Healbe GoBe3 User manual

| SMART BAND |

READ THROUGH THIS USER GUIDE
CAREFULLY BEFORE YOU START USING GoBe3
WHAT IS GoBe3?
HEALBE GoBe3 is the new version of a unique smart band featuring an automatic calorie
intake counter and water balance tracker. No need to keep a food diary anymore. Just put
GoBe3 on your wrist and track calorie intake directly in your mobile app.
GoBe3 AUTOMATICALLY COUNTS AND TRACKS:
An independent study by the University of California, Davis, and Guangzhou Red Cross
Hospital has shown that GoBe is able to gather calorie intake information with up to 90%
accuracy compared to reference values. Such accuracy can be achieved by wearing the band
all day long (22–23 hours a day), keeping the band on during meals and for three to four
hours after food intake.
However, pulse, stress, water balance, and other measurements remain accurate even when
the band is worn for less than 22 hours a day.
Weight dynamics
tracking Data syncing with
Apple Health/Google Fit
Weight goals
management
THE HEALBE APP ALSO FEATURES:
Water balance
Energy balance
(caloric balance)
Calorie intake
Stress level
Calories burned
Steps and distance walked Constant day and night pulse
Night sleep quality and duration
CONFIGURATION AND COMPONENTS
Bioimpedance
sensor titanium
contacts
Band pin
Free loop
Display:
Left
touchscreen
area
Right
touchscreen
area
Optical sensor
Charging socket
Lever Lug screw pin
Band
attachment
2 3

PACKAGE CONTENTS
2. USB charging cable1. HEALBE GoBe3 smart band
with strap
3. User guide
SETUP
GoBe3 can only be activated and made fully functional by using iOS 10 (or higher) or Android
5.0 (or higher). Your mobile device must also support Bluetooth® Low Energy (Bluetooth LE)
technology.
BEFORE YOU START USING THE HEALBE GoBe3 BAND
To start using GoBe3, you should install the latest updates for the HEALBE application on your
device. If you already have the HEALBE app installed on your phone, just update it to the
latest version and go to the “Getting started with HEALBE GoBe3” section of the current
manual.
DOWNLOAD AND INSTALL ON YOUR SMARTPHONE THE HEALBE APP FOR
IOS/ANDROID. Type “HEALBE” into the search bar of your preferred app store or open your
phone’s camera application and focus it on the QR-code of the chosen application store
below:
1
CREATE A HEALBE ACCOUNT IN THE APP.
Once you have specied your data during registration, the HEALBE app calculates other
important parameters automatically: average step length, glass volume of the drink
notication, and comfortable sleep duration.
However, we recommend changing the default values in these elds to your own ones in the
User prole and GoBe menu to ne-tune the band and achieve the best results.
GoBe uses this data to adapt to the individual parameters of the current user, thus making all
the inner algorithms personal and more accurate.
GETTING STARTED WITH HEALBE GoBe3
Before activating GoBe3 for the rst time:
1. Peel o all the protective lms from the display and optical sensor on the back of the
band;
2. Without touching the display with spirit, wipe all external surfaces with an alcohol pad or
alcohol tissue;
3. The band’s display can be cleaned with a dry cotton pad or a soft natural cloth.
Attention! The band is supplied uncharged. Connect the band to a power source using the
charging cable, and it will turn on and start working automatically upon reaching a sucient
battery level.
2
CONNECT GoBe3 TO A POWER SOURCE TO TURN IT ON AND ACTIVATE IT:
1. Connect the charging cable to GoBe3: carefully pull out
the charging socket plug located on the band’s rear side and
push the cable until it stops. While plugging in the cable, make
sure that the logo is directed towards the sensors;
2. Connect the charging cable to the USB interface of your PC
or mains adapter and turn on the power source;
3. Wait until the GoBe3’s display shows the welcome screen with
a message that the device is ready to connect to the app.
3
or
4 5

ACTIVATE GoBe3 AND SET UP A CONNECTION USING THE MOBILE APP:
Warning!
The initial installation of updates may take up to one hour. We recommend combining this
process with charging the device.
4
1. Make sure that your smartphone’s Bluetoothе ( ) is
turned on (Settings Bluetooth);
2. Open the HEALBE mobile app on your smartphone;
3. Connect GoBe3 using the HEALBE app, placing your
phone no further than 35 inches (90 cm) from the band;
4. Follow the instructions in mobile app;
5. Wait for the automatic setup process to be completed.
Your GoBe3 rmware will be updated during setup.
WAIT UNTIL GoBe3’s INTERNAL BATTERY IS FULLY CHARGED:
1. Leave GoBe3 connected to a power source. When the band is fully charged, you can see
the message that the battery is fully charged. This process normally takes no more than two
hours;
2. Unplug the USB cable from the power source and then unplug it from GoBe3 and close
the charging socket’s plug on the rear side of the band.
5
6THE DEVICE IS READY TO WORK.
Put the band on your arm and fasten the strap so that the band’s sensors are rmly against
your skin but not too tight. This will maximize the device’s accuracy and keep you
comfortable at the same time.
HERE ARE SOME RECOMMENDATIONS THAT WILL IMPROVE YOUR GoBe3 EXPERIENCE:
When starting to use GoBe3, make sure it is turned on and ready to work. The display should
show the current time.
Wear the band on your arm without taking it o. It is important to wear the band throughout
most of the day (22–23 hours a day) in order to give it the opportunity to perform the most
accurate calculation of daily calorie intake and calories burned. If you cannot wear the band
permanently, it will aect all the measurements one or another way, but the accuracy of the
Energy balance will be one of the most severely aected.
The main measurement parameters and results are shown on the band display. A more
detailed analysis of your body’s state is available on the HEALBE mobile app.
We recommend charging the band after a night sleep and always before breakfast, for
example, when taking a shower.
In order not to forget the band at home while charging, put an important object nearby,
which will guarantee that you see the band too: house or car keys, travel card, work pass,
wallet, mobile phone.
Warning!
When the GoBe3 is in the state of waiting for the application to connect (this is indicated by
the word "WELCOME" or“PENDING”on the screen), the band automatically enters the power
saving mode following eight minutes of inactivity.
In the Power save mode, the GoBe will not be available for connection via the mobile
application. To set the device to normal mode, tap and hold your finger anywhere on the
«POWER SAVE» screen until it switches back to the "WELCOME" (or “PENDING”) state, and
then connect to the smart band via the HEALBE application.
8minutes
6 7

After the band is paired in the HEALBE app during the rst connection, GoBe3 connects and
syncs data automatically when the app starts up.
There is no need to keep your Bluetooth turned on all the time for the band to work. GoBe3
performs all the functions autonomously, and you only need Bluetooth enabled for
synchronization (transferring data from the smart band to the app). Rare data
synchronization saves the band’s battery power.
Place the band no further than 35 inches (90 cm) from your mobile phone. This will ensure a
stable connection.
We recommend weighing yourself regularly and updating your weight data in the app at
least two to three times a week. This signicantly increases the accuracy of HEALBE’s
algorithms.
GoBe3 turns on automatically if the internal battery level is sucient. To turn the device on,
charge the device. GoBe3 will turn on automatically while charging.
If you feel uncomfortable wearing the band, you can put it on the other hand. Changing
hands frequently is not recommended, as it takes some time for the band to adjust itself
afterward.
The experience of many users has shown that after some time the hand gets used to the
feeling of the band on the wrist and this feeling almost disappears. Usually, this period lasts
from one to two weeks.
After you put the band on, its sensors need from ten seconds to two minutes to adapt to
interaction with your body. If, for some reason, the sensors are unable to make contact with
your skin during the rst minute of usage, GoBe3’s screen will display a corresponding
message.
To speed up the GoBe3 calibration, you can gently moisturize the skin under the band with
plain water or breathe into the space between the sensors and your hand.
SCREEN UNLOCK
To unlock the GoBe, touch the display and hold your nger until the backlight turns on and
the band vibrates briey, and then remove your nger.
If the unlock is successful, the band vibrates for a second time and the Home screen is
displayed on the screen.
If you leave your nger on the screen for too long, the band does not unlock its sensor. In this
case, the GoBe3 does not vibrate for a second time and the backlight turns o.
After eight seconds of inactivity, the screen locks: the display turns o and the device no
longer responds to single taps or swipes.
USING THE GoBe3
GESTURES GoBe3
To interact with HEALBE GoBe3, please use the following gestures:
Left tap - touch the left part of the screen and release
Right tap - touch the right part of the screen and release
Double tap - touch any part of the screen twice in rapid
succession
8 9

AFTER THE FIRMWARE UPDATE IS INSTALLED
Now you can use gestures to access all the main screens and features:
Home screen
Measurement screens
Notications menu
Do Not Disturb mode conguration
The Home screen is the main screen of GoBe3. It provides access to all
features of the device.
HOME SCREEN
Left swipe - touch the right part of the screen and drag
your nger across the screen to the left
Right swipe - touch the left part of the screen and drag
your nger across the screen to the right
Long press - touch the screen and hold until it
responds
MEASUREMENT SCREENS
With the Measurement screens, you can constantly keep track of all the important
measurements that GoBe captures during the day. Energy balance, Activity, Stress,
Night sleep, Water balance, and Pulse measurements are all at the tips of your ngers.
DO NOT DISTURB
After turning on the Do Not Disturb mode, the device does not react to notications: the
backlight doesn’t turn on, the band doesn’t vibrate, and the Current notications screen is
not shown. These restrictions include all the notications: hydration reminders, stress level
spike notications, low-battery, skin contact warnings, and so on.
All the notications which are not shown during the Do Not Disturb mode are stacked in
the GoBe’s Last notications section.
Important!
Smart wake-up alarms, pre-set in the app, are always accompanied by vibration, regardless
of the Do Not Disturb mode.
WATCH ONLY MODE
GoBe3 switches to the Watch only mode after the battery charge level
drops lower than 5%. In this mode, GoBe stops gathering
measurements and passing data, does not react to gestures, and is not
available for connection with the HEALBE mobile app.
Plug in the battery charger and wait until the device is charged to
continue using it. After reaching enough battery charge, GoBe
switches to normal mode.
10 11

CHARGING THE DEVICE
1. Connect the charging cable to GoBe3: Carefully pull out the charging socket plug located
on the band’s rear side, nd the logo on the cable and turn it towards the sensors, then insert
the cable until it stops;
2. Connect the charging cable to a USB port on your PC or mains adapter and turn on the
power source;
3. Wait until the GoBe3 display shows the screen with a notication that the charging
process has started;
4. Leave GoBe3 connected to the power source until the display shows the screen with a
message that the battery is completely charged;
5. Unplug the charging cable from the power source and then unplug it from the band;
6. Close the charging socket plug on the rear side of the band;
7. GoBe3 is ready to work. You can start using it.
ADVICE ON CHARGING THE DEVICE
Before charging GoBe3, make sure that the contacts on the band and charging cable are
clean and dry.
You can set your band’s charging schedule at your own convenience. GoBe3’s charge cycle
should be done once a day for two hours or two times a day for an hour each.
You can always buy a charging cable on our website: healbe.com/store.
We recommend charging your GoBe3 in the morning after waking up and before breakfast,
for a good opportunity to wear the band at least 30 minutes before your rst meal. In this
case, the estimated calorie level will be the most accurate.
We recommend manipulating the power socket plug carefully. If the plug is broken or lost,
the device may malfunction and the charging process may fail.
GoBe3 SYNCHRONIZATION
WITH HEALBE MOBILE APPLICATION
The GoBe3 performs measurements and stores the results throughout the entire time of
wearing, even if it is not connected to the HEALBE application on your smartphone. When
12 13
Data synchronization starts automatically when the app opens.
While the device syncs, make sure both the mobile phone and the band are no further than
35 inches (90 cm) apart to provide a stable connection.
Synchronize your GoBe3 with the HEALBE app at least two to three times a day. By doing so,
all the data will be saved and the sync will take less time.
If GoBe3 hasn’t synced with the app for several days, the next synchronization will take more
time than usual.
Warning! GoBe3 keeps unsynchronized data for ve days.
Data stored on the band for more than ve days will begin to be erased if you connect the
GoBe3 to the application less often than every ve days.
This only happens if you do not synchronize and continue wearing the band.
If you have problems syncing your device, please contact the HEALBE client support service
by sending an email to [email protected].
SKIN SENSITIVITY
We do not recommend applying moisturizing creams, cosmetics, or oils to the skin under
the sensors.
After working out or spending time in water, wipe and dry the rear surface of the band that
comes in contact with the skin, as well as your wrist, to avoid irritation from accumulated
moisture.
We do not recommend wearing the band if the skin zone under the sensor is marked by
tattoos, scars, inammatory changes, or other severe skin surface damage. All of these
factors may lead to skin irritation or allergic reactions.
Skin irritation may also be caused by an allergic reaction to the band’s materials. A full list of
materials in contact with the skin can be found on our website under the “Materials,
Contraindications & Allergies” section (healbe.com/manual-gobe3).
the band is connected to the app, it synchronizes, which means the data are being
transferred from the band to the phone.

Healbe
STAY UP-TO-DATE WITH OUR NEWS
ON OUR BLOG AND SOCIAL MEDIA:
Healbe | @myhealbe
healbe.com/blog
@healbe
WATER PROTECTION AND OPERATIONAL CONDITIONS
The GoBe3 is splash-resistant but not waterproof. This means that you can use the band in
the shower, in the rain, or during intensive workouts, but you can't submerge the device
under water.
If you use the smart band in high-humidity conditions or in contact with water, make sure
that the charging socket plug is closed. When the contact with water is over, wipe the band
with a dry towel or cloth and dry it out.
The band's case protection gets worse over time – this is a natural process. To keep your
GoBe3 protected from moisture and other external impacts for as long as possible, we
recommend the following:
Try not to drop the GoBe3 or expose it to other heavy mechanical impacts.
Do not expose the GoBe3 to prolonged contact with soapy water.
Do not let active substances come into contact with parts of the smart band: acids, solvents,
concentrated detergents, repellents, hair dyes, and so on.
Do not let the GoBe3 contact with seawater or salted water. If the band gets exposed to
seawater, be sure to wash all its surfaces with plain water and dry it with a cloth or cotton
swab as soon as possible.
Take o the band before going to the sauna or bath.
Do not leave GoBe3 near heaters, heat sources, in the cold or under direct sunlight for a long
time. It is also not recommended to expose the band to sudden changes in temperature.
ADDITIONAL INFORMATION
BATTERY
Internal battery capacity: 350 mAh.
Battery life: up to 32 hours.
LONG-TERM STORAGE
We do not recommend storing the device with a completely uncharged battery. If you realize you
are not going to use the band for a long period of time, please contact HEALBE Customer Care
team for instructions on how to switch to long-term storage mode at [email protected].
ACCESSORIES
You can always buy additional accessories on our website: healbe.com/store.
WARRANTY SERVICE
Our goal is to make your GoBe3 usage experience pleasant and easy.
You can return the band within 30 days from the date of purchase. Warranty service is available
for 12 months.
We welcome any feedback or suggestions that can help us make our product better.
If you have any questions about GoBe3, you can send us an email at [email protected].
UPDATES AND NEWS
Please update the band rmware and mobile app regularly. This will help to extend battery life,
improve the accuracy of measurements, and enhance usability.
14 15

REGULATORY INFORMATION AND LIST OF CERTIFICATES
The list of certicates is accessed dierently in the Welcome/Pending mode, rather than in
the Regular Operation mode when the band has already been paired with a mobile phone
and updated.
TO SEE THE LIST OF CERTIFICATES:
1. In Welcome / Pending mode – swipe right.
2. In the Regular operation mode – tap and hold the screen to unlock the device (see the
“Screen unlock”section of the current manual), go to the Notications menu, and long-press
the left part of the No notications* screen.
* The list of certicates is only available when in the Last notications GoBe menu section is
empty. If there are notications stacked in the Last notications section, clear them to go to
the No notications screen.
COMMUNICATIONS:
Bluetooth 4.2 BR/EDR and BLE, frequency band: 2402–2480 MHz.
WiFi: IEEE 802.11 b/g/n, frequency band: 2412–2484 MHz.
RF power: 0dBm
CERTIFICATES:
• SRRC
• CE
• EAC
IF YOU HAVE ANY QUESTIONS
For more information and a full list of GoBe3 screens, as well as for help
with navigation in the band menu, please visit healbe.com
or ask a question at [email protected].
• JRL
• CEC
• Prop65
16
