Hallman HRBIAF18PR User manual

Refrigerator
User Manual
All Freezer : HRBIAF18PR, HRBIAF24PR
All Refrigerator : HRBIAR24PR, HRBIAR30PR

Please read this manual before using the product!
Dear Valued Customer,
We wish you to get the best results from your product that has been
manufactured meticulously at modern plants and tested with detailed
quality control checks.
For this reason, we recommend that you read this user manual
thoroughly before starting the product.
If you hand over the product to someone else, please remember
to give the user manual as well.
This manual will help you use your appliance in a fast and safe way.
•Please read this user manual carefully before installing and using the product.
• Always follow the applicable safety instructions.
• Keep the user manual in an easily accessible place for further use.
•Please read all the other documents provided with the product.
Please keep in mind that this manual may apply to several product models.
This manual expressly indicates the differences between various models
A
Risk of injury and property damage.
B
Riskofelectric
shock.
C
Important information and useful hints.
Packaging materials of this product has been
manufactured from recyclable materials in accordance
with the National Environment Regulations.

1 ImportantInstructionsRegardingSafetyand Environment
This chapter contains safety information that will help you avoid the risk
personal injury or property damage. Failure to follow these instructions shall
render any product warranty void.
1.1 General Safety
•This product can be used by children at age 8and above and those people
who have limited physical, sensory or mental capabilities and people
who lack experience and information on the condition that they have been
given the instructions about the safe use of the product,
they are supervised and the risks have been eliminated.
Children should not play with the product.
Cleaning and care should not be performed by children unless
they are supervised by an adult.
•Unplug the product if you encounter a failure during use.
•If the product malfunctions, it must not be operated until repaired
by the authorized service provider. Risk of electric shock!
•Plug the product into a grounded socket protected by a fuse
that corresponds to the value on its nameplate.
Have a qualified electrician ground the product.
Our company cannot be held responsible for damages resulting
from the failure to use the product with a grounded socket pursuant
to local regulations.
•Unplug the product when not in use.
•Never wash the product by spreading or
pouring water onto it! Risk of electric shock!
•Never touch the plug with wet hands!
•Never unplug the product by pulling the cable.
Always pull the plug by holding the socket
•Do not plug the refrigerator if the wall socket is loose.
•Never connect your refrigerator to energy saving devices.
•Such systems are harmful to your product.
•Unplug the product during installation, care, cleaning and repairing procedures.
•Always have the Authorized Service Provider install the product and
establish its electrical connections.
The manufacturer cannot be held responsible for damages caused
by procedures performed by unauthorized persons.
•Do not eat cone ice cream or ice cubes immediately after you take them
out of the freezer compartment! This may cause frostbite in your mouth!
•Do not touch frozen food with wet hands! They may stick to your hand!
•Do not put bottled or canned liquid beverages in the freezer compartment.
They may burst!

1 ImportantInstructionsRegardingSafetyand Environment
•Never use steam or steam cleaners to clean or defrost the refrigerator.
Steam gets into contact with the live parts in your refrigerator,
causing short circuit or electric shock!
•Do not use mechanical devices or other means to accelerate
the defrosting process other than those recommended by the manufacturer.
•Never use the parts in your refrigerator such as the door and drawer
as a means of support or step.
This may cause the product to tip over or damage the parts of it.
•Do not damage the parts where the refrigerant is circulating with drilling
or cutting tools.
The refrigerant that might blow out when the gas channels of
the evaporator, pipe extensions or surface coatings are punctured causes
skin irritations and eye injuries.
•Do not cover or block the ventilation holes in your refrigerator with any object.
•Place the beverage with higher proofs tightly closed and vertically.
•Do not use gaseous sprays near the product since there is the risk or
fire or explosion!
•Flammable items or products that contain flammable gases (e.g. spray)
as well as explosive materials should never be kept in the appliance.
•Do not place vessels filled with liquid onto the product. Splashing water
on an electrical part may cause electric chock or the risk of fire.
• Do not store items that need precise temperature adjustment
(such as vaccines, heat-sensitive medication, science materials etc.)
in the refrigerator.
• If you are not going to use the product for a long time, unplug it
and remove the food in it.
• If there is a blue light on the refrigerator, do not look at this light with optical tools.
•Exposing the product to rain, snow, sun or wind is dangerous in terms of
electrical safety.
• In products with mechanical control (thermostat), wait for 5 minutes
to plug in the product again after unplugging.
• Do not overload the refrigerator. Objects in the refrigerator may fall down
when the door is opened, causing injury or damage.
Similar problems may arise if any object is placed onto the product.
• If the product has a door handle, do not pull the handle
when re-locating the product. The handle might be loose.
• Be careful not to jam your hand or any other body part in the moving parts
of the refrigerator.
• Do not put your hand or any other foreign materials into the ice machine
while it is operating.

1.2 Intended Use
•This product has been designed for domestic use. It is not suitable
for commercial use and it must not be used out of its intended use.
•It must be used only for storing food.
•The manufacturer will not take any responsibility for damages resulting
from improper use or transport.
•Original spare parts will be available for 10 years after the purchase date
of the product.
1.3 Children's Safety
•If there is a lock on the door of the product, the key should be kept
out of the reach of children.
•Do not let children play with the product.
1.4 Compliance with the WEEE Directive and Disposing the Waste Product:
This product conforms to the EU WEE Directive (2012/19 EU).
This product bears a classification symbol for waste electrical and
electronic equipment (WEEE).
This product has been manufactured from high quality parts and materials
which can be reused and are suitable for recycling.
Therefore, do not dispose the product with normal domestic waste or
other waste at the end of its service life.
Take it to a collection center for recycling electrical and
electronic equipment.
Please consult local authorities to learn about the locations
of such collection center.
1 ImportantInstructionsRegardingSafetyand Environment
ADANGER:
Before disposing your old refrigerator or freezer:
• Children may get locked inside.
• Remove the doors.
• Leave the shelves to prevent children from getting
inside the product easily.

1.5 Compliance with the RoHS Directive:
The unit you have purchased conforms to the EU RoHS Directive (2011/65/AB).
It does not contain harmful or prohibited materials specified in the Directive.
1.6 Packaging Information
•Packaging materials of the product have been manufactured from recyclable
materials in accordance with our National Environment Regulations.
•Do not dispose the packaging materials with normal domestic waste
or other types of waste.
•Take these materials to a recycling point designated by local authorities.
1 ImportantInstructionsRegardingSafetyand Environment
A
DANGER:
Risk of Fire or Explosion:
• This product uses flammable refrigerant.
• Do not use mechanical devices to defrost
the refrigerator.
• Do not use chemicals for cleaning.
• Do not pierce the refrigerant pipe.
• If the refrigerant pipe is pierced, it must be repaired
only by licensed service personnel.
• Please consult the repair/user manual
before cleaning the product.
All safety instructions must be followed.
•Dispose the product according to federal or
local regulations
1.7 Hydrocarbon (HC) Warning
•If your product's cooling system contains R-600a.
This gas is flammable.
Therefore, pay attention not to damage the cooling system or
the piping during use and transportation.
•If damaged, keep the product away from potential fire sources that
may cause it to catch fire and ventilate the room where the product is placed.

1.8 For Products with a Water Dispenser/Ice Machine
•Operating pressure for cold water inlet is between 1-5.5 bars.
If the water pressure exceeds 80 psi (5.5 bars), install a pressure limiting
valve to your mains system.
•If the mains pressure is lower than 1 bar, you can use an auxiliary pump
to compensate the low pressure.
•If you do not know how to check the water pressure,
please consult a professional plumber.
•If there is a risk of water impact in your installation, always use
a water impact protection equipment in that installation.
•Please consult professional plumbers if you are not sure if there is
water impact in your installation.
•Do not make installation on the hot water inlet.
•Take the necessary measures against the freezing risk of the hoses.
•The water temperature operating range must be 0.6°C (33°F) minimum
and 38°C (100°F) maximum.
1 ImportantInstructionsRegardingSafetyand Environment
CIf the product is damaged and if you see gas leak,
please keep away from the gas. It may cause frostbite
when it gets into contact with the skin. (including R134
CIgnore this warning if the cooling system of your product
contains R134a.
CType of gas used in the product is stated on the type
plate which is on the left wall inside the refrigerator.
AWARNING:
Never throw the product into fire for disposal.
AWARNING:
Never connect the product to a cold water mains with a
pressure of 5.5 bars (80 psi) and above

Maynotbeavailable in all models
CFigures in this user manual are schematic and may not
match the product exactly. If your product does not have
the relevant parts, the information applies to other
models.
2 Storagefeatures
- Freezer
Shelving
Ice
maker
(if
applicable)
Self
close bins
Door
bins
•
Selectable shelf heights.
•
Heat treated safety glass..
•
Removable ice container.
•
Hygienic ice scoop.
•
Freezer bins self close to ensure all bins close properly.
•
Adjustable and removable door bins.
Freezer
components
Door bin
Soft close small bin
Soft close big bin
Ice maker
Soft close ice bin
Shelving

CFigures in this user manual are schematic and may not
match the product exactly. If your product does not have
the relevant parts, the information applies to other
models.
2 Storagefeatures
- Refrigerator
Shelving
Water
dispenser
(if
applicable)
Soft
close bins
Door
bins
•
Selectable shelf heights.
•
Heat treated safety glass.
•
Removable ice container.
•
Hygienic ice scoop.
•
Soft close bins ensure bins close quietly and properly.
•
Adjustable and removable door bins.
•
Gallon bottle door bin.
Refrigerator
components
Maynotbeavailable in all models
Door bin
Gallon bottle door bin
Door bin
Shelving
Soft close small bin
SPE. TEMP. zone
Water
dispenser
Soft close big bin
REF. TEMP. zone

3 DisplayPanel
1 2 3 9 10 11 12 13
4 5 6 7 8
1
On/Off
button
Serves
to switch the whole appliance On and Off.
Press
the button to switch on the product,
the
product will be switched on in 5 seconds.
Press
the on/off button for 1.5 seconds to switch off.
2
Colder/
Wa
rmer
button
Press
button to change the freezer compartment temperature
from
5°F(-15°C) to -11°F(-24°C)
After
the temperature regulation is stopped,
the
nixie tube will flash for 5 seconds and take effect.
Super
freezing function will be enabled if keep pressing
after
-11°F (-24°C).
When
the snow symbol illuminate on the display
the
super freezing function will be enabled.
The super freezing feature assists with periods of high
freezer use, full grocery loads, or temporarily
Warm room temperatures.
After the super cool cycle completes,
the refrigerator will return to its previous setting.
3
Temp
. display
Displays
the set temperature of the freezer.
Fahrenheit
, Celsius, Super freezer lamp illuminate.
4
Lock
Press
lock key continuously for 3 seconds and
the
lock icon will light up.
Press
the lock key for 3 seconds to unlock the icon.
3
minutes without key operation lock key.
All
of the following operations must be performed
in
the unlocked state.
- Freezer

3 DisplayPanel
5
Holiday
mode
Press
the MENU button till the holiday symbol illuminates,
then
press the SELECT button to enable the function.
When
the Holiday Mode function is enabled,
freezer
temperature set at 0°F (-18°C)automatically.
Before leaving
-
Turn the ice maker to OFF on the control panel.
-
Shut off the water supply to the appliance.
On return
-
Turn on the ice maker.
-
Discard the first full bin of ice.
6
Eco
mode
Press
the MENU button till the Eco Mode illuminates,
then
press the SELECT button to enable the function.
When
the Eco Mode function is enabled,
and
freezer Temperature set at 5°F (-15 °C) automatically.
7
Sabbath Mode
Press
the MENU button till the Sabbath mode symbol illuminates
Then
press the SELECT button to enable the function.
When
the Sabbath mode function is enabled,
all
lights, buzzers, display panels will be switch off.
8
Menu/
child
lock
By
pressing MENU button for 3 seconds,
you
may lock/unlock the control panel.
The
child lock is a feature for preventing children
from
changing the product settings.
9
Water
filter
(if
applicable)
The
water filter symbol flashes and beeps to advise
the
user to replace the water filter.
After
the replacement is completed,
Press
the SELECT button for 5 seconds to reset.
The
set replacement time is 130 days.
10
Ice
Making
(if
applicable)
Press
the MENU button till the ice making symbol illuminates,
Then
press the SELECT button to enable the function.
When
the ice making function is enabled,
ice
maker will be automatically operating and
the
ice cubes will be accumulated in the ice tray.
NOTE
: Prepare the water filter for use before using the ice.
After
connecting the freezer to a water source
or
after replacing the water filter,
fill
and discard two full containers of ice.
- Freezer

3 DisplayPanel
11
Temperature
unit
Press
the MENU button till the Celsius and Fahrenheit
selection
symbol illuminates to change between Celsius
and
Fahrenheit. After that press the SELECT button to confirm.
12
Show
room
mode
Press
the MENU button till the show room symbol illuminates,
then
press the SELECT button to enable the function.
This
mode is used when the refrigerator is on display
in
a retail store or if you want to turn the cooling off
and
deactivate all other functions except interior lighting.
Note
:Do not store any food items while in show room mode,
as
the appliance then remains at room temperature.
13
Select
After
selecting menu, then press SELECT button
to
confirm the function.
- Freezer
CRecommended operating temperature
Freezer : 0°F (-18 °C)

3 DisplayPanel
1 4 5 11 12 13 14 15
6 7 8 9 10
- Refrigerator
1
On/Off
button
Serves
to switch the whole appliance On and Off.
Press
the button to switch on the product,
the
product will be switched on in 5 seconds.
Press
the on/off button for 1.5 seconds to switch off.
2
REF
.TEMP.
zone
colder/
Warmer
Button
Press
REF. TEMP button to adjust temperature
from
36°F(2°C) to 46°F(8°C).
After
the temperature regulation is stopped,
the
nixie tube will flash for 5 seconds and take effect.
Super
cooling function will be enabled if keep pressing
after
36°F (2°C).
When
the snow symbol illuminate on the display
the
super cooling function will be enabled.
The super cooling feature assists with periods of high
refrigerator use, full grocery loads, or temporarily
warm room temperatures.
After the super cool cycle completes,
the refrigerator will return to its previous setting.
3
Temp
. display
Displays
the set temperature of the REF. TEMP. zone
Fahrenheit,
Celsius, Super cooling lamp illuminate.
4
SPE
.TEMP.
zone
colder/
Warmer
Button
Press
SPE. TEMP. button to adjust temperature
from
30°F(-1°C) to 41°F(5°C).
After
the temperature regulation is stopped,
the
nixie tube will flash for 5 seconds and take effect.
5
Temp
. display
Displays
the set temperature of the SPE. TEMP. zone
Fahrenheit,
Celsius lamp illuminate.
6
Lock
Press
lock key continuously for 3 seconds and
the
lock icon will light up.
Press
the lock key for 3 seconds to unlock the icon.
3
minutes without key operation lock key.
All
of the following operations must be performed
in
the unlocked state.
2 3

3 DisplayPanel
7
Holiday
mode
Press
the MENU button till the holiday symbol illuminates,
then
press the SELECT button to enable the function.
When
the Holiday Mode function is enabled,
the
REF. TEMP and SEP.TEMP will be set
at
63°F (17°C) automatically.
NOTE
:Do not place food in the fresh food compartment
when
Holiday Mode is enabled.
8
Eco
mode
Press
the MENU button till the Eco Mode illuminates,
then
press the SELECT button to enable the function.
When
the Eco Mode function is enabled,
the
REF. TEMP will be set at 46 °F (8 °C)
the
SEP. TEMP will be set at 41 °F (5 °C) automatically.
9
Sabbath Mode
Press
the MENU button till the Sabbath mode symbol illuminates
Then
press the SELECT button to enable the function.
When
the Sabbath mode function is enabled,
all
lights, buzzers, display panels will be switch off.
10
Menu/
child
lock
By
pressing MENU button for 3 seconds,
you
may lock/unlock the control panel.
The
child lock is a feature for preventing children
from
changing the product settings.
11
Water
filter
(if
applicable)
The
water filter symbol flashes and beeps to advise
the
user to replace the water filter.
After
the replacement is completed,
Press
the SELECT button for 5 seconds to reset.
The
set replacement time is 130 days.
12
Water
dispenser
(if
applicable)
Press
the MENU button till the water dispenser symbol
illuminates,
Then
press the SELECT button to enable the function.
When
the water dispenser is enabled,
fresh
water can be provided from the dispenser fitted
on
the internal wall.
NOTE
: Prepare the water filter for use
before
using water dispenser.
After
connecting the refrigerator to a water source
or
after replacing the water filter,
fill
and discard two full containers of ice.
13
Temperature
unit
Press
the MENU button till the Celsius and Fahrenheit
Selection
symbol illuminates to change between Celsius
and
Fahrenheit. After that press the SELECT button to confirm.
- Refrigerator

3 DisplayPanel
14
Show
room
mode
Press
the MENU button till the show room symbol illuminates,
then
press the SELECT button to enable the function.
This
mode is used when the refrigerator is on display
in
a retail store or if you want to turn the cooling off
and
deactivate all other functions except interior lighting.
Note
:Do not store any food items while in show room mode,
as
the appliance then remains at room temperature.
15
Select
After
selecting menu, then press SELECT button
to
confirm the function.
- Refrigerator
CRecommended operating temperature
REF. TEMP. : 39°F (4°C)
SPE. TEMP. : 34°F(1°C)

4 BeforeUsingthe Refrigerator
4.1Thingsto do for energysaving
•Do not leave the doors of your refrigerator open for a long time.
•Do not put hot food or drinks in your refrigerator.
•Do not overload the refrigerator. Cooling capacity will fall
when the air circulation in the refrigerator is hindered.
•Do not place the refrigerator in places subject to direct sunlight.
Install the product at least 30 cm away from heat sources such as hobs,
ovens, heater units and stoves and at least 5 cm away from electrical ovens.
•Pay attention to store your food in refrigerator in closed containers.
•You can remove the drawer shelf of the freezer compartment to fill
the freezer compartment with maximum amount of food.
The given energy consumption value of the refrigerator has been determined
with the freezer compartment shelf or the drawer removed and the refrigerator
filled with maximum amount of food.
There is no harm in using a shelf or drawer according to the shapes and
sizes of food to be frozen.
•Thawing the frozen foods in the fridge compartment both saves energy
and reserves the quality of the foods
CTemperature of the room where your refrigerator is
located should at least be 10ºC/50°F. Operating your
refrigerator under cooler conditions is not recommended
with regard to its efficiency
CIf two coolers are to be installed side by side, there
should be at least 4 cm distance between them
4.2 Recommendations About the Fresh Food Compartment
•Make sure that the food does not touch the temperature sensor
in fresh food compartment.
To allow the fresh food compartment to keep its ideal storage temperature,
the sensor must not be hindered by food.
•Do not place hot foods or beverages inside the product.
AConnecting your refrigerator to systems that save
energy is dangerous as they may cause damage on the
product.

4 BeforeUsingthe Refrigerator
4.3 Initial use
Before using the product, make sure that all preparations have been made
in accordance with the instructions given in the "Important instructions
regarding safety and environment" and "Installation Instruction" chapters.
•Clean the interior of the refrigerator as recommended in the “Maintenance
and cleaning” section. Before you start the refrigerator, make sure
that the interior is dry.
•Plug the refrigerator in a grounded socket. The interior illumination is lit
when the door of the refrigerator is opened.
•Operate the refrigerator for 6 hours without placing any food in it and
do not open its door unless it is necessary
CYou will hear a noise when the compressor starts up.
The liquids and gases sealed within the refrigeration
system may also give rise to noise, even if the
compressor is not running and this is quite normal.
CFront edges of the refrigerator may feel warm.
This is normal.
These areas are designed to be warm
to avoid condensation.

5 Equipment
5.1 Door bin
To remove, lift up the door bin
and then pull out straight.
5.2 Glass shelves
To remove a shelf
- Fully open the corresponding door.
- Hold the front of the shelf, and then gently lift up and slide out.
To reinsert
- hold the shelf at an angle so the front is higher than the back,
and then insert the top hook into the top shelf notch.
- Put down the front slightly.
IMPORTANT NOTE:
Use care when handling glass shelves
to prevent breakage or scratching the interior.
AATTENTION:
You must wait for the glass shelves
to reach room temperature before immersing
them in water for cleaning.

5.3Bins
To remove the bin
- Pull the bin until it stops.
- Slightly unclip the front section of the bin and take it out completely.
To install the bin
- Pull the rails completely.
- Place the gap at the rear corners of the bin to the detail located
at the rear corners of the rails.
- Push the bin slowly down until you feel it clip front onto the rails.
CMake sure that the details at the right and left-hand
sides are fixed when installing the bin.
5 Equipment
5.4 SPE. TEMP. zone compartment
You can control the temperature in this section to store your food
such as fish, meat, delicatessen products.

5.5 Hinge Adjustment
When adjusting the hardness of the hinge: Hardness of the lower and
upper door hinges of the fresh food compartment is performed with
the help of a drill. Set the hinge adjustment screw to position "1" from
position "0".
5.6 Changingthe Directionofthe Door
Pleaseseetheinstallationinstructionsprovidedin thebag.
5 Equipment
