Hartman 68542009 User manual

ASSEMBLY INSTRUCTIONS
ROMA PERGOLA
(68542009)
ATTENTION:.
1. Please read these instructions carefully before assembly
2. Aluminium is soft metal and over tightening may strip thread or break the part
3. DO NOT use power tools you will need a Philips screwdriver to assemble the pergola
4. Please allow 60 minutes for assembly
5. Assembly will require 2 people and the use of a tall step ladder
ASSEMBLY STEPS:
For more information regarding maintenance of your furniture please visit
http://www.hartmanuk.co.uk/after_care_videos.html
PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to hp://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
1. Before assembly of pergola, slide curtain hooks (C) into slot of beam (see diagram)
2. If pergola is already assembled, detach leg from beams allowing access to beam slot
3. Attach front curtain (B) to curtain hooks (C)
4. Attach side curtain (A) to end canopy supports
5. If needed, attach curtains to legs using straps found on each curtain

C
B
A
7
1
1
PLEASE KEEP ME WITH YOUR PROOF OF PURCHASE FOR FUTURE REFERENCE
For replacement or lost spare parts please go to hp://faq.hartmanuk.co.uk/spares/
Should you have any queries about your furniture your first point of contact should be the retailer from whom
you purchased your product
3×2.2 M
3×2.16 M
A
B
Parts List Parts Picture Description Qty Part No
68542009A
68542009B
1600002
Side curtain
Front curtain
Curtain hook
