1 Press MENUbutton.
2 Press button to select Time menu, press button to enter.
3 Press button to select Clock item, press buttonto enter
setting.
Press button toselect hour or minute, press button
to adjust the value.
1 Press MENUbutton.
2 Press button to select Time menu, press button to enter.
3 Press button to select OffTime item, press button to
enter setting.
Press button toselect Repeat option, and then press
button to setit on.
Press button toselect hour or minute,
Press button to adjust the value.
When the offtime has arrived, the TV set will enter intostandby mode.
Clock
Off Time
1 Press MENUbutton.
2 Press button to select Time menu, press buttonto enter.
3 Press button to select On Time item, press button to
enter setting.
Press button toselect activate option, and then press
button to setit On.
Press button toselect hour or minute,
Press button to adjust the value.
When the ontime has arrived,the TV setwill switch on automatically.
On Time
Date
1 Press MENUbutton.
2 Press button to select Time menu, press buttonto enter.
3 Press button to select Date item, press buttonto enter setting.
Press button to select the option, and then press button to
adjust value.
OK
OK
OK
OK
OK
OK
OK
Hour < 02 >
Minute < 03 >
Close
Menu
OK
OK
OK
OK OK
OK
OK
Date < 02 >
Month < 3 >
Year < 2009 >
Close
Menu
OK
OK
OK
OK
Repeat < Off >
Hour < 00 >
Minute < 00 >
Close
Menu
OK
OK
OK
OK
OK
OK
OK
Activate < Off >
Hour < 00 >
Minute < 00 >
Close
Menu
TIME SETTINGS
NOTE: In DTV mode, because thetime information is
from the signal,theClock and Date are not able to be
changed.
If you wantto change the time, turn off the TV in ATV
mode,then turn onthe TV.
1 Press MENU button.
MENU
2 Press button to select Time menu, press button to enter.
3 Press button to select Time Zone item.
4 Press button to select the correct time zone.
5 Press button to save and exit.
Menu
OK
OK
OK
OK
Sleep
Time Zone
1 Press the MENU button and then use button to select the Time menu.
2 Press the button and then use button to select the Sleep.
3 Press the button and then use button to select the
number of minutes.Select Off, 5Min, 10Min, 15Min, 30Min,
45Min,60Min,90Min, 120Min, 180Min, 240Min
4 When you are satisfied with your choice, press MENU
button to return to the previous menu or press the EXIT
button to return to TV viewing. And the time begins to
count down from the number of minutes selected.
The sleep timer automatically shuts off the TV after a preset time
(from 5 to 240 minutes).
OK
OK
OK
OK
Menu
Press button to select Child Lock.
Press button to setOn or Off mode. If lock on mode is set, Child Lock is in
activated automatically. In suchcase, if Child Lock button (button on the television)
is pressed, thescreen will display Child Lock, which canbe erased bypress of
MENU button. 5seconds later after the latest press, the screen display will disappear
automatically. The Child Lock mode can be resumed by entering Lock Set menu,
set Child LockOn or Off.
1.Press button to select Change Password item.
Press button to enterthe submenu.
2.When you haveinputted the four digits you will be
prompted to enterit again.
Yournew password will then be automatically saved.
Using this functioncan control the tuner, program,
source volume andso on. Pressing MENU on the remote
control, press buttonto select Lock menu, press
button to enterthe sub-menu, and you will be required to
enter the password.The initial password of the television
is 0000. Ifyou forget your password, you can always
input 9443 toregain control.
Tuning Lock
Press to select Tuner Lock and to set On/Off. (To set On,some operation
such as searchwill be not available. When enter the Tuning menu, Tuner Lock will be on
the screen. Ifyou want to operate Tuning menu, you need to enter the Lock menu to set
Tuner Lock Off or operate unlock.)
Channel NO.
Channel NO. is opted for setting up preset channel.
Press button to select preset Channel. Press button to select channel number.
LOCK MENU SETTING
CHANGE PASSWORD
CHILD LOCK
OK
OK
Menu
OK
OK
OK
Menu
Channel set is opted for setting up start source.
Press button to select Off, DTV, TV, AV,SCART1,SCART2,S-Video,Component1,Component2,
PC, HDMI1,HDMI2,HDMI3,USB in turn. DVD is available for some model.
Source set
Press button to select Max Volume. Press button for adjustment between 0-100. If a certain
Value is set, when volume is being adjusted, the sound value can not exceed maximum volume
value. If current volume is over Max Volume, when lock set menu is set, current volume will
become set maximum volume, if current volume is below maximum volume, customer set volume
will stay unchanged.
Max Volume
Initial Volume
Clear Lock
Press button to select Unlock mode. Press button to unlock all set modes,
setting all lock options to off, and the maximum volume returns to 100.
The TV will remember it after your setting,that will be the volume when turn on the
TV next time.
Source Lock
Source Lock will control the On or Off of hinder external input
modes.
Press button to set as on or off.
When the source lock is set as on, TV source will display, at
this time, when press SOURCE button, the TV can switch to
correspondingsource and will display the Source is locked.
Parental Lock
Press button to select parental lock. Press button to select OFF or 4-18 to limit
the age of children who will watch TV.
OK
OK
Menu
