Forest OVERLAP APEX LOG STORE User manual

REMINDER
Always pre-drill before
screwing.
IMPORTANT
Assembly requires 2+
adults.
50MM
SCREWS
Tape Measure Drill &
2-3mm Drill
Bits
Pozidrive
Screwdriver
Sharp Knife Hammer
Forest Garden, Oak Drive, Hartlebury Trading Estate, Hartlebury, Worcestershire, DY10 4JB
EU Authorised Representative: Authorised Representative Service, 77 Camden Street Lower Dublin, D02 XE80, Ireland
Missing something or need more information?
Call our aftersales team on
0333 321 3142
Visit our website for spare instructions and
more information
www.forestgarden.co.uk
OVERLAP APEX LOG STORE
INSTRUCTIONS
ISSUE: 0122
We recommend using the following
tools (not supplied):
FIXING PACK CONTAINS:
FIXING PACK CODE: OALGSTFP
PLEASE KEEP PLASTIC BAGS AND SMALL PARTS
AWAY FROM CHILDREN
4 x 50mm Screws
QTY: 32
3.5 x 30mm Screws
QTY: 60
Position and secure the Side Panel to the oor bearers
beneath. Ensure the panel is ush to the oor.
Position the Floor in your desired location. Your log
store must be built on a solid and level base.
1
CHECK AND TIGHTEN ALL THE FIXINGS APPLIED TO
THIS PRODUCT ON A REGULAR BASIS.
FLOOR
2
SIDE PANEL
3.5 x 25mm Screws
QTY: 10
Felt Tacks
QTY: 30
Making British gardens great

113mm
113mm
50MM
SCREWS 50MM SCREWS
50MM
SCREWS
30MM
SCREWS
30MM
SCREWS
30MM
SCREWS
3 4
Position and secure the other Side Panel to the oor
bearers beneath and the Back Panel.
Position and secure the Front Panel to the Side Panels
and oor bearers beneath. The screws will need to be
drilled into the Side Panels at an angle.
5
FRONT PANEL
Position and secure the Back Panel to the oor bearers
beneath. Screw the Back Panel to the Side Panel. Ensure
the corner of the adjoining panels are as shown above.
BACK PANEL
SIDE PANEL
Position and attach the Apex Boards to the Back Panel
as shown above. Ensure to screw into the framework
behind. The point of the Apex Boards should be offset
approximately 113mm from the Back panel.
Position and secure the Cover Strips to the front and
back corners. Ensure the Cover Strip is ush to the
bottom board on the panels.
Repeat the process for the other Apex Boards. Position
and attach the Apex Boards to the Front Panel as
shown above. Ensure to screw into the framework
behind.
6
7
BACK COVER STRIP
(44x16x1372mm)
FRONT COVER STRIP
(44x12x1372mm)
APEX BOARD

10mm
50mm
30MM
SCREWS
30MM
SCREWS
25MM
SCREWS
Position your Roof Panels. Ensure they meet in the
middle of the apex and line up ush to each other.
From the inside, secure the Roof Panels to the Apex
Boards to x in place. Mark out where to pre-drill before
securing into place.
Place the felt over the roof and ensure there is
approximately 50mm overhang on all sides. Cut and fold
the felt at the corners as shown above. Take care when
trimming the roof felt.
Secure the felt to the roof, using felt tacks. Ensure the
felt tacks on the sides are placed in 150mm intervals. Fix
2 x felt tacks per block on each roof panel.
Position and secure the Blocks to the Side Barge
Boards. Ensure the Block is ush to the side with a
10mm offset as shown above.
Position and secure the Side Barge Boards to the roof
battens as shown above. Ensure the boards are ush to
the roof.
8
ROOF PANEL
INSIDE
9
10
SIDE BARGE BOARD
BLOCK

25MM
SCREWS
30MM
SCREWS
Use the labelled components to help identify the part code and description.
CHECK YOU HAVE ALL YOUR PARTS PRIOR TO ASSEMBLY.
(The parts do not have codes on them. They are listed below should you need to order one.)
Timber is a natural material of which will shrink and swell as a result of varying moisture content.
Assembly of damaged parts may be deemed to be acceptance and this may affect the remedies you are entitled to. If the product is not constructed
in accordance with the instructions, or is altered in anyway (e.g. painted), the manufacturer cannot be held liable for any resulting damage.
The components provided may be heavy. Please lift with caution and with a minimum of 2 people.
G
Label Part Code Description No.
AOALGSTFLR Floor 750x1828mm 1
BOPOSSP Side Panel 750x1375mm 2
COPOSBP Back Panel 1772x1375mm 1
DPOSFP Front Panel 1772x1375mm 1
E44161372PT Back Cover Strip 44x16x1372mm 2
F44121372PPT Front Cover Strip 44x12x1372mm 2
G121120907PAII83PT Apex Board 121x12x907mm 4
HAOSRF Roof Panel 784x970mm 2
I28280070PT Block 28x28x70mm 4
J121120784PPT Side Barge Board 121x12x784mm 2
K121121010PAII83PT Front/Back Barge Board 121x12x1010mm 4
LFIN25010512PT Finial 250x105mm 1
M85602 Green Mineral Felt 1x2.5m 1
Overlap Apex Log Store (OALGST)
A B C D E F
Position and secure the Front/Back Barge Boards to
the Roof Panel blocks and Side Barge Board blocks as
shown above.
11
FRONT/BACK BARGE BOARD
Attach the Finial to the centre of the Front Barge
Boards.
12
FINIAL

TREATED TIMBER CONTAINING A BIOCIDAL PRODUCT
CONTROL OF WOOD DESTROYING ORGANISMS
Active Ingredients - Propiconazole, Tebuconazole, IPBC, Permethrine, Benzyl-C12-16-Alkyldimethyl Chlorides. (Dip Treated)
Basic Copper Carbonate, DDA Carbonate, DDA Chloride. (Pressure Treated)
Wear gloves when handling. Avoid inhalation of sawdust. Do not use in contact with drinking water or food. Do not use for animal
bedding or in sh ponds. Dispose of treated wood responsibly.
H
HEALTH & SAFETY
THE ROOF OF THIS LOG STORE IS NOT A LOAD BEARING STRUCTURE
We strongly recommend that PPE (Personal Protective Equipment) is used throughout your build to ensure you are
protected from any potential health and safety risks. Do not exempt yourself from wearing PPE.
I J K L
