MODEL GE2 DUAL GAS & ELECTRIC WATER HEATER
OWNER’S MANUAL
HANSEN

Dimensions
Height 315mm
Width 305mm
Length 565mm
Model GE2
Capacity 19,5 Litres
Dry Weight 9kg
Water
Max Water Pump Supply Pressure 1,8 kPa Fiamma Aqua 8 Recommended
Working pressure 2 kPa
Pressure Relief Valve Set ting 3,0 kPa
Gas
Type LPG
Operating gas pressure 2,8kPa
Manifold pressure 2,1kPa
Heat input 1000watt
Injector size 0,70mm
Gas consumption 120 g/h
Recovery 25L/Hr
Electricity
Gas/electronics 12v DC (Min - 10v Max 13,8v)
Immersion element 1000watt
Voltage 230v~50hz
Working pressure 200kPa
Moisture res istance IPX1
120

Plastic dust
Travel cover

WARNING : Supply pump pressure MUST
NOT exceed 1.5 Bar. Recommend pump
Fiamma Aqua 8

9
10
1) Heat exchanger body
2) Thermostat mounting
3) Exhaust Flue
4) Wind shield
5) Gas burner
6) Gas connection
7) Sealing grommet
8) Gas Solenoid valve
9) Gas Injector
10) Spark Electrodes
Checking the spark & flame sense
1) Remove the upper heat plate by
loosening the securing 7mm nut.
2) Inspect the ceramic electrodes
for cracks
3) The distance between the spark
electrodes must be between 4-5mm.
4) The distance from the sense electrode
and the burner must be 4-5mm.

Black
Spark
Igniter
Electronic Control Board
9
10
+
-

Manufactured by : Hansen Water Heaters Pty Ltd
www.hansenproducts.co.za

Exterior Travel Cover
Fitting the Exterior cover by
pushing it over the flue exhaust.
Ensure the Cover is vertically straight
and line up the locking clip to the
the first slot on the flue vent (Pic 1)
Pic 1
PUSH
2 PULL
To remove the cover push the locking
clip in the side furthest from the face.
Remove by pulling on the tabs, the cover
fits snugly use a flat object against
the tab to pry off if tight.
1 PUSH
