Happier camper Hc1 2016 User manual

Congratulations on acquiring your HC1. You are now the proud

owner of the most advanced recreational vehicle in the world

with a moduar interior and 100% fiberglass shell.

The enclosed information is provided to assist you with your

new ultralight portable modular home. Please familiarize

yourself with its contents so that you have solid confidence in

the HC1’s functionality.

We know you and your family will have many, many years of

carefree, comfortable and safe enjoyment and we welcome

you to our family of Happier Camper HC1 owners.

OWNER’S MANUAL 2016

Introducing the Happier Camper HC1

The remarkable HC1 combines the very best of yesterday and today, delivering

affordable adventure and ground-breaking flexibility in an ultra-light package. Designed

and built in California.

Our Journey was long but oh so worth it.

Our first travel-trailer - the HC1, is the result of a life-time of research and five years of

design. Vintage-inspired with all the benefits of the today, it is the very essence of

Retro-modern.

ULTRA-LIGHT 1100 LBS

TOW WITH MOST STANDARD CARS

100% FIBERGLASS CONSTRUCTION IN & OUT

ADAPTIV™ MODULAR INTERIOR

LARGE REAR HATCH DOOR

SLEEPS UP TO FIVE (6’ 11” BED SPACE)

RIGID FRAME W/BUILT-IN STABILIZERS

INDEPENDENT TORSION AXLES / 13” WHEELS

FITS IN A SINGLE PARKING SPACE

FEATU RES

Designed and built in California USA • contact us for updated pricing sales@happiercamper.com • www.hc1.info

SPECIFICATION

DRY WEIGHT

TONGUE WEIGHT

FENDER TO FENDER

EXTERIOR HEIGHT

OVERALL LENGTH

INSIDE WIDTH

INSIDE WIDTH AT BED

INSIDE HEIGHT

GROSS VEHICLE WEIGHT RATING

REAR HATCH OPENING

WALKABLE FLOOR SPACE

1100 LBS

110 LBS

10'

7' 4"

13'

6' 6"

6' 11"

6' 1"

3500 LBS

55"W x 54"H

42 SF

BASIC

BASIC SLEEPER

FULLY EQUIPPED

PREMIUM

COMMERCIAL

CONFIGURATION PACKAGES

Retro-modern at heart, delivering affordable

adventure and ground-breaking flexibility in an

ultra-light package. Featuring our Adaptiv™

modular interior for maximum utility and fun.

ULTRA-LIGHT TRAVEL AND UTILITY TRAILERS

MODULAR INTERIOR

Our highly flexible Adaptiv™modular interior system allows you to easily customize your trailer on-the-fly to suit a

variety of needs. From camping, to hauling, to guest quarters, create the layout you want in just minutes. Configuring

and reconfiguring is a snap, and the possibilities are limitless. We have reimagined what is possible with an ultra-light.

WE ARE PROUD OF OUR PRODUCT AND WILL STAND

BY OUR QUALITY AND WORKMANSHIP WITH A

3-YEAR WARRANTY. SEE WEBSITE FOR DETAILS.

WARRANTY

LARGE REAR HATCH AND DOOR ADAPTIV™ MODULAR INTERIOR EASILY CONVERTS TO A MINI TOY-HAULER

* Specifications and pricing subject to change

COLOR OPTIONS (LOWER HALF GEL-COAT FINISH)

MAMMOTH WHITE SILVER LAKE MOJAVE SAGESEQUOIA ORANGETOPANGA TURQUOISEBISHOP REDPACIFIC BLUE

MEASUREMENTS AND FEATURES

• ULTRA-LIGHT 1100 LBS DRY WEIGHT

• TOW WITH MOST VEHICLES

• 100% TOUGH FIBERGLASS CONSTRUCTION

• ADAPTIV™ MODULAR PLATFORM

• LARGE REAR HATCH DOOR

• SLEEPS UP TO FIVE ACROSS 6’ 11”

• 70SF with 42SF OF WALKABLE FLOOR SPACE

• STORAGE SPACE THROUGHOUT

• CUSTOM PRECISION COMPONENTS

• PANORAMIC JALOUSIE WINDOWS

• SOLAR-POWERED W/ CONTOURED PANEL

• RIGID FRAME W/BUILT-IN STABILIZERS

• INDEPENDENT TORSION AXLES / 13” WHEELS

• ADVANCED BATTERY AND ELECTRICAL COMPONENTS

• FITS IN A SINGLE PARKING SPACE & MOST GARAGES

• MODULAR UPGRADES WITH MANY OPTIONS AVAILABLE

( 10' )

( 13' )

( 6.1' )

( 7.4' )

( 54" )

( 55" )

( 6’6” )

( 6’11” )

( 30.5" )

( 62" )

Designed and built in California, U.S.A

#happiercamper • www.hc1.info

STANDARD FEATURES

EXTERIOR SHELL

100% DOUBLE HULL FIBERGLASS SHELL

CUSTOM ENGRAVED DOOR HINGES

FRONT ROCKGUARD AND PORTHOLE DOOR WINDOW

PRECISION HARDWARE, LOCKS, AND COMPONENTS

MARINE-QUALITY PARTS AND ACCESSORIES

FULTON® HEAVY-DUTY FRONT WHEEL JACK

PANORAMIC JALOUSIE LEVER WINDOWS

HONEYCOMB FIBERGLASS BASE

ADAPTIV™ DYNAMIC INTERIOR

PREMIUM STYLISH SNAPDOWN BLINDS

NESTED SIDE-DOOR STORAGE

PREMIUM SLIDING BLIND CLOSURES

STAINLESS STEEL FLOOR DRAIN

PERIMETER WALL STORAGE SPACE

INTERIOR SHELL UPPER STORAGE SHELF

5 RECESSED TABLE LEG MOUNTS

6 HEAVY-DUTY RECESSED D-RING TIE DOWNS

The HC1 is the result of a lifetime of enthusiasm and five years of careful design.

An Adaptiv™interior comes standard along with features like a huge rear hatch, wide entry

door, classic wheel fenders, honeycomb fiberglass floor, and large panoramic windows.

* Specifications and features subject to change

STURDY REINFORCED TUBE FRAME

BUILT-IN REAR STABILIZING JACKS

SWIVEL-BACK TONGUE

2" HITCH RECEIVER (SIDE AND REAR DOOR)

TORSION AXLE INDEPENDENT SUSPENSION

STANDARD ELECTRONIC BRAKING SYSTEM

13" ALUMINUM WHEELS

UNDERCARRIAGE 13" FULL-SIZED SPARE TIRE

RETRACTABLE JACK WHEEL

7-PIN WIRING HARNESS

6 RECESSED D-RING TIE DOWN MOUNTS

CUSTOM CURBSIDE FOOTSTEP

INDEPENDENT DIMMABLE LED LIGHTING

LARGE 7" LED TAIL LIGHTS

VINTAGE-INSPIRED TEARDROP REAR SIDE MARKERS

EXTRA-BRIGHT LED FRONT MARKERS

AGM MARINE BATTERY AND MOUNT

AC-DC CONVERTER/BATTERY CHARGER/FUSE PANEL

AC POWER DUAL WALL PLUGS W/ USB PLUG

BUILT-IN DC POWER "CIGARETTE LIGHTER” PORTS

MARINE-GRADE EXTERIOR AC POWER INLET

INTERIOR SHELL

FRAME AND CHASSIS

ADAPTIV™MODULAR INTERIOR

Our highly flexible Adaptiv™modular interior system

allows you to easily customize your trailer on-the-fly, to

suit a variety of needs. From camping, to hauling, to guest

quarters, create the layout you want in just minutes.

Configuring and reconfiguring is a snap, and the

possibilities are limitless.

ELECTRICAL AND LIGHTING

Table of Contents

Safety information

Chassis

Main Camper Assembly

Adaptiv™ Interior

Featured Accessories

Propane System

Water System

Warranty

7-Way Wiring Diagram

IMPORTANT SAFETY INSTRUCTIONS PLEASE READ AND FOLLOW ALL RELATED OPERATIONAL MANUALS

AND THE INSTRUCTIONS IN THIS OWNER MANUAL BEFORE USE. THIS OWNER’S MANUAL IS INTENDED TO

ACT AS A GENERAL GUIDE FOR OPERATION. THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE AND

MAY/MAY NOT INCLUDE INFORMATION REGARDING YOUR CAMPER. ALWAYS REFER TO THE SPECIFIC

MANUFACTURER’S OWNER, OPERATIONS, AND SAFETY MANUAL FOR OPTIONAL EQUIPMENT WHICH

INCLUDES, BUT IS NOT LIMITED TO, FURNACES, REFRIGERATORS, WATER HEATERS, COOKTOPS, AND

DETECTORS. SAVE ALL INSTRUCTIONS.

Reporting Safety Defects If you believe that your vehicle has a defect which could cause a crash or could

cause injury or death, you should immediately inform the National Highway Traffic Safety Administration

(NHTSA) in addition to notifying HAPPIER CAMPER. If NHTSA receives similar complaints, it may open an

investigation, and if it finds that a safety defect exists in a group ofvehicles, it may order a recall and remedy

campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or

HAPPIER CAMPER. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236

(TTY: 1–800–424–9153); go to http://www.safercar.gov

or write to:

Administrator

NHTSA

1200 New Jersey Ave SE

Washington, DC 20590

You can also obtain other information about motor vehicle safety from http://www.safercar.gov

Helpful Hints:

•Make sure your trailer is properly connected to your vehicle prior to towing

•Be sure the connecting ball is securely locked into the hitch tongue

•Never tow your trailer with the wheel jack down– stow it up prior to travel

•Never tow your trailer without your safety chains attached securely

•Open your roof fan and/or windows for ventilation prior to sleeping

•Never carry any passengers in the trailer while it is in tow

•Ensure your doors, hatch, roof fan and windows are closed and locked prior to towing

•Make sure the stabilizer jacks are locked in the “up” position prior to towing

•Exercise caution when opening hatch (stored items may have shifted around)

•Secure any loose items in your cabin and galley to avoid damage

•Be sure modular components are secured into place, use hardware when needed

•Be sure side door and rear hatch are closed and locked when traveling

•Check that all running lights are working properly before your drive

**To help reduce the chance of theft, make sure to lock the ball hitch lock with a padlock

after unhitching your viehicle from the trailer. The ball hitch is located right at the tip of

the hitch tongue.

Chassis

MECHANICAL MAINTENANCE SHOULD ONLY BE PERFORMED BY A QUALIFIED MECHANIC. IF YOU DO NOT

HAVE THE EXPERIENCE OR THE TOOLS TO SAFELY COMPLETE MAINTENANCE PROCEDURES, PLEASE

CONTACT YOUR DEALER. WE ASSUME NO LIABILITY FOR INJURIES OR DAMAGES INCURRED AS A RESULT

OF IRRESPONSIBLE, UNAUTHORIZED SERVICING.

Tires/ Air Pressure

Air pressure is the most important factor determining tire life and under inflation is the

number one cause of trailer tire failure. Generic advice would be to maintain

recommended airpressure listed on the tire sidewall, and periodically inspect both tires

for tread wear and damage from road hazards. However, for a smoother, truer pull, we

advise that your trailer tires be 35psi. All tires must be identical in size for the tires to

properly manage the weight of the trailer. To properly maintain your tires, clean with mild

soap and water. Do not use tire-care products containing alcohol or petroleum distillates

and be sure to inspect the tires for any cuts, snags, bulges or punctures.

Tire Sizes

The tires are 5-lug

50 psi (we recommend not filling it to that level).

It is important to maintain proper wheel mounting torque on your lug nuts. When possible,

use a torque wrench to prevent loose wheels and broken studs. Start all nuts by hand to

prevent cross threading. Tighten the lug nuts in stages. First, tighten to 20-25 ft./lb., then

to 50-60 ft. /lb., and finally to 85-90ft. /lb. Check lug nut torque before the first use. Check

periodically thereafter.

How to Change a Flat

First, get your trailer to a safe area where you have the space to work on it freely. Now, you

are ready to begin:

•Loosen the lugs

•Drop the nose of the trailer by cranking the wheel jack all the way DOWN

•Flip out and extend the rear jacks as long as they can go

•Crank the weel jack all the way UP

•Remove the lugs and the tires – replace with the spare located under the frame on front

curb side (undo housing bolt)

•Repeat the above steps in reverse

•Torque the lugs – YOU ARE READY TO GO!

Axle

**Follow all safety and specific operating instructions supplied by the axle

manufacturer.** All models use rubber torsion axles which offer greater dampening than

conventional spring suspensions and allow each tire to move independently. This feature

gives a smoother ride and improved tracking and cornering over rough road conditions. In

addition, this typeof axle has no metal to metal contact or springs, shackles, hangers, or

U-bolts to wear out.

IMPORTANT SAFETY INSTRUCTIONS PLEASE READ AND FOLLOW ALL RELATED OPERATIONAL MANUALS

AND THE INSTRUCTIONS IN THIS OWNER MANUAL BEFORE USE. THIS OWNER’S MANUAL IS INTENDED TO

ACT AS A GENERAL GUIDE FOR OPERATION. THIS MANUAL IS SUBJECT TO CHANGE WITHOUT NOTICE AND

MAY/MAY NOT INCLUDE INFORMATION REGARDING YOUR CAMPER. ALWAYS REFER TO THE SPECIFIC

MANUFACTURER’S OWNER, OPERATIONS, AND SAFETY MANUAL FOR OPTIONAL EQUIPMENT WHICH

INCLUDES, BUT IS NOT LIMITED TO, FURNACES, REFRIGERATORS, WATER HEATERS, COOKTOPS, AND

DETECTORS. SAVE ALL INSTRUCTIONS.

Reporting Safety Defects If you believe that your vehicle has a defect which could cause a crash or could

cause injury or death, you should immediately inform the National Highway Traffic Safety Administration

(NHTSA) in addition to notifying HAPPIER CAMPER. If NHTSA receives similar complaints, it may open an

investigation, and if it finds that a safety defect exists in a group ofvehicles, it may order a recall and remedy

campaign. However, NHTSA cannot become involved in individual problems between you, your dealer, or

HAPPIER CAMPER. To contact NHTSA, you may call the Vehicle Safety Hotline toll-free at 1–888–327–4236

(TTY: 1–800–424–9153); go to http://www.safercar.gov

or write to:

Administrator

NHTSA

1200 New Jersey Ave SE

Washington, DC 20590

You can also obtain other information about motor vehicle safety from http://www.safercar.gov

Electric Brakes

The STANDARD electric brake on your camper is similar to the brakes on your towing

vehicle, with the exception that the camper’s brakes are electromagnetic, while your

towing vehicle’s brakes are hydraulic.

Keep in mind that you must have a controller installed in your tow vehicle in order to enjoy

the intended benefits of electric brakes. When the brakes in the towing vehicle are

activated, your controller determines how hard they are being pressed, and sends the

appropriate current through the hitch wire to the brake assembly. As you depress the

brake pedal, the controller sends more current to the electromagnet, and the brake shoes

press harder into the brake drums, forcing the wheel to resist rotation. Releasing the

brake pedal decreases the current to the brake assembly, allowing the wheel to spin

freely. The brakes are self-adjusting, but will need an initial manual adjustment after the

first 200 miles. The brakes should be inspected every 3000 miles. Contact your dealer

unless you have the tools and experience to do a brake inspection, adjustment, and

replacement.

Brake Adjustment (SEEK PROFESSIONAL ASSISTANCE):

• Elevate the camper by positioning jacks under the frame 12” to 20” behind the axle. Use

the jack stands under the frame to support the camper any time it is elevated.

• NEVER PLACE THE JACKS UNDER THE FLOOR OR USE THE STABILIZERS TO ELEVATE

THE CAMPER.

• Do not remove the wheels or hub/drum assembly.

• Locate the adjusting slot at the bottom of the backing plate and remove the protective

cover.

• Loosen until the wheel turns freely.

• Replace the protective plug.

• Repeat adjustment steps for the other wheel.

• Never adjust just one brake.

Brake Inspection

The brake linings and magnets are subject to wear and require inspection every 6,000

miles or annually. Replacement is necessary if the linings are worn (to within 1/16” or

less), contaminated with grease or oil, or abnormally scored or gouged. It is important to

replace all linings (both wheels) at the same time to maintain even braking action across

the axle. Annually inspect the wires under the trailer and on the axle for broken insulation

or faulty connections. Repair or replace as necessary.

Bearing Inspection

Wash all grease and oil from the bearing and cone using a suitable solvent. Dry the

bearing with a clean, lint free cloth and

completely inspect each roller. Replace the bearing cone and cup if there are any signs of

pitting, wear, or corrosion. Repeat the inspection procedure for the inner bearing cone.

Bearing Lubrication

Proper adjustment and adequate lubrication of the bearings are essential to the longevity

and performance of your trailer axle. The bearings should be lubricated every 6000 miles

or 6months.

Procedure

•Remove the rubber plug from grease cap.

•Insert grease gun on the grease zerk.

•Pump until new grease begins to appear.

•Replace rubber plug.

Frame

No normal maintenance is required, but if the welds or scratches need attention, first

remove any rust, dirt, or grease and coat with gloss black touch up paint. There is a

receiver located on the rear bumper. This receiver is designed for light weight cargo with

the load positioned close to the receiver and bumper. The HC1 has a GWR of 3500.

Coupler

Your coupler needs no adjusting or maintenance other than periodic oiling to ensure

smooth operation. The HC1 uses a coupler that receives a 2” ball. Set the hitch height of

the tow vehicle so that the trailer is being pulled in a horizontal position. The height 15" is

the optimal height after the tongue weight is resting on the hitch. Trailers must be towed

as level as possible for proper handling and weight distribution. Be surveyor hitch is

connected securely to the ball, and that the pin in secured in your fold away tongue.

Attaching the Trailer to the Tow Vehicle

Position the receiver over the ball, and lift the tab handle of the hitch upward as you lower

the jack. After the ball is seated, allow the handle to return back down, parallel to the

frame.

Stabilizers

All trailers are equipped with lightweight 17” stabilizer jacks. Use the provided crank to

quickly stabilize the trailer from the rear . Their high-strength design allows for increased

load stabilization and fine leveling. Use in conjunction with the front wheel jack.

HC1 Assembly

100% Fiberglass Shell

The HC1 shell is made of 100% double-hull fiberglass. This includes the honeycomb floor

and both interior and exterior molded shells.

Fiberglass Maintenance

Fiberglass should be maintained on a regular basis. So just how regular is regular? In

order to answer that question we have to ask what kind of exposure to the elements the

vehicle receives. If the vehicle is kept dry and inside a garage away from the elements,

then exposure is minimal and the fiberglass can be maintained about every 6 months or so

with great results. However, if the vehicle is kept out in the elements under constant

exposure, then regular maintenance should be done every 3 months without fail. Without

regular care and maintenance, fiberglass will begin to show signs of oxidizing in 4 to 12

months.

Choose a wax suitable for fiberglass, like Protect All, Polish, Wax and Treatment with UV

Protectant. Regardless of the product you select, be sure to follow the application

instructions to ensure that you get the best results and all the benefits that the product

has to offer. Youtube.com is a great resource for videos on fiberglass maintenance.

Fiberglass Off-Gassing

What exactly is off-gassing, and should you be concerned?

Sometimes common building materials, in this case ones used in the fiberglass

manufacturing process, continue to release chemical vapors after the manufacture is

complete. The main chemical in question is formaldehyde. This occurrence is called

off-gassing. Our state-of-the-art fiberglass factory uses the safest, eco-friendly

manufacturing practices in the industry to keep exposure to harmful chemicals to the very

minimum. You may also notice some leftover fiberglass “dust” near the edges of cabinet

openings, etc. for about a week after purchase. This is common to the manufacturing

process and will subside shortly after use.

All fiberglass products must undergo a "curing" process of 30 days before being usable.

Once the fiberglass has cured, the material is stable, and the chances of any off-gassing

occurring are next to none. Your HC1 will have been curing in a well-ventilated area for

30-60 days prior to arriving at our sales lot.

**If you're planning on storing your trailer in a sealed area for an extended period of time,

we recommend airing it out for 24 hours prior to use.

Insulated Weather Barrier

The HC1 features a thin but highly protective layer of insulation wedged between the two

layers of the inner and outer fiberglass hull. The insulation is used in the upper portion of

the trailer along the roof and side walls. There is no layer of insulation in the space where

the windows go, along the upper shelving and around the lower cabinets (to make more

usable space).

DOUBLE HULL FIBERGLASS

WEATHER BARRIER

ADAPTIV™ Modular interior

Our highly flexible Adaptiv™ modular interior system allows you to easily customize your

trailer on-the-fly to suit a variety of needs. From camping, to hauling, to guest quarters,

create the layout you want in just minutes. Configuring and reconfiguring is a snap, and

the possibilities are limitless.

Our Adaptiv™ modular system is designed to allow you to easily configure the interior of

the trailer on-the-fly and in a variety of ways, with several sleeping arrangements for up to

five people, as well as many storage and countertop options. Consisting of modular

components or cubes, the Adaptiv™ system is unique in its ability to easily and

conveniently change a small space into whatever configuration you may need at the time.

Whether a standard camper that can comfortably sleep a family of four, complete with

kitchenette, dining table, and storage, or just one big bed to jump around on! A mobile

office, a sales space, or a completely empty “mini-toy hauler” capable of hauling larger

gear — let your imagination run free with endless possibility. Many of our modular

components perform double-duty as indoor-outdoor furniture. Take the cubes outside to

use for sitting, storage, or washing. The rugged materials will stand up to the elements

and provide the ultimate in camping convenience.

The modular floor, cubes and components

The modular floor of the HC1 is made of 1.5” thick honeycomb fiberglass. It’s super strong

yet incredibly light. Grooves are embedded in the floor to hold the Adaptiv™ cube

components in place — just like Lego®. The floor panels have additional embedded

features like table bases, frame-mounted D-Ring tie-downs, and a front drain to easily

hose down the floor for quick and convenient cleanups.

Our Adaptiv™ cube components are made from highly-durable and weather-resistant

molded materials. Designed to securely snap together, the cubes are light-weight yet

rugged, and are easily cleaned. Optional locking hardware is available to secure the boxes

to the fiberglass walls for partially fixed layouts. Our wood components, table-tops,

counter-tops, lids, and doors, are precision crafted using “Lite-Ply®”, a specialized

material which is 55% lighter than regular plywood yet just as strong. Table legs easily

snap into the floor and are uniquely placed for maximum convenience. Premium cushions

and carpeted floor panels share a molded base for snapping onto the floor or on top of

bench cubes for additional comfort and style.

• Standard 16”bench cube

• Standard 20” x 20” counter top cube

• Standard 20“ x 20” form-fitting cushion

• Standard 20”x 21.5”nesting table top

• Standard 20”x 20” floor panels

• 20”x 60”folding flat cushion

• Wooden countertop cube

• Wooden lid concealing cube

• Countertop 13”x 20”extension

• Modular ice box/cooler cube

• Electronic AC/DC cooler/heater fridge cube

• Kitchenette sink module w/ clean & gray water

• Toilet cover component

• Deluxe kitchen w/sink, stovetop range & pull-out fridge

• Outside patio tablebase mount

• Side-wall and cube locking hardware

ADAPTIV™MODULAR INTERIOR

Our Adaptiv™modular interior system is designed to allow you to easily reconfigure the interior of the trailer hundreds of

ways, with several sleeping arrangements (up to 5), storage, utility, and flexibility. Consisting of six base components or

cubes, the Adaptiv™ system is unique in its ability to easily and conveniently change a small space into whatever

configuration you may need. A variety of bed sizes, counter tops, tables, and storage can be put together in nearly limitless

ways to quickly build your ideal compact space, a standard camper that can comfortably sleep a family of four complete with

kitchenette, dining table, and storage or just one big bed to jump around on. A mobile office, a sales space, a completely

empty "mini-toy hauler" capable of hauling larger gear — let your imagination free with limitless possibilities in a finite space.

Many of our modular components perform double duty as indoor-outdoor furniture. Take the cubes outside to use for sitting,

storage, or washing. The rugged materials will stand up to the elements and provide the ultimate in camping convenience.

BENCH COMPONENT KITCHENETTE COMPONENT TABLE COMPONENT

CUSHION COMPONENT FLOOR PANEL COMPONENT LID COMPONENT

Surrounding cushions

Standard 16" bench cube

Standard 20" countertop cube

Standard 20 x 20" form-fitting cushion

Standard 20" x 21.5" nesting table top

Standard 20" x 20" floor panels

Basic 20” x 20” cushion w/o molded base

20" x 60" folding flat cushion

Wooden countertop cube

Wooden lid concealing cube

Counter top flip-n-lock 13" x 20" extension

Cooler/Ice box cube

Mini kitchenette cube w/sink

Toilet port-a-potty cube

Deluxe kitchen w/pull-out fridge, stove &

sink

Patio tablebase mount/cube lid

AVAILABLE COMPONENTS

CONFIGURATION EXAMPLES

Featured Accessories

SUSPENSION AWNING

Simply insert the supporting rods into the designated holes and tuck the opposite ends

into the pockets of the fabric. Supplied guy lines allow you to adjust the height of the

fabric. Taking it down is the reverse procedure: wrap the fabric around the rods and roll it

towards the awning case. The fabric and rods can easily be removed from the case if you

want to store it during the off-season.

ROADSHOWER™

The road shower is a pressurized 5 gallon solar-heated water tank mounted sleekly

beneath the rear hatch. Create pressure with a standard bicycle pump.

CEILING FAN

Top quality ceiling fan, which evacuates the hot air that collects inside the roof peak. Best

results can be achieved by closing all other roof vents and opening a window on the

shaded side of the camper. The roof vent must be open approximately 3” before the motor

will operate. Always lower and lock the vent in the down position before travel.

Standard Electrical Features

Exterior Running Lights

The HC1 is equipped with state of the are LED technology lighting throughout the trailer.

The exterior lights are high performance and extra bright, there are no bulbs to replace

and should last for many years. If a light is not working, please check your trailer wiring

hook up, or be sure nothing has pinched the trailers interior wiring harness. The HC1 uses

a 7-pin connector for vehicle hook up.

Interior Lights with Dimmer Switch

The interior lights of the HC1 use powerful, long-lasting LED bulbs. The upper cabinet

lights are click-operated; just press them in to turn on and off. The dimmer controls are

located just inside, next to the side door entrance.

MIGHTY MINI™ Converter

**Follow all safety and specific operating instructions supplied by converter

manufacturer. **

The converter changes standard household electrical power into 12 volt DC, the type of

electrical power necessary for the operation of RV appliances and recharging RV batteries.

-When connected to shore power, the converter will charge and supply power to

electronics (AC to DC power).

-When connected to shore power, the converter will automatically charge the onboard

AGM battery deep cycle battery. The converter will charge the battery quickly to 95% and

then slowly trickle-charge the remaining percentage, lengthening the life cycle of your

battery. The converter works as a breaker box for both AC fuses and DC fuses.

Please follow converter manual for operation and safety instructions. Do not block the

small, automatic cooling fan on the converter.

Auxiliary Battery

TO AVOID CONVERTER DAMAGE, DO NOT REVERSE THE BATTERY POLARITY!

Caution: Wet RV Batteries can contain sulfuric acid. Handle with care. An auxiliary battery

enables you to operate 12-volt dc appliances without draining your tow vehicle battery or

plugging your converter into a 120-volt AC receptacle. Lights, heater fans, water pumps,

roof fans, radios, and cigarette lighter receptacles can run on the auxiliary battery power.

Air conditioners, microwave ovens, and standard outlets operate exclusively on 120 volts

AC and therefore cannot run from auxiliary battery power. THE HC1 uses a large high

powered AGM deep cycle battery because its design gives maximum performance

between recharging without damaging the battery. Note: A deep cycle battery will take

longer to recharge as compared to a regular automotive battery. Secure the lug and wire

that has the 20-amp in line fuse to the batteries positive terminal. The lugs on the

remaining two white wires connect to the battery’s negative terminal.

** Do not reverse the polarity of the battery and 12 volt wires as damage canoccur to the

converter and wiring system **

If there is an electrical problem, first check the 20-amp fuse at the battery then check the

fuses located in the converter. Do not replace battery fuses with anything other than a

20-amp fuse. Some models are equipped with an internal storage box for the battery. This

dual-vented battery box is required to discharge the hydrogen gas produced during

charging. In cold weather, store the battery in a location where the temperature remains

above freezing. Do not charge or store your battery in the camper unless it is in its proper

enclosure.

120 Volt AC Amp Ratings Appliance or Electronic Equipment Estimated Amps

•Air Conditioner 12-16 Amps

•Blender 5-6 Amps

•Coffee Maker 5-8 Amps

•Compact Disc Player 1 Amp

•Computer (Laptop) 2-3 Amps

•Converter 1-8 Amps

•Crock Pot 1-2 Amps

•Curling Iron <1 Amp

•Drill 2-6 Amps

•Electric Blanket 0.5-1.5 Amps

•Electric Fan 1 Amp

•Electric Water Heater 9-13 Amps

•Electric Skillet 6-12 Amps

•Hair Dryer 5-12 Amps

•Iron 5-10 Amps

•Light (60 watt % 120V) <1 Amp

•Microwave 8-13 Amps

•Microwave (Convection Oven) 13 Amps

•Refrigerator in AC mode 5-8 Amps

•Space Heater 8-13 Amps

•Television 1.5-4 Amps

•Toaster 7-10 Amps

•Vacuum (handheld) 2-6 Amps

•VCR 1-2 Amps

•Washer/Dryer 14-16Amps

12 Volt DC Amp Ratings Appliance or Accessory Estimated Amps

•Aisle Light 1 Amp

•CO Detector 1 Amp

•LED Lights <1 Amps

•Furnace 10-12 Amps

•LP Gas Leak Detector 1 Amp

•Overhead lights (Per Bulb) 1 Amp

•Porch Light 1 Amp

•Power Roof Vent 1.5 Amps

•Radio/Stereo 4 Amps

•Range Hood (Fan & Light) 2-3 Amps

•Refrigerator (LP Gas Mode) 1.5- 2 Amps

•Security System 1 Amp

•Television (12 volt) 4-5 Amps

•TV Antenna Booster <1 Amp

•TV Antenna Booster 12 Volt outlet Up to 8 Amps

•Variable Speed Ceiling / Vent Fan 4 Amps

•VCR Recorder / Player 2 Amps

•Water Pump 4 Amp

Wattage % Volts = Amps ; Amps X Volts = Watts

Solar Panels and Inverter

It is possible for the HC1 to have perpetual power for its built-in electronics. The beefy

AGM Deep Cycle battery is continuously charged by the contoured 100-watt solar panel.

The auto-switching power converter provides both a DC and AC fuse panel and charges

your battery when plugged in. The super-clean waveform Zamp Solar™ power inverter

provides 600 watts of medical-grade power for your sensitive devices (computers, CPAP).

We built the HC1’s power system to be extremely efficient for extreme fun.

LP (Liquid Petroleum) Gas Tanks

The HC1 does not have a large propane tank. After years of experience, we feel strongly

that a large propane tank can be a safety hazard in a small, ultra-light fiberglass trailer.

Propane is a powerful fuel with many uses, but it can also be costly, smelly and is very

combustible. We recommend you use caution when using any flammable materials, and

ALWAYS use in a well-ventilated area to prevent any carbon monoxide accumulation. The

HC1 uses 1LB tanks for its portable propane heater and Dometic® stove top. The portable

butane stovetop uses disposable butane cartridges. If you have added your own propane

tank to the HC1, follow these instructions to maximize your LP gas experience:

To remove the tanks (or bottles) for filling, turn the tank valves off. Disconnect the hose or

fitting to the tank valve. Loosen the wing nut on the mounting bracket. To transport or

store the tank, install the plastic plug into the valve body. This prevents dust, dirt, and

moisture from collecting in the valve. This plug also protects the threads. After filling the

tanks, fasten them securely to the mounting bracket using the wing nuts. Checking for

Leaks A hissing sound, condensation, or LP odor may indicate a ruptured gas line, in which

case you should turn the tank valve off immediately and have the system service by an

authorized service center. Before checking for leaks, make sure all LP gas appliances are

turned off. Put out all flames and sources of sparks. Turn the tank valve on and generously

apply a mild soap and water solution to each connection. Bubbles will appear if there is a

leak. If it leaks at a fitting, simply tightening the fitting may stop the leak. Caution: Do not

over tighten the fitting as they may crack. If the leak continues even after tightening,

replace the fittings. Leaks around the seals or vents of the regulator will require replacing

the regulator. After testing for leaks, purge the air in the gas lines by opening a valve until

you detect the odor of LP gas. Allow enough time for the gas to dissipate before lighting

any appliances. Periodically inspect the tanks for dents, cracks, and corrosion. Inspect the

mounting hardware and hoses for signs of wear, and replace if necessary. Always keep the

valve on the tank closed when not in use or when traveling. Never fill a tank over 80%.

Never test for leaks with a flame, or use products containing ammonia or chlorine to test

for leaks. Do not store your tank in an enclosed place with extreme temperature changes.

If necessary, you may repaint your tank.

Stovetop

** Follow all safety and specific operating instructions supplied by stove manufacturer.

** NEVER OPERATE THE STOVE FOR COMFORT HEATING! BEFORE LIGHTING THE STOVE,

OPEN A WINDOW AND A ROOF VENT FOR ADEQUATE VENTILATION. Failure to observe

these rules may result in potentially dangerous levels of carbon monoxide inside the

camper if equipped with a built-in counter cooktop burner indoor/outdoor cook top.

Manual Lighting Instructions:

•Make sure LP gas is on at the shutoff valve.

•Press burner control inwards and turn counter-clock wise.

•Immediately light the burner by holding a match or handheld spark igniter near the

burner ports.

•Extinguishing instructions: Turn the appropriate burner knob clockwise to off.

Indoor / Outdoor Butane Stove Instructions:

** Follow all safety and specific operating instructions supplied by stove manufacturer. *

For units equipped with the indoor/outdoor stove or grill:

** Do not operate indoor / outdoor stove or grill with optional awning erect. **

Water System

The HC1 sink/kitchenette component features an onboard water tank that can be filled

manually through the inlet on the rear of tank. It holds approx. 5 gallons of water. Your

camper has two hoses, one for filling the storage tank with fresh water and one for grey

(used) water. When connected, you can drain the grey water through the exterior drainage

port located on the inside wall of the camper's interior.

Common Issues & Troubleshooting

Contact Happier Camper

[email protected]

310.570.8864

3-Year Structural Warranty

Happier Camper warrants the fiberglass structure to be free from defects in workmanship

for a period of 36 months from the date of sale. The warranty does not apply to any trailer

which has been altered outside our factory, or which has been subject to misuse,

negligence, or accident. Correspondence regarding the warranty should include the serial

number, date of purchase, owner’s name, and full contact information. Many appliances

and components offered carry their own warranties. Please consult your manual for a

complete list. Happier Camper conducts ongoing product development and thus reserves

the right to change specifications and pricing without notice or obligation to prior sales.

Featured Accessories

SUSPENSION AWNING

Simply insert the supporting rods into the designated holes and tuck the opposite ends

into the pockets of the fabric. Supplied guy lines allow you to adjust the height of the

fabric. Taking it down is the reverse procedure: wrap the fabric around the rods and roll it

towards the awning case. The fabric and rods can easily be removed from the case if you

want to store it during the off-season.

ROADSHOWER™

The road shower is a pressurized 5 gallon solar-heated water tank mounted sleekly

beneath the rear hatch. Create pressure with a standard bicycle pump.

CEILING FAN

Top quality ceiling fan, which evacuates the hot air that collects inside the roof peak. Best

results can be achieved by closing all other roof vents and opening a window on the

shaded side of the camper. The roof vent must be open approximately 3” before the motor

will operate. Always lower and lock the vent in the down position before travel.

Standard Electrical Features

Exterior Running Lights

The HC1 is equipped with state of the are LED technology lighting throughout the trailer.

The exterior lights are high performance and extra bright, there are no bulbs to replace

and should last for many years. If a light is not working, please check your trailer wiring

hook up, or be sure nothing has pinched the trailers interior wiring harness. The HC1 uses

a 7-pin connector for vehicle hook up.

Interior Lights with Dimmer Switch

The interior lights of the HC1 use powerful, long-lasting LED bulbs. The upper cabinet

lights are click-operated; just press them in to turn on and off. The dimmer controls are

located just inside, next to the side door entrance.

MIGHTY MINI™ Converter

**Follow all safety and specific operating instructions supplied by converter

manufacturer. **

The converter changes standard household electrical power into 12 volt DC, the type of

electrical power necessary for the operation of RV appliances and recharging RV batteries.

-When connected to shore power, the converter will charge and supply power to

electronics (AC to DC power).

-When connected to shore power, the converter will automatically charge the onboard

AGM battery deep cycle battery. The converter will charge the battery quickly to 95% and

then slowly trickle-charge the remaining percentage, lengthening the life cycle of your

battery. The converter works as a breaker box for both AC fuses and DC fuses.

Please follow converter manual for operation and safety instructions. Do not block the

small, automatic cooling fan on the converter.
