
• Protection Functions 47
• Technical Data 49
• Troubleshooting 50
• Firmware Upgrade 51
• Maintenance 51
Page Page

GB
GB
6 Modus 600RT - English Modus 600RT - English 7
Introduction
1
Warnings:
Failure to observe the instructions below may
result in loss of life or serious bodily injury. To
prevent re, excessive heat, chemical leakage,
explosions, and electrical shock, follow the
safeguards below:
• Do not insert any foreign metallic objects
into the electrical contacts of the product,
accessories, connecting cables, etc
• Do not use any batteries, power sources, or
accessories not specied in the instruction
Manual. Do not use any deformed or modied
batteries, or the product if it is damaged
• Do not short-circuit, disassemble, or modify
the product or batteries. Do not apply heat or
solder to the batteries. Do not store batteries
with metal objects. Do not expose the batteries
to re or water. Do not subject the batteries to
strong impact or continuous mechanical shock
• Do not place batteries in microwave, cooker or
high-pressure container
• Do not use the product in locations where there
is ammable gas
• Do not re the ash at anyone driving a car or
other vehicle
• Do not disassemble or modify the equipment.
High-voltage internal parts may cause electrical
shock. If you drop the equipment and the
casing breaks open to expose the internal
parts, do not touch the exposed parts. There is
a possibility of an electrical shock
• Do not store the product in dusty or humid
places or location with lots of oil smoke. Do not
store battery in charger
• Keep the batteries and other accessories out of
the reach of children and infants
• Do not drop product or battery in re or water
• Do not expose product or battery to excessive
temperature (below 0ºC or above 40ºC) or
strong direct sunlight
• Battery temperature while on charge or in use
should never increase above 60ºC/140ºF. If
higher temperature occurs, stop using and stop
charging immediately
• Do not use paint thinner, benzene, or other
organic solvents to clean the product
Caution:
• Failure to observe the instructions below may
result in serious bodily injury or damage to
property
• When the product is not in use for a prolonged
period, make sure to remove the batteries
before storing
• When disposing of a battery, insulate the
electrical contacts with tape. Contact with other
metallic objects or batteries may cause a re or
an explosion. Dispose of battery in accordance
with the appropriate regulations
• Do not store or leave product or battery in
trunk or on dashboard of a vehicle or in direct
sunlight or with a high interior temperature
as overheating can result in burns if touched
leaking, re or explosion
• Do not re the ash with the ash head (light-
emitting unit) in contact with a human body or
any object doing so may result in the risk of
burns and re
• Do not re the ash near the eyes. Keep the
ash unit at least 1m (3.3 feet) away from
face. It may hurt or damage the eyes. Using
bounce ash to reduce light intensity is also
recommended

GB
GB
8 Modus 600RT - English Modus 600RT - English 9
Nomenclature - Body
Nomenclature - Control Panel
Nomenclature - LCD Panel
01
04
02
05
03
06
08
09
07
10
12
11
01. Catchlight Panel
02. Built-in Wide Panel
03. Flash Head
04. Optical Control Sensor
05. Focus Assist Beam
06. Slave Flash Ready Indicators
13. Function Button 2
14. Function Button 1
15. < > Mode Selection
Button / Lock button
16. < > Test Button / Flash
Ready Indicator
17. <SET> Set Button
07. Sync Cord Jack
08. USB Port
09. Hotshoe
10. Dot-matrix LCD Panel
11. Battery Compartment
12. Lock Wheel
01.ETTL: E-TTL II autoash
02. : Automatic
: Manual
03.Zoom: zoom display
04.Focus Distance
05. : High-speed sync
: Second curtain sync
06. Battery level indicator
07. : Flash exposure
compensation
08.Flash exposure
compensation amount
09. : Flash exposure
bracketing
10.Flash exposure
bracketing counter
11.Aperture
12.Distance indicator scale
13.Effective ash range
14. Beep on/off (C. Fn 7)
18. Function Button 3
19. Function Button 4
20. < > Wireless Mode/
Master/Slave
21. ON/OFF Power Switch
22. Select Dial
17
13 18
14
19
15
21
20
16
22
01 02 03 04 05 06
08 11
14
12
13
09
10
07
(1)E-TTLAutoash
• The display will only show the settings currently applied.
• The functions displayed above function buttons 1 to 4, such
as and change according to settings’ status.
• When a button or dial is operated, the LCD panel
illuminated.
Nomenclature

GB
GB
10 Modus 600RT - English Modus 600RT - English 11
(2) Manual Flash
(3) Multi Flash LCD Panel in Five Modes
(4) Radio Control Shooting/Optical
Control Shooting
(a) Master Unit - Flash Mode
M : Manual ash Manual ash output power
Flash power Number of ashes
O1: Standard Optical. 02: Preash Optical
MULTI : Stroboscopic ash Flash frequency
(1) Attached to the Camera
(2) 2.4GHz Radio Control: As a Master Unit
(3) 2.4GHz Radio Control: As a Slave Unit Group A
15
19
20
16 17 18
15. : Radio control
wireless shooting
: Optical control
wireless shooting
16. Flash mode : ETTL/M/
MULTI/Gr Group (Group
ash radio control)
17. : Master
18. RATIO : Flash ratio
19. :Master unit ash ON
:Master unit ash OFF
:Master unit bounce ON
20. Firing group
21. Ratio scale
Channel no. Optical only Slave mode Group A/B/C...
(b) Slave Unit
21

GB
GB
12 Modus 600RT - English Modus 600RT - English 13
(4) Optical Control: As a Master Unit
(5) Optical Control: As a Slave Unit
08
06
05
04
A B C
07
09
01
03
02
(A) Group A
(B) Group B
(C) Group C
(1) ON/OFF - switch
(2) SEL - select button
(3) Adjust Dial - To adjust
settings
(4) Lock Wheel
(5) LCD Screen
(6) Power / Status LED
(7) Hot shoe
(8) Test - button
(9) Micro USB - rmware
update
Nomenclature - Viper TTL
Transmitter
Transmitter LCD Screen
Multi Mode
(10) Manual / TTL / OFF Mode
(11) Flash exposure
compensation amount
(12) Manual ash output
(13) High-speed sync
(14) Second curtain sync
(15) Always On
(16) Battery indicator
(17) Number of ashes
(18) Flash frequency
(19) Flash output power
16
15
13
14
1211
10
191817
B CA
• The Viper transmitter is included in the “Modus 600RT
Wireless Kit” & “Modus 600RT Wireless Pro Kit” and sold
separately

GB
GB
14 Modus 600RT - English Modus 600RT - English 15
Getting Started
2
What’s in the Modus 600RT?
1. Modus 600RT
Speedlight
2. Li-ion Battery Pack
3. Battery Charger
4. Charger Power Cable
5. Mini Stand
6. Protection Case
7. Instruction Manual
What’s in the Modus 600RT
Wireless Kit?
1. Modus 600RT
Speedlight
2. Viper TTL Transmitter
3. Li-ion Battery Pack
4. Battery Charger
5. Charger Power Cable
6. Mini Stand
7. Protection Case
8. Instruction Manual
9. 2 x AA Batteries
What’s in the Modus 600RT
Pro Kit?
1. 2 x Modus 600RT
Speedlight
2. Viper TTL Transmitter
3. 2 x Extreme Li-ion
Battery Pack
4. Battery Charger
5. Charger Power Cable
6. 2 x Mini Stand
7. 2 x Protection Case
8. Instruction Manual
9. 2 x AA Batteries
Battery and Charger
• The Modus 600RT uses a lithium ion battery HLX-MD1
and it must be charged before use
• Use only the MD1 charger to charge the battery
• Remove battery from charger when charging is nished
and disconnect charger from mains
A fully charged battery will offer approx 500 ashes at full
power and even more when power level is reduced. The
composition and construction of the MD1 battery pack
offers very reliable and fast refresh time for the speedlight.
How to store the battery
When not in use remove battery from the charger or
the speedlight and store battery in a cool and dry place.
Exposing the battery to higher temperature can shorten
the lifetime of the battery. Store the battery almost empty
(one bar in the battery level indicator) when not used for
a long period of time. For optimum battery life use battery
regularly and if not used for more than 6 months charge
the battery fully and use it with the Modus 600RT until the
battery level is down to 1 bar again before storage.
Battery Lifetime
The lifetime of a recharable battery is limited. The capacity
will drop progressively with use and age of battery
pack. Replace the battery pack when the ash cycle
time becomes longer or the number of ashes reduces
noticeably. The battery lifetime can vary substantially
depending on storage, operation conditions and exposure
to unsuitable enviormental conditions
Caution
• Do not short circuit the battery
• Do not drop battery into water or re
• Do not drop or dismantle or subject the batteries to
strong impact or continuous mechanical shock
• Stop using the battery if the battery has any signs of
damage or bulging to housing and dispose of battery in
accordance with the appropriate local regulations
How to charge the battery
The HLX-MD1 battery must be charged before use. Use
only the supplied MD1 charger to charge the battery.
Connect the MD1 charger to the mains with the supplied
mains cable and the power LED will light up red if
connected correctly. To start the charge insert the HLX-
MD1 battery into the MD1 charger and the green LED
bars will start to illuminate, indicating that the battery is
charging. 4 green LED’s on indicates full charge. Remove
the battery from charger when fully charged.

GB
GB
16 Modus 600RT - English Modus 600RT - English 17
Fitting and Removing the Battery
1. To t the battery,
push the battery
compartment cover
downward and open it.
2. According to the
triangle sign on the
battery pack, insert it
into the compartment
until a white clip locks
the battery with a click
sound.
3. To remove the battery,
tap the white clip and
the battery pack will
pop out. Then close the
compartment.
Battery Level Indication
Make sure the battery pack is securely tted in the ash.
Check the battery level indication on the LCD panel to see
the remaining battery level.
Low Battery Warning
Battery Level
Indication
Meaning
3 bars
2 bars
1 bar
No bars
Blinking
Full
Middle
Low
Lower battery, please recharge it
The battery level is going to be
used out immediately.
Note: Please recharge the battery
as soon as possible (within 10
days). Then, the battery can be
used or stored as detailed in the
“How to store the battery” section.
Attaching to Camera
1. Attach the Speedlight
to the camera.
Slip the ash’s
mounting foot into the
camera’s hotshoe all
the way.
2. Secure the Speedlight
Rotate the lock ring on
the mounting foot until it
locks in position
3. Detach the Speedlight
Rotate the lock ring on
the mounting foot until it
is loosened. Then slide
the speedlight off the
camera hotshoe
Power Management
Use ON/OFF Power Switch to power the ash unit on or
off. Turn off if it will not be used for an extended period of
time. Setting as a master ash, it will turn the power off
automatically after a certain period (approx. 90 seconds)
of idle use. Pressing the camera shutter halfway or
pressing any ash button will wake up the ash unit.
Setting as a slave ash, it will enter sleep mode after a
certain period (adjustable, 60 minutes by default) of idle
use. Pressing any ash button will wake it up.
Disabling Auto Power Off function is recommended
when the ash is used off camera. (C.Fn-APO)
Slave Auto Power Off Timer is set to 60 minutes by
default. Another option “30 minutes” is available. (C.Fn-
Sv APOT, Page 46)

GB
GB
18 Modus 600RT - English Modus 600RT - English 19
FlashMode-E-TTLAutoash
This ash has three ash modes: E-TTL, Manual (M),
and MULTI (Stroboscopic). In E-TTL mode, the camera
and the ash will work together to calculate the correct
exposure for the subject and the background. In this
mode, multiple TTL functions are available: FEC, FEB,
FEL, HSS, second curtain sync, modeling ash. These
can be controlled with the Modus 600RT or with the
camera’s menu screen.
* Press < MODE > Mode Selection Button and three ash modes
will display on the LCD panel one by one with each pressing.
ETTL Mode
Press < MODE > Mode Selection Button to enter E-TTL
mode. The LCD panel will display E-TTL.
• Press the camera release button halfway to focus. The
aperture and effective ash range will be displayed in
the LCD panel.
• When the shutter button is fully pressed, the ash will
re a preash which the camera will use to calculate the
correct ash output power the instant before the photo
is taken.
FEC: Flash Exposure Compensation
With FEC function, you can adjust the calculated level
from -3 to +3 in 1/3 stops. It is useful in situations where
minor adjusting of the TTL system is needed based on the
lighting environment.
SET
SET
Setting FEC:
1. Press Function Button
2< >. The
icon < > and ash
exposure compensation
amount will be
highlighted on the LCD
panel.
2. Set the ash exposure
compensation amount.
• Turn the Select Dial to
set the amount.
• “0.3”means 1/3 step,
“0.7”means 2/3 step.
• To cancel the
ash exposure
compensation, set the
amount to “+0”.
3. Press < SET > button
again to conrm the
setting.
FEB: Flash Exposure Bracketing
You can take three shots while automatically changing the
ash output for each shot. The camera will record three
images with different exposures: one exposed according
to camera calculations, one over-exposed and another
under exposed. Over and under exposure amount is user
adjustable from -3 to +3. This function helps get correct
exposure especially in shooting moving objects or when
environmental lights are complex.
1. Press function button 3
<>. The icon <
> and the exposure
bracketing amount will
be highlighted on the
LCD panel
2. Set the ash exposure
compensation amount.
• Turn the Select Dial to
set the amount.
• “0.3”means 1/3 step,
“0.7”means 2/3 step.
3. Press < SET > button
again to conrm the
setting. Then your FEC
and FEB settings are
displayed on the LCD
panel.

GB
GB
20 Modus 600RT - English Modus 600RT - English 21
• FEB will be cancelled after three photos are taken. For
best results, set the camera drive mode to “single” and
ensure the ash is ready before shooting.
• FEB can be used with FEC and FEL.
You can prevent the FEB from being cancelled
automatically after three photos are taken. (C.Fn-FEB
ACL, Page 46)
The FEB shooting sequence can be changed. (C.Fn-
FEB, Page 46)
FEL: Flash Exposure Lock
FEL can lock the correct ash exposure setting for any
part of the scene. With <ETTL> displayed on the LCD
panel, press the camera’s <FEL> button. Check your
camera manual for details of how to activate <FEL> on
your camera.
Second-Curtain Sync
With a slow shutter speed, you can create a light train
following the subject. The ash res right before the
shutter closes.
High-Speed Sync
High Speed Sync (FP ash) enables the ash to
synchronize with all camera shutter speeds. This is
convenient when you want to use aperture priority for
ll-ash portraits.
1. Focus the subject.
2. Press the <FEL> button
• Aim the centre of the
view nder at the
required part of the
scene and press <FEL>
button
• The speedlight will
re a preash and the
required ash output for
the subject is retained in
memory
• Each time the <FEL>
button is pressed, a
preash will be red and
a new ash exposure
setting will be locked
2. Check that < >
is displayed in the
viewnder
1. Press Function Button
4< > so that <
> is displayed
1. Press function button
4 <> button so that
< > is displayed on
the LCD panel.
2. To return to normal
ash press the function
button 4 < > button.
• If the subject is too far away and underexposure, the < >
icon will blink in the viewnder. Move closer to the subject
and try the FE lock again.
• If <ETTL> is not displayed on the LCD panel, FE lock
cannot be set.
• If the subject is too small, FE lock might not be very
effective.
• If you set a shutter speed that is the same as or slower
than the camera’s maximum ash sync speed, < > will
not be displayed in the viewnder
• With high-speed sync, the faster the shutter speed, the
shorter the effective ash range
• To return to normal ash, press <>button twice
• Multi ash mode cannot be set in high-speed sync mode
• Over-temperature protection may be activated after 15
consecutive high-speed sync ashes

GB
GB
22 Modus 600RT - English Modus 600RT - English 23
SET
SET
1. Press < MODE >
button so that <M>is
displayed
2. Turn the Select Dial to
choose a desired ash
output amount
3. Press < SET > button
again to conrm the
setting
1. Press <MODE> button
so that < MULTI > is
displayed
2. Turn the Select Dial
to choose a desired ash
output power
3. Set the ash frequency
and number of ashes
• Press < TIMES >
button
• Turn the Select Dial
to set the number of
ashes
• Press the < HZ>
• Turn the Select Dial to
choose a desired ash
ring frequency
• After you nish
the setting, press
<SET> button and
all the settings will be
displayed.
Flash Mode - Manual Flash
The ash output is adjustable from 1/1 full power to
1/128th power in 1/3rd stop increments. To obtain a
correct ash exposure, use a hand-held ash meter to
determine the required ash output.
Flash Output Power Range
The following table makes it easier to see how the stop
changes in terms of f/stop when you increase or decrease
the ash output.
For example, when you decrease the ash output: 1/2,
1/2-0.3, or 1/2-0.7, or increase the ash output:1/2,
1/2+0.3, 1/2+0.7, 1/1.
Figures displayed when reducing ash output level→
1/1 1/2 1/4
1/1-0.3 1/2-0.3 ------1/1-0.7 1/2-0.7
1/2+0.7 1/4+0.7 ------1/2+0.3 1/4+0.3
←Figures displayed when increasing ash output level
Optical O1 Secondary Unit Setting
In M manual ash mode, press <O1/O2> button so that
this ash can function as an optical O1 secondary ash
using its optical sensor. With this function, the ash will
re synchronously when a second main ash res. This is
the same effect as usng a radio trigger to re the ash off
camera. This helps create multiple lighting effects.
Optical O2 Secondary Unit Setting
In M manual ash mode, press <O1/O2> button so that
this ash can function as an optical O2 secondary ash
using its optical sensor. With this function, the ash will
re synchronously when a second main ash res as in
O1 but it will ignore the metering pre-ash and re only in
response to the exposure ash from the main unit.
• O1 and O2 optic triggering is only available in Mmanual
ash mode.
Flash Mode: Multi (Stroboscopic
Flash)
With stroboscopic ash, a rapid series of ashes is red.
It can be used to capture multiple images of a moving
subject in a single photograph.
You can set the ring frequency (number of ashes per
sec.expressed as Hz), the number of ashes, and the
ash output power.
Calculating the Shutter Speed
During stroboscopic ash, the shutter remains open until
the ring stops. Use the formula below to calculate the
shutter speed and set it on the camera.

GB
GB
24 Modus 600RT - English Modus 600RT - English 25
Number of Flashes / Flash Frequency
= Shutter Speed
For example, if the number of ashes is 10 and the ring
frequency is 5 Hz, the shutter speed should be at least 2
seconds.
• To avoid overheating and deteriorating the ash head,
do not use stroboscopic ash more than 10 times in
succession
• After 10 times, allow the speedlight to rest for at least 15
minutes. If you try to use the stroboscopic ash more than
10 times in succession, the ring might stop automatically
to protect the ash head. If this happens, allow at least 15
minutes’ rest for the speedlight
• Stroboscopic ash is most effective with a highly reective
subject against a dark background
• Using a tripod and a remote control is recommended.
• A ash output of 1/1 and 1/2 cannot be set for stroboscopic
ash
• Stroboscopic ash can be used with“buLb”
• If the number of ashes is displayed as “--”, the ring
will continue until the shutter closes or the battery is
exhausted. The number of ashes will be limited as shown
by the following table.
Maximum Stroboscopic Flashes:
If the number of ashes is displayed as “--”, the maximum number of
ashes will be as shown in the following table regardless of the ash
frequency.
Wireless Flash
Photography:
(2.4GHz) Control
3
Master/Slavewirelessashlighting
• When the camera’s shooting mode is set to a fully
automatic mode or an Image Zone mode, the operations
in this chapter are not available. Set the camera’s shooting
mode to P/Tv/Av/M/B (Creative Zone Mode).
• The “Modus 600RT” attached to the Camera Hot shoe is
called the “Master” unit. A second “Modus 600RT” which is
wirelessly controlled is called the “Slave” unit
• You can also wirelessly control the Modus 600RT as a
“Slave” unit using a “Viper TTL” transmitter as a “Master”
unit attached to the camera hotshoe
Using (Master/Slave) with wireless 2.4GHz control
function allows you to easily perform shooting with
advanced wireless multiple ash lighting in the same
way as E-TTL II autoash photography. The system is
designed so that the setting’s of the “Master” attached to
the camera are automatically applied to the wireless slave
speedlights. Therefore you do not need to operate or
adjust the slaves during shooting
Positioning and Operation Range (Example of
wirelessashshooting)
•Master/Slavewirelessashlighting
MASTER
SLAVE
2.4GHz
wireless
control
with up to
100m range
• The “Master” attached to the camera can be a “Modus
600RT” or “Viper TTL transmitter”
• Use the supplied mini stand to hold the Slave unit in
upright position
• Before shooting perform a test falsh and test shooting
• The transmission distance may vary depending on the
position of the slave speedlight, enviorment and weather
conditions

GB
GB
26 Modus 600RT - English Modus 600RT - English 27
Wirelessmultipleashshooting
You can divide the slave units into two or three groups and
perform E-TTL II autoash while changing the ash ratio
(factor). In addition, you can set and shoot with a different
ash mode for each ring group, for up to 5 groups.
• Auto Shooting with Two Slave Groups
MASTER
SLAVE
GROUP A
SLAVE
GROUP B
●AutoShootingwithThreeSlaveGroups
B
A
C
●ShootingwithaDifferentFlashModesetforEach
Group
CEILING
Auto external
flash metering
E
A
B
C
D
E-TTL II
Manual
Flash
Manual
Flash
Manual
Flash
* The ash mode settings are indicated only as an
example
Wireless shooting using radio transmission has
advantages over wireless shooting using optical control,
such as being less affected by obstacles, and not having
to point the slave unit’s wireless sensor
toward the master unit. The main functional differences
are as follows:
Radio Control Optical Control
• There are four ash modes in wireless radio control: TTL,
M, Multi and Gr. Choose one of these modes by pressing
the MODE Button.
Wireless Settings
You can switch between normal ash and wireless ash.
For normal ash shooting, be sure to set the wireless
setting to OFF
Master Unit Setting
Slave Unit Setting
Master Unit Flash ON/OFF
You can switch ON or OFF the “Master” unit ash that is
controlling the wireless “Slave” units. When Master ash is
ON, it will ash as group A
Press < > button
so that < > and <
MASTER > are displayed
on the LCD panel.
Press < > button
so that < > and <
SLAVE > are displayed
on the LCD panel
1. Press Function Button
4so that < MENU2 >
is displayed on the LCD
panel

GB
GB
28 Modus 600RT - English Modus 600RT - English 29
OK
• 2. Press Function
Button
• < / > to control
the ON/OFF of the
master unit.
• < > The master unit
ash ring is ON.
• < > The master unit
ash ring is OFF.
1. If you have a Viper TTL,
start the DCM matching
with the Viper TTL
• Turn < ON > the Viper
TTL transmitter whilst
holidng down the < test
> button and release
<test> button after 2
seconds
• The Viper LCD will
show < Co di ng>
2. If you are not using a
Viper TTL and only wish
to DCM several Modus
600RT, then use any
Modus 600RT as the
Master unit
• Press <Function
Button 1> whilst turning
< ON > the power to the
Modus 600RT
• A green LCD on the
Modus 600RT will show
< MASTER >
3. Press <Function
Button 2> whilst turing <
ON > power to the slave
Modus 600RT
4. A red LCD will show
“Slave OK”. This slave
Modus 600 RT is now
DCM matched
5. DCM match the same
way, any additional slave
Modus 600RT while the
Master is still on
• To reset the Modus
600RT to factory default
settings press function
buttons 3 & 4 at the
same time and hold
until the LCD shows <
RESET > release the
buttons
• When the Modus
600RT is reset the DCM
is also reset back to
open channel and the
previous DCM is lost
1. Master Unit Setting
• Attach a Modus 600RT
to the camera and set
it as the master unit
(Page 27)
• The Viper TTL
Transmitter can also be
used as a master unit
to control the wireless
slave Modus 600RT
(Page 42)
Setting the DCM
(Digital Channel Matching)
Initialy the Modus 600RT wireless 2.4GHz is set to a
general “open channel” and can be used as it is. To
avoid interference with other wireless ash systems we
recommend to DCM (digital channel match) your Modus
600RT speedlight’s and Viper TTL.
Master – Viper TTL or Modus 600RT
ETTL Fully Automatic Wireless
Flash Shooting
Basic Automatic Wireless Flash shooting
with a Single Slave Unit
Slave - Modus 600RT
Once all slave units are DCM matched, reboot all master and
slave’s by turning OFF/ON
• Once all devices are DCM matched they will memorieze
the unique ID even it power is removed. Therfore you only
need to DCM your set once
• If you add more speedlights or Viper TTL units to your
range then you need to carry out the DCM matching for all
your units again
Modus 600 RT - Reset

GB
GB
30 Modus 600RT - English Modus 600RT - English 31
2. Slave Unit setting
• Set the slave Modus
600RT to < SLAVE >
setting (Page 27)
3. Position of camera
and speedlight
• Position the camera
with the master unit
attached and the Modus
slave within radio range
4. Set the master unit
ashmodeto<ETTL>
• Check that the master
unit is set to <ETTL>. If
not press < MODE >
button until <ETTL> is
displayed
• Check that the slave
unit is set automatically
to <ETTL> by the
master unit
5 Check Master/Slave
units are ready
• Check master
speedlight, ready
indicator is lighting and
that the slave ash
ready indicators are
blinking
6 Check the Master
slave speedlight
operation
• Press the master unit’s
< > test button
• The slave speedlight
will ash. If it does not
re, check the position
or distance of slave
from master
• You are now ready to
take a photo with the
wireless ash lighting
Using Automatic Wireless Flash
with Multiple Slave Units
When stronger ash output or more convenient lighting
operation is needed, increase the number of slave
speedlight’s. To add slave units, use the same steps as
setting“automaticwirelessashwithasingleslave
unit” (Page 23). Any slave speeedlight can be set as
group (A/B/C).
When the number of slave units is increased or the
master ash ring is set to ON, automatic control is
performed to re all ashes at the correct ash output to
ensure that the total ash output results in the standard
exposure.
• If the slave unit’s auto power off takes effect, press the
master unit’s test ash button to turn on the slave unit.
Note that the test ash cannot be performed while the
camera’s metering timer, etc. is operating
• The slave units auto power off setting can be changed
(C.Fn-Sv / APOT page 46)
• In the C.Fn settings you can enable a beeper to sound
when a Modus 600RT is recharged and ready to re again
Advanced setting with fully automatic
wirelessash
With the wireless system the following functions set on
the master unit will automatically be adjusted on the slave
unit. For this reason you do not need to operate the slave
unit (s) and can operate it from the master in the same
way as normal ash photography.
• Flash Exposure Compensation < > (Page 18)
• Flash Exposure Bracketing < FEB > (Page 18)
• Flash Exposure Lock (Page 20)
• High-Speed Sync < > (Page 20)
• Manual Flash (Page 22)
• Multi / Stroboscopic Flash (Page 23)
• Second Curtain Sync - is only enabled when using the
Viper TTL Transmitter

GB
GB
32 Modus 600RT - English Modus 600RT - English 33
Multiple Master Unit
You can use two or more cameras with master ash
units on each to change camera shooting while keeping
the same lighting setup (slave units) in wirelesss ash
photography.
• All Master / Slave devices must be reset to open channel
ETTL: Shooting Flash Ratio A:B
You can divide slave groups into two A and B groups and
adjust ash ratio. The total output of A and B will be auto-
matically contolled to a standard exposure.
MASTER
SLAVE
GROUP A
SLAVE
GROUP B
ETTL: Shooting Flash Ratio A:B C
AB
C
1. Setting the slave group <C>
• Use the same method of step 1 (Page 32) to set a slave
unit to ash group <C>
2 Setting <RATIO A:B C>
• Use the same method of step 2 and step 3 (Page 32) to
set the master unit as <RATIO A:B C>
3Settingashexposurecompensationforgroup<C>
• Press Function Button 3 < Gr > to select A: B
or C then use the select dial to set the amount of ash
ratio for groups Aand B, and the amount of ash
exposure compensation for group C
• You can add a group C to ring groups A and B. C can
have separate FEC setting which is usefull to eliminate
subject shadows or other effect’s.
SET
1. Settingtheash
groups of slave unit
• Set the ash as slave
unit
• Press Function Button
3< Gr > and
choose <A> or <B>
• Set one slave unit as
<A>, the other as <B>
2. Setting < MENU >
• Step 2 to Step 4 are set
on the master unit.
• Press the Function
Button 4 < MENU 1
> on the master unit
so that < MENU 2 > is
displayed
3. Setting <RATIO A:B>
• Press Function Button
2< RATIO > so that
<RATIO A:B> is
displayed
4. Settingashratio
• Press Function Button
3< Gr >
• Turn the Select Dial to
set the amount of ash
ratio and press <SET>
button to conrm
5. Taking the picture
• The slave units will ash
according to the ash
ratio

GB
GB
34 Modus 600RT - English Modus 600RT - English 35
ID=A ID=A ID=A
If three slave units are all set to <A> in terms of
slave ID, these slave units will be controlled as if
they were one camera ash in slave group A.
Slave Group A
• When setting < RATIO A:B C >, group A, B and C will re a
ash synchronously; when setting< RATIO A:B >, group C
will not re a ash
• If shooting under the situation that group C is toward the
main shooting subject, over exposure might occur
• In some EOS lm cameras that support E-TTL autoash,
you cannot perform multiple ash wireless shooting with a
ash ratio setting
• The ash ratio of 8:1 to 1:1 to 1:8 is equivalent to 3:1 to 1:1
to 1:3 (1/2 step increment).
• The details of the ash ratio settings are as follows.
M: Wireless Flash Shooting with
Manual Flash
This describes wireless using manual ash. You can shoot
with a different ash output setting for each slave unit
(ring group). Set all parameters on the master unit.
1Settingtheashmode
• Press <MODE> button
until <M> is displayed
• Set the manual ash
output (Page 22)
2 Setting the number of
ashgroups
• Press the Function
Button 2 < RATIO > to
set the groups to re
• The setting changes as
follows each time you
press the < RATIO >
button:
ALL(RATIO OFF)→
A/B(RATIO A:B)→
A/B/C(RATIO A:B:C)
3Settingashoutput
Press Function Button
3< Gr > to select the
group. Turn the Select
Dial to set the ash output
of the groups. Press
<SET> button to conrm
4 Taking the picture
Each group res at the set
ash ratio
Setting <MULTI>
stroboscopicash.
• Press <MODE> button
on the master unit
so that <MULTI> is
displayed
• Setting the stroboscopic
ash parameters as
detailed on page 23
• All ash groups have
the same number
of ashes and ring
frequency
• You can use the <
TIMES > and < Hz >
buttons as described
earlier to set the power
level for each group in <
MULTI > mode
• To re multiple slave units with the same ash output,
select ALL < ALL > in step 2.
Multi: Wireless Flash Shooting
with Multi Flash
Gr: Shooting with a different
Flash Mode for each group
When using an EOS digital camera released since 2012,
such as the EOS-1DX (except for EOS 1200D), you can
shoot with a different ash mode set for each ring group,
with up to 5 groups (A/B/C/D/E).
The ash modes that can be set are E-TTL II autoash
/ Manualash / off. When the ash mode is E-TTL
exposure is controlled to result in standard exposure
for the main subject as a single group. This function is
for advanced users who are very knowledgeable and
experienced in lighting.

GB
GB
36 Modus 600RT - English Modus 600RT - English 37
SET
SET
1.Settheashmode
to <Gr>
• Press the <MODE>
Button and set the
ash mode to < Gr >
2.Settheringgroupof
the slave units
• Operate and set the
slave units one by one
• Press Function Button
3< Gr > to assign
the ash to group <A>,
<B>, <C>,<D> or <E>
• Set the ring group
(A/B/C/D/E) for all the
slave units
3.Settheashmode
• Set the ash mode of
each ring group by
operating the master
unit
• While < MENU1 >
is displayed, press
Function Button 3 <
Gr > and turn the
Select Dial to choose
the group
• Press Function Button
2< MODE > and
select the ash mode of
the selected group from
<ETTL>, <M> and <---(
OFF )>
• Use Function Button
4 to return to previous
menu
• Repeat step 3 to set the
ash mode of all groups
4.Settheashoutput
andashexposure
compensation amount.
• While a ring group
is selected, press
Function Button 3 <
>
• Turn the Select Dial to
set the ash function
corresponding to
ash mode, and press
<SET> Button to
conrm
• When using the <M>
mode, set the ash
output power
• When using the
<ETTL> mode, set
the ash exposure
compensation amount
as required
• Repeat step 4 to set
the ash function of all
groups
• Press Function Button
4to return to the
shooting-ready state
5. Take the picture
• Each slave unit res
in the respective ash
modes set.
A
B
A
E
C
D
MASTER
SLAVE
SLAVE
SLAVE
SLAVE
SLAVE

GB
GB
38 Modus 600RT - English Modus 600RT - English 39
Wireless Flash
Photography:
Optical Transmission
4
Thisproductsupportsopticalcontrolwirelessash
applications and functions as either a master or a
slave unit. As a master unit, it can control Canon
speedlites e.g. 580EXII, 600EX-RT optically. As a
slave unit, it can receive optical signals from Canon
speedlites e.g. 580EXII, 600EX-RT and from Canon
camerasbuiltinashesinwirelessmodee.g.
7D/60D/600D.
• You can set up one, two or three slave groups for E-TTL
II autoash shooting. With E-TTL II autoash, you can
easily create various lighting effects.
• Any ash settings (of ash exposure compensation,
high-speed sync, FE lock, FEB, manual ash, Multi
ash) on the master unit will be automatically sent to the
slave units. So the only thing you need to do is to set
the master unit to ETTL mode without any operation for
the slave units at all during the shooting.
• This ash can work in ETTL autoash, M manual ash,
and Multi stroboscopic ash modes when set as a
master unit.
Positioning and Operation Range
Indoors
Outdoors
15m(49.2ft)
10m(32.8ft)
80°
8m(26.2ft)12m(39.4ft)
MASTER
SLAVE
• Even with multiple slave units, the master unit can control
all of them via wireless.
• In this user manual, “master unit” refers to the speedlight
attached to the camera and “slave unit” will be controlled
by the master unit.
Wireless Settings
You can switch between normal ash and wireless ash.
For normal ash shooting, be sure to set the wireless
setting to OFF
Master Unit Flash ON/OFF
You can switch ON or OFF the “Master” unit ash that is
controlling the wireless “Slave” units. When Master ash is
ON, it will ash as group A.
For more detailed information on this feature see
description under 2.4GHz Radio control (Page 27 )
• Even if the master unit ash ring is disabled, it still res a
preash to transmit wireless signals
Setting the optical Communication Channel
The Modus 600RT has four optical communication
channels. The master and the speedlights must be set to
the same channel.
Master
• Press function button 4 until < MENU3 > is displayed
• Press function button 1 < CH > and use the
select dial to set the required channel
• Press set to lock selection
• Press function button 4 to return to < MENU1 >
Slave
• Press function button 4 < CH > and use the
select dial to set the required channel
• The channel must be set the same as the master
speedlight
Master Unit Setting
Press < > button
so that < > and <
MASTER > are displayed
on the LCD panel.
Press < > button
so that < > and <
SLAVE > are displayed
on the LCD panel.
Slave Unit Setting
