H&B HF-355 User manual

MODEL: HF-355
RE: SYSTEM SET UP PROCEDURE INSTRUCTION
- INCLUDED 1 PC STAND FOR THE MAIN UNIT ( )
FIXING THE BASE TO THE MAIN UNIT:
- INCLUDED 2 PCS STAND FOR THE SPEAKERS ( )
WHEN THESE
ARROWS ARE ALIGNED
THE BASE IS PROPERLY
INSTALLED ONTO MAIN UNIT
SYSTEM SET UP PROCEDURE
A. AS A "SHELF SYSTEM" (TABLE TOP USE)
1. PLACE THE STAND UNDER
THE MAIN UNIT OR SPEAKERS
2. SLIDE THE STAND FROM DOWN TO
UPWARD (SEE DIAGRAM BELOW).
3. STOP WHEN ARROWS ARE ALIGNED (SEE DIAGRAM).
THE STAND IS NOW LOCKED TO MAIN UNIT OR SPEAKERS.
(TO RELEASE THE STAND FROM THE MAIN UNIT OR SPEAKERS, SLIDE THE
STAND FROM DOWN TO UPWARD (OPPOSITE DIRECTION) UNTIL IT BECOMES
RELEASED.
CLICK

WA R NING : To reduce
the risk of electric shock, do
not remove cover (or back).
No user-serviceable
parts inside. R efer
servicing to qualified
service personnel.
C AUTION
R IS K OF E L E C TR IC S HOC K
DO NOT OP E N
The exclamation
point within the
triangle is a warning
sign alerting you of
important instructions
accompanying the
product.
The lightning flash
and arrowhead
within the triangle
is a warning
sign alerting you of
"dangerous voltage"
inside the product.
C AUT ION
DO NOT E XP OS E T O DR IP P ING O R S P LAS HING L IQUIDS !
WA R NING :
TO R E DUC E THE R IS K OF FIR E OR E LE C TR IC S HOC K, DO NOT
E XP OS E T HIS AP P LIANC E T O DR IP P ING O R S P LAS HING LIQUIDS .
E -2
C LA S S 1 L AS E R P R ODU CT
K L A S S E 1 L A S E R P R O DUK T
L A S E R DE C L A S S E
L AS E R DI P R IMA C L AS S E
K L AS S E 1 L AS E R
L AS E R P R IME R A C L AS E
L AS E R C L AS S E 1
K L AS S E 1 L AS E R PR ODU K T
C A UTIO N: INVIS IB LE LAS E R R ADIATION WHE N OP E N AND
INT E R LOC K S DE F E ATE D. AV OID E XP OS UR E TO B E AM.
V OR S IC HT: U NS IC HT B A R E L A S E R S T R A HL UNG T R IT T A US ,
WE NN DE C K E L G E ÖFFNE T UND WE NN S IC HE R HE IT S VE R R IE GE LUNG
ÜB E R B R ÜC K T IS T. NIC HT DE M S TR A HL A US S E T ZE NI.
VAR NING : OS Y NL IG L AS E R S TR ÁLNING NÄ R DE NNA DE L ÄR ÖP PNAD OC H
S P Ä R R Ä R UR K O P P L AND. S T R Á L E N Ä R FA R L IG .
A DVA R S E L : US Y NL IG L A S E R S T R Á L IN G V E D Á B N ING . NÁ R
S IK K E R HE DS AFB R YDE R E E R UDE A F F UNK T ION. UNDG Á UDS /E T TE L S E FOR
S T R Á L ING .
ATTNE NZIONE : R A DIONS L AS E R INVIS IDIL E . NON GUAR DA R E
DIR E T TAME NTE NE L LA S OR GE NTE DE L L AS E R .
A C HTUNG : L AS E R L INS E NIC HT B E R ÜHR E N UNS IC HT B AR E R L AS E R S TR AHL.
AVIS O: A L E NT E NUNC A DE VE S E R T OCADA.
C AUT ION: G R OUNDING OR P O LAR IZATION. T HE P R E C AUT IONS
S HOULD B E TAK E N S O THAT THE WIDE R B LADE OF THE AC P LUG
MUS T MATC H T HE S LOT IN R E C E P TAC LE "WALL S OC K E T ".
US E R MANUAL
U S B
FLASHMEMORY
PLAYBACK
RE MO TE
CO N TRO L
B L U E
B A C K L IG HT
DIS P L AY
C L O C K
QUARTZ
DIGITAL
HIG H OUTPUT MIC R O S HE L F S Y S TE M
DIG IT AL C D-R ADIO-C L OC K HI-FI
WITH WAL L MOUNTING C APAB IL IT Y
MODE L : HF-355
D IG ITA L
P L A Y B A C K
M P 3
P L L
DIG ITA L
TUNE R
HF-355

E-3
QUICK START !
1. CONNECT THE SPEAKERS & TABLE STANDS
2. PLUG AC-CORD INTO WALL SOCKET & UNWRAP THE FM-ANTENNA WIRE
3. PRESS “POWER” KEY TO SWITCH “ON” THE UNIT
(CONTINUED)
E-4
5. TO LISTEN TO RADIO
5. PRESS “POWER” KEY TO POWER "OFF" THE UNIT ("STANDBY MODE")
(CONTINUED)
END
- PRESS "TUNER/BAND" KEY TO SWITCH TO RADIO (TUNER) MODE
- PRESS "TUNER" KEY TO SWITCH TO "FM" RADIO BAND.
- PRESS "TUNER" KEY AGAIN TO SWITCH TO "AM" RADIO BAND.
- PRESS & RELEASE NEXT TO TUNE RADIO FREQUENCY UP (1-STEP).
- PRESS & RELEASE BACK TO TUNE RADIO FREQUENCY DOWN (1-STEP).
- “PRESS & HOLD” NEXT (2 SECS.) TO SCAN UP (TO SEEK NEXT STATION).
- “PRESS & HOLD” BACK (2 SECS.) TO SCAN DOWN (TO SEEK PREV. STATION).
PRESS "BACK" TO TUNE DOWN
PRESS "NEXT" TO TUNE UP
P
S
R
D
I
N
R
T
A
S
W
I
D
T
E
U
O
4. TO LISTEN TO CD-PLAYER
- PRESS "FUNCTION" KEY REPEATEDLY UNTIL "CD" IS DISPLAYED
- PRESS "OPEN/CLOSE" KEY
- INSERT A DISC (CD-AUDIO or CD-MP3)
- PRESS "PLAY" KEY ( ) TO START PLAYING CD
- ADJUST VOLUME (VOL+) or (VOL )
FM-ANTENNA WIRE

E-5
LOCATION OF CONTROLS
18. USB SOCKET
19. SLEEP KEY
20. EQ (EQUALIZER) KEY
21. TIMER KEY
22. CD REPEAT KEY
23. DESK STAND (FOR MAIN UNIT)
24. SPEAKERS (LEFT & RIGHT)
25. STANDS (FOR SPEAKERS)
26. SPEAKER-OUT SOCKETS (LEFT & RIGHT)
27. HEADPHONE JACK
28. AUDIO LINE IN SOCKET [DVD/AUX]
(LEFT & RIGHT)
29. SUB WOOFER OUTPUT
30. BACK UP BATTERY COMPARTMENT
(BEHIND THE UNIT)
31. AC-CORD & PLUG
32. FM-ANTENNA WIRE
21
2325
3
45
6
9
10
13
15
16
17
14
7
8
11
12
19
20
21
22
26
2/
29
31 32
30
24
27
25
24
E-6
POWER SUPPLY
- THIS SET WORKS ON NORMAL HOUSEHOLD AC-POWER.
- MAKE SURE THE SET VOLTAGE OF THE UNIT MATCHES YOUR LOCAL VOLTAGE.
- INSERT THE PLUG OF THE AC-CORD INTO A WALL OUTLET WITH AC-POWER.
- PRESS THE “POWER” ON/ OFF KEY TO SWITCH “ON” THE UNIT.
WHEN THE POWER IS “ON” THE ENTIRE DIGITAL DISPLAY WILL BE LIT UP WITH
A “BLUE” BACK-LIGHT. THIS INDICATES THE HI-FI IS SWITCHED “ON”.
IMPORTANT : HOW TO TELL IF POWER IS "ON" ?
CONNECTION OF SPEAKER BOXES
- PLACE THE SPEAKER BOXES AS FAR APART AS POSSIBLE FOR BEST SOUND EFFECT.
- UNWRAP THE SPEAKER-CORDS OF BOTH SPEAKER-BOXES.
- INSERT THE "RED" WIRE OF THE LEFT SPEAKER-BOX INTO THE "RED" ( + ) SPEAKER
CONNECTOR BEHIND THE MAIN-UNIT, WHICH HAS THE "L" INDICATION (UNDER THE
SPEAKER-CONNECTOR).
- INSERT THE "BLACK" WIRE OF THE LEFT SPEAKER-BOX INTO THE "BLACK" ( - )
SPEAKER CONNECTOR BEHIND THE MAIN-UNIT, WHICH HAS THE "L" INDICATION
(UNDER THE SPEAKER-CONNECTOR).
- REPEAT THE ABOVE 2 STEPS FOR THE RED & BLACK WIRES OF THE "RIGHT"
SPEAKER BOX, BUT THIS TIME, INSERTING THEM INTO THE RED & BLACK
CONNECTORS WITH THE "R" INDICATION.
- WHEN INSERTING EACH WIRE INTO A CONNECTOR, PRESS DOWNWARDS ON
THE CONNECTOR'S PLASTIC KNOB (RED OR BLACK PART) & PUSH THE EXPOSED
METAL END OF THE WIRE ALL THE WAY INTO THE HOLE ABOVE THIS KNOB.
- THIS UNIT IS DESIGNED TO OPERATE WITHOUT EVER BEING TOTALLY POWERED "OFF".
IT WILL EITHER BE "ON" OR "STANDBY MODE".
- IN STANDBY MODE, THE BLUE BACK-LIGHT OF THE DIGITAL DISPLAY WILL BE
SWITCHED OFF BUT THE DISPLAY WILL SHOW THE CURRENT TIME (CLOCK FUNCTION).
- WHEN IN STANDBY MODE, YOU CAN USE THE POWER SWITCH (ON REMOTE CONTROL
OR ON FRONT PANEL OF THE MAIN UNIT) TO SWITCH "ON" THE UNIT.
- TO CONSERVE ELECTRICITY, PLEASE SWITCH THE UNIT TO "STANDBY MODE"
WHEN NOT LISTENING TO RADIO OR CD MUSIC.
REMOTE CONTROL
LOCATION OF REMOTE CONTROLS
1. POWER ON/ OFF BUTTON
2. FIND/ M/S KEY
3. TIMER KEY
4. EQ KEY
5. SLEEP KEY
6. MEMORY DOWN KEY
7. BAND KEY
8. INTRO/ M/ S KEY
9. RANDOM KEY
10. REPEAT KEY
11. MEMORY UP KEY
12. DIRECT KEYS (NUMBER KEYS)
13. MUTE KEY
14. MEMORY/ PROGRAM
15. CD PLAY/ PAUSE
16. CD NEXT/ TUNE UP
17. CD BACK/ TUNE DOWN
18. CD STOP/ BAND
19. VOLUME UP
20. VOLUME DOWN
KEY
KEY
KEY
KEY
KEY
KEY
KEY
1
2
3
4
5
6
7
8
9
10
20
11
12
13
15
17
19 18
16
14
1. CD DOOR (MOTORIZED)
2. CD/ CLOCK/ RADIO DIGITAL
MULTIFUNCTION DISPLAY KEY
3. CD BACK/ TUNE-DOWN KEY
4. CD PLAY/ PAUSE KEY
5. CD NEXT/ TUNE-UP KEY
6. CD PROGRAM KEY
7. CD STOP KEY
8. FIND/ ESP/ DISPLAY KEY
9. MEM (+) KEY
10. FUNCTION KEY
11. TUNER/ BAND KEY
12. MEM ( ) KEY
13. OPEN/ CLOSE KEY
14. POWER ON/ OFF KEY
15. REMOTE CONTROL SENSOR
16. VOLUME UP KEY
17. VOLUME DOWN BUTTON
18

DIGITAL CLOCK FUNCTION
- THE SET HAS A BUILT-IN DIGITAL CLOCK, WHICH IS DISPLAYED WHEN THE UNIT IS
IN "STANDBY MODE" OR WHEN YOU PRESS & HOLD PROGRAM KEY FOR TWO
SECONDS DURING CD OR RADIO OPERATION.
- TO SET THE CORRECT TIME, FOLLOW THIS PROCEDURE:
HOW TO SET CORRECT TIME:
SWITCH UNIT TO "STAND-BY" MODE
(DISPLAY LIGHT = OFF)
PRESS & HOLD PROGRAM FOR 3 SECONDS
DISPLAY SHOWS HOUR OR HOUR (FLASHING)
12 24
PRESS NEXT OR BACK TO SELECT 12-HOUR
OR 24-HOUR CLOCK DISPLAY SYSTEM & PRESS
PROGRAM TO CONFIRM YOUR SELECTION
PRESS NEXT OR BACK REPEATEDLY TO SET THE
CORRECT HOUR IN THE DISPLAY & PRESS PROGRAM
TO CONFIRM
PRESS NEXT OR BACK REPEATEDLY TO SET THE
CORRECT MINUTE IN THE DISPLAY & PRESS PROGRAM
TO CONFIRM
CORRECT TIME IS NOW SET & WILL BE SHOWN
IN THE DISPLAY!
E-7
E-8
AUTOMATIC POWER ON/OFF TIMER FUNCTION
HOW TO SET TIMER
- THIS SET HAS A TIMER FUNCTION TO ENABLE YOU TO PROGRAM THE UNIT TO
AUTOMATICALLY SWITCH “ON” OR “OFF” AT PRESET TIMES. THIS IS USEFUL AS A MORNING
ALARM CLOCK :
AUTOMATIC POWER OFF SLEEP FUNCTION
- THIS SET HAS A SPECIAL SLEEP TIMER FUNCTION WHICH CAN AUTOMATICALLY
SWITCH OFF THE UNIT. THIS IS USEFUL FOR SLEEPING TO MUSIC AT NIGHT.
- AT ANY TIME WHILE THE UNIT IS OPERATING (CD PLAYER OR RADIO), PRESS
KEY REPEATEDLY TO CHOOSE THE AUTOMATIC POWER OFF TIME.
SLEEP
90
MINS
80
MINS
70
MINS
60
MINS
50
MINS
(*OFF MEANS SLEEP TIMER IS DEACTIVATED)
1. PRESS AND HOLD TIMER KEY. THE SYMBOL APPEARS IN THE DISPLAY.
2. PRESS NEXT OR BACK TO ADJUST THE HOUR OF THE DESIRED "POWER ON" TIME
AND THEN PRESS TIMER TO CONFIRM.
3. PRESS NEXT OR BACK TO ADJUST THE MINUTES OF THE DESIRED "POWER ON"
TIME AND THEN PRESS TIMER TO CONFIRM.
4. NOW THE SYMBOL IN THE DISPLAY CHANGES TO SHOW .
5. PRESS NEXT OR BACK TO ADJUST THE HOUR OF THE DESIRED "POWER OFF"
TIME AND THEN PRESS TIMER TO CONFIRM.
6. PRESS NEXT OR BACK TO ADJUST THE MINUTES OF THE DESIRED "POWER OFF"
TIME AND THEN PRESS TIMER TO CONFIRM.
7. NOW THE DISPLAY WILL INDICATE THE "WAKE UP MODE" (CD OR RADIO).
PRESS NEXT TO CHOOSE THE DESIRED MODE & PRESS TIMER TO CONFIRM
8. THE DISPLAY THEN SHOWS THE "WAKE UP VOLUME LEVEL" (LOUNDNESS).
PRESS BACK OR NEXT TO DECREASE OR INCREASE THE VOLUME LEVEL TO BE
USED FOR THE MUSIC TO BE PLAYED WHEN THE TIMER SWITCHES ON THE UNIT AT THE
PRE-SET TIME.
9. PRESS TIMER TO CONFIRM. THE UNIT WILL THEN AUTOMATICALLY DISPLAY ALL YOUR
SETTINGS IN SEQUENCE:
ON
"POWER ON TIME" ( )
ON
"POWER OFF TIME" ( )
OFF
"POWER ON MODE" (CD OR TUNER)
"POWER ON VOLUME LEVEL" (LOUDNESS)
(NOTE : THE AUTOMATIC POWER ON/OFF TIMER WILL SWITCH ON THE UNIT AS IF YOU HAVE
MANUALLY PRESSED THE “POWER” KEY. IF YOU HAVE SELECTED "WAKE TO RADIO",
THE EXACT PRESET RADIO BAND & STATION WILL BECOME ACTIVATED WHEN POWER
SWITCHES ON).
10. FINALLY THE UNIT WILL RETURN TO THE NORMAL DISPLAY, EXCEPT THAT THE SYMBOL
WILL BE SHOWN, TO INDICATE THAT YOU HAVE PROGRAMMED A POWER ON/OFF ALARM
SETTING.
11. IN CASE YOU WISH TO DISABLE THE TIMER, PRESS TIMER & THE SYMBOL DISAPPEARS.
OFF*
40
MINS
30
MINS
20
MINS
10
MINS
OFF

E-9
ELECTRONIC VOLUME CONTROL
- THIS UNIT USES AN ELECTRONIC VOLUME CONTROL .
- TO INCREASE OR DECREASE THE LOUDNESS OF UNIT, PRESS
THE VOLUME UP (VOL +) OR VOLUME DOWN (VOL -) KEYS RESPECTIVELY.
- RELEASE THE KEY WHEN VOLUME LEVEL IS AT THE DESIRED LOUDNESS.
- SOMETIMES, ESPECIALLY DURING LISTENING TO THE RADIO, YOU MAY NOTICE
A "CLICK-CLICK-CLICK" (REPEATING) SOUND WHEN YOU ARE INCREASING OR
DECREASING THE VOLUME. THIS IS A NORMAL CONDITION & THE SOUND WILL
DISAPPEAR WHEN YOU RELEASE THE VOLUME KEY (WHEN YOU REACH THE
DESIRED VOLUME LEVEL).
(PUSH BUTTON TYPE)
E-10
RADIO MEMORY (STATION PRESET MEMORY STORAGE)
- AT ANY TIME, THE CURRENTLY DISPLAYED STATION OR FREQUENCY CAN BE
STORED INTO ONE OF THE MEMORY POSITION.
- PRESS KEY ONCE.
- PRESS OR TO SELECT DESIRED MEMORY POSITION. (THERE ARE
10 MEMORY POSITIONS FOR EACH RADIO BAND).
- PRESS KEY ONCE TO SAVE THE SELECTED STATION INTO THE
SELECTED MEMORY POSITION.
- TO RECALL ANY SAVED MEMORY, SIMPLY PRESS OR , THE SAVED
RADIO-BAND WILL BE RECALLED.
- TO CLEAR THE MEMORY OF ANY POSITION, SIMPLY SAVE A NEW STATION TO
THE SAME MEMORY POSITION.
PROGRAM
M+ M-
M+ M-
INSERTION AND REMOVAL OF DISCS
IMPORTANT: ALWAYS HOLD A CD BY IT'S EDGES. AVOID GETTING ANY FINGER-PRINTS,
SMUDGES OR DIRT ONTO THE SURFACE OF A DISC. IN CASE THIS HAPPENS,
USE A SPECIAL CD-CLEANING CLOTH OR CLEANING KIT TO REMOVE THE DIRT OR
SMUDGES.
PRESS THE "FUNCTION" KEY REPEATEDLY UNTIL THE DISPLAY SHOWS "CD".
PRESS THE OPEN/ CLOSE KEY TO OPEN THE CD-DOOR. CAREFULLY PLACE
A COMPACT DISC (CD OR MP3 DISC) ONTO THE CENTER SPINDLE WITH THE
LABEL SIDE (PRINTED SIDE OF DISC) FACING OUTWARDS (TOWARDS YOU).
PRESS THE "OPEN/ CLOSE" BUTTON TO AUTOMATICALLY CLOSE THE CD-DOOR.
THE CD-DISPLAY WILL SHOW THE TOTAL NUMBER OF TRACKS ON THE DISC
AFTER A FEW SECONDS. THE CD IS NOW READY TO BE PLAYED. TO REMOVE
A DISC, PRESS THE OPEN/ CLOSE KEY. THE DOOR WILL OPEN UPWARDS ALLOWING
THE REMOVAL OF THE CD INSIDE.
OPERATION OF RADIO
- PRESS THE KEY ONCE TO SWITCH ON THE SYSTEM POWER.
- PRESS THE TO SELECT THE DESIRED RADIO BAND.
- FOR MW (AM) STATIONS, ROTATE OR REPOSITION THE SET TO IMPROVE RADIO
RECEPTION.
- FOR FM STATIONS, EXTEND AND ADJUST THE TELESCOPIC ANTENNA TO OBTAIN
THE BEST RECEPTION.
- USE THE FM MONO/STEREO BUTTON TO SELECT THE DESIRED MODE. IN SOME
CASES, WHERE RECEPTION IS POOR, IT MAY BE ADVISABLE TO SELECT
“MONO” MODE, TO IMPROVE CLARITY OF THE RADIO SIGNAL.
KEY
POWER
TUNER
MUSIC EQUALIZER
- PRESS KEY REPEATEDLY TO CHOOSE THE DESIRED SOUND EFFECT
ACCORDING TO THE MUSIC YOU ARE LISTENING TO :
EQ
*PASS CLASSIC JAZZ ROCK POP
(*PASS MEANS EQUALIZER IS BY PASSED OR "OFF")
MANUAL FREQUENCY ADJUSTMENT (SCAN MODE)
- PRESS (AND IMMEDIATELY RELEASE) THE KEY OR
KEY TO “SCAN” (MANUALLY ADJUST) THE RADIO FREQUENCY “UP” OR “DOWN”
BY 1-STEP AT A TIME.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY AT EACH
STEP’S POSITION.
- WHEN A DESIRED FREQUENCY OR STATION IS REACHED. IT CAN BE SAVED
INTO ONE OF THE “MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
AUTOMATIC FREQUENCY ADJUSTMENT (SEEK MODE)
- PRESS AND HOLD (FOR 2 SECONDS) THE OR KEYS
TO “SEEK” (AUTOMATICALLY ADJUST) THE RADIO FREQUENCY “UP” OR “DOWN”
TO THE NEXT AVAILABLE RADIO STATION.
- THE RADIO DIGITAL DISPLAY WILL INDICATE THE EXACT FREQUENCY OF THE
NEXT STATION THAT IS FOUND.
- WHEN A DESIRED STATION IS REACHED. IT CAN BE SAVED INTO ONE OF THE
“MEMORY” POSITIONS. (SEE “RADIO MEMORY” SECTION).
NEXT BACK
NEXT BACK
NORMAL CD OPERATION
- PRESS KEY TO SWITCH ON THE UNIT.
- PRESS THE "FUNCTION" KEY REPEATEDLY UNTIL THE DISPLAY SHOWS "CD"
- PRESS THE "OPEN/ CLOSE" KEY & INSERT A CD AS DESCRIBED.
- PRESS KEY. THE DISK WILL START SPINNING & THE FIRST
SONG (TRACK) WILL START PLAYING. THE DISPLAY WILL INDICATE THE CURRENT
TRACK NO.
- AT ANY ANYTIME DURING PLAYBACK, PRESS THE KEY
TO PAUSE OPERATION OF THE UNIT. PRESS KEY TO RESUME
OPERATION AT THE SAME TRACK & POSITION.
- AT ANYTIME DURING PLAYBACK, PRESS THE KEY TO STOP OPERATION
OF THE SET. THIS WILL RESET THE SET TO THE FIRST TRACK (IF YOU PRESS
PLAY AFTER STOP, THE FIRST TRACK WILL ALWAYS START PLAYING).
- AT ANYTIME DURING PLAYBACK, PRESS AND RELEASE THE OR
KEYS TO SKIP FORWARD OR BACKWARDS BY ONE TRACK, AS DESIRED.
- ANY ANYTIME DURING PLAYBACK, PRESS AND HOLD THE OR
KEYS TO FAST-FORWARD (CUE) OR FAST-REVERSE (REVIEW) THE SPECIFIC
TRACK, WHICH IS CURRENTLY PLAYING.
POWER
PLAY
PLAY
PLAY
STOP
PROGRAM
NEXT BACK
NEXT BACK

E-11
- MP3 (MPEG 2, LAYER 3) IS A DIGITAL FILE FORMAT FOR AUDIO (MUSIC).
- YOU CAN DOWNLOAD MP3 SONGS FROM MANY WEBSITES ON THE INTERNET
(PLEASE OBSERVE THE COPYRIGHT REGULATIONS OF YOUR COUNTRY).
- MP3 SONGS ARE MUCH SMALLER IS MEMORY SIZE COMPARED WITH NORMAL
CD-AUDIO FORMAT SONGS. THIS IS CALLED “COMPRESSION” & IT ALLOWS
MUCH MORE RECORDING TIME ON A STANDARD CD THAN THE NORMAL
74 MINUTES (FOR NORMAL CD-AUDIO).
WHAT IS MP3 ?
- PRESS KEY TO SWITCH ON THE UNIT.
- INSERT AN MP3 CD INTO THE PLAYER AND CLOSE THE CD DOOR.
- PRESS THE KEY.
- THE DISK WILL SPIN AND THEN PLAYBACK THE FIRST SONG (TRACK), THE
DISPLAY WILL INDICATE THE CURRENT TRACK NO. (“001” IF IT IS THE FIRST
TRACK) AS WELL AS THE PLAY TIME OF THAT TRACK IN MINUTES AND SECONDS.
- AT ANYTIME DURING PLAYBACK, PRESS KEY TO PAUSE
OPERATION OF THE UNIT. PRESS KEY TO RESUME
OPERATION AT THE SAME TRACK & POSITION.
- AT ANYTIME DURING PLAYBACK, PRESS AND RELEASE OR
TO SKIP FORWARDS OR BACKWARDS BY ONE TRACK.
- AT ANYTIME DURING PLAYBACK, PRESS AND HOLD OR
TO REVIEW (FAST REWIND) OR CUE (FAST FORWARDS) THE CURRENT TRACK.
- AT ANYTIME DURING PLAYBACK, PRESS AND HOLD KEY FOR 1
SECOND. THE DISPLAY WILL SHOW THE FILE NAME (SONG NAME) INFORMATION.
HOW TO PLAY MP3 DISCS
POWER
PLAY
PLAY
PLAY
FIND
NEXT BACK
NEXT BACK
E-12
PROGRAMMING THE CD-PLAYER
- THE CD PLAYER CAN BE PROGRAMMED TO PLAY ANY SEQUENCE OF UPTO 64
TRACKS, AS DESIRED.
- ALWAYS PRESS THE KEY BEFORE STARTING THE PROGRAMMING.
- PRESS THE ONCE, THE DISPLAY WILL SHOW THE “MEMORY”
SYMBOL TO INDICATE THAT THE SET IS NOW IN “MEMORY PROGRAMMING MODE”.
- PRESS THE OR TO SELECT THE TRACK (SONG)
NUMBER YOU WISH TO BE STORED IN THE CURRENT MEMORY (PROGRAM)
POSITION.
- PRESS THE TO CONFIRM YOUR SELECTION.
- REPEAT THE PREVIOUS 2 STEPS, EACH TIME SELECTING ANY TRACK NUMBER
OF YOUR CHOICE TO BE STORED IN SUCCESSIVE (PROGRAM) POSITIONS.
- AFTER A MAXIMUM OF 64 SONGS (OR LESS) HAVE BEEN SELECTED AS
DESCRIBED ABOVE, PRESS , THE DISPLAY WILL NOW SHOW
MEMORY TO INDICATE YOU HAVE SAVED A PROGRAM-MEMORY.
- PRESS , THE CD-PLAYER WILL PLAYBACK THE “SAVED SEQUENCE” IN
THE PROGRAM MEMORY.
- TO CLEAR (CANCEL) THE ENTIRE PROGRAM WHICH IS STORED IN THE
MEMORY, SIMPLY PRESS , THIS WILL RESET THE MEMORY &
CLEAR THE PROGRAM.
KEY
KEY
KEY
KEY
KEY
STOP
PROGRAM
PROGRAM
PROGRAM
PLAY
STOP
NEXT BACK
FOR NORMAL CD-AUDIO DISCS:
- PRESS THE OR TO SELECT THE ALBUM (FOLDER DIRECTORY)
NUMBER WHICH CONTAINS THE SONG YOU WISH TO SELECT
- PRESS THE TO CONFIRM
- PRESS THE OR TO SELECT THE TRACK (SONG) NUMBER
YOU WISH TO TO BE STORED IN THE CURRENT MEMORY (PROGRAM) POSITION.
- PRESS THE BUTTON TO CONFIRM YOUR SELECTION.
- REPEAT THE PREVIOUS 4 STEPS, EACH TIME SELECTING ANY ALBUM AND TRACK
NUMBER OF YOUR CHOICE TO BE STORED IN SUCCESSIVE (PROGRAM) POSITIONS.
- AFTER A MAXIMUM OF 64 SONGS (OR LESS) HAVE BEEN SELECTED AS
DESCRIBED ABOVE, PRESS , THE DISPLAY WILL NOW SHOW
MEMORY TO INDICATE YOU HAVE SAVED A PROGRAM-MEMORY.
- PRESS , THE CD-PLAYER WILL PLAYBACK THE “SAVED SEQUENCE”
IN THE PROGRAM MEMORY.
- TO CLEAR (CANCEL) THE ENTIRE PROGRAM WHICH IS STORED IN THE
MEMORY, SIMPLY PRESS , THIS WILL RESET THE MEMORY &
CLEAR THE PROGRAM.
KEY
KEY
KEY
KEY
FOR CD-MP3 DATA DISCS:
PROGRAM
NEXT BACK
NEXT BACK
PROGRAM
PROGRAM
PLAY
STOP
- THE EXACT LENGTH OF RECORDING TIME DEPENDS ON THE
“COMPRESSION RATE” OF THE MP3 SONG YOU HAVE DOWNLOADED.
- COMPRESSION RATE IS SPECIFIED IN “KBPS” (KILOBITS PER SECOND). FOR
EXAMPLE : “128 KBPS”: THE HIGHER THIS NUMBER, THE BIGGER THE MP3 FILE
SIZE (THE BETTER THE SOUND QUALITY) AND THE LOWER THE RECORDING
TIME ON A CD-R. NORMALLY BASED ON 128 KBPS, YOU SHOULD HAVE
APPROX. 250-300 MINUTES OF RECORDING TIME ON A CD-R.
- MP3 SONGS CAN BE RECORDED WITH SOME “TEXT INFORMATION” AS PART
OF THE SAME FILE. IT CONSISTS OF (AMONG OTHER DETAILS:)
- FILE NAME (SONG NAME)
- ARTIST NAME
- YOUR CD-MP3 PLAYER CAN LOCATE (“FIND”) A SONG ON AN MP3-CD DISC FROM
THE "FILE NAME", THEREFORE YOU SHOULD TRY TO NAME ALL YOUR MP3 FILES WITH
THE ACTUAL NAME OF THE SONG THAT IT CONTAINS.
- THERE ARE BASICALLY 2 WAYS TO MAKE AN MP3-CD WITH YOUR FAVORITE
SONGS :
- DOWNLOAD MP3 SONGS FROM INTERNET & BURN THEM ON A
CD-R DISC ON YOUR COMPUTER.
- CONVERT CD-AUDIO FILES (FROM A NORMAL MUSIC CD) ONTO
YOUR COMPUTER INTO MP3 FORMAT, USING A KIND
SOFTWARE CALLED “CD-RIPPER”.
(WHICH IS FREEWARE/SHAREWARE ON INTERNET).
TEXT DISPLAY MODE (id3 display)
- THIS UNIT IS CAPABLE OF DISPLAYING THE "TEXT INFORMATION" (id3 TAG) OF AN MP3
SONG ON THE LCD DISPLAY.
- TO SWITCH ON THIS FUNCTION, SIMPLY PRESS & HOLD THE KEY FOR 3
SECONDS.
- TO SWITCH BACK TO NORMAL DISPLAY MODE (TO DISPLAY TRACK NUMBER, etc.),
PRESS & HOLD THE KEY AGAIN FOR 3 SECONDS.
FIND
FIND

E-13
E-14
- WITH ANY SELECTED ALPHABET, THERE MIGHT BE SEVERAL SONGS ON THE
DISC (WHICH BEGIN WITH THE SAME ALPHABET). TO SEARCH FOR ALL SONGS
BEGINNING WITH A PARTICULAR ALPHABET, PRESS AND “HOLD” THE
OR KEYS (FOR 2 SECONDS) UNTIL THE “FIND” STOPS FLASHING
IN THE DISPLAY.
NEXT
BACK
- ONCE THE "FIND" SYMBOL STOPS FLASHING, PRESS THE KEY TO
DISPLAY THE NEXT SONG STARTING WITH SAME ALPHABET. REPEAT UNTIL
DESIRED SONG IS LOCATED.
- AT ANYTIME, WHEN YOU HAVE LOCATED A DESIRED SONG (AS SHOWN ON SCREEN)
JUST PRESS “PLAY” TO LISTEN TO IT.
- TO EXIT THE “FIND” MODE PRESS THE KEY TWICE UNTIL THE “FIND”
SYMBOL DISAPPEARS FROM THE DISPLAY.
FIND
FIND
- MP3 FILES (SONGS) CAN BE ORGANIZED INTO DIRECTORIES WHEN YOU RECORD
THEM ON TO A CD-R DISC. EACH DIRECTORY IS CALLED AN "ALBUM" AND YOU
CAN (FOR EXAMPLE) ORGANIZE YOUR ALBUMS ON A DISC SO THAT EACH ALBUM
CONTAINS SONGS BY A PARTICULAR ARTIST, OR ALTERNATIVELY, BY A DIFFERENT
GENRE OR TYPE. YOU CAN ORGANIZE SONGS & ALBUMS IN ANY WAY YOU WISH
SO THAT YOU CAN LOCATE & PLAY BACK THOSE SONGS WITH GREATER EASE &
CONVENIENCE.
- TO SEARCH FOR SONGS WITHIN A PARTICULAR ALBUM, PRESS THE KEY
TWICE WHEN AN MP3-CD IS PLAYING (OR STOPPED).
- THE "FIND" & "ALBUM" SYMBOLS WILL ACTIVATE IN THE DISPLAY, TOGETHER WITH
THE NUMBER "1". THIS IS THE "ALBUM NUMBER" (IT INDICATES THE NUMBER OF
THE DIRECTORY ON THE DISC).
FINDING (SEARCHING) MP3 SONGS BY ALBUM (DIRECTORY)
NEXT
FRED . . . . . . . .
NAME OF ALBUM
(DIRECTORY)
ALBUM
NUMBER
EXAMPLE:
01
PRESS ONCE
- PRESS or TO ADVANCE THE ALBUM NUMBER
(01 02 03 ...). THE NAME OF EACH ALBUM (THE DIRECTORY NAME) WILL
APPEAR IN THE LOWER PART OF THE DISPLAY FOR EACH SELECTED ALBUM NUMBER.
NEXT BACK
FIND ALBUM
NEXT
VALERIE. . . . ..
ALBUM
NUMBER
02
NAME OF ALBUM
(DIRECTORY)
PRESS ONCE
ETC ...
FIND ALBUM
- WHEN THE DESIRED ALBUM NAME APPEARS ON SCREEN, "PRESS & HOLD" THE
KEY (FOR 2 SECONDS) UNTIL THE "ALBUM"SYMBOL
DISAPPEARS. THIS WILL OPEN THE SELECTED ALBUM & ALLOWS YOU TO
DISPLAY ALL THE SONGS CONTAINED INSIDE THAT ALBUM SO THAT YOU CAN
SELECT THE DESIRED SONG & PLAY IT.
NEXT
ALBUM
ALBUM
NEXT
FINDING (SEARCHING) MP3 SONGS BY SONG NAME
- AT STOP OR PLAY MODES, PRESS KEY ONCE.
- THE “FIND” SYMBOL WILL “FLASH” IN THE DISPLAY, AND THE LETTER “A” WILL BE
SHOWN.
THIS IS THE “SEARCH ALPHABET”.
- PRESS OR KEYS TO ADVANCE THE
“SEARCH ALPHABET” (A B C D...) TO SEARCH FOR THE DESIRED ALPHABET.
- AT EVERY SELECTED “SEARCH ALPHABET” THE LOWER PART OF THE DISPLAY
WILL SHOW THE NAME OF THE FIRST SONG BEGINNING WITH THAT SELECTED
ALPHABET, ON THE DISC.
FIND
A -- ANNA . . . . .
NAME OF SONG
(MP3 FILE)
SEARCH
ALPHABET
EXAMPLE:
PRESS ONCE
FIND SYMBOL
NEXT BACK
NEXT
B -- BEATRICE . . .
NAME OF SONG
(MP3 FILE)
SEARCH
ALPHABET
FIND SYMBOL
PRESS ONCE
NEXT
ETC...

E-15
CHRISTIAN... . . . ..
NAME OF 1st SONG IN
THE SELECTED ALBUM
01
PRESS & RELEASE REPEATEDLY
TO SCROLL THROUGH ALL SONGS
CONTAINED INSIDE THE SELECTED ALBUM
VALERIE. . . . ..
ALBUM
NUMBER
02
PRESS & HOLD FOR 2 SECS. !
ALBUM
NAME
THIS WILL
DISAPPEAR
AFTER
2 SECONDS
ALBUM
NEXT
CHRISTIAN... . . . ..
NAME OF 1st SONG IN
THE SELECTED ALBUM
FIND
01
PRESS & RELEASE REPEATEDLY
TO SCROLL THROUGH ALL SONGS
CONTAINED INSIDE THE SELECTED ALBUM
NEXT
NEXT
- ONCE THE "ALBUM" SYMBOL HAS DISAPPEARED, PRESS KEY
REPEATEDLY TO DISPLAY EACH SONG CONTAINED INSIDE THE SELECTED ALBUM.
- AT ANYTIME, WHEN YOU HAVE LOCATED A DESIRED SONG (AS SHOWN ON SCREEN)
JUST PRESS "PLAY" TO LISTEN TO IT.
- TO EXIT THE "FIND" MODE PRESS THE KEY ONCE UNTIL THE "FIND"
SYMBOL DISAPPEARS FROM THE DISPLAY.
FIND
NEXT
E-16
3D-VIRTUAL SURROUND
USB FLASH DRIVE PLAYBACK
- THIS UNIT IS EQUIPPED WITH A USB SOCKET WHICH CAN ACCEPT STANDARD
USB FLASH DRIVES (ALSO KNOWN AS "PEN DRIVES") WHICH ARE FOR MEMORY
STORAGE. (COMPATIBLE WITH USB VER. 1.1 & 2.0).
- TO UTILIZE THIS FUNCTION, INSERT A USB FLASH DRIVE INTO THE USB
SOCKET & PRESS THE "FUNCTION" KEY REPEATEDLY UNTIL THE DISPLAY
SHOWS "CARD-USB".
- PRESS OR TO SKIP FORWARD OR BACKWARDS TO SELECT
THE DESIRED MP3 FILE ON THE USB FLASH MEMORY DRIVE.
- PRESS TO START PLAY BACK OF THE SELECTED SONG.
3D-VIRTUAL SURROUND
REPEAT PLAYBACK FUNCTION
- AT ANYTIME DURING PLAYBACK:
- PRESS KEY REPEATEDLY TO SELECT
= TO REPEAT THE CURRENT TRACK
= TO REPEAT ALL TRACK (FULL CD)
= TO REPEAT ALL SONGS FROM CURRENTLY SELECTED
ALBUM(DIRECTORY)
RANDOM-PLAY FUNCTION
- THE UNIT IS EQUIPPED WITH A SPECIAL FUNCTION WHICH ALLOWS YOU TO
LISTEN TO ALL THE TRACKS (SONGS) ON A CD IN “RANDOM” ORDER.
- TO ACTIVATE THIS FUNCTION, SIMPLY PRESS THE KEY ONCE, THE
DISPLAY SHOW “RND”.
- TO CANCEL RANDOM-PLAY FUNCTION, SIMPLY PRESS KEY ONCE.
RANDOM
RANDOM
REPEAT 1
REPEAT ALL
REPEAT ALBUM
REPEAT
USB
NEXT BACK
PLAY
DISPLAYING THE SONG NAME (id3)
REMEMBER TO PRESS & HOLD THE KEY FOR 3 SECONDS TO SWITCH ON THE "TEXT
DISPLAY MODE" (TO DISPLAY id3 TAG INFORMATION OF THE SONG ON THE LCD DISPLAY).

USING THE AUDIO LINE IN CONNECTION (DVD/ AUX)
- YOU CAN CONNECT THE AUDIO OUTPUT OF AN EXTERNAL DEVICE SUCH AS A
DVD PLAYER TO THIS UNIT, TO LISTEN TO THE SOUND OF THAT DEVICE (DVD)
THROUGH THE HIGH QUALITY AMPLIFIER OF THIS MUSIC SYSTEM.
- TO CONNECT THE EXTERNAL DEVICE (eg. DVD PLAYER) PLEASE USE A
STANDARD RCA CABLE TO CONNECT THE "AUDIO LINE-OUT" OF THE DEVICE
(LEFT AND RIGHT CHANNELS) TO THE "AUX/DVD AUDIO LINE-IN" RCA JACKS
(LEFT AND RIGHT) ON THE REAR PANEL OF THIS UNIT.
- SWITCH THE FUNCTION SELECTOR TO "AUX" ON THE FRONT PANEL.
- MAKE SURE THAT THE SPEAKERS ARE CONNECTED TO THE MAIN UNIT.
- SWITCH ON THE POWER OF THE MAIN UNIT AND THE EXTERNAL DEVICE
(DVD PLAYER).
- START PLAYBACK OF THE EXTERNAL DEVICE (DVD) AND ADJUST THE VOLUME
CONTROL OF THE MAIN UNIT TO THE DESIRED LEVEL.
- REMEMBER TO SWITCH OFF THE POWER OF THE MUSIC SYSTEM (MAIN UNIT)
WHEN YOU ARE FINISHED USING THE EXTERNAL DEVICE.
ANTI-SKIP (ANTISHOCK) FUNCTION [ESP]
- THIS UNIT HAS A BUILT-IN DIGITAL ANTI-SKIP FUNCTION WHICH PREVENTS
CD "SKIPPING" WHEN THE UNIT IS PHYSICALLY MOVED OR SUBJECTED TO
VIBRATIONS FOR UP TO 100 SECONDS.
- WHENEVER ANY CD OR CD-MP3 DISC IS PLAYED , THE DISPLAY WILL
INDICATE A FLASHING SYMBOL FOR ABOUT 50 SECONDS. THIS
MEANS THAT THE ANTI-SKIP MEMORY IS BEING FILLED UP (BUT IS NOT
YET FULL). THE ANTI-SHOCK PROTECTION IS ALREADY ACTIVE (IN USE) AT
THIS TIME, BUT IS NOT YET UP TO THE MAXIMUM 100 SECONDS CAPACITY.
- ONCE THE SYMBOL STOPS FLASHING, THE ANTI-SHCOK MEMORY IS
FULL & THE UNIT NOW PROVIDES ANTI-SKIP PROTECTION FOR 100
SECONDS OF VIBRATION.
- PLEASE NOTE THAT THE ANTI-SKIP FUNCTION ONLY PROTECTS AGAINST
NORMAL VIBRATION OR MINOR MOVEMENT. SEVERE OR STRONG SHOCKS/
VIBRATIONS TO THE UNIT MAY STILL CAUSE SKIPPING.
ESP
ESP
E-17 E-18
THE APPARATUS SHOULD NOT BE EXPOSED TO DRIPPING OR SPLASHING
AND NO OBJECTS FILLED WITH LIQUIDS SHOULD BE PLACED ON THE
APPARATUS.
SPECIFICATIONS
AC-POWER SUPPLY : ...................................... AC 110V/220V , 50/60 Hz
AC-POWER CONSUMPTION : ..........................32W
REMOTE CONTROL UNIT : ................................3V (AAA SIZE/ UM-4/ LR03/ R03G x 2 PCS)
(BATTERIES NOT INCLUDED)
SPEAKER : ......................................................... 4” x 2 WOOFER + 1½” X 2 TWEETER
SPEAKER CAPACITY POWER : .........................@ 4 Ohm
AMPLIFIER MAXIMUM POWER : ....................... 10 W
~
AS WITH ALL CD-PLAYERS, THIS SYSTEM USES A LASER DEVICE
DO NOT STARE INTO BEAM OR VIEW DIRECTLY WITH OPTICAL
INSTRUMENTS
CONNECTING AN EXTERNAL POWERED SUBWOOFER
(NOT INCLUDED)
- THIS UNIT HAS A BUILT IN SUBWOOFER CONNECTION WHICH CAN BE
CONNECTED TO ANY STANDARD POWERED SUBWOOFER.
- BY CONNECTING TO A POWERED SUBWOOFER, THE LOW FREQUENCY
(BASS SOUND) CAN BE STRONGLY ENHANCED TO PROVICE A MUCH RICHER
AND DEEPER SOUND TO YOUR MUSIC.
- TO USE THIS FACILITY, SIMPLY CONNECT ANY STANDARD POWERED
SUBWOOFER (EASILY AVAILABLE FROM MOST MUSIC EQUIPMENT SHOPS)
USING THE RCA JACK ON THE REAR PANEL OF THE MAIN UNIT.
- SWITCH ON THE POWERED SUBWOOFER.
- PLAY ANY MUSIC SOURCE (CD or RADIO or AUX) AS USUAL.
- YOU WILL IMMEDIATELY NOTICE THE DEEPER SOUND, WHICH CAN BE
FURTHER ENHANCED BY SWITCHING ON THE "SUPER BASS" FUNCTION ON
THE MAIN UNIT.
- PLEASE NOTE THAT THE SPEAKERS SHOULD BE CONNECTED AS USUAL TO
THE MAIN UNIT, WHEN USING A SUBWOOFER.
- PLEASE NOTE THAT "PASSIVE" (NON-POWERED) SUBWOOFERS WILL NOT
WORK WITH THIS UNIT.

- INCLUDED 1 PC STAND FOR THE MAIN UNIT ( )
FIXING THE BASE TO THE MAIN UNIT:
- INCLUDED 2 PCS STAND FOR THE SPEAKERS ( )
WHEN THESE
ARROWS ARE ALIGNED
THE BASE IS PROPERLY
INSTALLED ONTO MAIN UNIT
SYSTEM SET UP PROCEDURE
A. AS A "SHELF SYSTEM" (TABLE TOP USE)
1. PLACE THE STAND UNDER
THE MAIN UNIT OR SPEAKERS
2. SLIDE THE STAND FROM DOWN TO
UPWARD (SEE DIAGRAM BELOW).
3. STOP WHEN ARROWS ARE ALIGNED (SEE DIAGRAM).
THE STAND IS NOW LOCKED TO MAIN UNIT OR SPEAKERS.
(TO RELEASE THE STAND FROM THE MAIN UNIT OR SPEAKERS, SLIDE THE
STAND FROM DOWN TO UPWARD (OPPOSITE DIRECTION) UNTIL IT BECOMES
RELEASED.
CLICK
E-19
Warranty certificate
H&B provides a twelve (12) month warranty from the date of purchase against material and manufacturing defects.
In the event of defects covered by the warranty, the product must be returned to the dealer that sold the product.
If any problems arise, information on our authorized service centers is available the dealer who sold the product.
Terms of Warranty
1. The warranty is only valid on presentation of a correctly completed warranty certificate and sales ticket, and if
the serial number on the product is fully legible.
2. The obligations of H&B are limited either to repair or replacement of defective components. The repair or
replacement of defective components is based on an assessment by H&B.
Exchange is only possible if the repair cannot be performed.
3. Warranty repairs must be performed by an authorized H&B dealer, or an authorized service centre. No
remuneration is provided for repairs performed by unauthorized workshops.
Any repairs or damage to the product caused by unauthorized intervention are not covered by this warranty.
4. This product will not be viewed as defective, either in materials or in manufacture, if adaptation to national, local,
technical or safety-related requirements is required in countries other than the specific country for which the
product was originally designed and manufactured.
5. This warranty does not cover these types of adaptations, and no remuneration will be offered for these types of
adaptations or for any consequential damages. The warranty does not cover the following:
Periodic inspection, maintenance and repair or replacement of parts resulting from normal wear.
Costs connected to transport,disassembly or installation of the product.
Misuse, including use for other purposes than was intended or faulty installation.
Damage caused by lightning, water, fire, natural catastrophes, war, insurrection, incorrect line voltage, insufficient
ventilation or other causes beyond the control of H&B.
This warranty applies to every legal owner of the product during the warranty period.
Notice
H&B reserves the right to make improvements in the products described in this manual at any time without prior
notice.
H&B makes no representation or warranties with respect to the contents hereof and specifically disclaims any
implied warranties of
merchantability or fitness for any particular purpose. Further, H&B reserves the right to update this manual and to
make changes in its content without obligation to notify any person or organization of such update or change.
This product is designed to help you in reproducing materials for which you own the copyright or have obtained
permission to copy from the copyright owner. Unless you own the copyright or have permission to copy from the
copyright owner, you may be violating copyright laws and may be subject to payment of damages and/or other
penalties. If you are uncertain about your rights, you should contact your legal advisor.
Distributor
H&B products are distributed by:
JPF Entertainment
50, rue Ardoin
Bat 566
93400 Saint Ouen
FRANCE
[email protected]
www.hb-direct.com
Tel + 33 1 49 489 340 - Fax + 33 1 40 109 599
E-20
