HARVEST Nodestream AVR2 User manual

®
Quick Start Guide
™
MEDIA
ENCODER
AVR2

Welcome to the Nodestream AVR2
Please read these instructions carefully before using this product and save this
quick start guide for future reference. See the User Manual for full details via the
QR code on the back page.
®
2
In the Box
1 x power cable
(region specic)
D9 null modem
1 x Ethernet cable1 x HDMI cable
D9 gender changer
Multi-cast streaming solution
Video Source AV2 Unit Cloud Devices
(via AVRLive)
AVR2™
Overview

®
3
Rear Connections
Front Interface
For further information on connections, refer to AVR2 User Manual.
IMPORTANT: 100-240VAC 47/63HZ only (UPS Recommended)
RESET
START
STOP
VIEW
the AVR2 unit
streaming video and/or data
streaming video and/or data
the preview screen (display)
Power
Switch
Power
Socket
Display
Overview

The AVR2 is designed to be mounted in a standard 19” rack and occupies 2U of
space
Install at all 4 mount points
Connect Ethernet, video source input, and power cable
mount point
®
4
1
2
Ensure there is adequate spacing around the AVR2 device for cooling. The cool air
travels in the direction as shown by the arrows.
No vertical loading on the AVR2 device.
Installation
The AVR2 device requires an open Internet connection, refer to the User
Manual for information on advanced network conguration.

®
5
1
2
3
Switch on the power (on the rear of the AVR2 unit)
The LEDs on the interface panel turn on and the display turns on
Once the unit has powered up, the status is indicated by the STREAMING LED
The display automatically turns off after 5 minutes. Press View to wake the display.
The device is congured to auto start when AC power is applied.
Red Network error
Blue Idle
Green Online and streaming
Start Up
AVR2
MEDIA
ENCODER

®
Contact and Support
suppor[email protected]
User Resources
All rights reserved. This document is the property of Harvest Technology Pty Ltd. No part of
this publication may be reproduced, stored in a retrieval system or transmitted in any form or
by any means, electronic, photocopy, recording or otherwise without the written consent of the
Managing Director of Harvest Technology Pty Ltd.
Harvest Technology Pty Ltd
7 Turner Ave, Technology Park
Bentley WA 6102, Australia
www.harvest.technology
AVR Live Web Access
AVR2™ Dashboard access: http://avrlive.com/
Troubleshooting
Issue Cause Resolution
Device not powering PSU switch set to off position
AC not connected
Conrm AC connected and switch is in the
on position
‘No signal’ displayed on screen Video source not connected or
powered
Damaged cable
Test the video source with an alternate display
Change out cable
No network -
Streaming LED solid Red
No connection to server Check Ethernet cable is plugged in
Ensure required rewall ports are unblocked
(see User Manual)
Check network settings, contact your network
administrator to diagnose network issues
HTG-TEC-GUI-005_2
