Harman JBL STAGE3 607C User manual

Installation manual
STAGE3 607C
STAGE3 607CF
STAGE3 427
STAGE3 427F
STAGE3 527
STAGE3 527F
STAGE3 627
STAGE3 627F
STAGE3 637F
STAGE3 6427
STAGE3 8627
STAGE3 9637
STAGE3 9637F

STAGE3 607C

Specication
• Type: 6-1/2”(165mm) 2-way
component system car speaker
• Power Handling: 50W RMS, 250W (Peak)
• Sensitivity (@2.83V/1m): 92dB
• Frequency Response: 55Hz - 20kHz
• Impedance: 3ohms
Thiele-Small Parameters
• BL (Tm): 3.316
• DCR (ohms): 2.45
• Mms (g): 14.017
• Sd (cm2): 138.93
• Cms (μm/N): 0.316
• Vas (l): 8.6375
• Fs (Hz): 75.6
• Qes: 1.482
• Qms: 11.842
• Qts: 1.317
• Crossover Point: 5kHz

STAGE3 607CF

Specication
• Type: 6-1/2”(165mm) 2-way
component system car speaker for
factory upgrade without grille
• Power Handling: 50W RMS, 250W (Peak)
• Sensitivity (@2.83V/1m): 92dB
• Frequency Response: 55Hz - 20kHz
• Impedance: 3ohms
Thiele-Small Parameters
• BL (Tm): 3.316
• DCR (ohms): 2.45
• Mms (g): 14.017
• Sd (cm2): 138.93
• Cms (μm/N): 0.316
• Vas (l): 8.6375
• Fs (Hz): 75.6
• Qes: 1.482
• Qms: 11.842
• Qts: 1.317
• Crossover Point: 5kHz

STAGE3 427

Specication
• Type: 4”(100mm) 2-way coaxial car
speaker
• Power Handling: 30W RMS, 150W (Peak)
• Sensitivity (@2.83V/1m): 90dB
• Frequency Response: 75Hz - 20kHz
• Impedance: 3ohms
Thiele-Small Parameters
• BL (Tm): 2.467
• DCR (ohms): 2.74
• Mms (g): 5.501
• Sd (cm2): 63.62
• Cms (μm/N): 0.387
• Vas (l): 2.2146
• Fs (Hz): 109.1
• Qes: 1.698
• Qms: 12.973
• Qts: 1.501
• Crossover Point: 7kHz

STAGE3 427F

Specication
• Type: 4”(100mm) 2-way coaxial car
speaker for factory upgrade without
grille
• Power Handling: 30W RMS, 150W (Peak)
• Sensitivity (@2.83V/1m): 90 dB
• Frequency Response: 75Hz - 20kHz
• Impedance: 3 ohms
Thiele-Small Parameters
• BL (Tm): 2.467
• DCR (ohms): 2.74
• Mms (g): 5.501
• Sd (cm2): 63.62
• Cms (μm/N): 0.387
• Vas (l): 2.2146
• Fs (Hz): 109.1
• Qes: 1.698
• Qms: 12.973
• Qts: 1.501
• Crossover Point: 7kHz

STAGE3 527

Specication
• Type: 5-1/4”(130mm) 2-way coaxial car
speaker
• Power Handling: 40W RMS, 200W (Peak)
• Sensitivity (@2.83V/1m): 91dB
• Frequency Response: 75Hz - 20kHz
• Impedance: 3ohms
Thiele-Small Parameters
• BL (Tm): 3.148
• DCR (ohms): 2.61
• Mms (g): 9.81
• Sd (cm2): 102.07
• Cms (μm/N): 0.281
• Vas (l): 4.1374
• Fs (Hz): 95.9
• Qes: 1.555
• Qms: 13.546
• Qts: 1.395
• Crossover Point: 6kHz
