Service Manual
AUTHENTICS L16
Wireless 300W powered loudspeaker with CLARI-FI, phono
input, real wood grain enclosure.
Released EU2014 Harman Consumer Group, Inc. Rev 1,12/2016
8500 Balboa Boulevard
Northridge, California 91329
QUICK START GUIDE 2
LED INDICATION TABLE 9
SPECIFICATIONS 10
WIFI SETUP 11
TROUBLESHOOTING 12
EXPLODED VIEW + PARTS 13
PARTS LIST 14
PCB DRAWINGS 21
BLOCK DIAGRAM 25
SCHEMATIC DIAGRAMS 26
CONTENTS

AUTHENTICS L16

Quick Start Guide
Guide de démarrage rapide
AUTHENTICS L16
WPS
ON / OFFPOWEROPTICALPHONO INGROUNDING
AUX IN
WPS
iPad
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
*For charging external
devices only
For charging external
devices only*

Quick Start Guide
Guide de démarrage rapide
AUTHENTICS L16
2
3
PRESS < 1s

Quick Start Guide
Guide de démarrage rapide
5
AUTHENTICS L16
4< 2s
JBL L16
PAIR
YES NO
<2s <2s <2s <2s <2s

Quick Start Guide
Guide de démarrage rapide
7
AUTHENTICS L16
6
iOS
1
3
2
WPS
Wireless router
WPS
USB
AUX IN
WPS
AUX IN
WPS
iPad
Allow
> 2s

Quick Start Guide
Guide de démarrage rapide
9
8
AUTHENTICS L16
JBL MusicFlow app
JBL MusicFlow app
jbl.com/authenticsl16
JBL MusicFlow app

Quick Start Guide
Guide de démarrage rapide
EN
•Type: Powered three-way stereo speaker with wireless audio playback
and control
• High-frequency transducers: 19mm tweeter
• Mid-range transducers: 2 inch mid range
• Low-frequency transducers: 5.25 inch woofer
• Frequency response: 40Hz – 35kHz
• Maximum SPL: 108dB @ 1m
• Signal to Noise Ratio (wireless & analogue inputs): 92dB
• Signal to Noise Ratio (digital inputs): 98dB
• Amplifier power: 6 x 50W RMS
• Amplifier THD at full power: < 0.1%
• Wireless audio playback formats: AirPlay, DLNA, Bluetooth,
auto-switching
• Connections: 1 x stereo 3.5mm, 2 x USB (type A), 1 x Stereo RCA
phono input, 1 x Digital optical input
• Dimensions (H x W x D): X-X/X" x X-X/X" x X-X/X"
(XXXmm x XXXmm x XXXmm)
• Weight: XX lb (XXkg)
• Power supply: 100-240V~50/60Hz
• Power consumption: 120W maximum, <0.5W eco-standby mode
• Bluetooth transmitter frequency range: 2.402 - 2.480GHz
• Bluetooth transmitter power: Max 4dBm
• Bluetooth transmitter modulation: GFSK, π/4 DQPSK, 8DPSK
• Airplay Frequency range: 2412MHz~2472MHz (2.4GHz ISM Band, USA
11 Channels, Europe 13 Channels)
• Airplay Transmitter power: <20dBm (EIRP)
• Airplay Modulation: 802.11b:DSSS (DBPSK, DQPSK, CCK) ;
802.11g:OFDM (BPSK, QPSK, 16QAM, 64QAM);
• Airplay network compatibility: 802.11b/g
AUTHENTICS L16

Authentics L16
LED Indication Table
14
LED State Indication
Power LED White, Constant Operational mode
Amber, Constant Sleep mode
Off OFF/Standby mode
Bluetooth LED White, Constant Bluetooth connected
White, Regular Flash Bluetooth disconnected and pairing mode
AirPlay LED White, On AirPlay source active, Wi-Fi info sharing
DLNA LED White, On DLNA source active, Wi-Fi Manual Connect mode
Aux-in LED White, Constant Line-in source active
Phono LED White, Constant Phono source active
Optical LED White, Constant Optical source active
Volume LEDs White, Constant Volume Level
All LEDs Flash five times Factory settings restored
Wireless Charging White, On Charging device recognition
White, Breathing Charging
White, Quick Flash Error indicator
LED Indication Table

Authentics L16
Specifications
16
Specifications
Type Powered three-way stereo speaker with wireless audio
playback and control
High-frequency transducers 1 inch tweeter
Mid-range transducers 2 inch midrange
Low-frequency transducers 5.25 inch woofer
Frequency response 35 Hz – 35 kHz
Maximum SPL 108 dB @ 1m
Signal-to-Noise ratio (analog inputs) 92 dB
Signal-to-Noise ratio (phono MM input) 78 dB
Signal to Noise Ratio (digital inputs) 95 dB
Amplifier power 6 x 50W RMS
Amplifier THD at full power <1%
Wireless audio playback technologies AirPlay, DLNA, Bluetooth
Connections 1 x stereo 3.5 mm, 2 x USB (type A), 1 x Stereo RCA
phono input, 1 x Digital optical input
Dimensions (H x W x D) 294 mm x 818 mm x 369 mm
Weight 16.3 kg
Power supply 100-240 V~50/60 Hz
Power consumption 300 W maximum, <0.5 W eco-standby mode
Bluetooth transmitter frequency range 2.402 - 2.480 GHz
Bluetooth transmitter power Max 4 dBm
Bluetooth transmitter modulation GFSK, π/4 DQPSK, 8DPSK
AirPlay frequency range 2412 MHz~2472 MHz (2.4GHz ISM Band, USA 11
Channels, Europe 13 Channels)
AirPlay transmitter power <20 dBm (EIRP)
AirPlay modulation 802.11b:DSSS (DBPSK, DQPSK, CCK) ;
802.11g:OFDM (BPSK, QPSK, 16QAM, 64QAM)
AirPlay network compatibility 802.11b/g

1. Download the JBL Music app to help you
easily join your Wi-Fi network.
2. Find “+” in the dashboard, then press it for a
step by step guide.
Wi-Fi setup
B. Wi-Fi Sharing with Cable
1. Connect your iPhone, iPad or iPod touch to the top
USB port using the USB to 30-pin or USB to
Lightning cable that is provided with your iphone,
ipad or ipod touch.
2. Ensure your iPhone, iPad or iPod touch is connected
to your Wi-Fi network.
3. Switch the Authentics to the AirPlay input by pressing
the source button.
4. Press the AirPlay button on the JBL Authentics for
more than 2 seconds.
5. A pop up window will be displayed on your iPad,
iPhone or iPod touch with the question “Share Wi-Fi
Settings?”
6. Press Allow. The phone will then transfer settings and
the Authentics will attempt to join your wireless network.
This could take up to 1 minute.
Once the JBL Authentics is connected to the network, the
Wi-Fi LED will be constant White.
+
Setup by APP For iOS user
1. Power on JBL Authentics and wait for about 1
minute. Then switch source to DLNA mode by
pressing source button.
2. Long press the source button for 5 seconds then
release, the DLNA LED shall flash twice.
3. Use your computer or phone/ tablet to search for a
Wi-Fi Network called “JBL_L16XXX” on the Wi-Fi
list and connect it. Once connected successfully,
the DLNA LED will stop flashing.
4. Open the web browser on your computer or
phone/tablet, and in the address bar, type
“192.168.1.1” and press enter. You should see the
JBL Authentics setup page.
5. Choose the Wi-Fi network you want to join, enter the
password and click “Save”.
6. JBL Authentics will then attempt to connect to your Wi-Fi
Network (the LED shall flash during the connecting
process). Once connected successfully, the LED will stop
flashing and an audio tone will be heard.
Connect your computer or phone/ tablet to the same Wi-Fi
network as Authentics and enjoy your music wirelessly.
Manual setup:
Authentics L16
297 mm
257 mm
210 mm 170 mm

Authentic L16 troubleshooting flow
Dear customers,
We kindly thank you for using this product, following are instruction if you have troubles using it.
A. If the product is unable to power on, there are below actions you should follow:
1. Make sure the circuit is open and you should plug in your product then turn the AC power
switch into option “on”, then press the power key.
2. If the product is still unable to work, please contact our customer service.
B. When you can’t wake up the Bluetooth via your phones/computers, advice will be taken by
following:
1. Make sure your phones/computers have an available Bluetooth function.
2. Please keep the source option of the product is located on Bluetooth set and keep the
Bluetooth indication logo in flickering situation.
3. Besides above two items, you also need to take care your Bluetooth connection option is for
“JBL-L16-bluetooth wireless”.
4. If the Bluetooth function is still no working, please reboot the product and connect again.
C. When you can’t connect the Bluetooth function via the NFC tag, we will suggest you below:
1. Make sure your device is available for NFC connection.
2. You need to put your device in near front of the NFC area, you need to mind that too far
interval between you device and the NFC tag won’t be able to arouse the Bluetooth.
3. If there is still no connection tips on your device, we advice you reboot your device for double
connection.
D. If the product is unable to connect the airplay, we will suggest you below:
1. Make sure the USB connection between your Iphone/ipad and the product is available.
2. After 5 seconds press the source key, the screen of your device will jump out a caption “do
you want to share your device via airplay”, and you should choose “allow” for the allowable
connection.
3. Make sure the itune software of your computer is running, and you should choose the
“JBL-L16-WIFI” for your music sharing.
4. If the airplay still doesn’t work, please reboot your router and computer then connect again.
F. If the product is unable to connect the DLNA, we will suggest you below:
1. Make sure your source select is DLNA mode.
2. Please make sure all devices for wireless linking is power on.
3. Please be sure your internet IP code input is: 192.168.1.1, then you should choose your
network device to be compatible with your router.
If there are any other problems, welcome to contact our customer service.
Thank you for your feedback ！
Mobile: +86
Address:
Fax:
Company signature:

JBL AUTHENTICS L16 EXPLODED VIEW AND PARTS

JBL AUTHENTICS L16 PARTS LIST
700134 07801-> 710134 07801 loudspeaker 1,00
JBL Authentic L16 loudspeaker
806013400500S foam 1,00 358*110*200 upper left
806013400600S foam 1,00
358*110*200 upper right
806013400700S foam 1,00 358*110*200 downward left
806013400800S foam 1,00
358*110*200 downward right
813100500100S non-woven fabrics bag 1,00 1000(unsealed)*500
801013400100S inner box 1,00 358*200*50
EWP0200008340 Power cord 1,00
Power cord,EMEA,L=2000mm,black ,H05VV-F 3*0.75/Ф6.5,EMEA plug ,triangle plug
EWP2200008240 Power cord 1,00 Power cord,EN,L=2000mm,black,H05VV-F 3*0.75/Ф6.5,EN plug,triangle plug
800013400900S carton 1,00 835*385*315
805013400800S gifty box 1,00 L16 EMEA
815013414000S sticker 1,00
160*60 PET
819003900400S leaflet 1,00 32pp safe sheet
815001005055 sticker 1,00 9*4 blank chrome paper scroll
815001005056 sticker 1,00 18*4 blank chrome paper scroll
815001005057 sticker 2,00 HF 50*20 blankchrome paper scroll, HF
815001005058 sticker 1,00
SONY brand, 70.7*48.5 blank chrome paper scroll,
815001005059 sticker 1,00 90.85*62 blank chrome paper scroll,
815007731801S sticker 4,00
45*50mm BOPP
811071200100S PE bag 1,00 680
（
unsealed
）
*1160 , for gifty box
811000132001 PE bag 1,00
125*226*3C PO print
819013402100S leaflet 1,00 157gchrome paper，22p，80*150
710134 07801-> APA200L160101 TI level 1,00 L16 Main Board TI level
APA200L160201 Ti level 1,00
L16 Volume Control Board TI level
APA200L160401 Ti level 1,00 L16 IO Board TI level
APA200L160501 Ti level 1,00
L16 DSP Board TI level
ETSMO1024BA0N SMPS 1,00 SMPS ,input 100V-240V, output 27V/5A,5V/3A,
京泉华
APA200L160301 TI level 1,00
L16 Source Select Board TI level
350050 14301
speaker
2,00 HMM 4ohm mid range
110134 07801 woofer 2,00
HMM 4ohm
320025 03706 tweeter 2,00 4ohm
EW16074606000 wire 1,00
6P black red wire, one side 6P/3.96mmVH style plug,other side speaker connectted
EWF1028090180 FFC wire 1,00
FFC wire ,type A ,white,18PIN,PH=0.5mm,L=280mm
PAS00027001
Airplay module 1,00 Airplay module,Brigeco type CX870-3IB IC:2581A-CX8703I FCC:ZQC-CX873I
EWA6L16L80030 bluetooth antenna 1,00
2.4G PCB antenna with shielded wire ,one side with metal toggle, other side
EWA6L16L80010 antenna 1,00
Airplay copper tube anttnna ,with shielded wire ,one side with metal toggle, other side
EWA6L16L80020 antenna 1,00
Airplay PCB anttnna ,with shielded wire ,one side with metal toggle, other side PCB
ESW0922040030 boat shape switch 1,00
boat shape switch,2 options ,2 groups ,4PIN,
凯威
P/N:HRS-6109-0ABR-RoHS(RL3),
EWF2028090100 FFC wire 1,00 FFC wire ,eype B,white ,10PIN,PH=1.0mm,L=280mm
EW24034412000 wire 1,00
12P balck red wire, both sides 12P/2.54mm, buckled jack ,jack reversed wire order
EW18034604010 wire 1,00
4P black red wire ,both sides 4P/3.96mm type VH jack , jack reversed wire order
EWD1006006000 single wire 1,00
single double isolation wire ,UL1007,L=60mm,balck ,18AWG,both sides 5mm
EWD1006026001 single wire 1,00
single double isolation wire,UL1007,L=60mm,red ,18AWG,both side 5mm soldered ,with
EW16044603010 wire 1,00
3P red black terminal double isolation wire,one side 3.96mm plug ,other side 5mm
EW16044606000 wire 1,00
6P red black wire,one side 6P/3.96mmVH type plug,other side with speaker connectted
EJP0121300010 AC SMPS jack 1,00
triangle plug,black ,250V,10A, folded,with UL&CE certification ,
金佳
FL540 025 double tape 0,01 3M
，
9448HKB W=8MM (骏万丰)
EZAB9930C2121 free lead solder 2,00
HF free lead soldered, B9930C
，
conductor core1.2mm,main component:tin +0.7%
FL503 010 adhesive 2,00 BG-800, black (UL certification),
安盛电子，
HF,HB
FL581 008 581 008 1,00 red oil , fastening material
FL591 164 shrink tube 0,60
shrink tube Φ6.0 black
DF0168001010 port tube assemble 2,00 167.6*148.5*119.6 DG0129002010+DG0114001010+DG0095001010
MT0690001010P wooden box assembly 1,00
XT0690001010P+GB0199001010P
MZ0208001010 top case 1,00 208.4*128.4*74.5,ABS
（
V0
）
, matt balck, eroded
HZ0206003010 bottom case 1,00
205.9*105.9*47,ABS
（
V0
）
,matt balck, eroded, white print
ZJ0108004010 port tube bracket 2,00 107.8*91.6*28.8,ABS（V0）matt black
JL0020010010 key
（
Source
）
1,00 20.1*18.6*10,ABS757,surface electroforming CD line,plated 8400C,laser mark
JL0024003010 key
（
power
）
1,00
Φ23.6*16.8,ABS757,surface electroforming CD line,plated 8400C,laser mark
JL0036009010 key
（
WPS
）
1,00 35.7*19.9*11.4,ABS matt black ,surface eroded
XN0045005010 volume knob 1,00 Φ45*11.5 ABS757,surface electroforming CD line,plated 8400C
Code name Part number Part name Usage Spec Location

Code name Part number Part name Usage Spec Location
MZ0049003010 Source cover 1,00 Φ49*15.1 ABS757,surface electroforming CD line,plated 8400C,laser mark
ZS0022004010 switch decorate cover 1,00 21.6*11.6*7.7 ABS matt eroded
AJ0056003010 guide light bracket 1,00 Φ56*17 transparent ABS
，
surface eroded
TT0010029010 grommet 12,00 9.6*9 45° black TPE
MP0020005010 LOGO badge 1,00 19.97*19.97*8 AL
，
surface oxidate line mark, spray silver oil
SR0574001010 heat sink 1,00 574*184*31.5 AL
，
spray silver oil
DQ0209007010 垫圈 1,00
209*129*35.1 50° black rubber
，
with double tape bottom and side
TT0061001010 rubber cover 1,00 61*46*26.5 35° black rubber
TT0012027010
脚垫
4,00 Φ12.5*3
；
black silicon rubber
，
hardness 80±5°
，
one side with double tape
GA0003006010
垫片
4,00 Φ3*2.5 30° black silicon rubber
ZZ0007005010 interval pillar 5,00 Φ7.1*Φ3.9*9.7 NL66(94V-2)
SBW050202160 screw 8,00 carbon steel cross shape semi ball screw M5*20
自攻木（头
Φ9.5
）黑锌（
common
）
SKW040162101S screw 14,00
carbon steel cross shape countersunk
SPT030101160S screw 10,00
800-0148-001 carbon steel cross shape semi ball screw :PT3*10
自攻牙
(
头
Φ6)
黑锌
SBT030061160 screw 5,00 carbon steel cross shape semi ball screw PB3*6
自攻牙
(
头
Φ6.3)
黑锌
(
通用
) |
JG589761 screw 18,00
carbon steel cross shape semi ball screw with plate : PWM3*8
机牙
(
头
Φ7);
彩锌
SBT025102160 screw 3,00 carbon steel cross shape semi ball screw PA2.5*10 自攻牙(头Φ6)黑锌 ( common)
SWT017064111S screw 2,00
carbon steel cross shape semi ball screw with plate
AJ0077001010 fixed case
（
volume
）
1,00 77*74*13 ABS
（
V0
）
matt black
AJ0076001010 fixed case
（
Source
）
1,00 76*67*10 ABS
（
V0
）
matt black
AJ0079003010 fixed case
（
top case
）
1,00
79.3*64.3*8.5 ABS, matt black, eroded
TT0015019010 steel foot 4,00 Φ14.7*31.5
碳钢，电泳黑
STW035202160 screw 5,00
carbon steel
大扁头
TA3.5*20
自攻木（头
Φ8
）三价铬黑锌（
common
）
GA0588001010S EVA 6,00 588*8*1 black EVA
， 硬度
35
， 单面粘胶
GA0700001010
垫片
1,00 700*4*1T
防火
CR,
硬度
25
单面粘胶
QQ0195002010 EVA strip 1,00 195*8*1 gray high flexible EVA
JG589062 589 062 6,00 carbon steel cross shape semi ball screw M3.5*9
自攻牙
(
头
Φ5.7)
， 白锌
SCW030122161S screw 8,00 carbon steel cross shape
薄片头
3*12
木牙自攻粗牙
(
头
Φ5)
黑锌（
common
）
GA0011020010 垫片 2,00 Φ11*Φ8*2 black PORON L-32
硬度
30°,
单面背胶
SCM040124121S screw 1,00 carbon steel
内六角圆柱头
4*12
机牙（头
Φ7
）侧边压花
,
白锌
(common)
QQ1000007010 acoustic foam 1,00 150*1000*50 white fireproof foam
FL520 003 520 003 5,00
cleaning liquid
GA0038011010 insulating trip 1,00 38*28*0.1 black
防火麦拉片
GA0058008010 insulating trip 1,00 58*38*0.38 black
防火麦拉片
GA0138003010 insulating trip 1,00 138*58*0.5 0.5mmblack
防火
PC
片
QQ1875000303S stripe foam 1,00 500*30*3mm, fireproof , environmental protection material
。
FL580 010 silicon cleaning liquid 0,05
for rubber finishing
FL583 011 密封胶条 0,02 Φ5*5 black pressure-sensitive adhesive
FL587 022 587 022 1,00
φ9*φ4*0.8 iron, with white zinc plated
GA0111002010 EVA 2,00 110.8*18*2
；
35±5°black fireproof EVA
，
with double tape one side
GA0180011010 EVA 2,00
180*4*2
；
35±5°black fireproof EVA
，
with double tape one side
FL504 001 504 001 5,00 HS-747H
JG589853 screw 4,00
carbon steel cross shape semi ball screw with plate
EW48034215010 wire 1,00
15P black red wire ,both sides 15P/1.5mmVH type jack,jack reversed wire order
EWD1020007840 single wire 1,00
single wire ,UL1007,L=200mm,black,20AWG,one side Φ4.2
接地环
,one side
EWDB006596800 single wire
single double isolation wire ,UL1672,L=65mm, white,18AWG,one side Φ4.2
接地环
,one
EWDB006547820 single wire 1,00
single double isolation wire ,UL1672,L=65mm,yellow ,20AWG,one side Φ4.2
接地环
,one
GA0028019010 EVA 1,00
28*18*8 blackEVA
，
35±5°
，
normal double tape on bothe sides
JG589840 screw 8,00 800-0065-007 carbon steel cross shape semi ball screw PT3*8
自攻牙
(
头
Φ5.6);black
FL591 044 ribbon 1,00
4*150mm transpearent nylon ribbon
WT0590002010 grill assembly 1,00 WG0590002010+QQ1170001010+MP0020005010
GA0645001010 EVA 1,00 645*12*1 gray
高弹
EVA
，
hardness 15±5°
，
one side with PET double tape
GA0031010010 EVA 4,00 31*15*6 blackEVA
，
hardness 35±5°
GA0050040010 EVA 1,00 Φ50*0.5
；
blackEVA
，
hardness 35±5°
GA0058010010 insulating trip 1,00 58*38*0.38 black
防火
PC
片
APA200L160101-
APA200L161101 HI level 1,00 L16 Main Board HI level
EJU4100600010 USB jack 2,00
USB jack ,
插件
,
垂直立式母座
,1
个端口
,6PIN,H=15mm,Mingheng:USB-AF-15.0
J671,J672
ESW0611040480 tickle switch 1,00 tickle switch,1
档
,1
组
,4P,4.5mm*4.5mm*5mm,
明衡
:TC-1321B,H:5mm,160
克力
SW201
EJH1233703500 eraphone jack 1,00 stereo jack,7P,black,
立式
,
插口不带金属
,3.5mm
插口，金佳型号
: CK3.5-32B J501
EJT1210341500S terminal jack 1,00
terminal jack,straight pin ,nickelage,手插型,3pin,gray ,1.5mminterval ,JST ZH
J502
EJT1211511500 terminal jack 1,00 terminal jack,straight pin,nickelage,
手插型
,15PIN,white 1.5mminterval J503
EJCN025W0602 terminal jack 1,00
6p, 2.5mm, white , with straight pin
CON201

Code name Part number Part name Usage Spec Location
SR0096001010 heat sink 1,00 96*40*30 AL，拉铝+机加工
JG589887 screw 4,00 carbon steel cross shape semi ball screw PM3*8
机牙
(
头
Φ5.6);
蓝白锌
GA0012044010S insulating trip 3,00
12*10*0.3 绝缘导热硅胶片
EW09024202000S wire 1,00
HF 2P
彩红线
,1
脚为红黑线
,one side 1.25mminterval
EKM14MARLE020 NFC module 1,00 HF NFC Tag,
型号
,HYAN:HY-TH19,25*15*0.18mm,HF
ZZ0003048010 interval pillar 4,00 M3*D5.5*L10
； 正六边形，碳钢，彩锌
JG589853 screw 4,00
carbon steel cross shape semi ball screw with plate :
QQ0012001010
导电海绵
2,00 10*12*10
； 海绵外包导电布，单面背导电胶
APA200L161101-
APA200L165101 SMT level 1,00 L16 Main Board SMT
层
ECE0092210550S
电解
capacitor 4,01 220UF/35V,±20%,Φ8×12mm,pin interval 5.0mm,编带立式蛙脚 C724,C775,C805,C806
ECFC684MBAS0NS
薄膜
capacitor 12,04
金属膜
capacitor(CL2),(CL21X)680nF/50V,±20%,-40
℃
~85
℃
,pin interval 5mm,
C728,C729,C730,C731,C732,C733,C734,C735,C818,C819,C820,C821
ECET471MLES0NS
电解
capacitor 3,01 470Uf/35V,±20%,105°C,D10*L16,pin interval 5mm,
编带立式直脚
C771,C780,C884
EJT1210613962S terminal jack 2,01
CONN,HEADER,6 PIN,N/A,MID-MOUNT,THD,PITCH 3.96MM (0.156
CON800,CON801
EJCN396W0400 pin jack 1,00
3.96interval 4
脚直插
jack white
CON807
EJT1211212540 terminal jack 1,00 terminal jack, straight pin,nickelage,
手插
,12P,white ,interval 2.54mm, with buckle J601
EJT1216422540 terminal jack 1,00
terminal pin socket ,black,
直插双排
,2*32pin,nickelage,pin interval 2.54mm,
高
7.1±0.25mm
J302
ENLSR100MZ01NS
磁屏蔽电感
12,04
磁屏蔽电感,NDUCTOR,10.5UH,±20%,D*H=13*15mm,pin interval
L706,L707,L714,L715,L710,L711,L718,L719,L724,L725,L728,L729
ENBGA600MB00NS
电阻型磁珠
6,02 resistance magnet ball ,60 OHM,20%,@100MHz,6.0x3.5mm,]width of guard 10mm,DIP L701, L702,L704,L721,L722,L1703
EJA1210205000S metal terminal 1,00 metal terminal, stright pin, nickelage,
单排型
,2PIN, interval :5mm,187X032mm CON601
APA200L165101-
LRML16L810100 PCB 1,00
L16,L8 main board,4 layers,FR4,200*160mm,thick 1.6mm, green oil white print,Version
ECS01041H040 Chip capacitor 92,37
CAP-CER,0402,100N,10%,50V,X7R
C241, C242, C243, C244, C245, C246, C247, C248, C250, C251, C252, C254, C255, C256, C272,
ECC3001030330S Chip capacitor 28,11 CAP-CER,0402,10N,10%,16V,X7R
9,C430,C431,C433,C440,C673,C690,C449,C450,C451,C452,C428
ECC0002200620S Chip capacitor 2,01
HF CAP-CER,0402,22P,5%,50V,NPO(COG)
C219,C220
ECC3001020430S Chip capacitor 7,03 CAP-CER,0402,1N,10%,25V,X7R C305,C306,C315,C353,C435,C501,C502
ECC0001010621S Chip capacitor 1,00
HF CAP-CER,0402,100P,5%,50V,NPO(COG)
C239
ECC0004700620S Chip capacitor 9,04 CAP-CER,0402,47P,5%,50V,NPO(COG) C401,C402,C403,C404,C642, C901,C902,C903,C904
ECC1223KABT0NS Chip capacitor 1,00 CAP-CER,0402,22N,10%,25V,X7R C436
ECC0004710620 Chip capacitor 4,02
CAP-CER,0402,470P,5%,50V,NPO(COG)
C509, C510, C511, C512
ECC3002720220 Chip capacitor 2,01 CAP-CER,0402,2.7N,5%,50V,X7R C515, C516
ECC0011050630 Chip capacitor 24,10 CAP-CER,0603,1U,10%,25V,X7R
C711, C758, C759, C760, C761, C796, C797, C798, C799
ECC2106MPAT0NS Chip capacitor 6,02 CAP-CER,0603,10U,20%,10V,X5R C417, C418, C419, C420, C650, C651
ECCB03T104BJBS Chip capacitor 20,08
CAP-CER,0603,100N,5%,50V,X7R,SAMSUNG:CL10B104JB8NNNC
7,C803,C808,C885
ECC2473KBBT0NS Chip capacitor 2,01 CAP-CER,0603,47NF,±10%,50V,X7R,TAPE C604, C608
ECC3014710631S Chip capacitor 2,01 CAP-CER,0603,470P,10%,50V,X7R C605, C607
ECC2472KBBT0SS Chip capacitor 1,00 CAP-CER,0603,4.7N,10%,50V,X7R,SAMSUNG C606
ECC3011030620S Chip capacitor 15,06 CAP-CER,0603,10N,5%,50V,X7R C634, C662, C666, C736, C737, C738, C739, C740, C741, C742, C743, C822, C823, C824, C825
ECC0011010620S Chip capacitor 18,07
HF CAP-CER,0603,100P,5%,50V,NPO(COG)
C793, C794, C795
ECC1011020620S Chip capacitor 19,08 CAP-CER,0603,1N,5%,50V,NPO(COG),WALSIN
C809,C826,C827,C828,C829,C641
ECC3012240630S Chip capacitor 12,05
CAP-CER,0603,220N,10%,50V,X7R
C715, C717, C719, C721, C763, C764, C765, C766, C810, C811, C812, C813
ECC0013310631S Chip capacitor 12,05 CAP-CER,0603,330P,5%,50V,NPO(COG) C716, C718, C720, C723, C767, C768, C769, C770, C814, C815, C816, C817
ECC7024750430 Chip capacitor 4,02
CAP-CER,0805,4.7U,10%,25V,X5R
C352, C609, C636, C637
ECC3021060130S Chip capacitor 2,01 CAP-CER,0805,10U,10%,6.3V,X5R C270, C273
ECC3021040630S Chip capacitor 2,01 CAP-CER,0805,100N,10%,50V,X7R C639, C647
ECCX05T226OKBS Chip capacitor 8,03
HF CAP-CER,1206,22U,10%,16V,X5R,SAMSUNG:CL31A226KBCNNNC
C412,C434,C438,C443,C446,C685,C686,C692
ECC4106KOBT0NS Chip capacitor 18,07 CAP-CER,1206,10UF,±10%,16V,X7R,TAPE
C681, C682
ECC3012230620S Chip capacitor 1,00
CAP-CER,0603,22N,5%,50V,X7R
C640
ECC2105KLAT0NS Chip capacitor 9,04 CAP-CER,0603,1U,10%,35V,X5R,NA C706, C714, C725, C762, C772, C776, C800, C804, C807
ECT2041060350S 钽capacitor 3,01
CAP,TANTALUM,1210,10U,16V,20%,Case B
C421,C507,C508
ECES471MADT0NS chip
电解
capacitor 2,01 HF CAP,SMD,47UF,25v,±20%,-40
℃～
105
℃
,Φ6.3*5.4,Braid C534, C535
ECE6074700352S chip 电解capacitor 10,04
HF CAP,47UF,ELEC,16V,20%,CASE C,brand :Teapo
C302,C312,C517,C521,C522,C633,C538,C546,C675,C688
ECE6071010151S chip
电解
capacitor 5,02 E-CAP,SMD,100UF/6.3V,±20%,D6.3*L5.4 C223,C227,C611,C618,C694
ECE6071010351S chip
电解
capacitor 9,04 E-CAP,SMD,100UF/16V,20%,SIZE D(Φ6.3*5.4) C309,C331,C423,C425,C644,C645,C671,C693,C695
EDA4BS3161000S diode 2,01
HF diode,BAS316 High-speed diode SOD323
D351, D352
EDSMB0SK24SBNS
肖特基
diode 1,00 DIODES,SCHOTTKY BARRIER RECTIFIER,SMB,SK24SB,2.0A D604
EDSMA0SK24SANS
肖特基
diode 2,01 DIODES,SCHOTTKY BARRIER RECTIFIER,SMA,SK24SA,2.0A D601, D602
EBMTAP2305N3NS MOS
管
3,01
P-CHANNEL ENHANCEMENT MODE POWER MOSFET,Advanced Power Electronics
Q603, Q604, Q606
EDA4BAT540200S diode 1,00
diode,SOT23,BAT54CLT1G,30V,200MA DUAL SCHOTTKY,PANJIT
D801
EBPTAMBT3906NS triode 1,00 HF triode,PNP,SOT23,MMBT3906,200mA,HF Q351
EBNTAMBT3904NS triode 6,02 HF triode,NPN,SOT23,MMBT3904,100mA,HF Q352, Q601,Q602,Q605,Q607,Q504
EBN42SC273010S chip triode 3,01 triode,NPN,SMD,2SC2712GR Q501, Q502, Q503
ENB1121020010S SMD bead 40,16 HF INDUCTOR,1K@100MHz,0402,MURATA,BLM15HD102SN1
5,L526,L527,L528,L529,L530,L531,L532,L533,L534,L535,L536,L537,L538,L539,L540,L541,L542,L5
ENBS2471AT00NS SMD bead 2,01
SMD bead,0603,470±25% Ohm@100MHz,200mA,DCR 0.55 OHM max
L271, L272

Code name Part number Part name Usage Spec Location
ENBS2601AT00NS SMD bead 1,00 SMD bead,0603,600±25% Ohm@100MHz,100mA,DCR 1.5 OHM max L330
ENBS3331AT00NS SMD bead 18,07 SMD bead,0805,330 Ohm,±25%,@100MHz,2.0A,DCR 0.05 OHM max
8
ENBS1222NT00NS SMD bead 2,01
Inductor SMD,0402,Chip Ferrite Bead,2k Ohm @ 100 MHz
L507,L508
ENLSR150MR00NS 磁屏蔽
电感
2,01 INDUCTOR,15uH,0.068 MOHM,+/-20%,2.05A,BODY SIZE:6X6MM,HEIGHT:4.5MM L602,L603
ENLSR68AMR00NS
磁屏蔽电感
1,00 INDUCTOR,6.8UH,+/-20%,Rdc=0.024 Ohm,Is=4.55A,8040 L610
ENLSR38AMR00NS
磁屏蔽电感
1,00
INDUCTOR,3.8UH,+/-20%,13mohm,I sat,6.5A,Irms 4.25A.BODY
L671
EJF0021081000 FFC jack 1,00
FFC jack,
单列下接卧式
,
单面接触
,chip
型
,10PIN,white ,pin interval 1.0mm
J504
EJF0021880500 FFC jack 1,00 FFC jack,
单列下接卧式
,
单面接触
,chip
型
,18PIN,white ,pin interval 0.5mm J505
EJA3225012540 pin jack 1,00 chip
排针母座
,nickelage,
双排
,2*25pin,pin interval 2.54mm,
高
7.1±0.25mm J401
EJT3220211250 terminal jack 1,00 HF terminal jack,SMD,90℃,nickelage,2P,white（black）,P=1.25mm J351
EJK4100300010 coaxial jack 1,00 mini coaxial jack, vertical mother jack,Ф2mm,paster package 3 pad J332
ERS1B0000ZT0WS Chip resistance 62,25
RES-CHIP,0402,1/16W,0 OHM,+0.05 MAX,TAPE,WALSIN
2,R423,R424,R425,R426,R427,R428,R429,R430,R431,R432,R433,R435,R436,R437,R441,R452,R
ERS0201030120 Chip resistance 45,18 RES,0402,10K OHM,1/16W,+1%
8,R419,R481,R482,R483,R511,R512,R556,R557,R558,R559,R560,R561,R562,R563,R564,R565,R
ERS1B0101FT0NS Chip resistance 48,19
RES-CHIP,0402,100 OHM,1/16W,+/-1%
5,R246,R247,R248,R252,R253,R257,R258,R259,R260,R261,R262,R263,R268,R270,R275,R278,R
ERS1B4993FT0NS Chip resistance 1,00 RES-CHIP,0402,499K,1/16W,1% R210
ERS0203300140S Chip resistance 48,19
HF RES,0402,33 OHM,1/16W,+/-5%
R264, R265, R282, R303, R304, R305, R306, R309, R310, R311, R312, R313, R314, R315, R406,
ERS0202220120 Chip resistance 6,02 RES,0402,2.2K OHM,1/16W,+/-1% R224, R225, R316, R317, R414, R415
ERS0201020140S Chip resistance 3,01 HF RES-CHIP,0402,1/16W,1k OHM,5% R308, R438, R439
ERS0204720120 Chip resistance 1,00
RES,0402,4.7K OHM,1/16W,+/-1%
R318
ERS0201040121S Chip resistance 9,04 RES,0402,100K OHM,1/16W,1%, brand
：
WALSIN R334, R515, R516, R530, R676, R678, R681, R682, R683
ERS0204730120 Chip resistance 8,03
RES,0402,47K OHM 1/16W +/-1%
R503, R504, R532, R535, R574, R606, R607, R692
ERS0208230120 Chip resistance 2,01 RES,0402,82K OHM,1/16W,+/-1% R505, R506
ERS0201050120S Chip resistance 4,02
RES-CHIP,0402,1/16W,1M OHM,1%
R507,R627,R649,R653
ERS1B0204FT0NS Chip resistance 1,00 RES-CHIP,0402,200K OHM,1/16W,1% R508
ERS0202440120 Chip resistance 1,00
RES,0402 240K OHM 1/16W +/-1%
R509
ERS1B0332FT0NS Chip resistance 2,01 RES-CHIP,0402,3.3K OHM,1/16W,1% R517,R591
ERS0204700121S Chip resistance 1,00 HF RES,0402,47 OHM,1/16W,+/-1% R531
ERS1B1371FT0NS Chip resistance 1,00
RES-CHIP,0402,1.37K OHM,1/16W,+/-1%
R434
ERS0202720140 Chip resistance 1,00 RES,0402,2.7K OHM,1/16W,+5% R513
ERS1B6340FT0NS Chip resistance 6,02 RES-CHIP,0402,634 OHM,1/16W,+/-1% R519, R520, R523, R524, R525, R526
ERS1B0910FT0NS Chip resistance 2,01 RES-CHIP,0402,91 OHM,1/16W,+/-1% R521, R522
ERS1B0475FT0NS Chip resistance 1,00
RES-CHIP,0402,4.7M OHM,1/16W,+/-1%
R534
ERS1B4753FT0NS Chip resistance 1,00 RES-CHIP,0402,1/16W,475K OHM,1%,NA R686
ERS1B4222FT0NS Chip resistance 1,00 RES-CHIP,0402,42.2K OHM,1/16W,+/-1% R687
ERS2C0100JT0NS Chip resistance 1,00 RES-CHIP,0603,1/10W,10 OHM,5% R203
ERS0300000220S Chip resistance 38,15 HF RES-CHIP,0603,0 OHM,5%,1/10W,N/A,LF
R645, R646, R647, R688, R696, R697, R703, R704, R708, R709, R713, R714, R718, R719, R752,
ERS0302030220S Chip resistance 2,01
RES,0603,20K OHM,1/10W,+/-1%
R601, R612
ERS0339220220S Chip resistance 1,00 RES,0603,39.2K OHM 1/10W 1% SMD,brand :Walsin R603
ERS0363410220 Chip resistance 1,00
RES,0603,6.34K OHM,1/10W,+/-1%
R613
ERS0301030221S Chip resistance 2,01 HF RES-CHIP,0603,1/10W,10K OHM,1%,WALSIN R634,R806
ERS0338300220S Chip resistance 1,00
RES-CHIP,0603,1/10W,383 OHM,1%,NA
R633
ERS0322120220S Chip resistance 1,00 RES,0603,22.1K OHM,1/10W,+/-1% R671
ERS0312730220S Chip resistance 1,00 RES,0603,127K OHM,1/10W,+/-1% R672
ERS010406F00 Chip resistance 2,01
HF RES,0603,100K OHM,1/10W,+/-1%
R674, R882
ERS0307530121S Chip resistance 2,01 RES-CHIP,0603,1/10W,75K OHM,1%,NA R691, R693
ERS2C1001FT0NS Chip resistance 12,05
RES-CHIP,0603,1/10W,1K OHM,1%,brand ,Walsin
R701, R702, R706, R707, R711, R712, R716, R717, R750, R751, R755, R756
ERS0303300221S Chip resistance 1,00 HF RES-CHIP,0603,1/10W,33 OHM,1%,NA R721
ERS0305620220S Chip resistance 1,00
RES,0603,5.6K OHM,1/10W,+/-1%
R723
ERS051306J00 Chip resistance 4,02 RES,0603,51K OHM,1/10W,+/-5% R726, R727, R760, R761
ERS0302200220S Chip resistance 12,05
RES-CHIP,0603,1/10W,22 OHM,1%,NA
R728, R729, R730, R731, R732, R733, R734, R735, R762, R763, R764, R765
ERS03033A0220S Chip resistance 12,05 HF RES,0603,3.3 OHM,1/10W,+/-1%,PB-FREE R736, R737, R738, R739, R740, R741, R742, R743, R766, R767, R768, R769
ERS4E0000ZT0WS Chip resistance 3,01 RES-CHIP,1206,1/4W,0 OHM,+0.05 MAX,TAPE,WALSIN R651,R694,R592
EID000R458000S IC 2,01
双运放，型号： RC4580IDR，封装:SOP8,TI
U502, U503
EIQTALM1117MNS IC 2,01 LM1117MP-ADJ/NOPB 800mA Low-Dropout Linear Regulator,LDO,SOT-223,TI U602,U605
EKM3L16L80010 bluetooth module 1,00 bluetooth module,L16,L8
机种用
,flash 16M,Sunitec:BM153 U330
EIMFPPIC512LNS IC 1,00 IC,MCU,512KB,100pin,TQFP100,Microcip:PIC32MX460F512LT80IPT U201
EIVSOS54331DNS IC 1,00
IC,TPS54331DDA,3A,28V INPUT,STEP DOWN SWIF DC/DC CONVERTER WITH
U604
EIVDATPS5442NS IC 1,00
TPS54428DDA,TI,DC-DC,4.5V-18V input,4A-Synchronous Step-down converter with
U671
EIVUS37S3959NS IC 2,01 IPOD
解密
IC-2.0C,MFI337S3959,PG-USON-8-1,HMM party pad using. U202, U302
EICCS42528C00S IC 1,00 IC,QFP-64,CS42528-CQZ U401
EINHTPS54286NS IC 1,00
TPS54286,HTSSOP14,2-A DUAL NON-SYNCHRONOUS CONVERTER WITH
U601
EIUQFTPS2546NS IC 1,00
USB CHARGING PORT CONTROLLER WITH LOAD DETECTION,TPS2546,16-pin
U672

Code name Part number Part name Usage Spec Location
EISSZRT9703GNS IC 1,00 3A Smart Universal Power Switch with Flag,80mOHM,RT9703GS,SOP8 U673
EIPSXTPA3116NS IC 3,01 IC 4 CHANNEL Class D POWER AMPLIFIER, TPA3116D2 TI SSOP32 U701, U702, U703
EIXSOF040B80NS IC 1,00
IC FLASH 4Mbit 80MHz SPI SOIC8,SST25VF040B-80-4I-SAE, no need software
U203
EDTNAMP0542TNS TVS管2,01 TVSdiode,SMD,2-Line ESD protection,6pin,1.6*1.0*0.4mm,SEMTECH:RClamp0542T U674, U675
EQA0400452220S
晶振
1,00 4MHZ SMD ,2pins Y201
ERS0303330220S Chip resistance 6,02 RES,0603 33K OHM 1/10W ±1% PB-FREE R705, R710, R715, R720, R754, R759
ERS1B0201JT0NS Chip resistance 1,00
RES-CHIP,0402,1/16W,200 OHM,±5% ,TAPE
R659
ERS0333230220S Chip resistance 1,00 RES,0603,332K OHM,1/10W,1% R628
ERS1B0681FT0NS Chip resistance 1,00 RES-CHIP,0402,680 OHM,1/16W,±1% R255
ECC10168A0620S Chip capacitor 1,00 HF CAP-CER,0603,6.8P,±0.5PF,50V,NPO(COG) C677
ECC2103KBBT0SS Chip capacitor 1,00 CAP-CER,0603,10N,10%,50V,X7R,SAMSUNG C881
ECC3016820430S Chip capacitor 1,00
CAP-CER,0603,6.8N,10%,50V,X7R
C610
ECC3018220430S Chip capacitor 1,00 CAP-CER,0603,8.2N,10%,50V,X7R C678
ERS0201000120S Chip resistance 2,01
RES,0402,10 OHM,1/16W,±1%
R527, R528
ERS1B1052FT0NS Chip resistance 2,01 RES-CHIP,0402,10.5K OHM,1/16W,+/-1% R501, R502
ERS0302220240S Chip resistance 1,00
RES-CHIP,0603,1/10W,2.2K OHM,5%,
R602
ERS0203010140S Chip resistance 1,00 RES,0402,300 OHM,1/16W,5% R615
ERS0204720140S Chip resistance 1,00 HF RES-CHIP,0402,1/16W,4.7K OHM,5%,NA R529
ERS0301520220S Chip resistance 1,00
RES,0603,1.5K OHM,1/10W,+/-1%
R614
ERS0303340220S Chip resistance 1,00 RES,0603,330K OHM,1/10W,+/-1% R652
ERS1B0124JT0NS Chip resistance 3,01
RES-CHIP,0402,1/16W,120K OHM,±5% ,TAPE
R626, R648, R654
ERS1B0152FT0NS Chip resistance 1,00 RES-CHIP,0402,1.5K OHM,1/16W,+/-1%,NA R658
ERS1B0471JT0NS Chip resistance 2,01
HF RES-CHIP,0402,1/16W,470 OHM,5%
R205, R355
ERS1B0561FT0NS Chip resistance 2,01 RES-CHIP,0402,560 OHM,1/16W,+/-1% R657,R616
ERS0332410220 Chip resistance 1,00
RES,0603,3.24K OHM,1/10W,+/-1%
R635
ERS0301040240S Chip resistance 3,01 RES-CHIP,0603,1/10W,100K OHM,5%,Walsin R725,R885,R886
ERS0203300120 Chip resistance 2,01 RES,0402 33 OHM 1/16W +/-1% R293,R294
ERS0202230140 Chip resistance 1,00
RES,0402,22K OHM,1/16W,+/-5%
R590
ERS1B0680FT0NS Chip resistance 4,02 RES-CHIP,0402,68 OHM,1/16W,+/-1% R402,R403,R404,R405
ERS3D0000ZT0WS Chip resistance 6,02 HF RES-CHIP,0805,1/8W,0 OHM,+0.05 MAX,TAPE,WALSIN L672, L673, L674, L675, L676, L677
ERS0401000340S Chip resistance 2,01 HF RES-CHIP,0805,1/8W,10 OHM,5%,WALSIN R605,R611
ERS0490920320S Chip resistance 1,00
RES,0805,90.9K OHM,1/8W,1%
R630
ERN2N0103AT0NS
热敏电阻
1,00 Chip NTC Thermistor,SDNT Series,0603,10K,+/-3%,SDNT1608X103H3450HTF RP701
ELR2012102210
继电器
1,00
G6K-2G-Y,OMRON,LOW SIGNAL RELAY,Non-latching 3.2 mm coil-contact terminal
K501
EDAC1N4140200S chip diode 1,00 HF DIODE,1N4148WS,SOD323,200mW,1N4148WS-7-F(DIODES) | D501
ENBS3601AT01NS SMD bead 1,00 FERRITE BEAD,SMT,0805,600 OHM@100MHZ,+/-25%,600mA L546
ERS04022A0340S Chip resistance 2,01
RES,0805,2.2 OHM,1/8W,+/-5%
R631,R675
ECC3014710630S Chip capacitor 2,01 CAP-CER,0603,470P,10%,50V,X7R,SAMSUNG C643,C684
ERS0202230120S Chip resistance 8,03
RES,0402,22K OHM,1/16W,+/-1%
R901,R902,R903,R904,R905,R906,R907,R908
EIOSZ00LM833NS IC 1,00 OP-AMP,LM833,SOP8 IC901
APA200L160201-
APA200L161201 HI
层
1,00 L16 Volume Control Board HI
层
APA200L161201-
APA200L165201 SMT
层
1,00 L16 Volume Control Board SMT层
ESE1210001010
编码器
1,00
编码器
,
不带螺纹
,
塑胶柄
,
立式插件
,
中空型
,5PIN,
高
15mm,
升威型号
:EC350302X2A-HA1-
JP2
ESW0611040480 tickle switch 1,00 tickle switch,1
档
,1
组
,4P,4.5mm*4.5mm*5mm,
明衡
:TC-1321B,H:5mm,160
克力
SW1
APA200L165201-
LFCL16L810100 PCB 1,01 L16,L8 Volume Control PCB,2
层板
,FR4,68*68mm,
黑油白字
,
版本
X2.
EJF30218A0500 FFCjack 1,01
FFCjack,立贴反位,双列,单面接触,chip 型,18PIN,pin interval 0.5mm,mingheng:FPC-0.5-
JP1
EBN4T39043010S triode 12,07
晶体管
,MMBT3904LT1G, NPN(SMD),SOT-23 Q1,Q2,Q3,Q4,Q5,Q6,Q11,Q12,Q13,Q14,Q15,Q16
ECC2150KBBT0NS Chip capacitor 2,01
CAP-CER,0603,15P,±10%,50V,X7R,TAPE
C1,C2
ECC3011030630S Chip capacitor 12,07 HF CAP-CER,0603,10N,10%,50V,X7R,WALSIN C3,C4,C5,C6,C7,C8,C9,C10,C11,C12,C13,C14
ERS0304730220S Chip resistance 2,01
HF RES-CHIP,0603,1/10W,47K OHM,1%,NA
R18,R19
ERS0300000220S Chip resistance 25,15 HF RES-CHIP,0603,0 OHM,5%,1/10W,N/A,LF
30,R31
ERS0305100220S Chip resistance 12,07 HF RES,0603,51 OHM,1/10W,+/-1% R32,R33,R34,R35,R36,R37,R38,R39,R40,R41,R42,R43
ERS0304720240S Chip resistance 12,07
HF RES-CHIP,0603,1/10W,4.7K OHM,5%,
R44,R45,R46,R47,R48,R49,R50,R51,R52,R53,R54,R55
ERV2N0250NT0FS
压敏电阻
2,01
HF RES-VARISTOR,
压敏电阻
,ESD Protection,3PF,0603,25V,brand
R16,R17
EDLS2YWNA030NS LED 11,07
HF DIODE,LED,SMD,0603,white,
明炬型号
:INH-S1608BAW55TP-G,
亮度
200-
LED1,LED2,LED3,LED4,LED5,LED6,LED7,LED8,LED9,LED10,LED12
EDL4040010040S LED 1,01 LED,SMD,0603,
橙色
,BRIGHTEK S1A1608A2CA-1A-24 LED11
APA200L160301-
APA200L165301 SMT
层
1,00 L16 Source Select Board SMT
层
ESW0611040480 tickle switch 1,00 tickle switch,1
档
,1
组
,4P,4.5mm*4.5mm*5mm,
明衡
:TC-1321B,H:5mm,160
克力
SW1
APA200L165301-
LFTL16L810100 PCB 1,00 L16,L8 Source Select PCB,2
层板
,FR4,48*48mm
绿油白字
,
版本
X2.
EJF30210A1000 FFCjack 1,00 FFCjack,
立
贴,
双列
,单面接触,10PIN,interval 1.0mm,jinjia:1.0S-1-10PT CN1
EBN4T39043010S triode 7,02
晶体管
,MMBT3904LT1G, NPN(SMD),SOT-23 Q1, Q2, Q3,Q4, Q5,Q6,Q11
ERS0300000220S Chip resistance 16,05
HF RES-CHIP,0603,0 OHM,5%,1/10W,N/A,LF
R1,R2,R3,R4,R5,R6,R7,R8,R9,R10,R11,R12,R13,R34,R35,R43

Code name Part number Part name Usage Spec Location
ERS0305100220S Chip resistance 7,02 HF RES,0603,51 OHM,1/10W,+/-1% R36,R37,R38,R39,R40,R41,R42
EDLS2YWNA030NS LED 7,02
HF DIODE,LED,SMD,0603,white,
明炬型号
:INH-S1608BAW55TP-G,
亮度
200-
LED1,LED2,LED3,LED4,LED5,LED6,LED7
ERS0304720240S Chip resistance 7,02
HF RES-CHIP,0603,1/10W,4.7K OHM,5%,
R17,R18,R19,R20,R21,R22,R23
ECC3011030630S Chip capacitor 7,02 HF CAP-CER,0603,10N,10%,50V,X7R,WALSIN C2,C3,C4,C5,C6,C7,C8
APA200L160401-
APA200L161401 HI level 1,00 L16 IO Board HI
层
EJR1201630010S RCAjack 1,00 CONN,RCA JACK,6 PIN,N/A,VERTICAL,THD,DUAL RED-WHT SHORTING J1
ESW0333080010 拔动switch 1,00 拔动
switch ,3
档
,3
组
,8PIN,SS-23D03-G8 switch,
明衡
,
型号
:SS-23D03-G8 H:8MM
J2
EJO4030010030 optical jack 1,00 optical jack,Optical Receiver,3PIN,2
个定位孔
,DLR11B0,11.5*11.5*13.5mm J4
HP043900S terminal 1,00 12.5*11.1*9.2
黄铜表面上锡
EWD1020097800 single wire 1,00 单支线,UL1007,L=200mm,white,20AWG, one side Φ4.2
接地
环,one side
浸
锡3mm
APA200L161401-
APA200L165401 SMT
层
1,00 L16 IO Board SMT
层
EJT1210341500S terminal jack 1,00
terminal jack,直针,nickelage,手插型,3pin,gray,1.5mminterval ,JST ZH SERIES,JST B-3B-
J3
EJT1211511500 terminal jack 1,00 terminal jack,
直针
,nickelage,
手插型
,15PIN,white1.5mminterval J5
ECFC152JBCS0NS 薄膜capacitor 2,01 金属化聚酯膜
(CL21X),1.5NF,50V,±5%,-55℃
～
85℃,
红色
,pin interval 5mm,
编带包装 C26,C48
ECFC562KBAS0NS
薄膜
capacitor 2,01
金属膜
capacitor(CL2),(CL21X)5.6nF/50V,±10%,-40℃~85℃,pin interval
C24,C46
ECFC183JBAS0NS 薄膜capacitor 2,01 金属膜
capacitor(CL2),(CL21X)18nF/50V,±5%,-40
℃
~85
℃
,P5 red
成型编带 C23,C45
APA200L165401-
LFYL16L810100 PCB 1,01 L16,L8 PCB From to IO Board,2层板,FR4,40*80mm绿油白字,
版本
X2.
ECC3011010631S Chip capacitor 13,08 CAP-CER,0603,100P,5%,50V,NPO C1,C4,C10,C14,C15,C21,C22,C36,C37,C43,C44,C55,C63
ECC3011020620S Chip capacitor 2,01
CAP-CER,0603,1N,5%,50V,X7R
C19,C41
ECC3011030620S Chip capacitor 5,03 CAP-CER,0603,10N,5%,50V,X7R C6,C59,C71,C72,C73
ECCB03T104BKBS Chip capacitor 24,14
CAP-CER,0603,100N,10%,50V,X7R,SAMSUNG:CL10B104KB8NNNC
70,C74,C75
ECE6071000450S chip
电解
capacitor 4,02 E-CAP,SMD,10UF/25V,+/-20%,4.0X5.4 mm(SIZE:B) C16,C17,C38,C39
EDAC1N4140200S chip diode 20,12
HF DIODE,1N4148WS,SOD323,200mW,1N4148WS-7-F(DIODES) |
D1, D2, D3, D4, D5, D6, D7, D8, D10, D11, D13, D14, D15, D16, D17, D18, D19,D20, D21, D22
ENB1121020010S SMD bead 12,07 HF INDUCTOR,1K@100MHz,0402,MURATA,BLM15HD102SN1 L1, L2, L3, L4, L5, L6, L7, L8, L9, L11, L12, L14
EBN42SC273010S chip triode 8,05
triode,NPN,SMD,2SC2712GR
Q1, Q2, Q3, Q4, Q5, Q6, Q7, Q14
ERS0300000220S Chip resistance 3,02 HF RES-CHIP,0603,0 OHM,5%,1/10W,N/A,LF R5, R9, R107
ERS2C0100JT0NS Chip resistance 3,02 RES-CHIP,0603,1/10W,10 OHM,5% R13,R108, R110
ERS0306810121S Chip resistance 2,01
RES,0603,680 OHM,1/16W,+/-1%
R52, R89
ERS0301020141 Chip resistance 4,02 RES,0603,1K OHM,1/16W,+/-5% R1, R16, R30, R74
ERS0302020220S Chip resistance 2,01 RES-CHIP,0603,1/10W,2K OHM,+/-1%,brand ::Walsin R23, R109
ERS0301030240S Chip resistance 25,15 RES-CHIP,0603,1/10W,10K OHM,5%,Walsin
R112, R114, R115, R116, R117, R119, R121
ERS0301230121S Chip resistance 2,01
RES,0603,12K OHM,1/10W,+/-1%
R27, R72
ERS0102430121S Chip resistance 2,01 HF RES,0603,24K OHM,1/16W,+/-1% R20, R106
ERS0302230141S Chip resistance 2,01 RES-CHIP,0603,1/10W,22K OHM,5%,NA R39,R84
ERS0303330240S Chip resistance 10,06 RES-CHIP,0603,1/10W,33K OHM,5% R58,R67,R95,R101,R28,R73,R33,R78,R62,R98
ERS0308230121 Chip resistance 2,01 RES,0603,82K OHM,1/16W,+/-1% R18, R25
ERS0301040240S Chip resistance 6,04
RES-CHIP,0603,1/10W,100K OHM,5%,Walsin
R6, R22, R35, R36, R80, R81
ERS0302440240S Chip resistance 1,01 RES,0603,240K OHM,1/10W,+/-5% R8
ERS0302040221S Chip resistance 1,01
RES-CHIP,0603,1/10W,200K OHM,1%,NA
R12
ERS0305640220S Chip resistance 2,01 RES,0603,560K OHM,1/10W,+/-1% R41, R85
ERS0304750240S Chip resistance 3,02
RES,0603,4.7M OHM,1/10W,±5%
R11,R57,R94
ERVTN025VNN0NS
压敏电阻
4,02
HF RES-VARISTOR,压敏电阻,ESD Protection,3PF,0402,25V,brand
RV1, RV2, RV3, RV4
EIOSZ00LM833NS IC 2,01 OP-AMP,LM833,SOP8 U2,U6
EICTL07400D0S IC 4,02
OP-AMP,TL074,SOP14(SO14),ST
U1, U3, U4, U5
ECES220MADT0NS chip
铝电解
capacitor 2,01 CAP AL ELECTROLYTIC SMT CAN,22UF/25V,±20%,SIZE C C31, C52
ECES101MADT1NS chip
电解
capacitor 4,02
E-CAP,EL,SMD,100UF,±20%,25V,105
℃
,D6.3*L7.7mm, brand :KJ
C25, C47, C56, C60
ELR2012102210
继电器
4,02
G6K-2G-Y,OMRON,LOW SIGNAL RELAY,Non-latching 3.2 mm coil-contact terminal
K1, K2, K3,K4
ECC3022240630S Chip capacitor 4,02
CAP-CER,0805,2.2U,10%,25V,X7R
C2, C3, C7, C9
ECC3021050330S Chip capacitor 2,01 CAP-CER,0805,1U,10%,16V,X7R C18, C40
ECE6072200350S chip 电解capacitor 2,01
E-CAP,SMD,22UF/16V,20%,SIZE B
C64, C67
ERS0301050240S Chip resistance 1,01 HF RES-CHIP,0603,1/10W,1M OHM,5%,WALSIN R26
ERS0303010240 Chip resistance 2,01 RES,0603,300K OHM,1/10W,+/-5% R66, R100
ERS02210603J Chip resistance 2,01
RES,0603,220 OHM,1/10W,+/-5%
R34, R79
ERS0304730220S Chip resistance 7,04 HF RES-CHIP,0603,1/10W,47K OHM,1%,NA R37,R47,R49,R50,R60,R82,R87
ERS030206J00 Chip resistance 6,04 RES,0603,3K OHM,1/16W,+/-5% R10,R24,R59,R68,R96,R102
ERS0305620240S Chip resistance 6,04 RES-CHIP,0603,1/10W,5.6K OHM,5% R38,R83,R111,R113,R120,R122
ECES221MADT0NS chip 电解capacitor 4,02
E-CAP,EL,SMD,220UF,±20%,25V,105
℃
,Low ESR,D8*L10mm,brand
C76, C78, C80, C81
ECC3011050430S Chip capacitor 4,02 HF CAP-CER,0603,1U,10%,25V,X7R,SAMSUNG C77, C79, C82, C83
EDWAZ46991200S
稳压
diode 2,01
稳压
diode,SOD123,MMSZ4699,12V D23,D24
EBNTAMBT3904NS triode 5,03 HF triode,NPN,SOT23,MMBT3904,100mA,HF Q8, Q9, Q10, Q11, Q12
EBPTAMBT3906NS triode 1,01 HF triode,PNP,SOT23,MMBT3906,200mA,HF Q13
ERS056306J00 Chip resistance 2,01
RES,0603,56K OHM,1/10W,+/-5%
R3, R14

Code name Part number Part name Usage Spec Location
ERS0301010240S Chip resistance 4,02 RES-CHIP,0603,1/10W,100 OHM,5% R15, R105, R31, R76
ERS0309120240S Chip resistance 4,02 RES,0603,9.1K OHM,1/10W,+/-5% R55, R70, R92, R104
ERS0303310141S Chip resistance 2,01
RES-CHIP,0603,1/10W,330 OHM,5%
R123, R124
APA200L160501-
APA200L161501 HI level 1,00 L16 DSP Board HI level
APA200L161501-
APA200L165501 SMT level 1,00 L16 DSP Board SMT level
EJA3225022540 pin jack 1,00 FCI,Connector,Header,nickelage,
双排
,2*25PIN,2.54mm,
公座
CON1
EP0083001010 shielding cover（top-bottom）1,00
83.4*66.7*6.7
；
0.3T
马口铁，表面脱脂
EP0067001010 shielding cover
（
bottom-top
）
1,00 67.5*64.4*2
；
0.3T
马口铁，表面脱脂
APA200L165501-
LFBL16L810100 PCB 1,00 DSP
板
,L16,L8 PCB From to DSP Board,2
层板
,FR4,67*82mm
绿油白字
,
版本
X2
ECC3001030330S Chip capacitor 46,14 CAP-CER,0402,10N,10%,16V,X7R
C43,C44,C45,C46,C47,C48,C49,C50,C51,C52,C53,C54,C55,C56,C57,C58,C59,C60,C79,C80,C81,
ECC0001800620S Chip capacitor 2,01 CAP-CER,0402,18P,5%,50V,NPO(COG) C4,C5
ECC1104KOBT0SS Chip capacitor 7,02
CAP-CER,0402,100NF,±10%,16V,X7R,SAMSUNG
C3,C8,C9,C11,C88,C99,C100
ECCB03T104BKBS Chip capacitor 5,02 CAP-CER,0603,100N,10%,50V,X7R,SAMSUNG:CL10B104KB8NNNC C7,C10,C13,C37,C73
ECC0011050630 Chip capacitor 2,01
CAP-CER,0603,1U,10%,25V,X7R
C61, C87
ECC3021060130S Chip capacitor 12,04 CAP-CER,0805,10U,10%,6.3V,X5R C15,C36,C39,C40,C41,C42,C72,C74,C75,C78, C90,C91
ECC0001200620 Chip capacitor 1,00
CAP-CER,0402,12P,5%,50V,NPO(COG)
C95
ECC1270JBCT0SS Chip capacitor 7,02 CAP-CER,0402,27P,5%,50V,NPO,SAMSUNG:CL05C270JB8NNNC C96,C97,C101,C102,C104,C105,C107
ECC3014710630S Chip capacitor 1,00 CAP-CER,0603,470P,10%,50V,X7R,SAMSUNG C120
ECE6074700150S chip
电解
capacitor 2,01
Cap,Aluminum,Audio,47uF,
C6, C12
ECE6071010150S chip
电解
capacitor 2,01 E-CAP,SMD,100UF/6.3V,+/-20%,D6.3*L5.4 C38, C93
ECE6072210330S chip
电解
capacitor 1,00
E-CAP,SMD,220UF/10V,±10%,D6.3*L5.4,105
℃
,编带
C92
ERS1B0000ZT0WS Chip resistance 8,02 RES-CHIP,0402,1/16W,0 OHM,+0.05 MAX,TAPE,WALSIN R11,R55,R56,R266,L12,L13,L14,L19
ERS1B0101FT0NS Chip resistance 6,02
RES-CHIP,0402,100 OHM,1/16W,+/-1%
R47,R48,R49,R50,R53,R54
ERS0201030120 Chip resistance 21,06 RES,0402,10K OHM,1/16W,+1% R21,R26,R27,R29,R32,R34,R35,R38,R57,R58,R59,R65,R66,R67,R82,R60,R61,R62,R63,R64,R68
ERS0201040121S Chip resistance 4,01
RES,0402,100K OHM,1/16W,1%, brand :
：
WALSIN
R73, R76, R79, R80
ERS0201840120 Chip resistance 1,00 RES,0402 180K OHM 1/16W +/-1% R93
ERS0201050120S Chip resistance 1,00 RES-CHIP,0402,1/16W,1M OHM,1% R70
ERS2C0100JT0NS Chip resistance 1,00
RES-CHIP,0603,1/10W,10 OHM,5%
R81
ERS0203930120 Chip resistance 1,00 RES,0402 39K OHM 1/16W +/-1% R95
ERS1B0330FT0NS Chip resistance 21,06 RES-CHIP,0402,33 OHM,1/16W,+/-1%,NA
R46, R71
ERS0205630140 Chip resistance 1,00 RES,0402,56K OHM,1/16W,+/-5% R94
ERS1B0561FT0NS Chip resistance 1,00
RES-CHIP,0402,560 OHM,1/16W,+/-1%
R92
ERS1B0680FT0NS Chip resistance 7,02 RES-CHIP,0402,68 OHM,1/16W,+/-1% R1,R2,R5,R6,R9,R10,R19
ERS03022A0121 Chip resistance 1,00 RES,0603,2.2 OHM,1/10W,+/-1% R111
ENBS1601ZT00MS SMD bead 9,03 HF SMD bead,0402,600 OHM,25%,300MA,Murata BLM15AG601SN1D L11,L15,L16,L17,L18,L20,L21,L22,L23
ENBS2471AT00NS SMD bead 1,00 SMD bead,0603,470±25% Ohm@100MHz,200mA,DCR 0.55 OHM max L1
ENBS3331AT00MS SMD bead 1,00
FERRITE BEAD,0805,330ohm @ 100MHz,±25%,1.5A,Murata, type
L2
ENB1043000020S SMD bead 2,01 HF SMD bead,0805,30±10 Ohm@100MHz,6A, brand :TDK, type:MPZ2012S300A L5, L7
ENBS2601AT00NS SMD bead 1,00
SMD bead,0603,600±25% Ohm@100MHz,100mA,DCR 1.5 OHM max
L56
ENLCS010YT01NS chip
电感
1,00 INDUCTOR,SMT,PWR,1UH,2.1A,30%,DCR 36mΩ Max,3.00mm*3.00mm*1.50mm L6
ESW0611030010 tickle switch 1,00
tickle switch,SMT,
卷带包装
,6mm*6mm*3.5mm,
柄长
=0.8mm,Φ3.0mm, vendor type :KFC-
SW1
EIDLQ21489KSNS IC 1,00 IC,ADSP-21489KSWZ-4B,AD,400MHz,5Mb RAM,LQFP-176 U1
EIDSXAK8133ENS IC 1,00 IC,Multi clock generator chipset,AK8133E,AKM,16pins SSOP U2
EIXSOF040B80NS IC 1,00
IC FLASH 4Mbit 80MHz SPI SOIC8,SST25VF040B-80-4I-SAE,不用烧录
U3
EIVSYTPS6208NS IC 1,00 IC,1.2A Step-Down Regulator,TPS62080DSG,TI,SON8 U5
EQA2700452240S
石英晶振
1,00
Crystal RALTRON 27 MHZ H13K SERIES(4pin),石英晶振,长方形,SMT,27
Y3
EJA3221412540 pin jack 1,00 CONNECTOR,nickelage,
双排
,2*7PIN, LEADS,2.54mm,SMT,
公座
CON2
EP0084001010 shielding cover（top-bottom）1,00
84.2*67.5*3
；
0.3T
马口铁，表面脱脂
EP0067002010
shielding cover
（
bottom-
1,00 66.7*63.6*2.7
；
0.3T
马口铁，表面脱脂
