HaiweiTech V1-W User manual

USER MANUAL FOR
HaiweiTech V1-W IP CAMERA

Ⅰ Interfaces
Ⅱ Getting Start
Ⅲ Web GUI
1-Status
2- Network
3- Protocols
4- RTMP/ RTMPS
5- SRT
7- Audio
8- OSD
9- Image optimize
10- ONVIF
11- Time code
12- Recording
13- P2P- Lens
Contents
14- System
6- TS code
Ⅳ Contact us

Wifi antenna
Audio out Line-in
Red: Power
Yellow: Streaming
RS485 port
USB Port
Power In
Factory reset
Start recording
Network port * Dismountable lens
Interfaces

①
②
①Connect the IP camera to router via a RJ45 cable
②Connect the PC to the router that has already connected to the V1-W
①Getting V1-W, Router, and PC connected
PC
V1-W

1- Get current IP
Windows+ R → cmd
→Enter: ipconfig
→Get the IPv4 Add
2- Enter Ethernet
3- Enter Properties
4- Enter IPV4 and fill the
IPv4 address you get from
the 1st step and its subnet mask
and default IP gateway
Fill the correct dns, 8.8.8.8
suggested for global streaming
5- Enter Properties
6- Adding an available IP
address @192.168.1.xxx and
save all configurations.
②Configure the PC Net

•If transmission over LAN required, you may need to configure an unusable
IP and gateway for the WIFI connection;
•If transmission over WIFI required, check the subsequent page
* DNS
In general, we recommend 8.8.8.8 for the DNS1, changing a DNS will
probably helps if the stream does not start.
* QR code
The QR code was designed for remote control based on the P2P technology.
Once the encoder/ IP camera got network adapted, this function will be
possible for the remote control or point to point transmission, here are steps for
this operation (the switch displays on the Additional functions- More- P2P)
1- Open a Browser and enter
Default IP address of the IPC
192.168.1.168. if it not accessible, please reset it by pressing the RST for 15s and try again.
2- Adapt the network to your own and
save the current settings by clicking
(IP address- gateway- DNS need
to be modified)
3- Reboot the IPC
③Configure the IPC Net

4 -If transmission over WIFI required,
you may need to configure an unusable
IP and gateway for the LAN connection.
④Getting WiFi connection
* Mount the WiFi antenna before getting start
1- Switch to STA mode
and Reboot the device
2- Get the Wi-Fi by
clicking
3- Choose the correct
Wi-Fi by clicking
red labeled area and
enter your code
5- Reboot the IPC

Web GUI
1- Status
The status of the processing and the streaming URL displaying here (1st and 2nd- RTSP, HTTP, UDP, RTP, HLS here).
The statistics of the encoded information will keep going if it works correctly; besides that, it provides overall view for current encoding information.
HTML5 based preview could be implemented by enabling the HLS function, but ensure it is H.264 based, for it does not support HLS over H.265.

APP—LiveX, control the encoder and record the video at anywhere,
any network, any device.
Android/ IOS: download it on its apple/ Google play store
Or scan the QR code to get the APP downloaded from our website
Video about LiveX on YouTube:
https://www.youtube.com/watch?v=GyAD7EhDvAc=210s
Or Search “Haiwei softwares”

3- Protocols
Protocols display on the
HTTP, RTMP, HTTP, RTSP, UDP, RTP, SRT can be configured here
HTTP/ RTSP/ Unicast/ Multicast
relevant protocol then it
RTP
Fill the server/ destination IP and port then it

Get the stream URL and stream key on
the platform (use Facebook as instance ) Fill rtmps://live-api-s.facebook.com:443/rtmp/2541…
on the URL option
the RTMPs then it
RTMP/S
Network configuration required before
streaming to platform
4

Listener mode Caller mode
SRT stream URL
srt://current IP:port
Caller server
Enter the Server/ destination IP and its Port then it
Encoder Decoder
SRT
5

TS Code
Current TS info
6
Video ID= Stream ID
Audio ID= video ID+1

Audio
OSD
Set up the audio encoding information here
Set up OSD (On Screen Display) here, the logo should be named
as logo.bmp ( at 24bit), the size of the file should not exceed
100kb.
The logo for 2nd stream should be named as logo_ext.bmp
8
7

Color
ONVIF
Those features would be of help under some different
environment, different figures should be considered if the
video is dim or over bright and other video performance
related issues.
Time Code
The server could be time.windows.com, or national NTP server
9
11
10

MoreRecording
•P2P
This function is for remote control or
P2P transmission, explained its steps to
get connected in THIS page
•LDC Correction
This function is designed for adapting
different type of lenses if the video
distorted
Here are some suggestion for different
lenses
4mm- 400, 6mm- 200. 8mm- 0
12 13

System
System
Version
Upgrade
* Timing reboot
If the streaming is TCP connection based (except UDP
and RTSP over UDP), setting up 168 hours is necessary so as
to avoid network cache and latency accumulation.
14
