BC950
5MP Network Box Camera
Quick Start Guide
Quick Start
Guide
Unpack Installation Notices Connectors
Connector Definition Camera Cabling Alarm I/O and RS-485 Connection
Find additional manuals, the
datasheet, the EU Declaration of
Conformity, and the latest firmware
for this product at:
tkhsecurity.com
CAUTION INSTALLATION SHALL BE PERFORMED BY
QUALIFIED PERSONNEL ONLY. INSTALLATION SHALL BE IN
ACCORDANCE WITH LOCAL PROCEDURES. THE CAMERA
CONTAINS BATTERIES. DO NOT REPLACE IN RISK OF
EXPLOSION.
BATTERY REPLACEMENT SHALL NOT BE APPLIED IN VIEW
OF THE RISK OF EXPLOSION. LE REMPLACEMENT DES
PILES NE DOIT PAS ÊTRE APPLIQUÉ AU RISQUE
D'EXPLOSION. DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS. METTRE AU REBUT LES
BATTERIES USAGÉES CONFORMÉMENT AUX
INSTRUCTIONS..
FOR “PoE” INPUT CONNECTION, USE ONLY WITH UL
LISTED I.T.E WITH “PoE” OUTPUT. DESCRIPTION FOR THE
“PoE” IS INTENDED TO BE CONNECTED TO NOT EXPOSED
(OUTSIDE PLANT) NETWORKS OR EQUIVALENT
STATEMENT IN INSTALLAION INSTRUCTIONS.
POUR LA CONNEXION DâÇÖENTREE "PoE", UTILISER
UNIQUEMENT AVEC UN I.T.E. LISTE AVEC UNE SORTIE
"PoE". LA DESCRIPTION DE "POE" EST CONÇUE POUR
ÊTRE CONNECTÉE À DES RÉSEAUX OR NON ÉNONCÉS
(INSTALLATIONS EXTÉRIEURES), DANS LES
INSTRUCTIONS D’INSTALLATION DE L’INSTALLATION.
Subject to modification. Actual product and accessories may differ in appearance.
BC950
IT IS NOT RECOMMENDED TO CONTINUOUSLY
(24/7) RECORD WITH THE MICRO SD CARD, AS
THE CAMERA MAY NOT SUPPORT LONG-TERM
CONTINOUS DATA READ/WRITE. CONTACT THE
MANUFACTURER OF THE MICRO SD CARD FOR
INFORMATION REGARDING THE RELIABILITY
AND THE LIFE EXPECTANCY.
Connector Definition
1 BNC For analogue video output
2 Alarm I/O Alarm I/O connection. Do not connect external
power to the alarm I/O connector of the camera.
3 Power LED For power connection indication
4 Power & RS-485 For DC12V/AC24V power connection
5 Reset Button Press the button with a proper tool for at least 20
seconds to restore the system.
6
Insert the microSD card into the card slot to store
videos and snapshots. Do not remove the
microSD card when the cam era is powered on.
7 Audio I/O Two-way audio transmission.
8 Iris control P-iris and DC-iris Lens connection
9 RJ45/PoE Network and PoE connections. Contact TKH
Security for a compatible PoE injector.
See the diagram and the pin definition below for the
alarm I/O connection.
Figure 2 Diagram of Alarm I/O connection pins
Table 3 Pin definitions
Table 1 Connector definition
❑The green link LED is lit when there is a good network
connection.
❑The orange network LED flashes to indicate that there
is network activity.
IN SOME CASES, AN ETHERNET CROSSOVER
CABLE MAY BE NEEDED WHEN CONNECTING
THE CAMERA DIRECTLY TO THE PC. CHECK THE
STATUS OF THE LINK INDICATOR AND THE
ACTIVITY INDICATOR LEDS. IF THE LEDS ARE
UNLIT, CHECK THE LAN CONNECTION.
Power Connector (DC 12V, AC24V)
Table 2 Pin definition
Pin Definition
1 DC12V + / AC24V
2 DC12V - / AC24V
3RS-485 D+
4RS-485 D-
2021 | Vision 1 (20210601) | BC950 QSG
1x 4-pin and 1x
7-pin power
terminal block
Figure 1 Camera Connectors
1
2
3
4
1
2
3
4
5
6
7
