7/23 Model 8606SS Page 1 of 4
0580002176(1)
1455 Kleppe Lane Sparks, NV 89431-6467 (775) 359-4712 Fax (775) 359-7424
E-mail: [email protected]  website: www.hawsco.com
Model 8606SS Dual Entry Stainless Steel
Emergency Shower Booth & Eye/Face Wash Booth
INSTALLATION, OPERATION
&
MAINTENANCE INSTRUCTIONS
INTEL # SSH-4
LIMITED WARRANTY
HAWS warrants that this specific product is guaranteed against defective material or poor
workmanship for a period of one year from date of shipment. HAWS liability under this
warranty shall be discharged by furnishing without charge F.O.B. HAWS Factory any
goods, or part thereof, which shall appear to the Company upon inspection to be of
defective material or not of first class workmanship, provided that claim is made in writing
to Haws within a reasonable period after receipt of the product. Where claims for defects
are made, the defective part or parts shall be delivered to the Company, prepaid, for
inspection. HAWS will not be liable for the cost of repairs, alterations or replacements, or
for any expense connected therewith made by the owner or his agents, except upon
written authority from HAWS, Sparks, Nevada. HAWS will not be liable for any damages
caused by defective materials or poor workmanship, except for replacements, as provided
above. Buyer agrees that Haws has made no other warranties either expressed or implied
in addition to those above stated, except that of title with respect to any of the products or
equipment sold hereunder and that HAWS shall not be liable for general, special, or
consequential damages claimed to arise under the contract of sale.
The emergency equipment manufactured by HAWS is warranted to function if installation
and maintenance instructions provided are adhered to. The units also must be used for the
purpose for which they were intended. This product is intended to supplement first-aid
treatment. Due to widely varying conditions, Haws cannot guarantee that the use of this
emergency equipment will prevent serious injury or the aggravation of existing or prior
injuries.
NO OTHER WARRANTIES EXPRESSED OR IMPLIED ARE AUTHORIZED,
PROVIDED OR GIVEN BY HAWS.
SHOULD YOU EXPERIENCE DIFFICULTY WITH THE INSTALLATION OF THIS
MODEL, PLEASE CALL:
TECHNICAL SUPPORT: 1-800-766-5612
FOR CUSTOMER SERVICE: 1-888-640-4297
NOTE TO INSTALLER: Please leave this information with the Maintenance Department.
7/23 Model 8606SS Page 2 of 4
LOCATION OF UNIT: The Model 8606SS Emergency Shower & Eye/Face Wash Booth
should be installed in close proximity to potential accident areas. It should be clearly
identified free from obstructions and easy to access.
SUPPLY LINE: The minimum recommended line size is 1” IPS with 30-90 psi (2-6 ATM)
flowing pressure. Where sediment or mineral content is a problem, an inlet filter is
recommended.
PLUMBING CONNECTIONS: Inlet supply is female 1” NPT. Waste outlet is 4” NPT (F).
TROUBLESHOOTING
PROBLEM
REPAIR CHECKLIST
1. No flow. 1. Check the main shut-off valve.
2. Insufficient water flow. 2. Verify minimum 30psi (2 ATM) flowing
supply line pressure.
3. Insufficient water flow on
eyewash, however, shower is
sufficient.
3. Probable clogging of flow control due
to inadequate line flushing. Unscrew
eye/face wash head and remove the
four screws to disassemble the head.
Clean flow control and reassemble
head. See SP65 Installation Drawing
for details.
4. Insufficient water flow at the
showerhead, however, eyewash
is sufficient.
4. Probable clogging of flow control inside
showerhead. Unscrew showerhead off
of elbow and clean rubber flow control.
5. Eyewash stream does not meet
desired eye level.
5. Possible blocked flow control, see
above solution. Possible non-leveled
eyewash assembly.
6. Water does not drain properly. 6. Check the main waste line of your
building to see if it does handle the
capacity required for the entire
drainage system.
For more information on Haws products, see our website: www.hawsco.com
© 2023 Haws®Corporation – All Rights Reserved
HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
4
5
2
1
3
7
6
CURTAIN, ITEM 8
(NOT SHOWN FOR CLARITY)
ITEM
DESCRIPTION
PART NO.
1
EYE/FACE WASH ASSEMBLY
SP65SS
2
VALVE REPAIR KIT
VRK 7650
3
PULL ROD
SP202
4
SHOWER/EYEWASH SIGN
SP178
5
TEST TAG
SP170
6
SHOWER HEAD
SP829SS
7
SHOWER VALVE ASSEMBLY
0006581890
8
SHOWER CURTAIN
0510002178
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT
IMPROVEMENTS MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
REVISION
IR
07/11/23
1
8606SS DUAL ENTRY SST BOOTH
1:50
IR
07/13/23
DRAWING TYPE:
SIZE: A
5940
BY:
SLS
PARTS BREAKDOWN
DATE:
DATE:
REV. ECN:
5940
CHK'D.:
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
IR
ECN:
WHEN ORDERING PARTS, PLEASE
SPECIFY PART NUMBER
SHEET 1 OF 1
0580002176
© 2023 Haws Corporation - All Rights Reserved.
HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
PAGE 3 OF 4
79"
2007mm
33 1/2"
848mm
19 1/2"
492mm
19 1/2"
492mm
16 3/4"
424mm
12 1/2"
320mm
B
B
4" NPT(F) WASTE
DRAIN COUPLING
1" NPT(F) INLET
(BOTTOM)
INSTALL SHOWER
CURTAIN TO GUIDE
ONE PER ENTRY
EYE/FACE WASH
ASSEMBLY
1" NPT(F) INLET
(TOP)
A
36 3/4"
931mm
30 1/4"
768mm
40 1/2"
1026mm
38 3/4"
984mm
DETAIL A
4X 1/2" ANCHOR
BOLT ASSEMBLY
82 3/4"
2102mm
61 1/2"
1559mm
87 1/4"
2215mm
42 1/2"
1078mm
SECTION B-B
NOTES:
1. WHEN INSTALLING THIS UNIT, LOCAL, STATE, OR FEDERAL CODES SHOULD
BE ADHERED TO FOR INSTALLATIONS (LOCATIONS), WASTE AND SUPPLY
REQUIREMENTS OTHER THAN SHOWN.
2. KEEP BOTH ENTRY WAYS AND INSIDE OF BOOTH CLEAR OF OBSTRUCTIONS.
3. DIMENSION MAY VARY ±1/2".
© 2023 Haws Corporation - All Rights Reserved. HAWS® and other trademarks used in these materials are the exclusive property of Haws Corporation.
THIS DOCUMENT IS TRUE AND CORRECT AT TIME OF PUBLICATION. CONTINUED PRODUCT
IMPROVEMENTS MAKE SPECIFICATIONS AND MEASUREMENTS SUBJECT TO CHANGE WITHOUT NOTICE.
APPROVED:
DRAWN:
PART NUMBER
SCALE:
REVISION
IR
07/11/23
1
1:50
IR
07/19/23
DRAWING TYPE:
SIZE: A
5940
BY:
SLS
INSTALLATION
DATE:
DATE:
REV. ECN:
5940
CHK'D.:
MODEL(S)
1455 KLEPPE LANE
SPARKS, NEVADA 89431
(775) 359-4712 FAX (775) 359-7424
E-MAIL: [email protected]
WEBSITE: WWW.HAWSCO.COM
IR
ECN:
SHEET 1 OF 1
0580002176.D
8606SS DUAL ENTRY SST BOOTH
PAGE 4 OF 4
