Hak5 WiFi Pineapple Mark VII User manual

This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful
interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. Warning
(Part 15.21) Changes or modifications not expressly approved by the party responsible for compliance could void the user’s authority to operate
the equipment. RF Exposure (OET Bulletin 65) To comply with FCC RF exposure requirements for mobile transmitting devices, this transmitter
should only be used or installed at locations where there is at least 20cm separation distance between the antenna and all persons.
Information to the User - Part 15.105 (b) Note: This equipment has been tested and found to comply with the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning
the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: * Reorient or
relocate the receiving antenna. * Increase the separation between the equipment and receiver. * Connect the equipment into an outlet on a
circuit different from that to which the receiver is connected. * Consult the dealer or an experienced radio/TV technician for help.
WiFi Pineapple is a trademark of Hak5 LLC. This product is packaged with a limited warranty, the acceptance of which is a condition of sale.
See Hak5.org for additional warranty details and limitations. Availability and performance of certain features, services and applications are
device and network dependent and may not be available in all areas; additional terms, conditions and/or charges may apply. All features,
functionality and other product specifications are subject to change without notice or obligation. Hak5 LLC reserves the right to make changes
to the products description in this document without notice. Hak5 LLC does not assume any liability that may occur due to the use or
application of the product(s) described herein. Made in China. Designed by Hak5 LLC, 548 Market Street, #39371, San Francisco, CA, 94104.
STATEMENT OF CONDITIONS
USB Host Port
USB-C Power /
Ethernet Port
Status LED
Reset Button
WiFi Pineapple Mark VII
Access from anywhere online.
Free download at https://c2.hak5.org
Connect to a 2-Amp USB power source.
Join the “Pineapple_XXXX” WiFi Network.
Browse to http://172.16.42.1:1471 and
follow the on-screen instructions.
Your WiFi Pineapple can also be provisioned
with a specially formatted USB flash disk, or by
connecting it to a computer using a USB cable.
Learn more at https://docs.hak5.org.
1
2
3

Your device may get hot to the touch; this is normal. Unplug the device and let it cool before removing it. This device complies with applicable
surface temperature standards and limits defined by the International Standard for Safety (IEC 60950-1). Still, sustained contact with warm
surfaces for long periods of time may cause discomfort or injury. Keep the device in a well-ventilated area when in use. Allow for adequate air
circulation under and around the device. Do not expose the device to water or extreme conditions (moisture, heat, cold, dust), as the device may
malfunction or cease to work when exposed to such elements. Do not attempt to disassemble or repair the device yourself. Doing so voids the
limited warranty and could harm you or the device. This device is not designed, manufactured or intended for use in hazardous environments
requiring fail-safe performance in which the failure of the device could lead directly
to death, personal injury, or severe physical or environmental damage.
The WiFi Pineapple is a network administration and pentesting tool for authorized
auditing and security analysis purposes only where permitted subject to local and
international laws where applicable. Users are solely responsible for compliance with
all laws of their locality. Hak5 LLC and affiliates claim no responsibility for
unauthorized or unlawful use. © Hak5 LLC.
INTERFACE: (3) WiFi, (1) USB 2.0, (1) USB-C Ethernet
STANDARDS: USB 2.0, 802.11b/g/n
DIMENSIONS: 107 x 93 x 21 mm
FREQUENCY RANGE: 2.412 ~ 2.4835 GHz
POWER: 10W (USB 5V 2A)
OPERATING TEMPERATURE: 35ºC ~ 45ºC
STORAGE TEMPERATURE: -20ºC ~ 50ºC
RELATIVE HUMIDITY: 0% to 90% (noncondensing)
SETUP LED STATUS INDICATIONS
IN THE BOX
SPECIFICATIONS
Starting up
Ready
Invalid USB Files
Flashing Firmware
DO NOT UNPLUG POWER
BLINKING BLUE
SOLID BLUE
SOLID RED
ALTERNATING
BLUE/RED
SAFETY INFORMATION AND WARNINGS
Full documentation at docs.hak5.org
Full documentation at docs.hak5.org
