HANNspree SV32AMUB User manual

Table of Contents
1
English
Regulatory Information ................................................................ 3
Description of Warning Symbols .................................................. 4
Safety Notices............................................................................. 5
Important Safety Instructions ....................................................... 6
Preface ....................................................................................... 9
Warranty and Service .................................................................. 9
1. Getting Started ......................................................................12
1.1 Package Contents ...........................................................12
1.2 Features .........................................................................13
1.3 Control Panel ..................................................................14
1.4 Input and Output Jacks ....................................................15
1.5 Remote Control ...............................................................17
1.6 Inserting the Remote Control Batteries .............................19
2. Setting up your TV .................................................................21
2.1 Basic Connections...........................................................21
2.1.1 Power Connection ..................................................21
2.1.2 Connecting an Antenna or Cable TV........................21
2.2 Connecting External Devices ...........................................22
2.2.1 Connecting External Earphones ..............................22
2.2.2 Connecting to AV Devices.......................................23
2.2.3 Connecting a VCR/ Set-Top Box/ DVD Player Using
Video Inputs ...........................................................24
2.2.4 Connecting a PC using VGA ...................................25
2.2.5 Connecting a PC using DVI.....................................25
2.2.6 Connecting HDMI ...................................................26
2.2.7 Connecting SPDIF ..................................................26
2.2.8 Connecting USB 2.0 ...............................................27
2.3 Using the TV ...................................................................28
2.3.1 Turning the TV On and Off ......................................28
2.3.2 Setup Wizard .........................................................29
2.3.3 Switching Source Signals........................................29
2.3.4 Performing an Automatic Channel Search................29
2.3.5 Selecting Channels.................................................30
2.3.6 Adjusting the Volume..............................................30
2.3.7 Editing the Channel List..........................................30
2.3.8 Setting the Favorite Channels .................................30
2.3.9 Viewing Images and Playing Music..........................31

Table of Contents
2
English
2.3.10 Performing PVR (Personal Video Recording) .........31
3. Adjusting On-Screen Display (OSD) Settings ..........................33
3.1 OSD Setting Menus .........................................................34
3.2 Adjusting Picture Settings ................................................34
3.3 Adjusting Audio Settings..................................................35
3.4 Adjusting Channel Settings ..............................................36
3.5 Adjusting V-CHIP Settings ...............................................37
3.6 Adjusting Setup Settings .................................................38
3.7 Adjusting PC Settings ......................................................39
4. Troubleshooting .....................................................................40
5. Specifications ........................................................................41
6. Appendix: Remote Control Guide............................................43
6.1 Introduction.....................................................................43
6.1.1 Setting Program Codes...........................................43
6.1.2 Searching Codes ....................................................44
6.1.3 Setting Volume Lock...............................................45
6.1.4 Setting Channel Lock..............................................45
6.1.5 Factory Setting Mode..............................................46
6.1.6 Description.............................................................48
6.2 Other Descriptions ..........................................................48
6.2.1 Double Clicking ......................................................48
6.2.2 Buttons Information ................................................48
6.2.3 Power-out Protection Capability ..............................48
6.3 Component Program Codes .............................................49
7. Setting the TV on the Wall......................................................56
8. Using the Cable Organizer .....................................................58

3
English
Regulatory Information
FCC Compliance Statement1
This device complies with part 15 of the FCC Rules. Operation is subject to the
following two conditions: (1) This device may not cause harmful interference, and (2)
this device must accept any interference received, including interference that may
cause undesired operation.
Additional Information
This equipment has been tested and found to comply with the limits for a Class B
digital device, pursuant to part 15 of the FCC Rules. These limits are designed to
provide reasonable protection against harmful interference in a residential
installation. This equipment generates, uses and can radiate radio frequency energy
and, if not installed and used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If this equipment does cause
harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorient or relocate the receiving antenna
• Increase the separation between the equipment and receiver
• Connect the equipment into an outlet on a circuit different from that to which the
receiver is connected
• Consult the dealer or an experienced technician for help
Warning: The Federal Communications Commission warns that changes or
modifications of the equipment not expressly approved by the party responsible for
compliance could void your authority to operate the equipment.
DOC Compliance Notice2
This digital apparatus does not exceed the Class B limits for radio noise emissions
from digital apparatus as set out in the Radio Interference Regulations of the
Canadian Department of Communications.This device complies with Canada ICES-
003 Class B.
1Applies only to products purchased in the United States of America
2Applies only to products purchased in Canada

4
English
Description of Warning Symbols
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
WARNING
This symbol is used to alert users to
pay attention to important
descriptions regarding usage,
maintenance (repair), and additional
important information related to this
TV.
CAUTION
This symbol is used to alert users to
the risk of electric shocks due to
dangerous and uninsulated
components.

5
English
Safety Notices
Installation Safety Notes
Location
Avoid allowing the TV to get prolonged exposure to sunlight or other strong
sources of heat. Leave sufficient distance between the TV and the wall to
provide enough space for the emission of heat.
WARNING
To reduce the risk of fire or electric shock, do not expose this apparatus to rain
or moisture.
Apparatus shall not be exposed to dripping or splashing and no objects filled
with liquids, such as vases, shall be placed on the apparatus.
CAUTION
These servicing instructions are for use by qualified service personnel only. To
reduce the risk of electric shock, do not perform any servicing other than that
contained in the operating instructions unless you are qualified to do so.
Notes:
• The LED-LCD HDTV is for entertainment use only and visual display
tasks are excluded.
• This device uses a VGA connector to connect to a PC. To reduce the
influence of main frequency on the source signal, use a VGA
monitor cable with ferrite shield.

6
English
Important Safety Instructions
1.
2.
3.
4.
Read these instructions.
Keep these instructions.
Heed all warnings.
Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings. Install in
accordance with manufacturer’s instructions.
8. Do not install near any heat sources such as radiators,
heat registers, stoves, or other apparatus (including
amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or
grounding-type plug. A polarized plug has two blades
with one wider than the other. A grounding-type plug has
two blades and a third grounding prong. The wide blade
or the third prong are provided for your safety. If the
provided plug does not fit into your outlet, consult an
electrician for replacement of the obsolete outlet.
NOTE: Applies to US only.
10. Protect the power cord from being walked on or pinched,
particularly at plugs, convenience receptacles, and the
point where they exit from the apparatus.
11. Only use attachments/accessories specified by the
manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table
specified by the manufacturer, or sold with the
apparatus. When a cart is used, use caution when
moving the cart/apparatus combination to avoid injury
from tip-over.
13. Unplug this apparatus during lightning storms or when
unused for long periods of time.

7
English
14. Refer all servicing to qualified service personnel.
Servicing is required when the apparatus has been
damaged in any way, such as power-supply cord or plug
is damaged, liquid has been spilled or objects have
fallen into the apparatus, the apparatus has been
exposed to rain or moisture, does not operate normally,
or has been dropped.
15. WARNING: To reduce the risk of fire or electric shock,
do not expose this apparatus to rain or moisture.
16. The apparatus shall be connected to a MAINS socket
outlet with a protective earthing connection.
17. Where the MAINS plug or an appliance coupler is used
as the disconnect device, the disconnect device shall
remain readily operable.
18. The apparatus should be used in moderate climate.
19. The apparatus shall not be exposed to dripping or
splashing and that no objects filled with liquids, such as
vases, shall be placed on the apparatus.

8
English
Personal safety
Installation
1. To avoid overloading the power supply, never plug too many electrical devices
into an outlet, power strip, or extension cable.
2. Dangerous high-voltage electric power components are located inside the TV.
To avoid electric shock, do not disassemble the casing.
3. Do not place or drop metals, small objects, or flammable materials into the
vent of the TV.
4. If the TV is dropped, falls down, or is otherwise damaged, unplug the power
cord immediately and contact an authorized service technician.
5. If any fluid is sprayed or dropped into the TV, contact an authorized service
technician.
6. The screen of the TV is made of glass. Avoid hitting or scraping it. If the
screen is broken, do not touch the broken glass.
7. Do not allow children to use the TV unattended.
8. Be careful when disconnecting the power plug. Hold the plug. Do not attempt
to disconnect the plug by pulling on the power cord.
1. Do not place the TV in locations where there is excessive steam or dust.
2. Avoid blocking the TV's vents, do not place the TV on a bed, sofa, carpet, or in
a sealed cabinet.
3. Install the outdoor antenna away from power transmission lines to avoid
possible danger.

9
English
Preface
Thank you for purchasing a Hannspree LED-LCD HDTV. Your new TV will allow you
to enjoy superior audio and video while enriching your lifestyle with advanced
technology.
Please carefully read this manual in its entirety before setting up, using or operating
your TV. To ensure the safe and correct installation and operations of the TV, it is
important that the safety and operation instructions in this manual are followed.
This instruction manual is designed to assist you in setting up and using the TV. The
information in this manual has been carefully checked for accuracy; however, no
guarantee is given to the correctness of the contents. The information in this manual
is subject to change without notice.
To the extent allowed by applicable law, Hannspree, Inc. (“Hannspree”) shall not be
liable for direct, indirect, special, exemplary, incidental or consequential damages
arising from any defect or omission in this manual, even if advised of the possibility
of such damages in advance.
For complete warranty service information, please refer to the “Warranty card”
enclosed with your TV.
As an ENERGY STAR® Partner, Hannspree has determined that this product
meets the ENERGY STAR® guidelines for energy efficiency. It meets strict energy
efficiency guidelines set by the U.S. Environmental Protection Agency and
Department of Energy. ENERGY STAR is a joint program of these goverment
agencies, designed to promote energy efficient products and practices.
Changes to certain fetures, settings, and functionalities of this TV can increase or
change the power consumption. Depending upon such changed settings, the
power consumption may exceed the limits required for the ENERGY STAR
qualification.
Warranty and Service

10
English
Recycling Information
We care very much about our environment protection strategy and firmly believe that
it helps us have healthier earth via appropriate treatment and recycling of industrial
technology devices at the end-of-life.
These devices contain recyclable materials, which can be re-decomposed and re-
integrated into brand-new marvels. On the contrary, other material can be classified
to hazardous and poisoned substance.
We strongly encourage you to visit our website or call to find out recycling
information and services available in your area.
http://www.hannspree.com/us
888.808.6789
Copyright
© Copyright 2010 Hannspree, Inc.
All rights reserved. This manual is protected by copyright and distributed under
licenses restricting its use, copying and distribution. No part of this manual may be
reproduced in any form by any means without the prior written authorization of
Hannspree. The TV described in this manual may include copyrighted software of
Hannspree (or other third parties). Hannspree (or other third parties) preserves the
exclusive rights for copyrighted software, such as the right to distribute or reproduce
the copyrighted software. Accordingly, and to the extent allowed by applicable law,
any copyrighted software contained in the product described herein shall not be
distributed, modified, reverse engineered, or reproduced in any manner without the
prior written authorization of Hannspree (or of other third parties).
The Hannspree logos presented herein are trademarks of Hannspree. All other
product names, trademarks or logos mentioned herein are used for identification
purpose only, and may be the trademarks or registered trademarks of their
respective owners.
The purchase of the product described herein shall not be deemed to grant, either
directly or by implication, estoppel or otherwise, any license under the copyrights,
patents, patent applications or trademarks of Hannspree, except for the normal, non-
exclusive use that arises by operation of law in the sale of a product.

11
English
Trademark Notice
Hannspree products incorporate High-Definition Multimedia
Interface (HDMI™) technology.
HDMI, the HDMI logo and High-Definition Multimedia Interface are trademarks or
registered trademarks of HDMI Licensing LLC.
License Notice and Trademark Acknowledgment
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
is a trademark of SRS Labs, Inc. TruSurround XT technology is
incorporated under license from SRS Labs, Inc.
TruSurround XT® creates a truly immersive surround sound experience with rich
bass and clear dialog from only two speakers.

12
English
1Getting Started
1.1 Package Contents
Make sure the following components are included in the box. Please contact
Hannspree Customer Service immediately if anything is missing or damaged.
Customer Service Contact Information:
http://www.hannspree.com/us
888.808.6789
Attention Card User Manual Quick Start Guide
Warranty Card Warranty Sticker Remote Control
Batteries Cleaning Cloth HDMI Cable
Power Cord
(Attached to the TV)
OK
INPUT
INFO
TV DVD AUDIO CABLE
GUIDE RETURN
MENU
MUTE
MTS
ASPECT SLEEP
FAV. C.C.
LAST
VOL
CH

13
English
1.2 Features
• Built-in TV tuner
• Audio/ Video support:
– PC audio input
– YPbPr input
– CVBS input
– 3.5 mm stereo earphone output
– VGA input
– HDMI input
– USB 2.0 (Photo/Music/Movie)
– R/L audio inputs for CVBS and YPbPr
– SPDIF/Optical Digital Audio output
– 15W slim woofer (SV42LMUB only)
• On-Screen Display (OSD) menu system
• Built-in stereo speakers
• Noise reduction
•3Dcombfilter
• De-interlace Image
• 3:2/ 2:2 Pull down
• Ambient light sensor
• PVR (Personal Video Recording)
• HELIOS (High Effect Linear Sound Optimize System)
• SRS TruSurround XT
Note:
The supporting devices mentioned in this manual may vary on different models.

14
English
1.3 Control Panel
Description Button Function
Power Press to turn the TV on or off.
Input source INPUT Press to open the input source list or return to the previous screen on the
OSD menu.
Menu MENU Press to open the OSD menu or
confirm a selection on the OSD menu.
Next channel
Press to increase the channel number
or move upward to the previous item on
the OSD menu.
Previous channel
Press to decrease the channel number
or move downward to the next item on
the OSD menu.
Volume increase Press to increase the volume or move
to the right on the OSD menu.
Volume decrease Press to decrease the volume or move
to the left on the OSD menu.
Remote IR
sensor Receive incoming remote control commands.
Power/ Standby
indicator Indicate power or standby status.
Speakers Deliver high-quality sounds.
CH
CH
VOL
VOL

15
English
1.4 Input and Output Jacks
Left side:
Rear side:
Description Connector Function
Service port Service only. Not available for users.
USB 2.0
Support JPEG, MP3, and Movie files.
(Please refer to page 27 for supported file
formats.)
Composite inputs
Connect to an external device, such
as a VCR, Set-Top-Box, or a DVD
player.
Earphone output Connect to earphones or external
speakers with built-in amplifiers.
HDMI A input
Connect to an external device, such
as a DVD player, a Set-Top Box, or a
PC’s DVI/ HDMI port.
HDMI B input
Connect to an external device, such
as a DVD player, a Set-Top Box, or a
PC’s DVI/ HDMI port.
Description Connector Function
Cable/ Antenna Connect to an antenna or cable TV.
SERVICE
VIDEO
DTV / TV

16
English
HDMI 1 input
Connect to an external device, such
as a DVD player, set-top box, or a
PC’s DVI/ HDMI port.
HDMI 2 input
Connect to an external device, such
as a DVD player, set-top box, or a
PC’s DVI/ HDMI port.
HDMI 3 input
Connect to an external device, such
as a DVD player, a Set-Top Box, or a
PC’s DVI/ HDMI port.
VGA (PC) input Connect to a PC’s VGA port.
Audio input (PC) Connect to a PC’s audio port.
SPDIF/Optical
Digital Audio
output
Connect to a Sound Bar or a home
theater system.
Component
inputs (video)
Connect to an external device, such
as a VCR, Set-Top-Box, or a DVD
player.
Component
inputs (audio)
Connect to an external device, such
as a VCR, Set-Top-Box, or a DVD
player.
Description Connector Function
1
2
3
VGA
A
UDIO IN
1
2
VIDEO

17
English
1.5 Remote Control
1. INPUT: Press to open the
input source list.
2. Power: Press to turn the
TV on or off.
3. TV: Press to select the
TV mode.
4. CABLE: Press to select
the Cable TV mode.
5. DVD: Press to select the
HDMI mode.
6. AUDIO: Press to select
the SPDIF mode.
7. INFO: Press to display
program information.
8. MENU: Press to display
the on-screen display
(OSD) menu.
9. WHEEL
(Up/Down/Left/Right/OK
): Press / / /
to scroll through the on-
screen display menu.
Press OK to confirm your
selection.
10. GUIDE: Press to view
the Electronic
Programming Guide
screen.
11. RETURN: Press to
return to the previous
menu.
12. Keypad: Use to select a
channel directly. Press
0-9 to enter the program
numbers (press 1 and 0
for channel 10).
13. Program entry: Press
this button for entering
DTV minor channel.
14. LAST: Press to return to
the last channel
selected.
15. MUTE: Press to mute
audio. Press it again or
press the volume adjust
buttons to restore
sound.
16. +VOL-: Press VOL+/- to
increase/decrease the
volume.
17. CH : Press CH /
to increase/decrease
the channel number.
18. MTS: Press to toggle
the audio mode (Mono/
Stereo/ SAP) in ATV or
the audio services in
DTV.
19. FAV.: Press to switch to
favorite channels.
20. C.C.: Press to open or
close the closed
captions.
21. ASPECT: Press to
adjust the width-to-
height ratio of the
image.
22. SLEEP: Press
repeatedly to set the
sleep time.
23. Record: Press to record
the program.
24. Stop: Press to stop
playing.
25. Pause: Press to pause
playing.
26. Play: Press to start
playing.
27. Previous: Press to skip
to the previous section.
28. Next: Press to skip to
the next section.
29. Rewind: Press to go
backward.
30. Fast-forward: Press to
go forward.
OK
INPUT
INFO
TV DVD AUDIO CABLE
GUIDE RETURN
MENU
MUTE
MTS
ASPECT SLEEP
FAV. C.C.
LAST
VOL
CH
1
3
7
10
9
12
13
16
19
23
27
5
21
18
15
25
29
2
4
8
11
14
17
20
24
28
6
22
26
30

18
English
Note:
• For best results, use the remote control within a proper distance from the
front of the TV. Do not exceed an angle of 30 degrees when pointing at the
TV.
• The operational distance may be shortened when the signal sensor is
directly exposed to strong light.
• Aim the transmitter on the remote control at the signal sensor and ensure
that there are no obstacles between them.

19
English
1.6 Inserting the Remote Control Batteries
1Open the battery compartment cover at the back of the remote control.
2Insert the batteries paying attention to the polarity markings (+ and -) inside the
battery compartment.
3Close the battery compartment cover.
PRESS
PRESS
