Issue Date:
2021-06-21
Page 1 of 8
Report Reference #
E158873-A6076-UL
Copyright © 2019 1
1
UL TEST REPORT AND PROCEDURE
Standard:
UL 62368-1, 3rd Ed, Issued: 2019-12-13 (Audio/video, information and
communication technology equipment Part 1: Safety requirements)
CAN/CSA C22.2 No. 62368-1:19, 3rd Ed, Issued: 2019-12-13
(Audio/video, information and communication technology equipment
Part 1: Safety requirements)
Certification Type:
Listing
CCN:
AZOT, AZOT7 (Audio/video, Information and Communication
Technology Equipment)
Complementary CCN:
N/A
Product:
NETWORK CAMERA
Model:
XND-C9083RV, XND-C8083RV, XND-C7083RV, XND-C6083RV
Rating:
12 Vdc, 1.1 A or PoE (48 Vdc), 0.27 A (for model XND-C9083RV, XND-
C8083RV)
12 Vdc, 1.05 A or PoE (48 Vdc), 0.27 A (for model XND-C7083RV,
XND-C6083RV)
Applicant Name and Address:
HANWHA TECHWIN CO LTD
6, PANGYO-RO 319BEON-GIL, BUNDANG-GU
SEONGNAM-SI GYEONGGI-DO 13488 KOREA
This is to certify that representative samples of the products covered by this Test Report have been investigated in accordance with the
above referenced Standards. The products have been found to comply with the requirements covering the category and the products are
judged to be eligible for Follow-Up Service under the indicated Test Procedure. The manufacturer is authorized to use the UL Mark on such
products which comply with this Test Report and any other applicable requirements of UL LLC ('UL') in accordance with the Follow-Up
Service Agreement. Only those products which properly bear the UL Mark are considered as being covered by UL's Follow-Up Service
under the indicated Test Procedure.
The applicant is authorized to reproduce the referenced Test Report provided it is reproduced in its entirety.
UL authorizes the applicant to reproduce the latest pages of the referenced Test Report consisting of the first page of the Specific Technical
Criteria through to the end of the Conditions of Acceptability.
Any information and documentation involving UL Mark services are provided on behalf of UL LLC (UL) or any authorized licensee of UL.
Prepared By:
Lawrnece Lee / Project Handler
Reviewed By:
SeulKi Park / Reviewer

Issue Date:
2021-06-21
Page 2 of 8
Report Reference #
E158873-A6076-UL
2
2
Supporting Documentation
The following documents located at the beginning of this Procedure supplement the requirements of this Test
Report:
A. Authorization - The Authorization page may include additional Factory Identification Code markings.
B. Generic Inspection Instructions -
i.
Part AC details important information which may be applicable to products covered by this Procedure.
Products described in this Test Report must comply with any applicable items listed unless otherwise
stated in the body of this Test Report.
ii.
Part AE details any requirements which may be applicable to all products covered by this Procedure.
Products described in this Test Report must comply with any applicable items listed unless otherwise
stated in the body of each Test Report.
iii.
Part AF details the requirements for the UL Certification Mark which is not controlled by the technical
standard used to investigate these products. Products are permitted to bear only the Certification Mark(s)
corresponding to the countries for which it is certified, as indicated in each Test Report.
Product Description
NETWORK CAMERA has been designed for INDOOR use and integrated a bracket for wall or ceiling mount.
It is a commercial equipment supplied from 12 Vdc or PoE (Power over Ethernet) and installed by service
personnel.
Model Differences
XND-C9083RV is basic model.
XND-C8083RV, XND-C7083RV, XND-C6083RV are identical to basic model except model designation, rating,
and resolution.
Test Item Particulars
Product group
end product
Classification of use by
Instructed person
Supply Connection
not mains connected:
ES1
Supply tolerance
None
Supply connection – type
12Vdc, PoE (Power over Ethernet)
Considered current rating of protective device
N/A
Equipment mobility
wall/ceiling-mounted
Over voltage category (OVC)
OVC I
Class of equipment
Class III
Special installation location
N/A
Pollution degree (PD)
PD 2
Manufacturer’s specified Tma (°C)
55
IP protection class
IPX0
Power systems
not AC mains
Altitude during operation (m)
2000 m or less
Altitude of test laboratory (m)
2000 m or less
Mass of equipment (kg)
1.35
Technical Considerations
The product was submitted and evaluated for use at the maximum ambient temperature (Tma)
permitted by the manufacturer’s specification of : 55 °C

Issue Date:
2021-06-21
Page 3 of 8
Report Reference #
E158873-A6076-UL
2
3
The product is intended for use on the following power systems : No direct connection
Considered current rating of protective device as part of the building installation (A) : N/A
Mains supply tolerance (%) or absolute mains supply : No direct connection
The Risk Group of a lamp or lamp system (including LEDs) is : RG 1
The following are available from the Applicant upon request : Installation (Safety) Instructions / Manual
Additional Information
4789887496
- Maximum Normal Load: Continuous operation with IR LED on.
Additional Standards
The product fulfills the requirements of: N/A
Markings and Instructions
Clause Title
Marking or Instruction Details
Equipment identification marking
– Manufacturer identification
Listee’s or Recognized Company’s name, Trade Name, Trademark or File
Number
Equipment identification marking
– model identification
Model Number
Equipment rating marking –
ratings
Input Ratings (voltage, frequency/dc, current/power) Output Ratings
(voltage, frequency/dc, current/power)
Hard Copy
A. IMPORTANT
B. Please check 'Manuals' from out website, before connecting to the
supply.
C. Company website URL (https://www.~~)
Website Manual - 1
This product is intended to be supplied by a Listed Power Supply Unit
marked “Class 2” or “LPS” or “PS2” and rated from below.
12 Vdc, 1.1 A or PoE (48 Vdc), 0.27 A (for model XND-C9083RV, XND-
C8083RV)
12 Vdc, 1.05 A or PoE (48 Vdc), 0.27 A (for model XND-C7083RV, XND-
C6083RV)
Website Manual - 2
The wired LAN hub providing power over the Ethernet (PoE) in accordance
with IEEE 802.3.af shall be a UL Listed device with the output evaluated as
a Limited Power Source as defined in UL60950-1 or PS2 as defined in
UL62368-1.
Special Instructions to UL Representative
N/A

Issue Date:
2021-06-21
Page 4 of 8
Report Reference #
E158873-A6076-UL
1
4
BD1.0
TABLE: Production-Line Testing Requirements
BD1.1
Electric Strength Test Special Constructions – Refer to Generic Inspection Instructions,
Part AC for further information.
Model
Component
Removable parts
Test probe
location
Test V rms
Test V
dc
Test
Time, s
N/A
N/A
N/A
N/A
N/A
N/A
N/A
Earthing Continuity Test Exemptions – This test is not required for the following models:
BD1.2
All model
Electric Strength Test Exemptions – This test is not required for the following models:
BD1.3
All model
Electric Strength Test Component Exemptions – The following solid-state components
may be disconnected from the remainder of the circuitry during the performance of this
test.
BD1.4
All model
BE1.0
Sample and Test Specifics for Follow-Up Tests at UL
Model
Component
Material
Test
Sample (s)
Test Specifics
N/A
N/A
N/A
N/A
N/A
N/A

Issue Date:
2021-06-21
Page 5 of 8
Report Reference #
E158873-A6076-UL
3
5
4.1.2
TABLE: List of critical components
Pass
Object / part No.
Manufacturer/
trademark
Type / model
Technical data
Product Category
CCN(s)
Mark(s) of
conformity
Supplement ID
Bottom Enclosure
(Metal)
Interchangeable
Interchangeable
Aluminium, Min. 2.0
mm thickness, See
enclosure for
dimension.
-
Tested in equipment
Top Enclosure
(Metal)
Interchangeable
Interchangeable
Aluminium, Min. 2.0
mm thickness, See
enclosure for
dimension.
-
Tested in equipment
Top Case Enclosure
(Plastic)
LOTTE CHEMICAL
CORPORATION
HN-1068(+)(f1)
Polycarbonate (PC),
Min. 1.5 mm thickness,
rated Min. V-0,
130 deg. C.
QMFZ2/8
UL
(E115797)
Transparent Dome
Cover (Plastic)
MITSUBISHI
ENGINEERING-
PLASTICS CORP
S-3000(&6)(f1)
Polycarbonate (PC),
Min. 1.8 mm thickness,
rated Min. V-2, 115
deg. C.
QMFZ2/8
UL (E41179)
Internal Plastic Part
Materials
LOTTE CHEMICAL
CORPORATION
NH-1035(+)
Min. 1.5 mm thickness,
rated Min. V-0, 80 deg.
C.
QMFZ2/8
UL (E115797)
Internal Plastic Part
Materials - Alternate
LOTTE CHEMICAL
CORPORATION
HN-1068(+)(f1)
Min. 1.5 mm thickness,
rated Min. V-0, 130
deg. C.
QMFZ2/8
UL (E115797)
Internal Plastic Part
Materials - Alternate
Interchangeable
Interchangeable
Min. 1.5 mm thickness,
rated Min. HB, 80 deg.
C.
QMFZ2/8
UL
Fuse (F1)
LITTELFUSE INC
452*$, 454*
T1.5AL, 125 V
JDYX2/8
UL (E10480)
Fuse (F1) - Alternate
SEMITEL
ELECTRONICS CO
LTD
S6125S
T1.5AL, 125 V
JDYX2/8
UL (E19180)
Transformer (T1)
Group-Tek.
Electronic
Technology Co Ltd
PDT25165 SR
105 deg. C, see
enclosure for more
detail.
-
Tested in equipment

Issue Date:
2021-06-21
Page 6 of 8
Report Reference #
E158873-A6076-UL
3
6
Line Filter (T7)
Group-Tek.
Electronic
Technology Co Ltd
PCM10021R
18 mH, 125 deg. C, see
enclosure for more
detail.
-
Tested in equipment
Opto-coupler (LS1,
LS2)
LITE-ON
TECHNOLOGY
CORP
LTV-816
Isolation Voltage: 5
300. Max. Operation
Temperature: 110 deg.
C
FPQU2/8
UL (E113898)
Opto-coupler (LS1,
LS2) -Alternate
COSMO
ELECTRONICS
CORP
K1010X*
Isolation Voltage: 5
000. Max. Operation
Temperature: 115 deg.
C
FPQU2/8
UL (E169586)
Lithium Battery
(BAT1)
SEIKO
INSTRUMENTS
INC MICRO-
ENERGY DIV
ML414H
Lithium (Coin),
Rechargeable, Max.
ChargingVoltage: 5.0
Vdc, Max.
ChargingCurrent: 300
mAh
BBCV2
UL (MH15628)
Camera module
(with Zoom, Focus
Motor)
DongGuan YuTong
Optical Technology
Co ., Ltd.
YTW30033A01DB.I
R-PIRIS-JZ-
8MP+H151+IR0510
Max 5.0 V
-
Tested in equipment
Internal wiring
Interchangeable
Interchangeable
Low voltage, rated
minimum 80 deg. C, 30
V, marked VW-1
AVLV2
UL
Thermal Pad
KOMOTECH CO
LTD
KGP-1
Min. 0.2 mm thickness,
rated V-0, 150 deg. C
QMFZ2/8
UL
(E245303)
Thermal pad
Interchangeable
Interchangeable
Min HB, Min 100 deg.
C
QMFZ2
UL
Connectors and
Receptacles
(Secondary circuits)
Interchangeable
Interchangeable
-
ECBT2
UL
Connectors and
Receptacles
(Secondary circuits)
-Alternate
Interchangeable
Interchangeable
Copper alloy pins
housed in bodies of
plastic rated Min. V-2
QMFZ2
UL
Internal Wiring
(Secondary)
Interchangeable
Interchangeable
Marked VW-1; Min. 30
V, 80 deg. C
AVLV2
UL

Issue Date:
2021-06-21
Page 7 of 8
Report Reference #
E158873-A6076-UL
3
7
FPWB
SI FLEX CO LTD
T1
Min. V-0
ZPXK2
UL (E218849)
FPWB - Alternate
Interchangeable
Interchangeable
Min. V-0
ZPXK2
UL
PWB
Interchangeable
Interchangeable
Min. V-0, 130 deg. C
ZPMV2
UL
Label
Interchangeable
Interchangeable
Suitable for use on
each type of surface to
which applied, rated for
maximum surface
temperature specified,
or 55 deg. C if not
specified.
PGDQ2 or PGJI2
UL
IR LED (4 EA- LD1,
LD2, LD3, LD4)
OSRAM
SFH4718A
Vf=2.3Vdc(max)
-
Tested in
equipment
IR LED
(2 EA- LD5, LD8)
OSRAM
SFH4713A
Vf=2.3Vdc(max)
-
Tested in
equipment
IR LED
(2 EA- LD6, LD7)
LITEON
OPTOELECTRONI
CS
LTE-R38386L-YE5-
SS
Vf=2.5Vdc(max)
-
Tested in
equipment

Issue Date:
2021-06-21
Page 8 of 8
Report Reference #
E158873-A6076-UL
1
8
Enclosures
Type
Supplement Id
Description
Photographs
03-01
External View 1
Photographs
03-02
External View 2
Photographs
03-03
Internal View
Photographs
03-04
Image sensor board (Top)
Photographs
03-05
Image sensor board (Bottom)
Photographs
03-06
Camera Module 1
Photographs
03-07
Camera Module 2
Photographs
03-08
Main board (Top)
Photographs
03-09
Main board (Bottom)
Photographs
03-10
LED Board
Diagrams
04-01
Diagram
Manuals
06-01
Manual
Miscellaneous
07-01
Dual language safety labeling CRD
Miscellaneous
07-02
Transformer (T1) Specification
Miscellaneous
07-03
Linefilter (T7) Specification
Miscellaneous
07-04
Label
Miscellaneous
07-05
LED Label

The following Page(s) are related to Diagrams-01. The next supplement, if applicable, will be identified with a new
Supplement Page Heading.
