Table of Contents
1
English
Regulatory Information ................................................................ 3
Decription of Warning Symbols .................................................... 3
Safety Notices............................................................................. 4
Preface ....................................................................................... 6
Warranty and Service .................................................................. 6
1. Getting Started ........................................................................8
1.1 Package Contents .............................................................8
1.2 Introducing the TV .............................................................9
1.3 Features ...........................................................................9
1.4 Control Panel ..................................................................10
1.5 Input and Output Jacks ....................................................11
1.6 Remote Control ...............................................................12
1.7 Inserting the Remote Control Batteries .............................14
2. Setting up your TV .................................................................16
2.1 Basic Connections...........................................................16
2.1.1 Power Connection ..................................................16
2.1.2 Connecting an Antenna or Cable TV........................16
2.2 Connecting External Devices ...........................................17
2.2.1 Connecting External Earphones ..............................17
2.2.2 Connecting to AV Devices.......................................18
2.2.3 Connecting a PC using VGA ...................................21
2.2.4 Connecting a PC using DVI.....................................21
2.3 Using the TV ...................................................................22
2.3.1 Turning the TV On and Off ......................................22
2.3.2 Switching Source Signals........................................22
2.3.3 Selecting Channels.................................................22
2.3.4 Adjusting the Volume..............................................23
3. Adjusting On-Screen Display (OSD) Settings ..........................24
3.1 OSD Setting Menus .........................................................25
3.2 Adjusting Picture Settings ................................................25
3.3 Adjusting Sound Settings .................................................26
3.4 Adjusting Channel Settings ..............................................26
3.5 Adjusting TV Settings ......................................................28
4. Troubleshooting .....................................................................30
5. Support Timing ......................................................................31

Table of Contents
2
English
6. Specifications ........................................................................32
7. Dissembling the stand base....................................................33
8. Using the Cable Organizer .....................................................34

3
English
Regulatory Information
CCC Warning
• Do not place the LCD TV where it can be subjected to drops of water.
• Do not place the LCD TV next to an object filled with water such as a
flower vase or the likes.
• When unplugging, pull on the plug head.
• Install the LCD TV near a power outlet for easy access when
connecting and disconneting the power plug.
Decription of Warning Symbols
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
This symbol is used to alert users
to pay attention to important
descriptions regarding usage,
maintenance (repair), and
additional important information
related to this TV.
CAUTION
This symbol is used to alert users
to the risk of electric shocks due
to dangerous and uninsulated
components.

4
English
Safety Notices
Installation Safety Notes
Location
Avoid allowing the TV to get prolonged exposure to sunlight or other strong
sources of heat. Leave sufficient distance between the TV and the wall to
provide enough space for the emission of heat.
WARNING
To reduce the risk of fire or electric shock, do not expose this apparatus to
rain or moisture.
Apparatus shall not be exposed to dripping or splashing and no objects
filled with liquids, such as vases, shall be placed on the apparatus.
CAUTION
These servicing instructions are for use by qualified service personnel only. To
reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.
Notes:
• The LCD TV is for entertainment use only and visual display
tasks are excluded.
• This device uses a VGA connector to connect to a PC. To reduce
the influence of main frequency on the source signal, use a VGA
monitor cable with ferrite shield.

5
English
Personal Safety
Installation
1. To avoid overloading the power supply, never plug too many electrical
devices into an outlet, power strip, or extension cable.
2. Dangerous high-voltage electric power components are located inside the
TV. To avoid electric shock, do not disassemble the casing.
3. Do not place or drop metals, small objects, or flammable materials into
the vent of the TV.
4. If the TV is dropped, falls down, or is otherwise damaged, unplug the
power cord immediately and contact an authorized service technician.
5. If any fluid is sprayed or dropped into the TV, contact an authorized
service technician.
6. The screen of the TV is made of glass. Avoid hitting or scraping it. If the
screen is broken, do not touch the broken glass.
7. Do not allow children to use the TV unattended.
8. Be careful when disconnecting the power plug. Hold the plug. Do not
attempt to disconnect the plug by pulling on the power cord.
1. Do not place the TV in locations where there is excessive steam or dust.
2. Avoid blocking the TV's vents, do not place the TV on a bed, sofa, carpet,
or in a sealed cabinet.
3. Install the outdoor antenna away from power transmission lines to avoid
possible danger.

6
English
Preface
Thank you for purchasing a Hannspree Liquid Crystal Display Television (LCD
TV). Your new TV will allow you to enjoy superior audio and video while
enriching your lifestyle with advanced technology.
Please carefully read this manual in its entirety before setting up, using or
operating your TV. To ensure the safe and correct installation and operations of
the TV, it is important that the safety and operation instructions in this manual
are followed.
This instruction manual is designed to assist you in setting up and using the TV.
The information in this manual has been carefully checked for accuracy;
however, no guarantee is given to the correctness of the contents. The
information in this manual is subject to change without notice.
To the extent allowed by applicable law, Hannspree, Inc. (“Hannspree”) shall not
be liable for direct, indirect, special, exemplary, incidental or consequential
damages arising from any defect or omission in this manual, even if advised of
the possibility of such damages in advance.
For complete warranty service information, please refer to the “Warranty Card”
enclosed with your TV.
Warranty and Service

7
English
Copyright
© Copyright 2009 Hannspree, Inc.
All rights reserved. This manual is protected by copyright and distributed under
licenses restricting its use, copying and distribution. No part of this manual may
be reproduced in any form by any means without the prior written authorization
of Hannspree. The TV described in this manual may include copyrighted
software of Hannspree (or other third parties). Hannspree (or other third parties)
preserves the exclusive rights for copyrighted software, such as the right to
distribute or reproduce the copyrighted software. Accordingly, and to the extent
allowed by applicable law, any copyrighted software contained in the product
described herein shall not be distributed, modified, reverse engineered, or
reproduced in any manner without the prior written authorization of Hannspree
(or of other third parties).
The Hannspree logos presented herein are trademarks of Hannspree. All other
product names, trademarks or logos mentioned herein are used for identification
purpose only, and may be the trademarks or registered trademarks of their
respective owners.
The purchase of the product described herein shall not be deemed to grant,
either directly or by implication, estoppel or otherwise, any license under the
copyrights, patents, patent applications or trademarks of Hannspree, except for
the normal, non-exclusive use that arises by operation of law in the sale of a
product.
Trademark Notice
Hannspree products incorporate High-Definition Multimedia
Interface (HDMI™) technology.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.

8
English
1Getting Started
1.1 Package Contents
Make sure the following components are included in the box. Please contact
Hannspree Customer Service immediately if anything is missing or damaged.
•TV
• User’s manual
• Quick start guide
• Warranty card
• Power cord
• Remote control and batteries
• Product registration card
• Cleaning cloth
According to WEEE regulation, this TV can’t be handled as normal
trash in Europe when it is out of usage. Please refer to the recycle
information from our website to handle it.
As an ENERGY STAR®Partner, Hannspree has determined that this product
meets the ENERGY STAR®guidelines for energy efficiency.

9
English
1.2 Introducing the TV
You can watch PAL and cable television channels, and easily connect a VCR, STB
or DVD player to the component and HDMI input ports (location of these ports
depends on model). You can also use the TV as a monitor for your PC by connecting
it through the VGA port.
Convenient control buttons located on the TV and a handy remote control let you
change channels, adjust the volume, and change display settings through an easy-
to-use on-screen display menu system. The built-in stereo speakers provide full rich
sound and a convenient audio output port lets you connect to an external audio
system or earphones.
1.3 Features
Note:
• The supporting devices mentioned in this manual may vary on different models.
For more information, please refer to the manufacturer’s user manual or the
Quick Start Guide of your TV model.
• The TV will automatically turn into the standby mode when there is no signal
input within 5 minutes.
• When PC is in sleep mode, wake up by mouse or keyboard input is not
supported. (PC input at power off can't wake up when H/V Sync is reached.)
• TV Tuner: Built-in TV Tuner
• Audio/ Video support:
– S-Video input
– VGA (PC) input
– AV input
– HDMI inputs
–YP
BPRinput
– R/L audio inputs
– PC line in
– 3.5 mm stereo earphone
output
• On-Screen Display (OSD) menu
system
• Built-in stereo speakers
• Image Enhancement Technology
– 3:2/2:2 pull down
– 3D Comb Filter
– Full HD TV
• Noise Reduction
• Advanced 3D de-interlacing
• Edge Enhancement

10
English
1.4 Control Panel
Description Button Function
Power Press to turn the TV on or off.
Input source
Press to select the input signal type selection:
TV, AV, S-VIDEO, HDMI1, HDMI2, YPbPr or
PC.
Menu Press to turn the on-screen display (OSD)
menu on / off.
Program select
Press to increase the program number or
move upward to the previous item on the
OSD menu and source menu.
Program select
Press to decrease the program number or
move downward to the next item on the OSD
menu and source menu.
Volume adjust Press to increase the volume or move to the
right on the OSD menu.
Volume adjust Press to decrease the volume or move to the
left on the OSD menu.
Remote IR
sensor Receive incoming remote control commands.
LED indicator Indicate power or standby status.
Speakers Deliver high-quality sounds.
㦰
㡖Ⳃ
㡖Ⳃ
䷇䞣
䷇䞣

11
English
1.5 Input and Output Jacks
Description Connector Function
Cable/Antenna Connect to an antenna or cable TV.
Earphone Output Connect to earphones or external
speakers with built-in amplifier.
Component
Inputs (audio)
Connect to an external device, such as a
VCR, STB, or a DVD player.
Component
Inputs (Video)
Connect to an external device, such as a
VCR, STB, or a DVD player.
PC Audio Input Connect to a PC’s line / audio port.
VGA (PC) Input Connect to a PC’s VGA port.
Video/S-Video
input (audio)
Connect to an external device, such as a
VCR, STB, or a DVD player.
Video Connect to an external device, such as a
VCR, STB, or a DVD player.
HDMI 1 Input
Connect a HDMI equipment or an HDMI-
DVI adapter cable to devices such as a
DVD player or STB.
HDMI 2 Input
Connect a HDMI equipment or an HDMI-
DVI adapter cable to devices such as a
DVD player or STB.
S-Video Connect to an external device, such as a
VCR, STB, or a DVD player.
Power Connector Connect to the included power cord.
Y
P B
P R
PC LINE IN

12
English
1.6 Remote Control
Description Icon Function
Power Press to turn the TV on or off.
Input Signal
Type
Press to select the input signal type selection:
TV, AV, S-VIDEO, HDMI1, HDMI2, YPbPr or
PC.
Keypad
Use to select a program directly. Press 0-9 to
enter the program numbers (press 1 and 0 for
program 10).
Last Press to return to the last channel selected.
(TV only)
Information Press to display current channel/ program
information.
Menu Press to turn the on-screen display (OSD)
menu on / off.
OK OK Press to confirm selection.
Arrows Press up, down, left or right to scroll through
the on-screen display menus.
Volume adjust Press to increase audio volume.
Press to decrease audio volume.
Mute
Press to eliminate sound. Press it again or
press the volume adjust buttons to restore
sound.
Dual sound Press to change the multi sound selection of
the TV channel.
ֵো⑤
᳔ৢ
ᰒ⼎
㦰
䷇䞣 /䷇䞣
䷇䞣
䷇䞣
䴭䷇
䷇എߛᤶ

13
English
Select
program
Press to increase the program number.
Press to decrease the program number.
Red, Green,
Yellow, Blue
Press the colored buttons to perform specific
tasks in the OSD menu. (TV only)
TV Press to select the TV input signal source.
AV / SV Press to select the AV / SV input signal source.
YPbPr Press to select the component input signal
source.
HDMI HDMI Press to select the HDMI input signal source.
Favorite
channel Press to select favorite channels. (TV only)
Sleep timer
Press repeatedly to set the sleep timer (15, 30,
45, 60, 90 or 120 minutes).
Cancel the timer by selecting the Sleep Off
option.
Aspect
Press to change the aspect include Auto, Full,
Normal, Panorama, Zoom, Subtitle, and Wide
mode.
Note:
• For best results, use the remote control within a proper distance from the
front of the TV. Do not exceed an angle of 30 degrees when pointing at TV.
• The operational distance may be shortened when the signal sensor is
directly exposed to strong light.
• Aim the transmitter on the remote control at the signal sensor and ensure
that there are no obstacles between them.
Description Icon Function
㡖Ⳃ /㡖Ⳃ 㡖Ⳃ
㡖Ⳃ
⬉㾚
㾚乥
ߚ䞣
୰ད
ⴵ⳴
↨՟

14
English
1.7 Inserting the Remote Control Batteries
1 Open the battery compartment cover at the back of the remote control (A).
2Insert the batteries paying attention to the polarity markings inside the
battery compartment (B).
3Replace the battery compartment cover (C).
A
B
C

15
English
CAUTION
• If the remote control is not used for a long period, remove the
batteries and store them properly.
• Handle damaged or leaking batteries carefully, and wash hands with
soap if they come in contact with leaked chemical fluids.
• If your remote control has two batteries, do not mix new and old
batteries, or the life of the new batteries will be shortened. Chemical
fluids may leak from the old batteries.
• Danger of explosion if battery is incorrectly replaced. Replace only
with the same or equivalent type recommended by the equipment
manufacturer. Discard used batteries according to manufacturer’s
instructions.
• Refer to your local recycling or waste disposal rules and contact a
local waste disposal vendor to dispose of used batteries.
• The remote control cover may have a magnet in it, so do not place
magnetic sensitive items such as watches, credit cards, or flash
media close to the cover.
• Do not use force when pulling the remote control cover open; you
may damage the hinge.

16
English
2Setting up your TV
2.1 Basic Connections
2.1.1 Power Connection
1 Connect the power cord to the AC IN input jack on the rear of the TV.
2Insert the plug at the other end of the power cord into a power outlet .
2.1.2 Connecting an Antenna or Cable TV
Connect one end of the VHF/UHF (Antenna) or CATV cable to TV jack on the rear
of the TV.
Note:
• Images are for illustration only and may vary by model or region.
• If you cannot receive channels after connecting to an antenna or cable TV line,
try scanning for channels.
Ground Clamp
Ground
Coaxial Cable
Antenna

17
English
2.2 Connecting External Devices
Connect external devices such as VCRs, STBs, DVD players, video game consoles,
earphones, or a PC to the TV using the appropriate ports on the rear of the TV.
2.2.1 Connecting External Earphones
Notes:
• External speakers or headphones are not included with the TV.
• The internal TV speakers will not output sound when headphones are
plugged in.
• Use external speakers with built-in amplifiers only.
• Only one external device for sound can be connected at a time.
Speakers
Headphones
(Built-in Amplifiers)

18
English
2.2.2 Connecting to AV Devices
The following diagram illustrates how to connect the AV devices to your TV via HDMI
(A), Component (B), and AV / SV (C).
or or
A B C
Y
P B
P R
or
S-VIDEO RL VIDEO P R LRHDMI Y P B
Audio
(Optional)
Video Cable
(Optional)
HDMI Cable
(Optional)
Cable
Audio / Video
(Optional)
VCR
STB
DVD
Video Game
Console
Cable

19
English
(A) Connecting HDMI
HDMI (High Definition Multimedia Interface) assures that the best video signal is
always sent from source to the TV. Refer to the following illustration to connect an
HDMI device to the TV.
(B) Connecting a VCR / STB / DVD Player Using Component Video
Connect the TV to a VCR / STB / DVD player using the component video inputs.
Note:
When the HDMI cable is connected, connecting the audio cable is not necessary.
However, it is necessary to do so if a HDMI to DVI cable is connected.
HDMI Cable
DVD Player
(Optional)
VCR
STB
DVD
Y
P B
P R
Audio Cable
(Optional)
Video Cable
(Optional)
