HAMECO HV-44 User manual
User Manual
HV-44
Desktop HD
Video Camera
hameco
www.hameco.eu
www.hameco.eu
HV-44 User Manual
hameco
2
Content
1. Quick Installation .................................................................... 3
1.1 Product Interfaces .................................................................. 3
1.2 Using the Product ................................................................... 4
2. Product Intoduction ................................................................ 4
2.1 Product Introduction .............................................................. 4
2.2 Product Features .................................................................... 5
2.3 Technical Parameters .......................................................... 6
4. Maintenance and Troubleshooting ...................................... 8
4.1 Camera Maintenance .............................................................. 8
4.2 Troubleshooting ...................................................................... 8
5. Product Disposal ...................................................................... 8
www.hameco.eu
HV-44 User Manual
hameco
3
1. QUICK INSTALLATION INSTRUCTIONS
1.1. Product Interfaces
1. Lens(xed) 3.USB2.0 cable outlet hole(unplug) 5.Screw hole for tripod
2. Audio IN(built in pick-up) 4. Flexible clip/base 6.Mounting and locating
holes
Picture 1.1 Interfaces Instructions
The USB 2.0 port available for plug and play, controls video output and powers the camera.
1.2. Using of the Product
1) Place the webcam on an LCD screen, the top of a laptop, desk or tripod directly.
2) Connect the USB cable with computer, video conference devices or other
USB input device.
3) Open the video software, select the video device to get video output.
www.hameco.eu
HV-44 User Manual
hameco
4
2. PRODUCT INTRODUCTION
2.1. Product Introduction
Product Dimensions
Pic. 2.1 Dimensions
Check and conrm all accessories are provided when opening the package:
• User Manual x 1
• Warranty Card x 1
www.hameco.eu
HV-44 User Manual
hameco
5
2.2. Product Features
HV-44 features perfect functions and excellent performance.
Adopts advanced ISP processing algorithms soas to provide vivid images with evenly
clear brightness, strong color layering, high resolution, and fantastic colorrendition.
Easy and convenient to install and maintain, stable and reliable.
Advantages
a. High-denition Image: high quality CMOS sensor. Supports compression of resolu-
tion up to 1920x1080 with frames up to 30fps. Provides clear, vivid HD image.
b. Multiple installation: Free to choose the place of installation, the device has a x
clamp which enables it to be installed on an LCD screen, the top of laptop or directly on
a desk and tripod.
c. Wide Application: Personal Video Platform, Videoconferencing, Cooperative Oce
etc..
d. Convenient application: No need to download driver or extra software, making usage
convenient and easy.
Features:
a. USB2.0: Easy plug and play, power and upgrade support.
b. Lens Option: 80 degree wide angle lens.
c. Built-in Mic: Built-in microphone pickup, for clear and natural stereo sound without
external pickup equipment.
d. Multiple Video Encoding: Supports H.264, H.26, .MJPEG, YUV video encoding
which enables the video to play more uently.
www.hameco.eu
HV-44 User Manual
hameco
6
Model Number HV-44
Camera Parameter
Image Sensor high quality CMOS sensor
Eective Pixels 2.07MP,16:9
Video Resolution
USB Output:
960x540/320x180/432x240/640x360/800x448/800x600/864x480/960x-
720/1024x576/
1280x720/1600x896/1920x1080/272x144/368x208/384x216/480x-
272/624x352/
912x512/424x240/640x480/320x240/160x120/P30
View Angle 88°(D) /80°(H)/ 50°(V)
Focal Length 3.24mm
Min Illumination 0.5Lux(F1.8, AGC ON)
Focus Manual
AF Fixed
Backlight contrast On/O
Exposure Auto/Manual
Video Adjustments Brightness, Denition, Saturation, Contrast, white balance, gain,
anti-icker, low brightnesscompensation adjustable
SNR >50dB
2.3. Technical Parameters
www.hameco.eu
HV-44 User Manual
hameco
7
Output Parameters
Video Output USB2.0(Power, upgrade support)
Video Compression MJPEG,YUV2,H.264,H.265
Audio Input Inbuilt omni-directional mics
Other Parameters
Input Voltage 5V
Input Current 500mA (max)
Power 2,5 W (max)
Storage Tempreture -10oC~ +60oC
Storage Humidity 20% ~ 95%
Working Tempreture -10oC ~ +50oC
Working Humidity 20% ~ 80%
Dimension 102mm*46mm*30mm
Weight 0.15kg
Accessory User Manual, Warranty card
www.hameco.eu
HV-44 User Manual
hameco
8
3.MAINTENANCE AND TROUBLESHOOTING
3.1. Maintenance
1) If camera is not used for a long time, please turn o power adapter switch and
AC plug.
2) Use a soft cloth or tissue to clean the camera cover.
3) Use soft cloth to clean the lens; Use a neutral cleanser if necessary. Do NOT use strong
corrosive cleansers as this may damage the lens.
3.2. Troubleshooting
No video output
a. Make sure the camera’s USB Cable is connected properly, USB Port is normal, and Pow-
er indication light on.
b. Disconnect the camera from the computer and re-connect by USB.
c. Make sure the video software selects the right device.
4.PRODUCT DISPOSAL
Safety
For your own safety, this product should only be used with CE and RoHS approved
equipment. Using this product with non-approved equipment would void the warranty.
Disposal of your product
Municipal waste stream. Old appliances must be collected separately in order to optimise
the recovery and recycling of the materials to reduce the impact on human health and
the environment. The crossed out “wheeled bin” symbol on the product reminds you of
your obligation that when you dispose of the appliance, it must be separately collected.
Consumers should contact their local authority or retailer for information concerning
the correct disposal of their old appliance
This product is in conformity with the relevant EU harmonisation legislation.
