INSTALLATION INSTRUCTIONS P-REAR-2
REAR PARTITION w/ EXIT HATCH
1997-2008 FORD E-SERIES VANS
**WILL NOT WORK IN 2008 15 PASSEN ER VAN (NO SPACE)**
TOOLS REQUIRED:
Power Drill
Drill Bit Set
Ratcheting Wrench
3 8” Socket Set
Eye Protection
HARDWARE:
QTY DESCRIPTION PART #
12 5 16” x 1 ½” Hex Head Lag Bolt GSM33066
2 ¼-20 x 1” Hex Head Bolt GSM33002
2 ¼” Flat Washer GSM31005
2 ¼-20 Serrated Nut GSM30023
2 Top Mounting Brackets HS-PA99008-1
1. INSTALLATION:
• Rear passenger seat will remain in place. There is very little space between seat and rear
doors.
• Place and position partition w spring clips facing towards rear of vehicle.
• Partition must be pushed tight against seat in order to close doors.
• Drill 3 16” pilot holes into floor of vehicle.
• Bolt partition to vehicle using 5 16” x 1 ½” Hex head lag bolts.
• Loosely bolt Top-mounting brackets to partition w (2) ¼-20 x 1” Hex Head bolt, washer,
and nut.
• Mark and pre-drill 3 16” pilot where bracket lands on vehicles rear door trim. Attach
using (4) 5 16” x 1 ½” Hex head lag bolts.
• Tighten all loose hardware
Top Mounting
Bracket Locations
