Model 7656WCSM
Eye/face Wash
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
No. 2080083(4)
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any goods,
or part thereof, which shall appear to the Company upon inspection to be of defective
material or not of first class workmanship, provided that claim is made in writing to Haws
within a reasonable period after receipt of the product. Where claims for defects are made,
the defective part or parts shall be delivered to the Company, prepaid, for inspection. HAWS
will not be liable for the cost of repairs, alterations or replacements, or for any expense
connected therewith made by the owner or his agents, except upon written authority from
HAWS, Sparks, Nevada. HAWS will not be liable for any damages caused by defective
materials or poor workmanship, except for replacements, as provided above. Buyer agrees
that Haws has made no other warranties either expressed or implied in addition to those
above stated, except that of title with respect to any of the products or equipment sold
hereunder and that HAWS shall not be liable for gene
ral, special, or consequential
damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED, PROVIDED
OR GIVEN BY HAWS.
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297

10/17 Model 7656WCSM Page 2 of 5
RECOMMENDED TOOLS: Adjustable wrench, pipe wrench, pipe joint sealant, Phillips
screw driver, ¼” hex key wrench.
LOCATION OF UNIT: The Model 7656WCSM eye/face wash should be installed in close
proximity to potential accident areas. It should be clearly identified free from obstructions
and easy to access. See ANSI Z358.1 guidelines for more information.
SUPPLY LINE: The minimum recommended line size is 1/2" IPS with 30-90 psi (2-6 ATM)
flowing pressure at supply inlet. Where sediment or mineral content is a problem, an inlet
filter is recommended.
PLUMBING CONNECTIONS: Inlet supply is male 1/2" IPS; waste is 2” IPS.
INSTALLATION PROCEDURE
Refer to installation drawing for clarification. Check parts list to ensure all required parts are
included.
1.
Install all items at dimensions shown in installation drawing.
2.
Each unit is factory preset to meet the 5 pound (22.2 N) maximum activation force
requirement for disabled persons. If adjustment is required after installation, follow the
adjustment directions below.
a)
Locate the two ball detents, one on each side of the eyewash tray. See installation
drawing.
b)
Using a flat screwdriver, adjust each ball detent to make slight contact with the
eyewash housing just before the ball detent snaps into its locating position on the
housing.
c)
Once both ball detents are adjusted as above, tighten each ball detent ¼ turn.
d)
Using a force gauge, ensure the force required to open the eyewash unit does not
exceed 5 pounds (22.2 N).
CLEANING INSTRUCTIONS FOR STAINLESS BEAD-BLASTED PRODUCTS
Haws recommended cleaning procedure for stainless bead-blasted products is as follows:
1.
Use a stainless steel polish and cleaner for removing stains and finger prints.
2.
Spray cleaner onto stainless surfaces and wipe dry with clean cloth. Cleaned surface
will resist new stains and fingerprints.
INCLUDED PARTS
MODEL PACKAGE
QUANTITY
ITEMS INCLUDED
7656WCSM
1
Mounting Frame/Eyewash assembly
1
Surface Mount Frame
1
Emergency Eyewash Sign
1
Test Tag

10/17 Model 7656WCSM Page 3 of 5
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1.
No flow.
1.
Check the main shut-off valve.
2.
Insufficient water flow at eye/face
wash.
2.
a.
Verify minimum 30 psi flowing supply
line pressure.
b.
Probable clogging of flow control due to
inadequate line flushing. Unscrew
eye/face wash heads and remove the
four screws to disassemble head. Clean
flow control and reassemble head.
c.
Remove cap located on in-line
strainer housing using a ¼” Allen
wrench to access and clean filter
screen. See installation drawing for
location.
3.
Eye/face wash streams do not
meet desired eye level.
3.
a.
Possible blocked flow control, see above
solution.
b.
Possible non-leveled eye/face wash
assembly.
4.
Tray too hard to open or does not
stay closed.
4.
See “Installation Procedure” Step 2.
For more information about Haws products, see our website: www.hawsco.com.
© 2017 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks usedin these materials are the exclusive property of Haws Corporation.

PARTS BREAKDOWN
SEATO-RING O-RING
SECTION A-A
A A 1
2
4
3
1TEST TAG
EYEWASH SIGN
2EYE/FACEWASH HEAD
3VALVE REPAIR KIT
4
APPROVED
DRAWN
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BYECN NO.
PAGE
DATE
DATE
ECN:
REVISED PER
CHKD
Haws Corporation - All Rights Reserved
HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
ITEM DESCRIPTION
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
WHEN ORDERING PARTS PLEASE SPECIFY MODEL NUMBER.
PART NO.
IR
7/13/10
4
0002080083
7656WCSM
.
NA
11
FV 11/23/17
4290
VWC
4 OF 5
PARTS BREAKDOWN
5240
2017
VWC
SP170
SP175
SP65PD
VRK7650

11-1/4"
286mm
14-1/2"
368mm
32-1/2"
826mm
6X Ø3/16" 3
4.8mm
MOUNTING
HOLE
REMOVABLE
ACCESS PANEL
(NOT SHOWN)
3-3/4"
95mm
18-1/2"
470mm
20-5/8"
524mm
FLOOR LINE
15/16"
24mm
SUPPLY
C
L
1/2" IPS SUPPLY
23"
584mm
(47-1/2")
(1207mm)
6-9/16"
167mm 2" NPT
FEMALE OUTLET
1-11/16"
43mm
3"
76mm
6-11/16"
170mm
C
L
11-1/2"
292mm
(34-5/8")
(879mm)
5"
127mm
(29-5/8")
(752mm)
BALL
DETENT
2X
IN-LINE
STRAINER
HOUSING
APPROVED:
DRAWN:
PART NUMBER
SCALE: SHEET OF
REVISION
DRAWING TYPE: SIZE: A
BY:ECN NO.
PAGE
DATE:
DATE:
ECN:
REVISED PER
CHK'D.:
Haws Corporation - All Rights Reserved. HAWS and other trademarks used in these materials are the exclusive property of Haws Corporation.
CR
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
[phone] FAX [phone]
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT IMPROVEMENTS
MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGEWITHOUT NOTICE.
I.ROBERTS 7/13/10
4
0002080083.D
7656WCSM
NA
11
FV 11/23/17
4520
VWC
5 OF 5
INSTALLATION
5240
2017
VWC
PULL DOWN
TO OPEN
EYE/FACE WASH
33"- 53"
838mm-1346mm
FLOW PATTERN
NOTES:
1. WHEN INSTALLING THIS UNIT, LOCAL , STATE, OR FEDERAL CODES SHOULD BE ADHERED TO FOR
INSTALLATION DIMENSIONS (LOCATIONS), WASTE AND SUPPLY REQUIREMENTS OTHER THAN SHOWN.
2. TO COMPLY WITH ANSI Z358.1-2014 FOR EMERGENCY EYEWASH OR EYE/FACE WASH:
EYEWASH OR EYE/FACE WASH SHALL BE POSITIONED SUCH THAT FLUSHING FLUID PATTERN IS
NOT LESS THAN 33" (838mm) AND NO GREATER THAN 53" (1346mm) FROM SURFACE ON WHICH
USER STANDS; AND 6.0" (153mm) MINIMUM FROM WALL OR NEAREST OBSTRUCTION.
3 MOUNTING HARDWARE NOT SUPPLIED.
4. DIMENSIONS MAY VARY BY ±1/2" (13 mm).
