Haier HRD-2423CIS-E User manual

THE FUTURE IS FRESH
USER GUIDE FOR DIRECT COOL
REFRIGERATOR
AND
E-WASTE GUIDELINE MANUAL
Haier Customer Care Toll Free (24x7)-1800-102-9999, 1800-419-9999
Website: www.haier.com/in www.facebook.com/haierindia
*Source Euromonitor International Limited; retail volume sales in units based on 2017 data.
Live Smart. Live Green. SMARTER LIFE BETTER PLANET
ECO LIFE
Major Appliances
*
World’s
....With Haier Refrigerators

Dear Friend,
At the outset, we at Haier thank you for your interest in our range of products.
A unique and international range of appliances designed solely with the
purpose of making modern life simpler. And how! The entire Haier range of
appliances ranging from Refrigerators, Televisions, Washing machines, Air-
conditioners, Microwave ovens, Dishwashers, Wine Coolers, Freezers,
Visicoolers, and Chocolate Coolers combines the best of technology,
features, performance and styling. Altogether, it is a result of our perfect
understanding of your lifestyle and needs.
But what is a great product without great service? Leaving no stone unturned
in giving you the best of service, we have also established an extensive
network of authorised dealers and authorised service centers, so that you get a
lifetime of great and timely service for your Haier Appliance.
It has been an honor and a pleasure bringing these hi-tech products to you and
we hope that you get as much happiness using them as we have got putting
them together for you.
Happy Inspired Living!
Thanking you

CONTENTS
1. KNOW YOUR REFRIGERATOR..........................................................................1
2. SAFETY SIGN & PRECAUTION .........................................................................3
3. PRODUCT INSTALLATION GUIDELINES.........................................................4
4. TEMPERATURE SETTING GUIDE......................................................................5
5. DEFROSTING.........................................................................................................5
6. FOOD STORAGE GUIDELINES...........................................................................5
7. CLEANING .............................................................................................................6
8. GENERAL SUGGESTIONS ..................................................................................7
9. FACTS......................................................................................................................7
10. TROUBLE SHOOTING BY YOURSELF .............................................................8
11. E-WASTE GUIDELINE MANUAL.......................................................................9
12. WARRANTY CARD

1. KNOW YOUR REFRIGERATOR
Refrigerator capacity Series :170L,181L,190L
Refrigerator E-commerce capacity Series :168L,179L,188L
Refrigerator capacity Series :195L,220L
Refrigerator E-commerce capacity Series :193L,218L
Freezer Box
Chiller Tray
Cabinet
Shelves
Fruit Box
Vegetable
Box
Base Stand
Temperature Control Knob
Door Rack
Top
Utility Rack
Half Rack
Lock
Door Rack
Big
Door Rack
Bottom
Cool Pack
Table Top
VC Fresh
Due to continuos improvements in our Products, specifications shown here are
subject to change without prior notice.
* Available in selected models only.
Drain Funnel
Freezer Box
Chiller Tray
Cabinet
Shelves
Veg. Box
Cover
Vegetable
Box
Adjustable Leg
Temperature Control Knob
Door Rack
Top Small
Lock
Sliding Tray
Door Rack
Middle Big
VC Fresh
Door Rack
Bottom Big
Drain Funnel
1

1. KNOW YOUR REFRIGERATOR
Refrigerator capacity Series :171L,182L,192L
Due to continuos improvements in our Products, specifications shown here are
subject to change without prior notice.
* Available in selected models only.
2
Freezer Box
Chiller Tray
Cabinet
Shelves
Veg. Box
Cover
Vegetable
Box
Adjustable Leg
Temperature Control Knob
Door Rack
Top Small
Lock
Door Rack
Middle Big
Door Rack
Bottom Big
Drain Funnel

Instructions with this sign is prohibited, it may cause damage to the
product or personal safety of the user.
Prohibition
Instructions with this sign is related to safe use of the product and
personal safety of the user. Operational rules should be strictly
followed, or it may cause damage to the product or to personal
safety of the user.
Warning
Attention
Instructions with this sign should be well attended by the user. Any
misuse or ignorance may hurt or seriously injure the user.
Note
Provides information that is not indispensable, but may be valuable
to the reader, such as tips and tricks.
2. SAFETY SIGN & PRECAUTIONS
Don't disconnect the power plug
by pulling cord, instead hold
on the plug firmly and pull
out from the socket. Don't
step on the power cord. Don't allow
power cord be pressed by heavy objects.
Don't touch the power cord with wet hands.
Don't use damaged
power cord or plug.
In case of gas leakage,
don't touch the power
outlet and ventilate the
room immediately.
Disconnect the power plug
before cleaning or repairing.
(repairing to be done by
authorized repair personnel
only)
The power cord is designed
with three wire plug to suit
three pin sockets only,
don’t discard the third wire plug to
insert in two pin sockets. Also make
sure of grounding, improper grounding
may cause breakdown or electric shock.
The fridge runs at 230V/50Hz.
Abnormal voltage
fluctuations may cause the
fridge unable to start or burning
of control panel, compressor or
abnormal noise from compressor, in such
case it is advisable to use voltage stabilizer.
Do not use or store
inflammable, explosives,
corrosive, alkali materials
near or in the fridge.
Do not use this fridge for
non-domestic purpose
medicines or chemicals.
Do not use combustible spray
near fridge to prevent fire.
Do not keep any other electric
appliances or heavy, unstable
objects or liquid containers
on top of the fridge.
Do not cling or hold on tightly to
the door or its shelves to avoid
any damage. Especially refrain
children from doing the same.
Do not touch freezer interior
and ice box with wet hands
to avoid frostbite.
3

Use handle to open and
close the door. Don't allow
children to play with
the door.
Do not place fridge in
wet or humid area where
water or rain drops can
splash on the fridge.
Disassembling, repairing or
any alterations to the fridge
should be done by
authorized repair
personnel only.
Do not put bottled liquid in the
freezer section, it may freeze the
contents and cause frost-cracking.
Close bottle caps tightly if storing
horizontally, to avoid leakage that
may cause ice formation/sweating
issues.
2. SAFETY SIGN & PRECAUTIONS
When you disconnect the power
cord for cleaning or
repairing purpose, reconnect
it after at least 5 minutes to avoid
compressor damage due to quick
transition between ON/OFF states.
Do not touch the compressor while
appliances is in operation.
You may get burn.
3. PRODUCT INSTALLATION GUIDELINES
1) Unpack your refrigerator in the presence of dealer or company personnel and check for
transit damage before installing the refrigerator. In case of damage, inform your dealer
immediately and don't install the unit.
2) If there is no transit damage, remove all the packing material and adhesive tapes from
exterior and interior of the refrigerator.
3) Read user guide manual carefully.
4) Choose appropriate location for your refrigerator that must be away from direct heat
sources and not in environment having temperature <10°C, maintain at least 20cm
distance from all the sides for well ventilation.
5) Level the refrigerator so that it rests firm on the floor, to do so, there are two adjustable
legs one at each front corner. Turn to the left to raise a corner and to the right to lower the
corner.
If you want refrigerator door to close when not held open, adjust front legs in such a way
that front refrigerator side is raised. If you want refrigerator door to remain motionless
when held open, adjust front legs in such a way that all four corners are leveled with each
other.
6) Gently wipe off interior and exterior of the refrigerator with soft cloth and mild detergent,
leave the doors open for a while to let it dry completely and to get rid of plastic smell,
however this smell will go away when refrigerator is cooled sufficiently.
7) Refrigerator could have been tilted during transport/handling, keep it standing for minimum
2 hours before switching it ON to ensure compressor gas stabilization.
8) Tear off transparent film cover from the refrigerator’s cabinet body and don't use any
external cover to protect the exterior of refrigerator, this is to ensure proper heat
dissipation for efficient cooling.
9) Switch ON refrigerator and let it cool sufficiently for 3-4 hours before loading food.
Install the fridge where the temperature is 10°C to 43°C. If your refrigerator is
installed in too low or high temperature, the internal cooling system may not work
properly.
4

MAKING ICE CUBES
1. Fill the ice cube tray with fresh water, being careful not to exceed the water level mark.
2. Place the filled ice cube trays in the freezer.
3. After ice has formed, slightly twist the tray with both hands
to release ice cubes.
4. For faster ice cube formation, use pre-cooled water or
leave behind a couple of ice cubes in the tray.
4. TEMPERATURE SETTING GUIDE
5. DEFROSTING
● Your refrigerator needs to be defrosted whenever excess ice forms around the
freezer or if the Defrost Indicator in the freezer gets covered by ice. For best results,
we recommend you defrost at least once in 3 days.
● To defrost, simply press the Defrost Button in the center of the Temperature Control
Knob. The ice will melt and the water will automatically evaporate from the
Evaporation Tray.
Temperature inside refrigerator can
be set by control knob.
Summer is for maximum cooling.
Winter is for minimum cooling.
OFF
1. Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
2. Don't use sharp objects like knife/scissor/blade/cutter etc to remove accumulated
ice from freezer, it can cause damage to the freezer.
Do not keep hot food in fridge,
bring it down to room
temperature before
storing it in. This will help to
reduce power consumption.
Food should be covered up with bags or
other type of containers,
this will help food to
retain its taste and
nutrients for longer
time. Prefer separate
bags / containers for different items.
Do not store food items very close to
each other, keep some
distance between them
for cool air circulation.
Wipe off excessive moisture
gathered on food or containers
or bags, this will lead to retain
food's freshness for longer time.
Try to reduce door opening frequency
and do not keep door open
for longer time.
Avoid placing high moisture contained
food items close to the
fridge walls, rather place
them near to the door to
avoid being frozen.
6. FOOD STORAGE GUIDELINES
Once you change temperature settings it needs some time to be stable, this time depends
on ambient temperature, door open frequency and temperature of food kept inside.
5

It is recommended to store root
vegetables (ex. Carrot,
Beetroot) without
their leaves to avoid
water dripping from
their leaves.
When keeping frozen food for thawing,
keep refrigerator
compartment
temperature lower to
save energy.
Food items such as onions, ginger, garlic
can remain fresh for
longer time even at room
temperature. No need
to refrigerate them.
Food items such as banana, pineapple,
papaya, and muskmelon
can turn bad easily if
stored at low temperature.
Avoid refrigerating them for
long time.
While storing large sized food
items, make smaller portions
to freeze it quickly.
Once frozen food is melted prefer
to cook them immediately to
ensure its quality. Do not
choose to freeze
them again.
Do not use covered glass containers for making or storing ice / ice creams.
6. FOOD STORAGE GUIDELINES
1. Disconnect the power cord.
2. In case you want to move the fridge for cleaning, know that it is heavy, make sure you
take necessary precautions to protect the floor when moving the fridge. Keep it up right
when moving.
3. Do not use hard brush or harsh cleanser or hot water or acid to clean the fridge. It is
recommended to use carbonated solution (4L water with a tablespoon of baking soda) to
clean exterior of fridge and use mild soap solution or mild detergent solution to clean
interior parts of the fridge.
4. To remove door utility racks while cleaning, hold it firmly from both the sides and
pull in upward direction. After cleaning place them in exact reverse manner.
5. Do not use extreme hot water to clean cold glass shelves to avoid great temperature
difference that may lead to glass burst.
6. Gaskets are easy to become dirty, clean it at least twice a year, wash it with mild
detergent solution using soft cloth.
7. Wipe interior and exterior parts with soft, clean, dry cloth.
8. Please clean the drain tray frequently as water & dust tend to accumulate in it, you can
use a dry piece of cloth to absorb accumulated water and avoid water spillage on the floor.
9. To avoid blockage in drain funnel with foreign particles, clean the funnel and chiller tray
regularly, don't use sharp objects to clean.
Food residue within the fridge will cause unpleasant odour,
to overcome this, regular cleaning is recommended.
For safety purpose, disconnect the power cord before cleaning.
7. CLEANING
6

8. GENERAL SUGGESTIONS
1. During power-off
Even during power off, food can remain well for several hours,
to ensure this try-
a) To keep door opening frequency as minimum as possible.
b) To put ice cubes container at the top side of refrigerator
compartment.
2. During disuse
If fridge is not in use for long time-
a) Disconnect the power cord.
b) Clean interior properly.
c) Keep each door open to avoid odour formation.
It is better to not opt for disusing the fridge to avoid shortening of its service life.
3. During Holidays
a) During moderate length holidays, leaving fridge in normal operation is preferable.
b) During long holiday period, it is recommended to take out all food items,
disconnect the power, clean interior properly and leave each door open to
prevent adour formation.
c) To operate again after holidays, keep fridge running for 3-4 hours before
storing food.
4. During Shifting
a) Disconnect the power supply.
b) Take out all the food items.
c) Fasten all shelves and boxes of both the compartments with the help of adhesive tape.
d) Fasten each door with the help of adhesive tape or lock the doors.
e) For safety reasons it is recommended that two people should
carry the fridge and inclination angle shouldn't be more than 45˚.
f) Do not move fridge by holding it’s handles.
Prohibited: Never keep the fridge flat parallel to the ground.
7
9. FACTS
During summer, increase in
power consumption is normal
due to increase in amount
of food storage, door
opening frequency and
ambient temperature.
Condensing pipe is situated at sides, back &
top of Refrigerator internally, it is used to
extract heat from the interior to outside air
due to which exterior surface may get hot
however it is totally normal condition & does
not affect performance of the product.
Water drops may appear
on the exterior of the
fridge when air humidity
is high specially in
monsoon season and
in coastal cities.
When compressor starts or shuts off, relay
may create some switching noise.
Also evaporator pipe may create noise during
temperature changes.

Problem
Description
Probable Root Cause
What you can do ?
Refrigerator does
not work
Power supply off
Check refrigerator's main supply plug is connected to
the socket and the switch is ON.
House fuse blown
Get this fixed with the help of an electrician.
Stabilizer does not work
Try connecting power plug directly to the wall socket, if
it works then get the stabilizer fixed by repairing center.
Refrigerator
attempts to start
but fails to
operate
Insufficient voltage supply
Install a voltage stabilizer in the mains with the help of
an electrician.
Low Cooling
Improper temperature setting
Set refrigerator temperature control knob to summer
mode
Hot food storage
Avoid storing hot food as it is, let them be at room
temperature before keeping them inside refrigerator.
Insufficient space for cool air
circulation
Maintain some distance between food containers, do not
cover refrigerator interior parts with cloth or plastic
sheets.
Door not closed properly
Make sure to close door properly after everytime you
open it
High door opening frequency
Reduce door opening frequency, as it allows ambient
hot air to get inside.
Refrigerator placed near to
heat source
Do not install refrigerator near to oven or room heater
or in contact with direct sunlight.
Lack of ventilation in area
surrounded by refrigerator
Maintain at least 20 cm distance from all sides of
refrigerator.
Over Cooling
Improper temperature setting
Set refrigerator temperature control knob to winter
mode
Noise
Refrigerator leveling not done
Adjust levels by rotating front two legs of refrigerator
Normal relay switch ON/OFF
noise
Whenever refrigerator starts or stops working, cut-in or
cut-off noise gets generated from relay located in
compressor. Generation of this noise is absolutely
normal condition.
Unnecessary objects could be
placed on or behind the
rerigerator
Check and remove unnecessary objects
Odour
Poorly wrapped food
Wrap food items properly, close box lids and bottle caps
tightly. Make sure utensils are covered with their lid.
Clean regularly
Formation of
water drops on
exterior of
refrigerator
High humidity in atmosphere
Specially during monsoon season atmospheric humidity
increases due to this there are chances of water drops
formation on exterior of refrigerator, make sure you
wipe off this moisture regularly to ensure products
performance.
Ice cubes have
odour / taste
Unsealed packages in the
freezer compartment may be
transmitting odour / taste to
the ice cubes or Interior
needs cleaning.
Ice tray and ice collecting box to be emptied and
washed,
clean interior frequently.
LED / Lamp not
working
LED / Lamp is out of order or
No power supply.
Call authorized service center for repair or replacement.
If problem persists, please contact your nearest authorized service
center for assistance.
10. BASIC TROUBLESHOOTING BY YOURSELF
8

11. E-WASTE GUIDELINE MANUAL
(Disposal of the product)
Do's :
• Give discarded electronic equipments only at authorized electronics waste collection
centers near you so that e-waste can be disposed or recycled in a proper way.
• Drop the discarded electronic equipments only in the bins meant for the electronic
waste
• Ask the retailer about the take back schemes.
• Consult the authorized service center as to whether the electronic equipment can
be repaired or not, before discarding the same.
• Tell your neighbors and other persons about the hazards of improper disposal or
handling or improper recycling of electronic waste.
• If the unwanted electronic equipments still does work or can be repaired then
consider donating them.
Don'ts :
• Don't dump the discarded electronic equipments in open or in any land fill site as
the same will result in contaminating the Soil and the ground water
• Don't dispose of the discarded electronic equipments in household bins or
municipal bins
• Don't sell or give your discarded electronic equipments to any trash dealer or
kabadiwala. any disposal through unauthorized agencies or person will attract
action under Environment Protection Act 1986
HAZARDS OF IMPROPER HANDLING AND/OR IMPROPER RECYCLING OF
ELECTRONIC WASTE
This crossed out wheeled bin symbol on the product and its user
guide represents the product and its electronic accessories are
covered by the E-waste management and handling rules 2011
and the product should not be disposed off with other household
waste at the end of their working life.
Improper handling or improper recycling of the electronic waste
results in hazardous metals/substances getting released into
environment and it is harmful to human health.
This appliance is RoHS compliant, which restricts the use of certain
hazardous substances in electrical and electronic equipment. We
take pride on meeting the toughest environmental standards in the
world as represented by RoHS criteria.
RoHS
COMPLIANT
Recycling of electronic equipments helps to save natural finite resources and also
reduces the environmental and health risks associated with improper handling/
disposing the electronic waste We should minimize our impact on the earth and
protect the environment for future generations.
9
Contact for further information:
Haier Appliances (India) Pvt. Ltd.
Building -1, Okhla Industrial Estate Phase El,
New Delhi-110020
Toll Free No. (24X7): 1800-102-9999
1800-419-9999
Email - [email protected]
Whatsapp - 855 304 9999

@

HAIER APPLIANCES (INDIA) PVT.LTD. (here-in-after referred to as "the company") hereby offers the
following warranty to the domestic purchaser commencing from the date of purchase. The company, at its
own sole discretion, will free of charge repair or replace any defective part or parts which prove to be
defective in workmanship and/or materials and not due to abnormal or improper usage by the customer/
consumer.
Product
Warranty on all
Models
Warranty for
Normal Model
Warranty for Inverter
Model
Parts Not
Covered
Refrigerator
Comprehensive
Period on Product
Extended Period on
compressor only
Extended Period on
Compressor & Fan
motor only
Plastic,
Glassware
and Bulb
1. All Side By side & French
Door Models
2. GTM with prefix–HRF/HEF
3. BMR with prefix-HRB/HEB
4. DC with prefix- HRD/HED
12 months
108 months
108 months
HAIER EXTENDED WARRANTY
HAIER REFRIGERATOR WARRANTY CARD
Customer Name: ............................................................. Address:………………………………………………
Serial No .................................. Date of Purchase: ..........................…..Model No …………………..................
Dealer Seal/Haier Seal:…………………………………………………………………………............................
TERMS AND CONDITIONS OF WARRANTY:
1. This extended Warranty offer is applicable for current year on purchases made during the offer period from authorized
dealers of the company.
2. The warranty term will commence and shall automatically terminate on completion of warranty period from the date of invoice.
3. The company is not liable for any delay in servicing due to reasons beyond the control of the company or any of its
authorized service centers.
4. Parts replaced or repaired under this warranty are warranted throughout the remaining period of the original warranty.
5. It is entirely left to the company's discretion to repair/replace parts at the site of installation or at the authorized service center
of the company.
6. This warranty shall be strictly limited to the repairs or replacement of defective parts specified in the warranty.
7. This warranty shall not, in any case, extend towards payment of any monetary consideration whatsoever or return of the
product.
8. The company may repair/replace parts free of cost during the warranty period. This warranty does not cover any Goods and
Service tax and any other taxes or levies applicable from time to time on the components/parts.
9. The parts shall be replaced by functional/ operating/ equivalent material only and not necessarily with brand new ones and are
likely to be different from the one originally fitted. The parts thus removed shall be taken back by the company.
10. The company reserves the right to retain any part or component replaced at its sole discretion during the warranty period.
11. In no event the company or its authorized service center shall be liable for any consequential damages or resulting liability,
damage or loss arising directly or indirectly out of any defect in the product.
12. This warranty is not valid in case of the following events:
a. If the product has been installed/serviced/repaired/opened or tampered by any unauthorized personnel/technician.
b. If defects arise/caused by accidents, alteration, misuse, neglect, substitution of original components with spurious/non-
genuine components, attacked by household pest/ rodents, flood, earthquake, lightning and /or any other act of God/natural
calamities.
c. The product is shifted outside India.
13. Any change of location or change in the ownership during the warranty period must be intimated in writing to the company.
14. The company's employees or its authorized representatives have no authority to vary the terms of this warranty.
15. This warranty is effected in New Delhi and claims, if any, shall be made only before the courts having jurisdiction in New
Delhi and no claims shall be made against the company outside New Delhi not withstanding that the appliances may have been
sold or delivered elsewhere.
16. This offer entitles customer to enjoy free of cost an extended warranty during the warranty period on select models as above
mentioned.
17. Labor, Gas charging and Transportation charges to be paid by customer accordingly during the extended warranty period of
108 months.
18. After the expiry of this warranty and/ or extended warranty period, the customer has to bear service charges and taxes as
applicable.
Note: - All consumer electronic products as listed in Schedule II of the E-waste Handling & Management Rules,
2011 should be disposed of according to the procedure laid under the said Rules.
Customer Name: ............................................................. Address:………………………………………………
Serial No .................................. Date of Purchase: ..........................…..Model No …………………..................
Dealer Seal/Haier Seal:…………………………………………………………………………............................
HAIER EXTENDED WARRANTY

NOTE

NOTE

Haier is the biggest Home Appliances Brand*in the world. We represent
a higher quality of life across 166 countries, and have transformed the
way people live. Haier has touched millions of lives. Bringing to them a
whole range of products that go far beyond mere appliances. Haier boasts
of a product range of 15,100 models across 96 categories. Haier products
are inspired by actual usage patterns of people and are designed in R&D
centers globally. Adding that little extra makes the difference. Haier is today
welcomed by millions to make their today better than yesterday. At Haier,
we call this Inspired Living.
Part No. 0060529097A Rev (02)
1800-102-9999, 1800-419-9999
(Toll Free - 24x7)
Email: [email protected]
Whatsapp: [phone]
Haier Appliances ( India) Pvt.Ltd.
Building -1, Okhla Industrial Estate Phase III,
New Delhi -110020
Tel- +91-1139496000,30674000,Fax: [phone]
Manufactured by : Haier Appliances (India) Pvt. Ltd.,
B-3, M.I.D.C. Ranjangaon, Tal. Shirur, Dist. Pune-412 220
