Halytech Illuminator User manual

HALYTECH Illuminator User Manual
Page 1
Illuminator
Floodlight Control and Facility Monitoring System
USER MANUAL
Illuminator User Manual Version 3.21
Copyright © Halytech
All rights reserved

HALYTECH Illuminator User Manual
Page 2
SOFTWARE LICENCE AND COPYRIGHT NOTICE
All software that is supplied as part of this equipment is protected by copyright laws and
international copyright treaties, as well as other intellectual property laws and treaties. This
software is licensed, not sold and is intended for use on this device only.
All title and copyrights in and to the software (including but not limited to any text, instructions,
code, “applets” incorporated into the software, images, photographs, animations, video, audio
and music) are owned by Halytech.
You may not reverse engineer, decompile, or disassemble this software for any purpose. No
part of this software may be copied, reproduced, loaned, rented, leased or transmitted in any
form or by any means electronic or mechanical, without the express written permission of
Halytech.
Halytech Pty Ltd
ABN 51 094 853 068
PO Box 6983
Baulkham Hills Business Centre
NSW 2153 Australia
Tel: [phone]
E-mail: [email protected]
www.halytech.com.au
Warning
This is a Class A product. In a domestic environment this product may cause radio
interference in which case the user may be required to take adequate measures.

HALYTECH Illuminator User Manual
Page 3
Table of Contents
Introduction ................................................................................................................................................................... 4
Typical Applications ................................................................................................................................................... 4
System Overview .......................................................................................................................................................... 4
V3.2X New Functionality .............................................................................................................................................. 4
Overview of Floodlight Control ................................................................................................................................... 5
Timer Mode ............................................................................................................................................................... 5
Club Controlled Mode ................................................................................................................................................ 5
Controls ..................................................................................................................................................................... 7
Inputs (Advanced Use Only) ...................................................................................................................................... 7
Alarms (Advanced Use Only) .................................................................................................................................... 8
Logger ....................................................................................................................................................................... 8
Web Server ................................................................................................................................................................ 9
Physical Connections................................................................................................................................................. 10
Antenna ................................................................................................................................................................... 10
Power ...................................................................................................................................................................... 10
Controls ................................................................................................................................................................... 11
Inputs (Advanced Use Only) .................................................................................................................................... 12
Auxiliary Connectors ................................................................................................................................................ 14
Numeric Keypad ...................................................................................................................................................... 15
Setting up an Illuminator for the first time ............................................................................................................... 16
Change Location and Lighting Setup ...................................................................................................................... 17
Setting Date and Time ............................................................................................................................................. 19
Change User and Password .................................................................................................................................... 20
Setting up Network Parameters ............................................................................................................................... 21
Setting up Email Parameters ................................................................................................................................... 23
Network Glossary .................................................................................................................................................... 24
Save Setup to Disk .................................................................................................................................................. 25
Load Setup from Disk .............................................................................................................................................. 25
Exiting Change Setup Mode .................................................................................................................................... 25
Normal Operation ........................................................................................................................................................ 26
Communicating with a PC ....................................................................................................................................... 26
Lights ....................................................................................................................................................................... 26
Clubs ....................................................................................................................................................................... 28
Report ...................................................................................................................................................................... 29
Advanced Operation ................................................................................................................................................... 31
Automatic Daily E-mail Reports ............................................................................................................................... 31
Inputs ....................................................................................................................................................................... 32
Calibrating Counter Inputs (if present) ..................................................................................................................... 33
Scaling Event Inputs (if present) .............................................................................................................................. 3 4 
Calibrating Analogue Inputs (if present) .................................................................................................................. 34
Viewing Current Inputs ............................................................................................................................................ 35
Monitoring Electricity Use ........................................................................................................................................ 36
Setting up Alarms .................................................................................................................................................... 37
Viewing Current Alarms ........................................................................................................................................... 38
Resetting Alarms ..................................................................................................................................................... 38
History ..................................................................................................................................................................... 39
About ....................................................................................................................................................................... 39
Front Panel Display .................................................................................................................................................... 40
SMS Commands .......................................................................................................................................................... 41
SMS Alarms ................................................................................................................................................................. 43
Software Upgrade ....................................................................................................................................................... 44
Numeric Keypad Operation........................................................................................................................................ 44
Appendix A: Connecting to an Illuminator Locally ................................................................................................. 45
Connecting a PC Directly to an Illuminator .............................................................................................................. 45
Connecting to an Existing Network (LAN) ............................................................................................................... 47
Appendix B: Connecting to an Illuminator Remotely .............................................................................................. 48
Remote Connection ................................................................................................................................................. 48
Appendix C: Connection to Mobile Network ............................................................................................................ 49
SIM Card Insertion and Removal ............................................................................................................................ 49
Appendix D: Testing E-mail Connectivity................................................................................................................. 51
Sending Test e-mails ............................................................................................................................................... 51
Appendix E: Logged Data Format ............................................................................................................................. 52

HALYTECH Illuminator User Manual
Page 4
Introduction
Halytech Illuminator is an integrated floodlight control and facility monitoring system.
It can control floodlights, monitor various sensors, generate alarms and log. The Illuminator is
a complete system. It includes all software, hardware and a cellular phone module. Setting up
and interrogating an Illuminator is a simple matter of viewing pages with any standard web
browser. An Illuminator can be accessed either locally via a direct cable connection or
remotely via internet or by sending and receiving SMS messages.
Typical Applications
 Sports Fields
 Parks
 Tennis Courts
 Community Halls
 Clubhouses
 Public Toilets
System Overview
Each Illuminator incorporates an industrial controller, input/output interface, a logger and a
4G/3G cellular phone interface.
Illuminator is capable of:
1. Controlling up to eight (8) controls – floodlight contactors etc.
2. Monitoring up to eight (8) inputs
3. Generating up to eight (8) alarms
4. Receiving SMS commands
5. Sending SMS messages
6. Logging status, control and alarm activity
7. Being configured by the user through any standard web browser
8. Sending automatic usage reports by email
V3.2X New Functionality
 Timer mode can be selected for all controls.
This is useful for lights that need to go on and off automatically e.g. clubhouses,
lighted paths etc.
 Light scenario can be named and can drive any number of controls.
For example – scenario ID 1 can be named “Field 1 50 lux” that drives only control 1,
while scenario ID 2 can be named “Field 1 100 lux” that drives controls 1 and 2.
 Introduction of “Turn-on delay” to prevent large current inrush when multiple lights are
turned on at the same time.
 Illuminator Central support.
Illuminator Central is an optional web based subscription service that allows any
number of Illuminators to be managed centrally. Illuminators keep on operating
independently, while at the same time allowing club and field management to be
handled efficiently from one central location. Illuminator Central also provides
comprehensive, aggregated usage reports.

HALYTECH Illuminator User Manual
Page 5
Overview of Floodlight Control
The Illuminator provides two Operation Modes – Timer Mode and Club Controlled Mode.
Timer Mode
An On-time and an Off-time are entered for the scenarios desired to be run in Timer mode for
each day of the week. The lights will automatically turn on and off as set. This mode is useful
for controlling lights with regular use patterns such as lighted paths, clubhouses etc.
Club Controlled Mode
This is the most often used mode where the lights are controlled directly by users during
allowed periods of time.
The Illuminator recognises two different types of users: an administrator and a number of
“normal users”.
The administrator has complete control over all floodlights. He or she can turn on and turn off
any light at any time, without time off delay. Furthermore, the administrator can override any
command issued by a “normal user”.
The administrator first decides during what period during the day “normal users” will be
allowed to control the lights. Each light scenario can have its own separate period.
The administrator can allow up to 49 “normal users” to control the lights. Each user is given a
different 4-digit PIN and the authority to control specific light scenarios.
The PINs and the access rights can be changed by the administrator as often as desired.
Lights are normally turned on and off by either:
1. sending an SMS command to the Illuminator, or
2. typing the same command into the numeric keypad
Administrators can also control the lights by accessing the Illuminator with a computer.
The SMS/keypad commands have the following format:
PPPPAL# where: PPPP is the four digit PIN
A is action, either 1 for ON, or 0 for OFF
L is one or more light scenario IDs
# terminates the command on the keypad
Example 1: user PIN is 2345, authority to control light scenario 6
234516# - turn on light scenario 6
234506# - turn off light scenario 6
Multiple scenarios can be turned on or off in the same command.
Example 2: user PIN is 7777 and they have the authority to control light scenarios 2 and 3,
the commands are:
7777123# - turn on light scenarios 2 and 3
7777023# - turn off light scenarios 2 and 3
777703# - turn off light scenario 3
Note: # is optional in SMS commands

HALYTECH Illuminator User Manual
Page 6
All valid SMS commands are acknowledged with a response SMS confirming action taken.
Invalid SMS commands generate an appropriate response, advising the user of the problem.
The administrator can set up a help contact such as ‘John Smith on [phone]’. These
contact details are added to the end of the SMS sent in response to an invalid command.
Once a user activates the lights, only he (or the administrator) can turn them off. This stops
practical jokes by other users.
If an authorised user “A” tries to activate the lights that are on and controlled by a user “B”,
the user “A” will take over the control of the lights. The Illuminator will stop charging the user
“B” and start charging the user “A”. This feature allows a new user to take control of the lights
without having to wait for the old user to turn them off first. It also prevents the old user who
forgets to turn off the lights at the end of his session turning them off later during the new
user’s session.
If an authorised user “A” tries to deactivate lights controlled by a user “B” via SMS, the user
“A” will receive a message advising that the lights are controlled by the user “B”, and the lights
will not turn off.
The keypad will always accept a command from an authorised user to turn off the lights,
however if the user does not currently have control of the lights they will not be turned off.
This is to confirm that they are no longer being charged for the lights in the case where they
are unaware the next user has already started their session.
A “Turn on delay” in seconds can be set if desired. It is used to eliminate large current draws
that can occur when multiple controls turn on at exactly the same time. With the “Turn on
delay” set to x seconds, the controls will come on in a staggered manner, x seconds apart.
If a user is allowed to turn the lights off, the command is accepted but the lights can be made
to continue stay on for a user configurable "Turn off delay" in minutes. This is particularly
useful for older (non-LED) type of lights to give a chance to a new user to turn the lights back
on without having to wait for the warm-up period.
The "Turn off delay" is not applied if the administrator turns the lights off outside the period of
control for normal users.
The lights turned on by normal users are automatically turned off at the end of the allowed
control period. Lights turned on by the administrator remain on until turned off by the
administrator.
All activations, deactivations and the means of control (automatic, keypad, computer or SMS
from a mobile telephone) are logged by the Illuminator. The Illuminator stores the most recent
1000 events in its memory. This information is available to administrators in the form of a
usage report. The report can span a number of days and can be used to prepare customer
bills.
The section titled “Normal Operation” details the procedure on defining users, their PINs,
access rights etc.
Automatic e-mail reports
An Illuminator can be set up to send daily e-mail reports. At 3:00 AM, an e-mail will be sent to
up to three recipients. Each e-mail has a spreadsheet file attachment containing data logged
over the recent day(s).
The advantage of daily e-mail reports is in the Illuminator ability to automatically deliver or
“push” data without any user intervention.

HALYTECH Illuminator User Manual
Page 7
Controls
The Illuminator provides 8 controls on two multi-pole connectors for controlling the floodlights.
Controls are labelled CN1 to CN8 respectively. Each is provided with two screw terminals
internally connected to a relay, providing voltage free contacts. In inactive state the two
terminals are open-circuit. Upon activation, the relay switches and the terminals are shorted
together. Controls can be activated in several different ways:
1. With a computer by accessing the “Lights” page with a browser and clicking on the
Manual Override ON/OFF buttons
2. By sending control SMS messages to the unit. All SMS commands are authorised
with 4 digit PINs.
3. By typing a message into the optional keypad. The keypad message format is
identical to the SMS message format.
Inputs (Advanced Use Only)
The Illuminator can monitor up to eight inputs via two multi-pole connectors. Each multi-pole
connector accepts four inputs. They are labelled IN1 to IN8 and each is provided with two
screw terminals. Wire sizes up to 1.5 mm2 may be used. Each input can be configured by the
user for operating in one of the following five modes:
1. “SWITCH” – switch closure or voltage free contact.
Switch inputs detect either an active (or “ON”) state or an inactive (or “OFF”) state.
The active state is indicated by shorting the two terminals together, while the inactive
state is indicated by the terminals staying open. A switch state must be stable for a
minimum of 3 seconds to be recognised.
NOTE: There is no galvanic isolation between different inputs or the Illuminator
internal circuitry.
2. “ANALOGUE”
Analogue inputs are used to monitor industrial sensors such as voltage, current,
temperature, pressure, light level etc.
Most common sensor types are supported, including:
4 - 20 mA sensors
0 – 5V sensors
NOTE: All analogue signals share a common ground
3. “COUNTER”
Count will increment each time the terminals are shorted. Frequencies up to 10Hz are
supported. The counter will roll-over from 99,999 to 0.
4. “EVENT”
Event inputs are used to record occurrences of pulses. A pulse is generated by
temporarily shorting the input terminals together. Minimum acceptable pulse width is
100 ms. Event inputs are suitable for monitoring pulses that occur less frequently
than once every 30 seconds. Each time an event occurs, the Illuminator logs the time
its occurrence as well as the total number of events. The total will roll-over from
99,999 to 0.
5. “DISABLED”
This mode disables the input. The input is removed from all reports and menus.
The user can tailor the system by assigning application specific input names. So for example
Input 1 may be called “PUMP 3 OK” etc.
All input types may be logged and/or used to trigger alarms.

HALYTECH Illuminator User Manual
Page 8
Alarms (Advanced Use Only)
The Illuminator can generate up to 8 alarms.
Upon activation, an alarm will send SMS messages
Each alarm can be programmed with a name, trigger source, 3 separate telephone numbers
and the text of a message. When the trigger becomes active, the alarm is triggered and the
alarm sequence starts.
Alarms are completely independent from inputs. So for example, an input can trigger more
than one alarm, each of which will send its own special SMS to its own special telephone
numbers.
Alarm SMS sending
If SMS sending is enabled for an alarm, an SMS with the programmed text is sent to each
telephone number starting with the first. If sending is successful, the unit waits for 30 minutes
for the user to reset the alarm sequence. Resetting the sequence stops the sending of SMS
messages.
If sending is not successful, due to network congestion for example, the SMS is sent to the
same number after 1 minute. Up to three attempts are made to each number before
proceeding to the next number.
After the 3rd attempt to the 3rd number (if applicable) the unit will stop sending SMS and wait
indefinitely for the alarm to be reset. This limits the number of SMS transmissions per alarm to
9.
Active alarms can be reset in two different ways:
1. By accessing the “Alarms” page with a browser and clicking on the active alarm
2. By sending an SMS message to the Illuminator
(Please see “Resetting Alarms” section for more details).
If an alarm is reset but its trigger source is still in the active state, a new alarm sequence will
NOT commence. Rather, the Illuminator will wait for the trigger source to first go inactive.
Logger
The Illuminator incorporates a high capacity solid-state data logger. The logger stores data
into non-volatile memory, maintaining its contents in the event of power supply failure.
All records are date/time stamped to a resolution of one second.
The Illuminator logs
1. Input changes
2. Control changes
3. Alarm activations and resets
4. SMS transmissions and their outcomes
5. SMS command reception
6. Numeric keypad activity
7. E-mail transmissions and their outcomes (if e-mail option installed)
8. System messages
Digital inputs are logged automatically whenever a change occurs.

HALYTECH Illuminator User Manual
Page 9
Web Server
A sophisticated web server is built into every Illuminator.
It allows users to communicate with the Illuminator using the familiar “Internet surfing”
approach. You can use any computer regardless of type and operating system to connect to
an Illuminator. NO SPECIAL SOFTWARE is required.
The web server is used for:
1. Setting up an Illuminator for the first time
2. Setting up clubs
3. Controlling floodlights
4. Monitoring inputs
5. Monitoring and resetting alarms
6. Downloading reports and logged data
7. Software upgrades
All operations are performed by accessing simple web pages.

HALYTECH Illuminator User Manual
Page 10
Physical Connections
Antenna
Each Illuminator is supplied with a panel-mount “whip” antenna suitable for most applications.
Directional antennas with higher gains are available for fringe areas. Also available are Puck
style antennas designed to minimise vandalism.
Attach the antenna to the antenna connector located on the top of the Illuminator case. Hand
tighten only. Using tools to tighten antenna connectors may damage them, voiding the
warranty.
Power
Illuminator does not have an ON / OFF switch. The unit starts operating as soon as power is
applied.
The unit is fitted with two power connectors:
 Charger – for connection of an external mains power supply
 Battery – for connection of an optional external rechargeable battery
An Illuminator is normally powered by the supplied mains powered power supply (“plugpack”).
An external rechargeable battery can be also connected to provide back-up power in case of
mains power failures.
Simply connect the mains power supply to the “CHG” connector and the battery to the battery
connector socket – as shown in the illustrations above.
IMPORTANT NOTE:
You must observe the correct polarity when connecting the power supply and the battery.

HALYTECH Illuminator User Manual
Page 11
Controls
Controls are connected to terminals marked CN1 to CN8.
Each control provides normally open relay contacts rated to 30V, 1A resistive loads.
To drive your floodlight contactors you will need to install external isolation relays. These
relays serve a dual purpose:
 They isolate the Illuminator from potentially dangerous 240V circuits
 They provide a suitable contact rating for driving the floodlight contactors.
The Illuminator provides voltage free relay contacts. Consequently you will also need a
separate power supply to drive the isolation relay coils.
NOTE: External protection diodes must be installed across all external isolation relay coils
if the coils are driven by DC power supplies. A set of protection diodes is provided with each
Illuminator.
The circuit diagram below shows how to interface the Illuminator to the isolation relays.
(Only a single control is shown for clarity.)

HALYTECH Illuminator User Manual
Page 12
An example of the external isolation relay setup is shown below in the picture. This particular
setup is configured for driving 4 contactors – hence there are 4 isolation relays. Your
electrician will be able supply the isolation relays as a part of the Illuminator installation.
Inputs (Advanced Use Only)
Inputs are connected to terminals marked IN1 to IN8.
1. “SWITCH”, "COUNTER" and "EVENT" type:
+
-
Illuminator system ground
Illuminator
IN X
Switch

HALYTECH Illuminator User Manual
Page 13
2. “ANALOGUE” type accepts an analogue voltage from 0 – 2.5V. The following
diagrams show wiring details for most common sensor types.
(i) 2-WIRE 0 - 20 mA and 4 – 20 mA current loop sensors require an external 120
Ohm, ¼ W resistor (supplied):
(ii) 4-WIRE 0 - 20 mA and 4 – 20 mA current loop sensors require an external 120
Ohm, ¼ W resistor:
(ii) Voltage inputs may require up to two external resistors:
SENSOR RANGE
V
ALUE OF Rx
V
ALUE OF R
y
0
–
2.5V None required Leave ou
t
0
–
5V 1 Kohm ¼ W metal film 1 Kohm ¼ W metal film
0
–
10V 3.3 Kohm ¼ W metal film 1 Kohm ¼ W metal film
Senso
r
+
+
-
-
Power
Supply
+
-
Illuminator system ground
Illuminator
IN X
120 Ohm ¼ W
Resistor
+
-
Sensor
+
-
Illuminator system ground
Illuminator
IN X
Ry
Rx
Senso
r
+
+
-
-
Power
Supply
+
-
Illuminator system ground
Illuminator SMS
LC
IN X
120 Ohm ¼ W
Resistor
+
-

HALYTECH Illuminator User Manual
Page 14
Auxiliary Connectors
Local Area Network (LAN) connector is used for connections to a PC or to a LAN.
AUX1 connector is not used in a standard Illuminator. It is reserved for future enhancements
and special applications.
The optional keypad plugs into AUX2 connector.
ILLUMINATOR AUXILIARY CONNECTORS

HALYTECH Illuminator User Manual
Page 15
Numeric Keypad
An optional numeric keypad can be used to control floodlights. It is provided for users who do
not have access to mobile phones. The keypad can be added at any time. The Illuminator will
automatically recognise the keypad and start acting on its commands.
Please refer to “Numeric Keypad” for details on how to use the keypad.
Each keypad is supplied with 10m of cable. One end of the cable is terminated in a DB9
connector at the factory. The DB9 connector plugs into Illuminator AUX2 connector. The
Illuminator provides all power and communications signals to the keypad.
The other end of the cable is attached to the numeric keypad screw terminal block as shown
in the diagram below.
NOTES:
1. The keypad is not weatherproof. It must be installed in a suitable location protected
from the elements.
2. Keep the cable as short as possible and route it away from other wiring. This will
minimise any problems that may occur in electrically noisy environments. Do not roll
up excess cable. Instead, cut the unterminated end to size.
3. Some cables may have a blue wire instead of a green one.
NUMERIC KEYPAD CONNECTION DIAGRAM

HALYTECH Illuminator User Manual
Page 16
Setting up an Illuminator for the first time
A new Illuminator must be connected to a mobile telephone network by inserting a valid SIM
card. Please refer to Appendix C for details.
A new Illuminator is shipped from the factory with a default, generic setup. You will need to
change this setup to customise the Illuminator for your application.
Setting up an Illuminator involves one or more of the following steps:
1. Setting Illuminator location and lighting setup
2. Setting Illuminator date and time
3. Setting your username and password
4. Setting network and e-mail settings
(Setting up clubs, their PINs and access rights is covered in the section “Normal Operation”.)
Connect locally to the Illuminator as described in Appendix A.
The "Lights" page will be displayed.
Click on “Change Setup” in the blue menu pane on the left. The following page will be
displayed:
IMPORTANT: Make sure that ‘Standalone Mode’ is selected at the top of the page.
(Halytech setup of Illuminators connected to Illuminator Central is included in the subscription
and is not normally performed by the end user.)
NOTE: Accessing the “Change Setup” page automatically disables logging and alarm
generation and also resets all active alarms.

HALYTECH Illuminator User Manual
Page 17
Change Location and Lighting Setup
It is important to choose a unique location name for every Illuminator. This location name is
sent at the beginning of each SMS transmission to identify the particular Illuminator device.
If not already displayed, access the “Change Setup” page as described in “Setting up an
Illuminator for the first time” above.
Click “Change Location & Lighting Setup”.
Settings common to all lighting scenarios are available for modification on the top half of the
page.
Enter a unique location name for this particular Illuminator. The name can be up to 16
characters long. For this example, let’s use “Wingham Field” as the name. Simply type this
into the space provided.
Invalid SMS commands generate an appropriate response, advising the user of the problem.
'Help contact person' contains the name and the telephone number that users can call if they
have problems with SMS commands. These contact details are added to the end of the SMS
sent in response to an invalid command.
'Maximum on time (minutes)' sets the maximum time that lights can be left on. For normal
users this works in conjunction with the periods during the day in which they are allowed to
control lights.
'Turn off delay (minutes)' is useful for classic (non-LED) lights.
If a user commands the Illuminator to turn the lights off, the command is accepted but the
lights are kept on for the number of minutes entered here. This gives a chance to a new user
to turn the lights back on without having to wait for the warm-up period.
'Turn on delay (seconds)' is useful when the Illuminator is commanded to simultaneously
activate multiple controls. Instead of turning on all relevant controls at exactly the same time,
they are turned on in a staggered manner, the entered number of seconds apart. This
minimises potentially large inrush currents that could trip circuit breakers etc.
‘Cost per kWh’ is used to calculate actual lighting cost in dollars, based on the cost of
electricity entered here and the power rating of individual lighting scenarios discussed in the
next paragraph.
The bottom half of the page is used to define power rating of lighting circuits and how
individual lighting scenarios act on physical Illuminator controls that drive actual lighting
circuits via contactors.
The information entered here is based purely on how the lighting circuits have been wired up
by your electrician.

HALYTECH Illuminator User Manual
Page 18
Two simple setup configurations will be described to illustrate common lighting scenarios.
Setup 1:
Two independent scenarios
 Athletics Oval where all lights come on together. Combined power of all lights is 12 kW
 Soccer Oval where all lights come on together. Combined power of all lights is 16 kW
Only two out of eight Illuminator controls are needed in this example. Let’s assume that
Illuminator Control 1 is driving the contactor that turns on Athletic Oval lights, and that
Illuminator Control 2 is driving the contactor that turns on Soccer Oval lights
This information is entered as follows:
Setup 2:
Two scenarios that share one or more common Illuminator controls
 Soccer 50 lux where half of the lights come on. The power of this portion of the lights is 9
kW
 Soccer 100 lux where all of the lights come on. The power of the additional half of the
lights is 11 kW, for a total of 20kW
Only two out of eight Illuminator controls are needed in this example. Let’s assume that
Illuminator Control 1 is driving the contactor that turns on the first half of the lights, and that
Illuminator Control 2 is driving the contactor that turns on the second half of the lights.
This information is entered as follows:
You can exit at any time without making changes by clicking the “Cancel” button.
Save the new values by clicking on the “Save” button.

HALYTECH Illuminator User Manual
Page 19
Setting Date and Time
If not already displayed, access the “Change Setup” page as described in “Setting up an
Illuminator for the first time”.
Click “Time & Date”.
Confirm that the displayed date and time are correct. If you wish to change the date and/or
time simply enter the new values or click “Set from computer” to synchronise the date and
time with that of your computer.
Next select the Timezone appropriate to your location. Any applicable Daylight saving time
adjustments will be made automatically.
Enter the current date and time then click the
- “Set” button to set the date/time and return to the “Change Setup” page
- “Cancel” button to return to “Change Setup” page without altering the date/time
Click the “Set from computer” button to set the date and time to be the same as your
computer and return to the “Change Setup” page

HALYTECH Illuminator User Manual
Page 20
Change User and Password
Only authorised personnel may access an Illuminator. To connect to an Illuminator you must
enter a valid user name and password. Failing to enter them, disables all access to the
Illuminator. Similarly, if a valid sequence is entered, but no activity takes place for 10 minutes,
the access is revoked and the user must again log in.
Both the user name and the password can be set. Factory defaults are “user” and
“changeme” respectively. It is strongly advised that these be changed as soon as possible to
prevent unauthorised access.
In the event that you forget your new user name or password, you will no longer be able to
connect to an Illuminator. Please contact Halytech or an authorised distributor for assistance.
To change the user name and/or password access the “Change Setup” page as described in
“Setting up an Illuminator for the first time” earlier in this section.
Click “User & Password”.
Enter the new user name and password.
You can exit at any time without making changes by clicking the “Cancel” button.
Save the new values by clicking on the “Save” button.
