Hamilton/Buhl AMP37 User manual

Never-Ending Learning Innovation
Slim and Powerful 2.0 Channel Bluetooth®Soundbar
80 Little Falls Road, Fairfield, NJ 07004 • 1-800-631-0868 • www.HamiltonBuhl.com
Instruction Manual
Model #: AMP37

2
Amplitude™Soundbar
In the Box
1. Amplitude™Soundbar
2. Remote Control
3. Digital Optical Cable
4. Wall Mounting Brackets and Screws
This electronic unit contains material that should be recycled,
if discarded. When discarding, please take it to your local
recycle center. To discard packing material and used batteries,
please follow your local regulations.
Table of Contents
Introduction and Table of Contents .............................................................................................2
In the Box ..................................................................................................................................2
Warnings and Precautions ........................................................................................................3
Features ....................................................................................................................................3
Remote Features and Controls .................................................................................................4
LED Indicators...........................................................................................................................4
Connections...............................................................................................................................5
Basic Operations .......................................................................................................................6
Placement of the Unit ................................................................................................................6
Installation .................................................................................................................................7
Warranty ....................................................................................................................................8
Amplitude™
Thank you for choosing Amplitude™Slim and Powerful 2.0 Channel Bluetooth®Soundbar
from HamiltonBuhl. Please read this user manual carefully before operating.
5. Tabletop Stands
6. 3.5mm Stereo Audio Cable
7. Power Cable
8. AC Adapter
1
543
2 6 78

3
Amplitude™Soundbar
Warnings and Precautions
Warning:
• Follow warnings and cautions carefully to avoid risk of fire or electric shock.
• Ensure air circulates freely through the ventilation holes on this unit.
Allow at least 2” ~ 4” clearance around the unit.
• Do not expose this unit to direct sunlight, flames or heat.
• Keep this unit away from water, moisture and liquid-filled objects.
• Do not place this unit on top of other electrical equipment.
• Unplug this unit during lighting storms.
• Opening up this unit will void factory warranty.
Caution:
• Remove dead batteries immediately.
• Remove batteries if not in use for extended period of time.
• Do not mix old and new batteries.
• Properly dispose all batteries.
Features
• Latest MAXXBASS sound technology gives a richer, deeper and stronger dynamic bass.
• Slim, attractive, compact design.
• Various audio source inputs make it the ideal choice for home theater systems.
• Three preset sound modes allow you to change the sound as needed (Music, Movie
and Night).
• Supports Bluetooth®, Digital optical and AUX-In.

4
Amplitude™Soundbar
Remote Control Functions
1. Power On/Off
2. Reset
3. Mute
4. Volume Up
5. Volume Down
6. Bass Up
7. Bass Down
8. Treble Up
9. Treble Down
10. Bluetooth®
11. AUX Input 1
12. AUX Input 2
13. Digital Optical Input
14. Preset Sound Modes
1
23
4
5
6
7
9 8
11
4
10
12
13
LED Indicator Lights
• LED #1 (White) - Digital Optical input indicator
• LED #2 (Blue) - Bluetooth®input indicator
• LED #3 (Yellow) - AUX2 input indicator
• LED #4 (Green) - AUX1 input indicator
• LED #5 (Red) - Power indicator, volume indicator and preset mode switch indicator
Note: Please wait for a few seconds to see indicator lights when you first turn on or change input
on the unit.
12345

5
Amplitude™Soundbar
Connections
Note: Please connect the audio cables before switching on the unit.
1. DC input (Use the supplied power AC adapter - 18V/4A)
2. Digital optical digital audio input
3. AUX-In 1 and AUX-In 2: 3.5mm audio input interface, compatible with MP3 players, smart
phones and computers, etc.
4. Power On/Off button
5. Volume up button
6. Preset sound mode switch (Music/Movie/Night)
7. Volume down
Note: Make sure to match your cable with the corresponding input mode - the unit will store the
last input mode when you turn off to standby mode.
3
1
2
4
5
6
7

6
Amplitude™Soundbar
Basic Operations
Reset: The reset button returns the treble and bass levels to the factory default settings.
Preset Sound Settings:
There are three preset sound modes according to various contents.
• Music mode: Deeper bass with more dynamic sound ranges.
• Movie mode: Provides a surround sound effect.
• Night mode: Less bass and more clear vocals - ideal for news, radio, sports programming, etc.
LED Indicator:
The red LED will flash rapidly when volume, treble or bass is adjusted up or down. It will stop
flashing when it reaches maximum or minimum level.
When the unit is plugged in, it will be in Standby mode - the red LED is on. Once the power
button is pressed, the red LED will turn off and the previously selected signal input LED will
light up.
The desired signal inputs can be selected with remote control by pressing the various source
button options (i.e., AUX1, AUX2, Digital optical or Bluetooth®.)
When you press the preset sound modes (Music/Movie/Night), the red LED will flash twice
rapidly then the selected input LED will light up.
Bluetooth®Connection:
Turn on the unit then press Bluetooth®button from remote control to select Bluetooth®input.
When the blue LED light is flashing rapidly, the unit is scanning for a Bluetooth®enabled device
to pair. Turn on Bluetooth®in your enabled device and within the setup screen, search and select
“AMP37”. When prompted, enter passcode “0000” (four zeros). Once pairing is successful, the
blue LED light will become solid - the unit is ready to play.
Note: The unit will automatically connect with the device it was last paired with, when it is in range.
Placement of the Unit
For optimum sound quality, when seated, position soundbar at mid-torso level or at least
above the knees. The front of the soundbar should be clear of any objects. If the unit is
placed on a table, make sure to position the unit at least 4” away from a wall.

7
Amplitude™Soundbar
Installation
Caution: This device should only be installed by adults.
Install this soundbar below your TV set, with at least 4” (10cm) between the TV set and
the brackets.
1. Ensure all the cables are connected to the unit.
2. Install the supplied screws to the rear of this unit.
3. Drill screw holes and insert the provided
plastic mounts in preparation to affixing
wall brackets.
4. Utilizing the provided screws tightly
screw in the wall brackets into
previously prepared plastic mounts.
5. Align the mounting screws on the
soundbar with the wall brackets and
slip into place. Make sure the soundbar
is mounted firmly.
12.36” (314 mm)
Troubleshooting
Problem Reasons Solution
No sound Audio cables not properly connected or
not switched to the correct input mode.
Ensure audio cables are properly
connected with correct input mode
selected via remote control.
No power Power may be off. Ensure power is connected – press the
“On/Off” button on the remote control.
Remote unresponsive
Remote control not communicating
with soundbar.
Direct remote control to the unit without
any obstructions.
Remote control is too far away from
the main unit. Use remote control within 20 feet.
Remote control batteries are dead. Insert new batteries.
No sound on
Bluetooth®mode Not paired with Bluetooth®device. Pair according to Bluetooth®connection instructions.

Amplitude™ — 10/2016
v.1
80 Little Falls Road, Fairfield, NJ 07004
1-800-631-0868
www.HamiltonBuhl.com
Never-Ending Learning Innovation
Product Registration Instructions
Visit: www.HamiltonBuhl.com
1. Click on Customer Care
2. Click on Product Registration Icon
3. Please fill out all fields marked with * to register
W
A
R
R
A
N
T
Y
Warranty:
Warranty begins the date item ships from our warehouse. All products, except for metal
carts, have a one year warranty from original date of shipment, unless otherwise noted.
Metal carts have a limited lifetime warranty on all housing components; however, carts
have a one year warranty on any electrical / mechanical components.
