Installation&OperatingManual
R5
ìCemanuelestdisponibleenFranÁaissurdemandeî
SafetyTestingby
ASTME1509
MobileHomeApproved

2
Fig.1

3
Pleasereadthisentiremanualbeforeyouinstallanduseyournew
roomheater.Failuretofollowinstructionsmayresultin
propertydamage,bodilyinjury,orevendeath.
SUITABLEFORMOBILEHOMEINSTALLATIONS.
SAVETHESEINSTRUCTIONS
HarmanStoveCompany
352MountainHouseRoad
Halifax,PA17032
TestingLabel 2
Assembly&Installation 4
Venting 7
Operation 12
ESPControl 14
Maintenance 15
TroubleShooting 18
FeederParts 19
Specifications 19
WiringDiagram 20
Options 22
PartsList 23
Warranty 24
TableofContents

4
Unpacking
TheP61isboltedtotheskidtopreventmove-
mentduringshipping.
Tofreethestovefromtheskidyoumustre-
movethehold-downboltsintherearofthepedestal
base.
RemovingorInstallingrearcoverpanels
Toremovetherearcoverpanels,loosenthe
screwsslightlyandslidethecoversoutwardas
shownintheillustration.Toreinstall,simplyslide
backintoplaceandretightenthescrews.
Firebrick
Installthefirebrickverticallyontheangleabove
theburnpot.
FlameGuide
Installthecastironflameguideontopofthe
burnpotandmakesureitisfullyseatedagainstthe
augeropening.Thebottomoftheflameguideis
marked38+.
RearCover
Panels
AssemblyandInstallation
ShippingBolts:Theseholes
arealsousedforMobile
HomeInstallation
Fig.2

5
Installing
PlacethestoveonanoncombustiblefloororUL
approvedfloorprotectorthatextends6inchestothe
front,6inchestothesidesand1inchtotherearofthe
stove.
Placethestoveawayfromcombustiblewallsat
leastasfarasshowninfigures3,4and5.Pleasenote
thedifferenceinsidewallclearancewithandwithout
sideshields.
Notethattheclearancesshownareminimumfor
safetybutdonotleavemuchroomforaccesswhen
cleaningorservicing.Pleasetakethisintoaccountwhen
placingthestove.
Connectthepowercordtoa120V.A.C.60Hz
groundedreceptacle.
Afterconnectingthefluesystem,followtheabove
procedure.However,priortotakingthedraftreadingbe
surealldoorsandwindowsinthehomeareclosed.
Recordthedraftreading_______.Ifthisreadingismore
than.05"lowerthantheunconnectedreading,check
forpossiblerestrictionsortheneedforoutsideair(see
page8).
MobileHomeInstallation
Wheninstallingthisunitinamobilehomeseveral
requirementsmustbefollowed:
1.Theunitmustbeboltedtothefloor.Thiscanbe
donewith1/4"lagscrewsthroughthe2holesinthebase
plate.
2.Theunitmustalsobeconnectedfortheoutside
air.Seepage8.
3.Floorprotectionandclearancesmustbefollowed
asshown.
4.Unitmustbegroundedtothemetalframeofthe
mobilehome.
CAUTION:Thisappliancemustbeventedtotheout-
side.
Duetohightemperatures,thestoveshouldbeplaced
outoftrafficandawayfromfurnitureanddraperies.
Childrenandadultsshouldbealertedtothehazards
ofhighsurfacetemperaturesandshouldstayawayto
avoidburntoskinand/orclothing.
Youngchildrenshouldbecarefullysupervisedwhen
theyareinthesameroomasthestove.
Clothingandotherflammablematerialsshouldnot
beplacedonornearthisunit.
InstallationandrepairofthisHarmanStoveshould
bedonebyaqualifiedserviceperson.Theappliance
shouldbeinspectedbeforeuseandatleastannuallybya
qualifiedserviceperson.Morefrequentcleaningwillbe
required.Itisimperativethatcontrolcompartments,burn-
ers,andcirculatingairpassagewaysofthestovebekept
clean.
6"
6"
18"
10"
2"
1"
6"
WithSideShields
WithoutSideShields
FLOORPROTECTOR
FLOORPROTECTOR
Fig.5
Fig.3
FLOORPROTECTOR
9"-13"
9"-13"
9"WithSideShields
13"WithoutSideShields
Installation
Mobilehomeinstallationshouldbedonein
accordancewiththeManufacturedHomeand
SafetyStandard(HUD),CFR3280,Part24.
Fig.4

6
Venting
RequirementsforTerminatingtheVenting
WARNING:Ventingterminalsmustnotbere-
cessedintoawallorsiding.
NOTE:OnlyPLventpipewallpass-throughs
andfirestopsshouldbeusedwhenventingthrough
combustiblematerials.
NOTE:Alwaystakeintoconsiderationtheef-
fecttheprevailingwinddirectionorotherwindcur-
rentswillcausewithflyashand/orsmokewhenplac-
ingthetermination.
Inaddition,thefollowingmustbeobserved:
A.Theclearanceabovegrademustbeamini-
mumof18".1
B.Theclearancetoawindowordoorthatmay
beopenedmustbeaminimumof48".1
(withoutsideairinstalled,18î)
C.A12"clearancetoapermanentlyclosed
windowisrecommendedtopreventcondensation
onthewindow.
D.Theverticalclearancetoaventilatedsoffit
locatedabovetheterminalwithinahorizontaldis-
tanceof2feet(60cm)fromthecenter-lineofthe
terminalmustbeaminimumof18".
E.Theclearancetoanunventilatedsoffitmust
beaminimumof12".
F.Theclearancetoanoutsidecorneris11"
fromcenterofpipe.
G.Theclearancetoaninsidecorneris12".
H.Aventmustnotbeinstalledwithin3feet(90
cm)aboveameter/regulatorassemblywhenmea-
suredfromthehorizontalcenter-lineoftheregula-
tor.1
I.Theclearancetoserviceregulatorventoutlet
mustbeaminimumof6feet.1
J.Theclearancetoanon-mechanicalairsup-
plyinlettothebuildingorthecombustionairinletto
anyotherappliancemustbeaminimumof48î.1
K.Theclearancetoamechanicalairsupply
inletmustbeaminimumof10feet.1
(withoutsideairinstalled,6feet)
L.Theclearanceaboveapavedsidewalkora
paveddrivewaylocatedonpublicpropertymustbe
aminimumof7feet.1,2
M.Theclearanceunderaveranda,porch,deck
orbalconymustbeaminimumof12inches.1,3
NOTE:Theclearancetovegetationandother
exteriorcombustiblessuchasmulchis36îasmea-
suredfromthecenteroftheoutletorcap.This36î
radiuscontinuestogradeoraminimumof7feet
belowtheoutlet.
1CertainCanadianandorLocalcodesorregu-
lationsmayrequiredifferentclearances.
2Aventshallnotterminatedirectlyaboveaside-
walkorpaveddrivewaywhichislocatedbetween
twosingle†familydwellingsandservesbothdwell-
ings.
3Onlypermittedifveranda,porch,deck,orbal-
conyisfullyopenonaminimumof2sidesbeneath
thefloor.
NOTE:Wherepassagethroughawall,or
partitionofcombustibleconstructionisdesired,
theinstallationshallconformtoCAN/CSA-B365.
(ifinCanada)
VA
=Ventterminal =Airsupplyinlet
Fixed
Closed
Openable
Openable Fixed
Closed
InsideCorner
Detail
=Areawhereterminalisnotpermitted

7
Acombustionblowerisusedtoextractthecom-
bustiongasesfromthefirebox.Thiscausesanega-
tivepressureinthefireboxandapositivepressure
intheventingsystemasshowninfig.6.Thelonger
theventpipeandmoreelbowsusedinthesystem,
thegreatertheflowresistance.Becauseofthese
factswerecommendusingasfewelbowsaspos-
sibleand15feetorlessofventpipe.Themaximum
horizontalrunshouldnotexceed48".Ifmorethan
15feetofpipeisneeded,thediametershouldbe
increasedfrom3"to4"becausealargerpipecauses
lessflowresistance.Besuretouseapproved
pelletventpipewallandceilingpassthrough
fittingstogothroughcombustiblewallsand
ceilings.Besuretouseastartingcollartoattach
theventingsystentothestove.Thestartingcollar
mustbesealedtothestovewithhightempsili-
conecaulking.
VentPipe
Pelletventingpipe(alsoknownasPLvent)is
constructedoftwolayerswithairspacebetween
thelayers.Thisairspaceactsasaninsulatorand
reducestheoutsidesurfacetemperaturetoallowa
clearancetocombustiblesofonly3inches.The
sectionsofpipelocktogethertoformanairtightseal
inmostcases;however,insomecasesaperfect
sealisnotachieved.Forthisreasonandthefact
thattheP61operateswithapositiveventpressure
wespecifythatthejointsalsobesealedwith
clearsilicone.
OutsideAir
Outsideairisoptionalexceptinmobilehomes
andwherebuildingcodesrequire.Thebenefitof
outsideairismainlynoticedinsmallverytight
houses.
Toinstalloutsideairuse23/8"I.D.flexpipe
partnumber2-00-08543.Thereisabreak-awayhole
ontherearpanelwhichmustberemovedbefore
connectingtheflexpipe.Thepipeshouldberunout-
sideandterminatetothesideorbelowtheventpipe
outletsotheflueoutletismorethan12"fromthe
inletcover.Themaximumlengthrunofthispipeis
15feet.Ifalongerrunisneededthesizemustbe
increasedto3".Inletcoverpartnumber1-10-08542
shouldbeusedtokeepbirds,rodentsetc.outofthe
pipe.
HRV
WheninstallinginahousewithaHeatReclaim-
ingVentilationSystem(HRV)besurethesystemis
balancedandisnotcreatinganegativepressurein
thehouse.
Outsideairflexpipe
goeshere
InletCoverpart#
1-10-08543
Flexpipepart#
2-00-08543
Venting
IMPORTANTNOTICE
PelletVentPipeorPLVentPipeMustbeused.
+=Positivestaticpressure
=Negativestaticpressure
Fig.6
Fig.7

8
#2Preferredmethod
Thismethodalsoprovidesexcellentventingfor
normaloperationbutrequiresthestovetobeinstalled
fartherfromthewall.Theverticalportionofthevent
shouldbethreetofivefeethighandatleastthree
inchesfromacombustiblewall.Thisverticalsec-
tionwillprovidenaturaldraftintheeventofapower
failure.
#1Preferredmethod
Thismethodprovidesexcellentventingfornor-
maloperationandallowsthestovetobeinstalled
closesttothewall.Twoinchesfromthewallissafe;
however,fourinchesallowsbetteraccesstoremove
therearpanel.Theverticalportionoftheventshould
bethreetofivefeethigh.Thisverticalsectionwill
providenaturaldraftintheeventofapowerfailure.
Venting
Venting
Fig.8
Fig.9
3ft.
tocombustibles
3ft.
tocombustibles

9
#4Installingintoanexisting
chimney(USonly)
Thismethodprovidesexcellentventingfornor-
maloperation.Thismethodalsoprovidesnatural
draftintheeventofapowerfailure.Ifthechimney
conditionisquestionableyoumaywanttoinstalla
linerasinmethod#7.
#5Installingintoanexistingfireplace
chimney(USonly)
Thismethodprovidesexcellentventingfornor-
maloperation.Thismethodalsoprovidesnatural
draftintheeventofapowerfailure.
Thedamperareamustbesealedwithasteel
plateorfiberglass.Acapshouldbeinstalledonthe
chimneytokeepoutrain.Ifthechimneyconditionis
questionableyoumaywanttoinstallalinerallthe
waytothetopasinmethod#6.
Fig.10
Fig.11
Venting
Venting

10
#6Installingintoanexistingfireplace
chimney(USandCanada)
Thismethodprovidesexcellentventingfornor-
maloperation.Thismethodalsoprovidesnatural
draftintheeventofapowerfailure.
InCanadaandsomeplacesintheUSitisre-
quiredthattheventpipeextendallthewaytothetop
ofthechimney.
Inthismethodacapshouldalsobeinstalled
onthechimneytokeepoutrain.Besuretouseap-
provedpelletventpipefittings.Sealpipejointswith
siliconeinadditiontothesealingsystemusedby
themanufacturer.Pipesizeshouldbeincreasedto
4"usingthismethod.
#7Installingintoanexisting
chimney(USandCanada)
Thismethodprovidesexcellentventingfornor-
maloperation.Thismethodalsoprovidesnatural
draftintheeventofapowerfailure.
InCanadaandsomeplacesintheUSitisre-
quiredthattheventpipeextendallthewaytothetop
ofthechimney.Thepipeorlinerinsidethechimney
shouldbe4"diameter.
Inthismethodacapshouldalsobeinstalled
onthechimneytokeepoutrain.Onedisadvantage
ofthismethodisthatitishardertocleanthevent
pipe,therefore,thereisatendancynottodoitas
oftenasneeded.
Fig.12
Fig.13
Venting
Venting

11
#8Installingthroughtheceilingvent
Throughtheceilingvent,followPLvent
manufacturersrecommendationswhenusingwall
andceilingpassthrough.
Fig.14
Noinsulationor
othercombustible
materialsare
allowedwithin3"
ofthePLventpipe.
PLventmanufacturer's
firestopspacerandsupport
(SeePage9for
corner
installation
clearances)
Minimumfluevent
configuration
Itisrecommendedthat
outsideairbeinstalledwiththis
ventingconfiguration.
Min.abovegroundlevel
18"
Stormcollar
Flashing
3"min. 3"min.
12"min.
3"min.
Fig.15
Fig.16
Venting
DONOTINSTALLAFLUEDAMPERINTHE
EXHAUSTVENTINGSYSTEMOFTHISUNIT.
DONOTCONNECTTHISUNITTOACHIMNEY
FLUESERVINGANOTHERAPPLIANCE.
INSTALLVENTATCLEARANCESSPECIFIED
BYTHEMANUFACTURER
CAUTION
DONOTINSTALLINSLEEPINGROOM
WARNING
CAUTION
THESTRUCTURALINTEGRITYOFTHE
MOBILEHOMEFLOOR,WALL,ANDCEILING/
ROOFMUSTBEMAINTAINED.
THESTOVEISHOTWHILEINOPERATION.
KEEPCHILDREN,CLOTHINGAND
FURNITUREAWAY.CONTACTMAYCAUSE
SKINBURNS.

12
Operation
StartingFirstFire
Besurethepowercordispluggedintoa120volt
receptacle.Thiscanbeverifiedbytheredpower
lightonthecontrolpanel.
Fillthehopperwithpellets.
Filltheburnpotwithpelletstoaleveljustshortof
overflowing,fig.17.
Adjustfeedrate.Ifthisisyourfirstfireoryouare
tryingdifferentpellets,setthefeedadjusterto"3",
fig.18.Thisisaconservativenumberandwillprob-
ablyneedtobeincreased.Afteryouknowafeed
ratesettingthatworkswell,usethatsetting.Re-
member,toohighafeedratewillwastefuel.
TurnModeselectorto"OFF"andthento
"StoveTemp".Thiswillturnthecombustion
blowertohigh.Whenstartingafirealwaysturn
themodeselectorto"OFF"beforeselectingthe
desiredmode.Thisresetsthecontrolforstart-
up.
TurnTempDialto7.Thiswillallowthestoveto
burnatmaximumforfeedrateadjustingpur-
poses.
Applystartinggeltopelletsinburnpotandlight
thegel.Closethedoorafterlighting.Atthispoint
thedistributionandcombustionlightswillbeon
andthefeedmotorlightwillbeoff.Asthetem-
peratureofthefireincreases,thefeedmotorlight
willcomeonandpelletswillfeedintotheburn
pot.Asthestovetemperatureincreasesthedis-
tributionblowerspeedwillincrease.
After30to45minutesitmaybenecessarytoread-
justthefeedrate.Thefeedrateshouldbead-
justedsothereisaboutoneinchofashinfrontof
thefire,fig.20.Thisisamaximumburnposition
andusuallydoesnotachievethispositionunder
normalburnrates.
Fig.17
Fig.18
Fig.19
Fig.20
1"
"NEVERUSEGASOLINE,GASOLINE-TYPELANTERN
FUEL,KEROSENE,CHARCOALLIGHTERFLUID,OR
SIMILARLIQUIDSTOSTARTOR"FRESHENUP"AFIRE
INTHISHEATER.KEEPALLSUCHLIQUIDSWELLAWAY
FROMTHEHEATERWHILEINUSE".
P61-2MANUALSTARTUP

13
Whentouse"StoveTempMode"
In"StoveTempMode"theStoveTempDialde-
terminesthetemperatureofthestove.Heatoutput
andfuelconsumptionwillremainconstant.This
makesitpossibletotellhowlongahopperfullof
pelletswilllast.Thedistributionblowerspeedwill
varyaccordingtothepositionofthemodeselector,
fig.21.
Whentouse"RoomTempMode"
In"RoomTempMode"heatoutputiscontrolled
automaticallybytheRoomSensingProbe.When
theRoomSensingProbecallsforheat,thestove
willincreaseoutput.WhentheRoomSensingProbe
isgettingclosetothesettemperature,thestovewill
begintoleveloffoutputandkeepthefireburningat
justtherighttemperaturetomaintainthatsetting.
Highoutputisdeterminedbythefeedrate.The
maximumfeedrateshouldbesetfor1"ofashin
frontoffire.
In"RoomTempMode"fuelconsumptionissac-
rificedforexactroomtemperature.Therefore,asit
getscoldermorepelletswillbeburnedautomati-
cally.
Thedistributionblowerspeedwillvaryaccord-
ingtothepositionofthemodeselector,fig.21.
Shut-DownProcedure
Tokillthefireorstopburningthestove,turnthe
ModeSelectorto"OFF".Thiswillcausethefireto
diminishandburnout.Whenthefireburnsoutand
thestovecoolsdowneverythingwillstop.
Ifyoupulltheplugtoshutdownthestove,all
motorswillstop.Thismaycauseincompletecom-
bustionandsmokeinthefirebox.Iftheloaddooris
openedthesmokemayescape.
Thebestwaytoshutdownthestoveissimply
letitrunoutofpellets,thenthestovewillshutdown
automatically.
Thissettingwillproducemediumheatwiththe
distributionbloweron"low".
Thissettingwillproducearoomtemperatureof70
degreeswiththedistributionbloweratmediumspeed.
Thissettingwillproducecontinuousmaximumheatoutput
withthedistributionbloweratfullspeed.
Fig.21
P61-2MANUALIGNITION/OPERATION

14
ESPCONTROL
Feedadjuster
Setsthemaximum
feedrate
Test
Runsallmotorsat
fullspeedfortwo
minutestocheck
operation.Aftertwo
minutesthestove
willgotominimum
burnandthe
blowerswill
alternatefromhigh
toloweverytwo
minutestoremind
youthatyouarestill
in"TestMode".
DistributionBlower
speedadjustment
range.
STATUSLIGHTERRORMESSAGES:
1Blink:Indicatescontrolboardselfdiagnosticfail-
ure.Thisrequiresamanualreset*.
2Blinks:Indicatesthatthejumper(J2)ontherear
ofthecontrolboardisnotconnected.Withoutthis
jumpertheunitwillonlyburnatminimumrate.
3Blinks:IndicatesESP(ExhaustSensingProbe)
failure.Thisrequiresamanualreset*.
4Blinks:CanoccuronlyinRoomTempModeand
indicatesRoomSensingProbefailedornotinstalled.
IfaRoomSensingProbeistheninstalledthestatus
lightwillautomaticallyreset.
(Note)onlyafterunithaswarmedup.
6Blinks:Indicatesthatthecontrolhascalculated
poororincompletecombustionoccurringformore
than50minutes.SeeTroubleshootingsectionfor
moredetails.
*Manualreset,disconnectpowercordforafew
secondsandreconnect.Iferrorstilloccurscallyour
Dealer.
Tempdial
AllowsyoutoadjusttheRoom
temperatureinRoomTempModeusing
theouterscalemarkedindegrees
Fahrenheit.Italsoallowsyoutoadjust
thestovetemperaturewhileinStove
TempModeusingtheinnerscale
markedfrom1to7.
ModeSelector
AllowsyoutochoosebetweenRoom
TempMode,StoveTempMode,or
OFF.Alsoallowsyoutovarythe
distributionblowerspeedbyturningthe
knobtothehighorlowsideofeach
mode.
PowerLight
Indicatespowertothe
control.
IndicatesPowertothe
feedmotor.
IndicatesPowerto
combustionblower
StatusLight
Willbelitineitherstove
orroomtempmodewhen
pointerisnotwithinoff
positionbandexcept
afternormalshutdown.
Blinkstoindicateerrors
listedlistedbelow.
Indicatespowerto
distributionblower.
P61-2ESPCONTROL

15
Theroomsensorisasmalltemperaturesen-
sorontheendofa60"graywire.Thissensoris
installedmuchlikeastandardwallthermostat.Be-
causeitissosmall,itcanbehiddenalongthetrim
ofadoorwayorevenupthelegofacoffeetable.
Thereisaremoteroomsensorportontherearof
theunitforeasyexternalconnection.Usestandard
18-2thermostatwiretoextendthedistancetothe
desiredlocation(100'maximum).Theroomsen-
sorshouldbeinstalledinthelocationwhereyouwant
tocontrolthetemperature.
NOTE:Distancesofmorethan25feetfrom
theunitorinanotherroomarenotrecommended.
TheroomsensorisessentialfortheP61'sexcel-
lentefficiency.
NOTE:Itisrecommendedthattheroom
sensorbeinstalled,evenifonlyinstalledonthe
rearoftheunitasareturnairsensor.
Fig.22
RoomSensorInstallation
Fig.23
RoomSensorandRearShieldInstallation
RearShields
5/16"HexHead
Screws(2on
eachside)
5/16"Hex
Head
Screws(2
oneach
side)
Therearisolatedshieldsaresplitinthemiddlefor
easyremoval.Eachshieldhastwo5/16"hexhead
screwsthatonlyneedtobeloosened(NOT
REMOVED)toallowtheshieldtoslideawayfrom
theunit.NOTE:Itisnotrecommendedthatthe
unitbeoperatedwiththeshieldsremoved,due
tothehotandmovingpartswhichtheyprotect.

16
RemovingAshes:
Whenapproximatly1tonofpelletshasbeen
burneditwillbenecessarytoemptytheashpan.
Ashesshouldbeplacedinametalcon-
tainerwithatightfittinglid.Theclosedcon-
tainerofashesshouldbeplacedonanon-
combustiblefloororontheground,wellaway
fromallcombustiblematerials,pendingfinal
disposal.Ifashesaredisposedofbyburialin
soilorotherwiselocallydispersed,they
shouldberetainedintheclosedcontainer
untilallcindershavethoroughlycooled.
Itisrecommendedthatthestoveiscoldand
shutdownwhenremovingashpan.
1.Pullonlatchhandlesandremoveashpanas
shownatleft.Useashpanhandletocarry
anddisposeofashes.
2.Slidetheashpanbackintothestoveand
latchbypushinginonbothlatchessimulta-
neously.
Cleaning:
Thestovewillneedtobecleanedforapproxi-
matelyevery2to5tonsofpelletsburned.The
amountofpelletsburnedbeforecleaningwillvary
dependingonthebrandofpellets.
1.Shutdownstoveanddisconnectpower
cordtoinsurethatallmotorsarestopped.
2.Removeashpanasdescribedearlier.
3.Removecombustionblowercoverbyturning
thelatchverticalasshowninFig.26and
slidingthecoveroutoftheslotontheleft
Fig.27.Thiswillexposethecombustion
blowerwheelandflueoutlet,Fig.24.
4.Cleantheblowerwheelwithabrushanda
vacuumcleaner.
5.Useabrush(Fig.30)tocleantheflue,being
carefulnottodamagetheESPprobe.The
fluegoesstraightthroughintotheventpipe
(Fig.29)therefore,theventpipecanalsobe
cleanedtosomeextentthroughtheflue
outlet.
6.Reinstallblowercoverandrelatch.
Combustion
BlowerCover
Scraper
BlowerCover
Latch
BlowerWheel
FlueOutlet
HeatExchangerFins
Fig.25
Fig.24
BlowerCover
Latch
Maintenance

17
Latch"closed"with
blowercoverinplace.
Burnpotclean-outis
closed.
Latch"open"with
blowercoverpartly
removed.Burnpot
clean-outisopen.
Exposedblowerwheel
andflueopening,
NOTE:ESPprobeis
visible.
Blowercover
removed.
ESP
probe
ESPProbe
7.Openburnpotslideasshown,cleanwith
vacuumandclose.
8.Cleanheatexchangerwithscraperasshownat
left.
9.Brushorscrapetheinsideofthestoveto
removeflyash.
10.Scrapeburnpotwithflatendofscraperpro-
videdwiththestove.Fig.31.
11.Slideashpanintostoveandlatchintoplace.
Fig.26 Fig.27
Fig.28
Fig.29
Fig.30
Fig.31
Brushnot
supplied.Canbe
foundin
hardwarestores.
Becarefulnotto
damageESPprobe
whencleaningwith
brush.
SootandFlyAsh
Theproductsofcombustionwillcontain
smallparticlesofflyash.Theflyashwill
collectintheexhaustventingsystemand
restricttheflowofthefluegases.Incom-
pletecombustion,suchasoccursduring
startup,shutdown,orincorrectoperation
oftheroomheater,willleadtosome
sootformationwhichwillcollectinthe
exhaustventingsystem.Theexhaust
ventingsystemshouldbeinspected
atleastonceeveryyeartodetermine
ifcleaningisnecessary.
Maintenance

18
FEEDERDOESNOTFEED
1.Nopelletsinhopper.
2.FeedmotorwillnotrununtilESP
senses165deg.F.Maybeyoudidnotput
enoughpelletsintheburnpotbeforelighting
thefire.
3.Feedmotorhasfailed.
4.Somethingisrestrictingflowinthehopper
orcausingtheslideplatetostick.
5.Fireboxdraftmaybetoolowforlowdraft
pressureswitchinfeedercircuittooperate.
Checkforcloseddoors,looseormissinggas-
ketondoorsorhopperlid,faultypressure
switch.
PARTIALLYBURNEDPELLETS
1.Feedratetoohigh.
2.Drafttoolow.(Checkburnpotclean-outslide
anddoorgasket).
3.Burnpotorheatexchangertubesmayneed
tobecleaned.
4.Combinationofalltheabove.
SMOKESMELL
Sealtheventpipejointsandconnectiontostove
withsilicone.
FIREHASGONEOUT
1.Nopelletsinhopper.
2.Feedratetoolow.
3.Somethingisrestrictingfuelflow.
4.Feedmotorordraftmotorhasfailed.
5.Powerfailureorblownfuse.
SMOKEISVISIBLECOMINGOUTOFVENT
1.Air-fuelratioistoorich.
A.Feedratetoohigh.
B.Drafttoolowcausedbyagasketleak.
LOWHEATOUTPUT
1.Feedratetoolow
2.Drafttoolowbecauseofgasketleak.
3.Poorqualityordamppellets
4.Combinationof1.and2.
CleaningBurnPot
Wheneveryourstoveisnotburning,takethe
opportunitytoscrapetheburnpottoremovecarbon
buildup.Avacuumcleanerishandytoremovethe
residue.Besurethestoveiscoldifyouusea
vacuum.
Carbonbuildupcanbescrapedloosewiththe
fireburningusingthespecialtoolprovidedwithyour
stove.Scrapethefloorandsidesoftheburnpot.
Thecarbonwillbepushedoutbytheincomingfuel.
Alwayswearglovestodothis.
RemovingAshes
TurntheStoveTempDialtonumber1approxi-
mately30minutesbeforeremovingashes.Thiswill
resultinacoolerstoveandashpan.
MaximumTurbosettingsarenotneededin
mostcases.Operatinginthenormalrangeisrec-
ommendedwhenmaximumheatoutputisnotre-
quired.TheESPprobepreventsthestovefrombe-
ingover-fired.
Keepthestovefreeofdustanddirt.
HelpfulHints
Fuel
Pelletfuelsareputinto3categoriesintermsofashcontent.Premiumat1%orless,Standardat3%
orlessandallothersat3%ormore.
TheP61iscapableofburningall3categoriesofpelletsduetoapatentedfeederandburnpot
system.
Itshouldbenoted,however,thathigherashcontentwillrequiremorefrequentashremovalandmay
providelessBTU'sperlb.Normally,standardandhighashpelletscostlessthanpremiumpelletsandcan
becosteffectivewhenburnedintheP61.
Themoisturecontentmustnotexceed8%.HighermoisturewillrobBTU'sandmaynotburnproperly.
Trouble-Shooting

19
Weight 249lbs.
Blower 135cfm
FeedRate .75to7.5lbs.perhr.
HopperCapacity 72lbs.
Fuel WoodPellets
FlueSize 3inch
OutsideAirSize 23/8I.D.inch
FuseRating 5amp
32.375"
9"
23.5"
34.5"
5.250"
12.375"
Specifications
29.5"
P61-2FeederandSpecifications

20
P61-2WiringDiagram
