Hawg Wired HMA 150 User manual

d
de es si ig gn ne ed d a an nd d b bu ui il lt t i in n t th he e u u. .s s. .a a. .
H
HA AW WG G W WI IR RE ED D
H
H
HM
M
MA
A
A1
1
15
5
50
0
0
H
H
HA
A
AR
R
RL
L
LE
E
EY
Y
Y M
M
ME
E
ED
D
DI
I
IA
A
A A
A
AD
D
DA
A
AP
P
PT
T
TE
E
ER
R
R
I
IN NS ST TA AL LL LA AT TI IO ON N G GU UI ID DE E

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 2 NEWARK, CA
I
IN NT TR RO OD DU UC CT TI IO ON N
CONGRATULATIONS! YOU’VE JUST PURCHASED WHAT WE CONSIDER TO BE THE FINEST MOTORCYCLE
AUDIO EQUIPMENT AVAILABLE. WE TAKE PRIDE IN THE FACT THAT YOU’VE CHOSEN HAWG WIRED
PRODUCTS, AND WELCOME YOU TO OUR FAMILY OF AUDIOPHILE ENTHUSIASTS. OUR GOAL HERE IS
SIMPLE – TO BRING HIGH PERFORMANCE AUDIO FIDELITY TO YOU, THE RIDER, WITHOUT COMPROMISING
YOUR BIKE’S ELECTRICAL SYSTEM OR STORAGE SPACE. SOME SIDE EFFECTS MAY OCCUR HOWEVER,
INCLUDING BUT NOT LIMITED TO; PUZZLED LOOKS FROM OTHER MOTORISTS, OCCASIONAL SHOUTS
FROM YOUR NEIGHBORS, AND THE ENVY OF YOUR FRIENDS. AFTER YEARS OF DESIGN
AND ENGINEERING, CUSTOM CRAFTSMANSHIP, AND A CRAVE FOR CLEAN, CLEAR,
LOUD MUSIC, WE BELIEVE WE’VE NAILED THIS STUFF DOWN RIGHT.
THANK YOU FOR YOUR SUPPORT
THE HAWG WIRED TEAM
S
SE ER RI IA AL L N NU UM MB BE ER R
PLEASE RECORD THE MODEL AND SERIAL NUMBER[S] OF YOUR EQUIPMENT IN THE SPACE PROVIDED
BELOW AS YOUR PERMANENT RECORD. THESE NUMBERS CAN BE FOUND ON THE FRONT AND/OR
BOTTOM OF EACH COMPONENT. THIS WILL ASSIST US WITH YOUR FACTORY WARRANTY COVERAGE, AND
MAY BE USEFUL TO YOU IN THE UNFORTUNATE EVENT THAT IT’S STOLEN.
MODEL NUMBER[S]: SERIAL NUMBER[S]:
K
KE EY Y D DE ES SI IG GN N F FE EA AT TU UR RE ES S
THE HAWG WIRED HARLEY MEDIA ADAPTER INCORPORATES THE FOLLOWING KEY DESIGN FEATURES:
DEVICE CHARGING CAPABILITY USING STANDARD USB INTERFACE CABLES
INDUSTRY STANDARD INTERFACES MAKE FOR ACROSS-THE-BOARD COMPATIBILITY
BATTERY MONITORING TECHNOLOGY TO AVOID A DEAD BATTERY SITUATION
STANDBY MODE FOR KEY-OFF OPERATION AND CHARGE UP TO 30 MINUTES
MODULAR COMPONENT DESIGN ALLOWS BACKWARD COMPATIBILITY AND FUTURE UPGRADES
CONFORMAL COATED WEATHERPROOF PRINTED CIRCUIT BOARDS IN EVERY COMPONENT
COMPLETE WIRING KIT MAKES FOR A PROFESSIONAL, CLEAN, AND EASY INSTALLATION
THIS KIT HAS BEEN DESIGNED SPECIFICALLY FOR BOTH THE BATWING AND SHARKNOSE HARLEY-
DAVIDSON® FAIRINGS. IT CAN ALSO BE USED TO INSTALL THE MEDIA ADAPTER IN MOST AFTERMARKET
FAIRINGS WITH LITTLE OR NO MODIFICATIONS TO THE WIRING KIT.
ADDITIONALLY, THE UNIVERSAL NATURE OF OUR DESIGN INTERFACES MAKE IT AN EXCELLENT
SOLUTION FOR ANY MOTORCYCLE WITH ADEQUATE MOUNTING SPACE. IN FACT, THESE MEDIA ADAPTER
SYSTEMS ARE SO VERSATILE THAT THEY CAN BE INSTALLED AND USED IN PLACE OF A TYPICAL
AUTOMOTIVE SOURCE UNIT WITH IMPRESSIVE RESULTS.
DID WE MENTION THAT THESE ADAPTERS REPRODUCE REALLY CLEAN, REALLY LOUD MUSIC?

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 3 NEWARK, CA
K
KI IT T C CO ON NT TE EN NT TS S
KIT ITEMS INCLUDED: QUANTITY
HMA150 HARLEY MEDIA ADAPTER 1
HW1202C 2 CHANNEL AMPLIFIER 1
SX504-60 INTEGRATED COMPONENT SPEAKER 2
18” CONTROL CABLE 1
6’ POWER CABLE 1
LARGE VELCRO PAD 1
25 AMP ATC FUSE 1
ALCOHOL CLEANING PAD 1
T
TA AB BL LE E O OF F C CO ON NT TE EN NT TS S
BEFORE YOU BEGIN ................................................................................................. 4
GETTING STARTED.................................................................................................... 5
USER GUIDE............................................................................................................ 6
CONNECTORS AND CONTROLS .................................................................................................. 6
CONNECTORS DEFINED............................................................................................................. 7
CONTROLS DEFINED ................................................................................................................. 7
TROUBLESHOOTING.................................................................................................................. 8
SPECIFICATIONS...................................................................................................... 9

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 4 NEWARK, CA
B
BE EF FO OR RE E Y YO OU U B BE EG GI IN N
THIS SECTION IS INTENDED TO BRING YOU UP TO SPEED WITH OUR DOCUMENTATION CONVENTIONS.
WE RECOMMEND READING THIS MANUAL THOROUGHLY BEFORE BEGINNING YOUR INSTALLATION TO
ACHIEVE A TROUBLE FREE, LONG LASTING OUTCOME.
TERMINOLOGY USED IN THIS MANUAL:
SOURCE UNIT REFERS TO THE DEVICE THAT SUPPLIES THE SYSTEM WITH AUDIO SOURCE,
TYPICALLY YOUR MEDIA DEVICE, MINIDISC DEVICE, ETC.
MEDIA ADAPTER HMA150 MEDIA ADAPTER THAT INTERFACES BETWEEN THE SOURCE UNIT AND
AMPLIFIER SYSTEM, PROVIDING PWR/VOL/BAS/TRB CONTROL, USB CHARGING, ETC.
MAIN AMPLIFIER HW1202C 2 CHANNEL AMPLIFIER THAT PROVIDES THE DRIVING POWER TO THE
SPEAKERS. THE MAIN RED BOX IN THE KIT.
MEDIA HARNESS USED TO CONNECT THE MEDIA ADAPTER AND AMPLIFIER TO EACH OTHER, AND TO
THE MOTORCYCLE CHARGING SYSTEM.
STAND-BY OPERATION REFERS TO A MODE OF OPERATION OR FUNCTION THAT TAKES PLACE WITHOUT THE
USERS INTERACTION, TYPICALLY DEVICE CHARGING, BATTERY MONITORING, ETC.
3.5MM INPUT JACK USED TO CONNECT A SOURCE UNIT TO THE AUDIO SYSTEM, TYPICALLY USED WITH
AFTERMARKET SOURCE UNITS (PREFERRED METHOD).
MANUFACTURER INSTRUCTIONS REFERS TO ANY DOCUMENTATION PROVIDED BY A MANUFACTURER OTHER THAN
HAWG WIRED (IE. HARLEY-DAVIDSON®SHOP REPAIR MANUAL, AFTERMARKET
SOURCE UNIT OR SPEAKER MANUAL, ETC.).
QUICK CONNECT SYMBOLS:
KEEP AN EYE OUT FOR THE “QUICK CONNECT” SYMBOLS THROUGHOUT THIS MANUAL; THEY PROVIDE A
VISUAL LINK BETWEEN INSTRUCTIONS, DIAGRAMS, AND THE SYSTEM COMPONENTS.
POWER BATTERY POSITIVE (+12VDC)
GROUND BATTERY NEGATIVE (–), CHASSIS GROUND
REMOTE REMOTE TURN-ON LEAD ACTIVATED BY +12VDC
FUSE ESSENTIAL PROTECTION FROM SHORTS
LINE-IN SOURCE INPUT, LOW LEVEL OR HIGH LEVEL INPUT
SPEAKER TERMINAL BLOCK CONNECTIONS FOR SPEAKER OUTPUT
NOTE: IF ANYTHING ABOUT THE INSTRUCTION OR INFORMATION PROVIDED IN THIS MANUAL IS UNCLEAR, QUESTIONABLE,
OR YOU THINK WE’RE DEAD WRONG ABOUT SOMETHING, PLEASE CONTACT US.

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 5 NEWARK, CA
G
GE ET TT TI IN NG G S ST TA AR RT TE ED D
UNDERSTANDING HOW TO INSTALL AND CONFIGURE YOUR AUDIO EQUIPMENT IS THE KEY TO
MAXIMIZING YOUR SYSTEM’S POTENTIAL. THIS SECTION IS INTENDED TO HELP YOU PREPARE AND
STRATEGIZE YOUR PLAN OF ATTACK BEFORE YOU START CUTTING WIRES.
LOSE THE SPARK
DISCONNECT THE NEGATIVE BATTERY TERMINAL BEFORE DOING ANY
ELECTRICAL WORK ON YOUR MOTORCYCLE. ALWAYS DISCONNECT THE
NEGATIVE (–) BATTERY POST FIRST, FOLLOWED BY THE POSITIVE (+),
AND WHEN IT'S TIME TO GO BACK TOGETHER, CONNECT THE POSITIVE
(+) POST FIRST, FOLLOWED BY THE NEGATIVE (–). THIS CAN MINIMIZE
THE CHANCE OF SPARKS AND VOLTAGE SPIKES, AND IS A GOOD
GENERAL PRACTICE WHEN DEALING WITH ANY DC ELECTRICAL SYSTEM
(CAR, BOAT, MOTORCYCLE, ETC.).
BE WELL GROUNDED
BAD GROUNDS UNDER THE FAIRING HAVE PROVEN TO BE THE NUMBER ONE CAUSE OF PROBLEM
INSTALLS. THE BEST PLACE FOR CONNECTING TO CHASSIS GROUND IS ALWAYS DIRECTLY TO THE
FRAME ON A CLEAN SURFACE FREE OF PAINT, RUST, OR OTHER CONTAMINANTS.
ALWAYS USE THE SHORTEST LENGTH OF GROUND WIRE POSSIBLE BETWEEN CHASSIS GROUND
AND THE AMPLIFIER. NEVER USE A GROUND WIRE LONGER THAN THE ONE WE PROVIDE.
BATWING FAIRINGS, AMONG OTHERS, ARE NOT DIRECTLY MOUNTED TO THE BIKE FRAME, SO YOU
MUST RUN THE GROUND WIRE BACK THROUGH THE FAIRING TO THE FRAME.
THE GROUND WIRE AND POWER WIRE ARE EQUALLY IMPORTANT; IF EITHER ONE OF THEM IS
COMPROMISED, THE AMPLIFIER’S PERFORMANCE WILL DEGRADE OR CEASE TO FUNCTION.
USE PROTECTION EVERY TIME
ALWAYS INSTALL A MASTER FUSE WITHIN 12” OF THE BATTERY FOR ANY ADDITIONAL EQUIPMENT
ADDED TO YOUR MOTORCYCLE’S ELECTRICAL SYSTEM. THE MINI-FUSE INSTALLED ON THE MAIN
AMPLIFIER ONLY PROTECTS THE INTERNAL CIRCUITRY, NOT THE WIRING. IN THE EVENT OF A SHORT,
FAILURE TO INSTALL A FUSE NEAR THE BATTERY CAN CAUSE DAMAGE TO YOUR ELECTRICAL SYSTEM,
OR WORSE YET, THE POSSIBILITY OF FIRE. AND SINCE THE POWER WIRE FOR THE AMPLIFIER RUNS
DIRECTLY BENEATH YOUR GAS TANK, DON’T EVEN THINK ABOUT CUTTING CORNERS HERE.
CHECK YOUR POLARITY
THE WAY SPEAKER WIRES ARE MARKED FOR POLARITY (+/–) VARIES FROM BRAND TO BRAND. RED AND
BLACK COLORED WIRES ARE TYPICALLY POSITIVE (+) AND NEGATIVE (–) RESPECTIVELY, BUT WHEN IT
COMES TO WIRE PAIRS WITH ONE STRIPE, THINGS GET MESSY. SOME MANUFACTURES USE THE STRIPE
AS POSITIVE (+), WHILE OTHERS USE THE STRIPE AS NEGATIVE (–). BE SURE TO CHECK THE
DOCUMENTATION OF EACH COMPONENT YOU'RE DEALING WITH BEFORE MAKING CONNECTIONS.
THINK BEFORE YOU CUT
ALWAYS ROUTE WIRES AND CABLES SAFELY, AVOIDING SHARP EDGES AND BURRS ALONG THE WAY.
USE WIRE LOOM WHEN POSSIBLE. CHECK FOR PROPER LENGTH TO BOTH TERMINATION POINTS,
KNOWING WHERE EACH COMPONENT MOUNTS, BEFORE YOU CUT ANYTHING.
PROTECT THAT PAINT
IF YOU'RE LUCKY ENOUGH TO HAVE FENDER AND TANK COVERS, USE THEM EVERY TIME. IF YOU DON’T,
TOWELS, RAGS, EVEN AN OLD BLANKET WILL DO IN A PINCH. YOU ONLY HAVE TO DROP A TOOL AND
CHIP YOUR PAINT ONCE TO REGRET IT FOREVER.
READY TO GET SERIOUS ABOUT YOUR BIKE’S SOUND SYSTEM? ME TOO, SO HERE WE GO…
RECOMMENDED TOOLS
T-40 TORX®WRENCH
T-20 TORX®WRENCH
7/16" HAND WRENCH
3/16" ALLEN HEX WRENCH
P2 PHILLIPS SCREW DRIVER
WIRE CUTTERS
WIRE STRIPPERS
TERMINAL CRIMPING TOOL

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 6 NEWARK, CA
U
US SE ER R G GU UI ID DE E
CONNECTORS AND CONTROLS
A MAIN POWER TERMINALS B AMPLIFIER PROTECTION FUSE CPOWERINDICATOR
D LOW LEVEL INPUT JACK E LEFT SPEAKER OUT FRIGHTSPEAKEROUT
GETTING FAMILIAR WITH
YOUR SYSTEM CONTROLS IS
CRUSCIAL TO BEING ABLE TO
ENJOY YOUR AUDIO SYSTEM
WHILE KEEP YOUR EYES ON
THE ROAD. THE DRAWINGS
AND TABLE BELOW LISTS
THE CONTROLS AND
CONNECTORS OF THE
HMA150 MEDIA ADAPTER
INTERFACE AND AMPLIFIER
SYSTEM.
NOTE: THE MOUNTING LOACTIONS
OF THE USB AND INPUT
CONNECTORS MAY VARY.
A STATUS LED INDICATOR B POWER ON/OFF PUSHBUTTON
C VOLUME LEVEL ADJUSTMENT D TREBLE LEVEL ADJUSTMENT E BASS LEVEL ADJUSTMENT
F MEDIA DEVICE INPUT JACK G USB CHARGING PORT

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 7 NEWARK, CA
U
US SE ER R G GU UI ID DE E [
[C CO ON NT TI IN NU UE ED D] ]
CONNECTORS DEFINED
MEDIA DEVICE INPUT CONNECTOR:
THIS CONNECTOR ALLOWS THE ADAPTER TO ACCEPT INDUSTRY STANDARD INPUT FROM A MEDIA
PLAYBACK DEVICE OR OTHER PHONO JACK / RCA STYLE AUDIO OUTPUT. SOME EXAMPLES OF
COMPATIBLE MEDIA DEVICES ARE IPODS OR LIKE MP3 PLAYERS, MINI-DISC AND CD PLAYERS, EVEN
AFTERMARKET SOURCE UNITS USING AN RCA TO PHONO JACK ADAPTER.
NOTE: ALTHOUGH WE HIGHLY RECOMMEND USING THE LOW LEVEL INPUT CABLES WE SUPPLY WITH THE KIT,
TECHNICALLY YOU SHOULD BE ABLE TO UTILIZE ANY STANDARD PHONO JACK ADAPTER CABLE FOUND AT YOUR
LOCAL ELECTRONIC STORE TO MAKE THIS CONNECTION. IT’S OUR GOAL TO KEEP THINGS SIMPLE AND STANDARD IF
AT ALL POSSIBLE.
USB CHARGING CONNECTOR(S):
THIS CONNECTOR ALLOWS FOR DEVICE CHARGING THOUGH AN INDUSTRY STANDARD USB
CONECTION CABLE. SOME EXAMPLES OF COMPATIBLE DEVICES TO BE CHARGED ARE IPODS OR
LIKE MP3 PLAYERS, MINI-DISC AND CD PLAYERS, CELL PHONES, PDA OR OTHER COMPUTING
DEVICES, DIGITAL CAMERAS, ETC. A +5VDC CHARGING CIRCUIT PROVIDES POWER AS LONG AS THE
BIKES CHARGING SYSTEM PROVIDES AT LEAST +12VDC. IF THE BIKES CHARGING SYSTEM DROPS
BELOW +12VDC, THE CHARGING CIRCUIT IS SHUT DOWN TO AVOID A DEAD BATTERY SITUATION.
TIP: THE USB CHARGING CONNECTOR CAN BE ADAPTED FROM DIFFERENT STYLE USB CONNECTORS USING INDUSTRY
STANDARD USB ADAPTERS. IF YOU CAN CONNECT YOUR DEVICE TO A USB CONNECTOR ON YOUR COMPUTER, THEN
YOU SHOULD BE ABLE TO CHARGE IT WITH THIS ADAPTER.
CONTROLS DEFINED
POWER SWITCH:
THIS SWITCH TURNS THE MEDIA ADAPTER ON AND OFF. THERE ARE VARIOUS MODES OF OPERATION
IN BOTH THE ON POSITION (IN) AND OFF POSITION (OUT), INDICATED BY THE STATE OF THE LED.
OPERATION MODES ARE AS FOLLOWS:
HARLEY MEDIA ADAPTER MODES OF OPERATION
LED POWER AUDIO USB CHARGE BATTERY CONDITION MODE
ON / OFF
(IN / OUT) OFF DISABLED LESS THAN +12VDC LOW BATTERY SHUTDOWN
OFF
(OUT) OFF ENABLED MORE THAN +12VDC STAND-BY CHARGING
ON
(IN) ON ENABLED MORE THAN +12VDC
LESS THAN +13VDC
POWERED ON
TIMED OPERATION
(30 MINUTES)
ON
(IN) ON ENABLED MORE THAN +13VDC POWERED ON FULL FUNCTION
VOLUME ADJUSTMENT:
THIS CONTROLS THE OVERALL VOLUME OF THE AUDIO SYSTEM. KEEP IN MIND THAT MOST MEDIA
PLAYERS WILL HAVE THEIR OWN VOLUME SETTING, AND SHOULD BE ADJUSTED SO THAT MAXIMUM
VOLUME CAN BE ACHIEVED WITHOUT CAUSING SPEAKER DISTORTION.
BASS / TREBLE ADJUSTMENT:
THESE CONTROLS ADJUST THE TONAL CHARACHTERISTICS OF THE AUDIO PLAYBACK. ALWAYS
ADJUST THEM WITHIN A RANGE THAT DOES NOT CAUSE SPEAKER DISTORTION.

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 8 NEWARK, CA
U
US SE ER R G GU UI ID DE E [
[C CO ON NT TI IN NU UE ED D] ]
TROUBLESHOOTING
INFRACTION PROBABLE CAUSE RESTITUTION
MAIN AMPLIFIER DOESN’T
POWER UP (LED IS OFF)
REM WIRE IS NOT GETTING +12V
TO THE AMPLIFIER
CHECK YOUR WIRING OF THE
REMOTE TURN-ON WIRE. MAKE
SURE THE TURN-ON SOURCE IS
PROVIDING +12V.
PWR WIRE IS NOT GETTING +12V
TO THE AMPLIFIER
CHECK THIS WIRE ALL THE WAY
TO THE BATTERY. MAKE SURE
THE IN-LINE FUSE IS INSTALLED
AND NOT BLOWN.
GND WIRE IS NOT GETTING
GROUND TO THE AMPLIFIER
MAKE SURE THE GROUND
LOCATION SELECTED IS
PROVIDING A GOOD, CLEAN
CHASSIS GROUND.
AMPLIFIER(S) POWER UP, BUT
MAKE NO SOUND (LED IS ON)
SPEAKER WIRES ARE NOT
CONNECTED OR SHORTED
CHECK YOUR WIRING FROM THE
AMPLIFIERS TO EACH SPEAKER
IN THE SYSTEM. MAKE SURE
THAT THE WIRE TERMINALS ARE
NOT SHORTING TO THE BIKE
CHASSIS OR OTHER WIRES.
INPUT FROM SOURCE UNIT NOT
CONNECTED PROPERLY
CHECK YOUR LOW LEVEL INPUT
WIRING FROM THE SOURCE UNIT
TO THE MAIN AMPLIFIER.
SOURCE UNIT HAS NO OUTPUT CHECK THAT YOUR SOURCE UNIT
IS FUNCTIONING PROPERLY.
REFER TO MANUFACTURER
INSTRUCTIONS IF NECESSARY.
SPEAKER OUTPUT SOUNDS LOW
OR DISTORTED
SOURCE UNIT VOLUME SET TOO
LOW OR TOO HIGH
SET THE VOLUME LEVEL OF THE
ATTACHED MEDIA DEVICE TO AN
APPROPRIATE LEVEL TO STOP
THE DISTORTION OR INCREASE A
LOW VOLUME SITUATION.
LOW BATTERY CONDITION CHECK YOUR BATTERY FOR
PROPER CHARGE AND REPLACE
IF NECESSARY.

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 9 NEWARK, CA
S
SP PE EC CI IF FI IC CA AT TI IO ON NS S
HW1202C
INPUT CHANNELS: ........................................................................................................ 2 LOW LEVEL
OUTPUT CHANNELS: ......................................................................................................2 CHANNELS
NOMINAL OUTPUT IMPEDANCE: ..............................................................................................4 OHMS
NOMINAL POWER OUTPUT (WATTS RMS): ................................................................120 (2 X 60) WATTS
FREQUENCY RESPONSE: ................................................................................................ 10HZ-50KHZ
LOW LEVEL (RCA LINE-IN) SENSITIVITY:............................................................................. 200MV – 6V
INPUT IMPEDANCE: ........................................................................................................... 33K OHMS
CASE DIMENSIONS
MAIN AMPLIFIER: ................................................................................... 6.50” W X 3.75” D X 1.50” H
OUR AMPLIFIER TECHNOLOGY FEATURES CLASS-T®DIGITAL AMPLIFIERS BY TRIPATH
UNCOMPROMISED SOUND QUALITY TYPICALLY:.............................................0.010% THD+N @ 60W 4Ω
DYNAMIC RANGE = 103DB
OVER-CURRENT AND OVER-TEMPERATURE PROTECTION, TURN-ON AND TURN-OFF POP SUPPRESSION
CONFORMAL COATED WEATHERPROOF PRINTED CIRCUIT BOARD(S)
HMA150
INPUT CHANNELS: ........................................................................................................ 2 LOW LEVEL
OUTPUT CHANNELS: ..................................................................................................... 2 LOW LEVEL
USB DEVICE CHARGING:............................................................................................... +5V @ 500MA
POWER ON FULL FUNCTION: ............................................................................................ >= +13VDC
POWER ON TIMED OPERATION:.......................................................................... > +12VDC, < +13VDC
POWER OFF SHUTDOWN: ................................................................................................... > +12VDC
BASS ADJUSTMENT (TYPICAL):............................................................................................... ± 15DB
TREBLE ADJUSTMENT (TYPICAL): ............................................................................................ ± 15DB
SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT NOTICE

HMA150 HARLEY MEDIA ADAPTER INSTALLATION GUIDE
HAWG WIRED PAGE 10 NEWARK, CA
W
WA AR RR RA AN NT TY Y I IN NF FO OR RM MA AT TI IO ON N
HAWG WIRED OFFERS A LIMITED WARRANTY OF OUR PRODUCTS ON THE FOLLOWING TERMS:
• LENGTH OF WARRANTY
1 YEAR ON AUDIO SYSTEMS, ELECTRONICS, SPEAKERS, AND ACCESSORIES (RECEIPT REQUIRED).
• COVERAGE
THIS WARRANTY COVERS ONLY THE ORIGINAL PURCHASER OF A HAWG WIRED PRODUCT PURCHASED FROM AN AUTHORIZED
HAWG WIRED DEALER IN THE UNITED STATES. IN ORDER TO RECEIVE SERVICE, THE PURCHASER MUST PROVIDE HAWG WIRED
WITH A COPY OF THE RECEIPT STATING THE CUSTOMER NAME, DEALER NAME, PRODUCT PURCHASED AND DATE OF
PURCHASE.
• DEFECTIVE PRODUCTS
PRODUCTS FOUND TO BE DEFECTIVE DURING THE WARRANTY PERIOD WILL BE REPAIRED OR REPLACED (WITH A PRODUCT
DEEMED TO BE EQUIVALENT) AT HAWG WIRED'S DISCRETION.
• WHAT IS NOT COVERED
DAMAGE CAUSED BY ACCIDENT, ABUSE, IMPROPER OPERATIONS, WATER, THEFT
ANY COST OR EXPENSE RELATED TO THE REMOVAL OR REINSTALLATION OF PRODUCT
SERVICE PERFORMED BY ANYONE OTHER THAN AN AUTHORIZED HAWG WIRED SERVICE CENTER
ANY PRODUCT WITH THE SERIAL NUMBER OR TAMPER LABELS DEFACED, ALTERED, OR REMOVED
SUBSEQUENT DAMAGE TO OTHER COMPONENTS
ANY PRODUCT PURCHASED OUTSIDE THE U.S.
ANY PRODUCT NOT PURCHASED FROM AN AUTHORIZED HAWG WIRED DEALER
• LIMIT ON IMPLIED WARRANTIES
ANY IMPLIED WARRANTIES INCLUDING WARRANTIES OF FITNESS FOR USE AND MERCHANTABILITY ARE LIMITED IN DURATION
TO THE PERIOD OF THE EXPRESS WARRANTY SET FORTH ABOVE. SOME STATES DO NOT ALLOW LIMITATIONS ON THE LENGTH
OF AN IMPLIED WARRANTY, SO THIS LIMITATION MAY NOT APPLY. NO PERSON IS AUTHORIZED TO ASSUME FOR HAWG WIRED
ANY OTHER LIABILITY IN CONNECTION WITH THE SALE OF THE PRODUCT.
• HOW TO OBTAIN SERVICE
PLEASE CALL 510.894.2999 FOR HAWG WIRED CUSTOMER SERVICE. YOU MUST OBTAIN A RETURN MATERIAL
AUTHORIZATION NUMBER (RMA) TO RETURN ANY PRODUCT TO HAWG WIRED. YOU ARE RESPONSIBLE FOR SHIPPING
CHARGES OF RETURNED PRODUCTS TO HAWG WIRED.
• MADE IN THE USA
OUR PRODUCTS ARE PROUDLY DESIGNED, DEVELOPED AND BUILT IN THE USA*. THE MAJORITY OF THE COMPONENTS USED
IN THE CONSTRUCTION OF OUR PRODUCTS ARE PRODUCED BY AMERICAN COMPANIES. HOWEVER, DUE TO THE GLOBAL
NATURE OF MODERN MANUFACTURING AND THE ELECTRONICS INDUSTRY IN GENERAL, SOME PARTS MAY BE MANUFACTURED
IN OTHER COUNTRIES.
*OUR SPEAKERS ARE PROUDLY DESIGNED AND DEVELOPED IN THE USA. HOWEVER, DUE TO THE GLOBAL NATURE OF LOUDSPEAKER
MANUFACTURING, OUR SPEAKERS ARE MANUFACTURED IN OTHER COUNTRIES.
H
HA AW WG G W WI IR RE ED D, , I IN NC C. .
C
CO ON NT TA AC CT T U US S B BY Y E EM MA AI IL L
GENERAL INFORMATION – [e-mail]
SALES AND MARKETING – [e-mail]
TECHNICAL SUPPORT – [email protected]
C
CO ON NT TA AC CT T U US S B BY Y P PH HO ON NE E
MAIN 510.894.2999
EFAX 510.217.6994
MON-FRI 9AM–6PM PST
VISIT US ON THE WEB AT HAWG-WIRED.COM
COPYRIGHT © 2008 HAWG WIRED, INC. ALL RIGHTS RESERVED.
REV.1A PRINTED IN THE U.S.A.
