Haier L42A8A-A1 User manual

L42A8A-A1

Contents
1. Summarize
2. Main features
3. Appearance picture of complete set
4. Chassis appearance picture
5. Interface definition and interface electric requirements
6. Factory mode instructions
7. Structure size
8. The requirements of transportation, storage and usage
9. Appendix
1. Summarize
this chassis is used to match and connect the big screen LCD TV, it supports multi-system TV input signal ,
it can stored 128 TV programs at most, at the same time the highest resolution of this chassis can be up to
SXGA or appear R, G, B input signal of WXGA of 16:9 again, color appear again can support 24 bit, and it
can realize synchronous automatic check. It can support 1080P HD signal input at most, and includes two
rows CVBS signal, one row S terminal signal input, one row HDMI signal one row CVBS signal output.
Inbuilt 2x10W medium sound + 2x3W treble sound output, four rows two channels external audio signal
input, one row sound output. Support left and right sound balance, equalizer adjustment function.
Meanwhile, this chassis can support TV signal and digital display in HD signal at the same time, and there are
3A picture optimise, 3A demo.
2. Main Features
LCD TV control panel support specifications:

Input/Output signal
Analog RHB(0.7Vp-p)
Composite Video Signal(1.0Vp-p +/-5%)
TV Video
Four rows two rows external audio input(PC sound
effect card and AV equipment sound input)
Video support system PAL: NTSC(AV)
TV receiving band VHF-L:49.75-160.25MHz VHF-H:168.25-450.25MHz
UHF:451.25-863.25MHZ
Support Mode VGA, SVGA, XGA, SXGA , WXGA
Color 24bit
H-synchronous range 30-70KHz
V-synchronous range 56-75Hz
Output signal LVDS standard
Audio Output power 2Χ10WΧ
Control button TV/AV, VOL-, VOL+, POWER, CH-, CH+, MENU
(All the function can be operated by remote
controller)
OSD menu VGA: picture screen sound route function menu
TV: picture sound route function menu
OSD language English
Power input 150-240V(AC)
Power operations Normal working mode, standby mode
Power consumption 140W (without load)
Plug and play function Support
Power manage Standby Power consumption
3. Appearance picture of complete set

The sound box part and the structure of complete set is separable,so it need install solely.
4. Appearance picture of chassis
5. Interface definition (see appendix 2) and interface electric requirements
1. Power interface: supply the working power to chassis from power board..
2. Background light control panel interface: control the switch and brightness of screen background light
S-VIDEO input
PC audio input
VGA input
Power input
socket
Key control
socket
Screen connecting
Wire socket
Background light
control interface
Up grading
socket
CVBS input
AV1video input
AV video output
Speakeroutput
Remote control
socket
（down）HD signal input
AVaudio output
AV1audio input
HD signal audio input
Earphone socket
The speaker power socket
HDMI input
Side AVsocket

3. Remote control interface: support Toshiba receiving negotiation.
4. Control panel interface: 7 button control.
5. Sound output interface: sound signal output.
6. Program upgrading interface: upgrading program. Only for factory use.
6. Factory mode instructions
This chassis use new HYF-35R remote controller (grey, 41 button, can not share with the original blue 35
button HYF-35R ), the method to enter the factory mode is: Screen-----P.STD------S.STD------Sleep Time.
The following is the instructions of the factory menu of V2.1 version program
. DEBUG MENU.
Name Description
P.STD
S.STD
VOL SET
PICTURE MODE ADJUST
SOUND MODE ADJUST
VOLUME ADJUST
SAVE MODE
M.CLK
AGC
NO SET
DDRAM SET
AGC ADJUST
ENABLELOGO ON: open OFF: close
E2P SET ADJUST the DATA of EEPROM
FAC.MENU
Name Description
PWR. STB ON: power standby OFF: standby memory
ENABLELOGO Screen saver without signal ON: open OFF: close
TEST PAT. picture test
TV INIT Initialised factory signal do not use
E2P INIT Initialize EEROM
VERSION software property
BUS-SEL open or close BUS
WHITE BLC White blance adjust
Never adjust the following other items
7. Structure dimension (see appendix 1)
Relevant dimension specifications of control panel PCB，The specification of screw hole: diameter 3.3mm
screw hole , the structure diagram of hole position
8. Transportation, storage and usage requirements
1. Never press heavily and bend
2. Eliminated static
3. Relative humidity: below 80%

4. Storage temperature: -10¬+40℃
5. Usage temperature: 0¬+40℃
9. Appendix
Appendix 1: the dimension diagram of structure
Appendix 2: interface definition table
XP600 (9PIN/2.5): Power interface
NO. Definition Description
1 STN Power-on signal(high-level is available)
2 GND Ground
3 5V CPU working voltage(standby but not power
off)
4 GND Ground
5 GND Ground
6
7
8
9
GND
12V
12V
12V
Ground
Chassis working power (standby but power off)
Chassis working power (standby but power off)
Chassis working power (standby but power off)
XP601 XP601A (3PIN/2.0):Background light control interface
NO. Definition Description
1 ADJ Background light brightness control
2 ON/OFF INVERTER ON/OFF (high level is
available )

3 GND Ground
XP501(4PIN/2.0): Remote control button interface
NO. Definition Description
1 IR Remotecontrolreceiving
2 +5V 5VPower
3 GND Ground
4 LED Powerindicatorcontrol
XP502(4PIN/2.0):
NO. Definition Description
1 KEY1 Control panel signal 1
2 GND Ground
3 KEY0 Controlpanelsignal2
4 GND Ground (air connect)
XP301 (Right sound), XP302 (left sound) (2PIN/2.5): Sound output interface
NO Definition Description
1 SPK+ Sound output signal +
2 SPK- Sound output signal -
XP503 (4PIN/2.5):
NO. Definition Description
1 5V CPU Power
2 GND Ground
3 RXD Signal interface
4 TXD Signal interface

L42A8A-A1
Drafted by：Chen Long Checked by：Peng You Approved by：Hu Xijia
User’s Manual
