Hatteras Single Cotton Rope Swing User manual

Single Cotton Rope Swing
Congratulations on your purchase of the Single Cotton Rope Swing.
We believe that you will find it a product of unsurpassed quality and durability.
The box should contain:
Single Cotton Rope Swing
(chain attached)
1 - “S” Hook
1 - Steel Hanging bracket
2 - 5/16 x 2” Hex Head Lag Bolts
Assembly Instructions:
NOTE: During shipping, the hanging chain may
come apart from the swing chains. If this has
occurred, lay the swing down and extend the swing
chains from each end of the spreader bar toward a
center point. Place the hanging chain above the
swing. Attach the hanging chain to the swing chains
using the attached “S hooks.”
Hanging Instructions:
1. Select a location for your swing that is 6 1/2 feet to
8 1/2 feet above ground or floor level and will support
a maximum of 350 lbs. Position hanging system
bracket along the center line of the beam on which
you wish to hang your swing. Make sure beam has
no knots or cracks or signs of rot.
CAUTION:
A. Mounting Hardware included is safety rated ONLY
for load bearing structures. The steel hanging bracket
is not safety tested and approved for concrete
surfaces, steel or plastic construction, particle board
and the like material, or vinyl siding.
B. The steel hanging bracket is to make contact with
mounting surface. Structural support unit must
accommodate maximum safe weight limit of 350
pounds.
C. Prior to each use of your swing, inspect the ropes
and other materials in your swing including but not
limited to: the mounting hardware, installation points,
and objects supporting your swing for signs of
weakness or wear. Do not use if there are any signs
that the material or supports are not in proper
condition.
IF YOU HAVE ANY QUESTIONS CONCERNING
INSTALLATION, PLEASE CONSULT A BUILDING EXPERT.
THE HAMMOCKSOURCE IS NOT RESPONSIBLE FOR
IMPROPER INSTALLATION.
2. Mark drill holes on center line with a pencil where
the bolt holes are located on the bracket and expose
bare wood.
3. Drill holes where indicated by marked spots with
a 1/4” drill, approximately 2” deep.
4. Position bracket with bracket holes over drill holes
and start bolts by hand. Tighten with wrench or socket.
Do not overtighten bolts. Bolts will strip the wood,
thus causing a reduction in load capacity.
5. Affix “S” hook to hanging bracket. Hook the chain
on the swing to the bottom of “S” hook. Adjust the
If you have any questions regarding our products, call our
toll-free consumer customer service line: 800.643.3522
Visit our web page: www.hatterashammocks.com
height of the swing with the chain for maximum comfort.
When sitting in the swing, your feet should touch the
ground with knees slightly bent. Note: The first time you
hang the swing, it may seem too high off the ground,
however; the ropes will stretch, bringing the swing to a
more comfortable level. Simply
adjust the chain to put your swing
at the desired height.
6. The design of this swing provides
ample room for push-out” seating.
After seated in the swing, the user
can place his or her feet at the edge
of the swing front and “push-out.”
The roomy design of the front of the
swing will provide a comfortable
rest for the legs.
WARNING:
- Not recommended for use by
children without adult supervision.
- Your swing is not built to hold more
than one person at a time.
- Your swing is not designed for high, rough swinging or
twisting movements.
- Do not allow the chain to twist as the strength of the
chain is dramatically reduced when it is twisted.
CARE AND MAINTENANCE:
Thank you for purchasing the Hatteras Hammocks® Single
Cotton Rope Hammock Swing. The Single Cotton Rope
Hammock Swing is designed to be weatherable. However, in
order to keep your swing in the best condition, bring it indoors
and out of extreme conditions.
A solution of mild soap and water will remove most dirt and is
not harmful to the natural cotton fibers. For stains: spot clean
and rinse thoroughly. Sponge thoroughly with clean water and
air dry.
WARRANTY INFORMATION:
Products of The HammockSource are guaranteed to be free of defects in
workmanship and materials for up to one year after the purchase date.
Prolonged exposure to weather conditions including snow, rain, and
humidity are not covered under the warranty nor is damage caused by
normal wear, mildew, or improper care including storage, maintenance,
and installation. If an item is found to be defective within one year of its
purchase, it will be replaced without charge upon the return of the unit
accompanied by a sales receipt. If you choose to return an item, you must
contact our customer service department at 800.643.3522 to obtain a
Return Authorization Number that will allow us to track your unit once it
arrives at our warehouse; thereby creating a faster response to your
concern.
Chain hung
correctly.
Chain hung
incorrectly.
Side
View of
hanging
bracket
Topical
view of
hanging
bracket
5037HB
P.OJ
Hanging Chain
“S” Hooks
Swing Chain
