Healthcraft Invisia WTRH-CRP User manual

Page 1 of 4
www.ActiveForever.com
Invisia™Wall Toilet Roll Holder
Installation Instructions:
WTRH-CRP / WTRH-PCW
-Wood studs.
-Adequate wood structural backing.
-No aligning structural wood studs.
-Suitably strong structural wall board.
#10 x 2" S/S
Screw and Lock
Washer
#10 x 2" S/S Bolt
with SnapToggle®
toggle bolts
STRUCTURE BEHIND WALL
(Wall Surface: Tile on 1/2" min cement board)
FASTENER
COMBINATION
THANK YOU...
Thank you for purchasing the Invisia™ Wall Toilet Roll Holder.
We are confident that you will find the unique design and
durable construction of this product to be of great assistance
in your daily routine.
To fully enjoy your Invisia™ Wall Toilet Roll Holder, please
take a few moments to read these instructions. You should
store these instructions in a safe place for future reference.
SAFETY CONSIDERATIONS
CAUTION: It is your responsibility to see that your Invisia™
Wall Toilet Roll Holder is properly assembled, installed, and
cared for. Failure to follow instructions in this manual could
result in serious injury. Support rails can be slippery when wet
- use this product with caution.
INVISIA™ WALL TRH INSTALLATION
The Invisia™ Wall Toilet Roll Holder should only be installed in
areas where the mounting surface is structurally sound.
Strengthening modifications may be required (see page 3 for
details). Should not be installed in fiberglass / acrylic bathroom
enclosures with insufficient stiffness and strength. Should not
be installed into metal studs. If you are not equipped to
undertake the outlined work we recommend that you have your
Invisia™ Wall Toilet Roll Holder installed by a qualified
contractor. Suggested maximum user weight of support rail is
350lbs/159kg, however this rating is conditional upon suitable
fasteners and supporting surface. Tray / paper holder are not a
weight bearing surface.
WARRANTY
All HealthCraft™ Products are covered by a one year limited
warranty with the exception of hand grips which are subject to
normal wear. Buyer hereby indemnifies, agrees to hold
harmless and defend HealthCraft™ Products Inc. from and
against any and all liabilities, claims, (founded and
unfounded), losses, damages, costs and expenses (including
without limitation consequential damages and reasonable
professional fees) resulting from buyers specification,
application, or improper use of goods described hereon;
buyers omission or neglect.
HealthCraft™ Products Inc. does not assume any liability for
damage resulting from services performed by others or faulty
installation, misuse or misapplication of goods sold by
HealthCraft™ Products Inc.
HealthCraft™ Products Inc. shall not be liable for prospective
profits or special, indirect, or consequential damages, or for
the cost of any corrective work done without HealthCraft™
Products Inc. prior approval. HealthCraft™ Products Inc. total
liability hereunder shall in no event exceed the purchase price
of the goods specified hereon.
TOOLS REQUIRED
• Level • Personal Protective Eyewear
• Hammer • Carbide tip drill suitable for tile
• Stud Finder • Protective blanket
• Center Punch
FASTENERS: INSTALLATION & MAINTENANCE
The Invisia™ Wall Toilet Roll Holder must be secured to the
wall with fasteners appropriate to the structural material.
Inspect, or have inspected (and tighten if necessary) the
screws on a monthly basis. Included are 2 sets of mounting
hardware for different wall applications.
For tile walls judged to be suitably strong, for moderate
support weight bearing applications, you may choose to use
the supplied SnapToggle® toggle bolts without reinforcing
structural improvement. If possible, line up the center hole of
the wall plate with a wood stud.
If you are using fasteners other than the ones supplied, we do
not recommend flat head style screws (i.e. a screw that
requires a countersunk hole). We recommend stainless steel
fasteners / lock washers (to prevent rusting). Also, residue
from steel drill bits and other non-stainless steel tools may
cause rust stains. Properly clean metal chips, debris etc. prior
to exposing to water.
TIPS FOR DRILLING INTO TILE
•Use carbide tipped masonry drill on ceramic, or consider a
diamond tip drill for porcelain tile.
• If possible, drill a smaller pilot hole first.
•Be careful to prevent the drill from moving when you first
start it rotating - use duct tape or a wood guide on the
surface of the tile to hold the drill from walking sideways.
•A variable speed drill on slow is best to start the hole. Do
not apply too much pressure when drilling. Do not use a
hammer drill.
WATERPROOFING
We recommend that sealant be applied around the wall
contact points for any products mounted in the shower. If not
properly sealed, there is the potential for water to seep into the
wall. This may cause the wood to rot, thus compromising the
structure the support rail is attached to.
CORIAN: CLEANING AND MAINTENANCE
The Invisia™ Collection features several tray surfaces made
from Dupont’s Corian® material. It is a very durable,
non-porous material that resists the growth of bacteria. Clean
with general household cleaners. The surfaces & edges can
be sanded and buffed to repair if necessary.

Page 2 of 4
Figure 4.
Figure 1.
WOOD
STUD
PLASTIC
RETAINER
WASHER
SNAP
CAP
MOUNTING LOCATION
We strongly recommend that you give some thought as to
the optimal location of your Invisia™ Wall Toilet Roll
Holder before installation. The following suggestions are
offered for your consideration, however, it is
recommended to consider advice from the appropriate
healthcare professional for locating any support rail.
To determine the optimal location, we recommend holding
the rail in place and walking through the motions of a
transfer (sitting, standing, reaching, etc.). Consider the
following when determining the optimal mounting
location:
1. If possible, move mounting location to match structure
behind the wall.
2. Avoid electrical / plumbing behind the wall.
3. Where possible, drill through tile - not through grout.
RECOMMENDED INSTALLATION LOCATIONS:
Side Wall (Figure 1a) - approximately 30-36" from back
wall, depending on toilet size & location.
Opposite Wall (Figure 1b)- recommended only if
opposite wall is close enough to safely reach.
Rail Height(Figure 1)- Install rail between 24-36"
depending on height of user.
INVISIA™ TOILET ROLL HOLDER INSTALLATION
Place a blanket down in the area that you will be installing
the Invisia™ Wall Toilet Roll Holder to protect the floor
from parts that may fall during installation. The proposed
mounting location must be cleaned prior to installation.
Refer to the fastener chart on page 1 to determine the
size of hole required for the appropriate wall construction.
NOTE: It may occur that one hole may be installed into a
stud, and the others installed with SnapToggle® toggle
bolts.
A1. Secure the corian base to the rail with the supplied flat
head bolts and supplied hex key. See Figure 4 for proper
orientation.
A2. Mark the horizontal and vertical location of the Invisia
™ Wall Toilet Roll Holder (if possible, line up the center
hole of the wall plate with the wood stud - use snap
toggles for outside holes if applicable). Use a level that
spans across the Wall Toilet Roll Holder to ensure the rail
is straight as shown in Figure 2.
A3.Use the wall plates as a locating guide and mark wall
with center punch. NOTE: If wall has tile, a light tap is all
that is required for punch to make notch.
A4.Use the appropriate drill bit on the marked wall to drill
a pilot hole for the fasteners. If SnapToggle® toggle bolts
are to be used, please see the separate installation
instructions. Continue with step A5.
A5. Fasten the Wall Toilet Roll Holder with the appropriate
fasteners, lock washer and plastic retainer washer as
shown in Figure 4.
NOTE: Perform a final tighten and inspection of all
fasteners. Test the installation by vigorously pulling on
the support handle of the Wall Toilet Roll Holder.
A6. Install the plastic snap caps to the plastic retainer
washers to cover the screws.
Your Invisia™ Wall Toilet Roll Holder is now installed.
WOOD
STUD
30-36"
24-36"
(a)
BACK
SIDE
OPPOSITE
(b)
FASTENER
LOCK
WASHER
Figure 3. TILE
Cement
Board
WOOD
STUD
“LIGHT TAP”
Figure 2.
www.ActiveForever.com

L
H
Page 3 of 4
.b1erugiF.a1erugiF
B
A
BATHROOM
WALL
(i.e. DRYWALL)
BACKSIDE
ACCESS TO
BATHROOM
L
H
Figure 4.
L
H
Figure 2a. Figure 2b.
TIPS FOR LOCATING A WOOD STUD
• For drywall surfaces, use a stud sensor to locate a stud.
•For tile surfaces, try a stud sensor to locate a stud. If no stud
is found, measure 16" from a perpendicular wall. Drill a small
hole in the grout to ensure the stud has been found. If there is
no stud at this location, bend a piece of wire in a “L” shape
and insert it through the hole. Spin the wire to determine
exactly where the stud is located and mark its location. Patch
all holes with silicone to keep moisture out of the wall.
•If there is access to the backside of the bathroom wall (i.e.
through a closet), measure the stud location and transfer the
measurements into the bath area.
STRUCTURAL REINFORCEMENT SUGGESTIONS
NOTE:Due to variances in local construction methods and
materials used, details given below are suggestions only.
Consult the appropriate local contractor for specific advice.
For concrete walls, you may be able to install fasteners
(such as a wedge anchor) directly into the concrete wall
without modification.
If there is access to the backside of the bathroom wall (i.e.
through a closet) and structural reinforcement is required,
consider cutting a hole in this backside wall to allow access to
the bathroom wall from behind (without having to remove /
replace ceramic tiles).
1. Choose optimal mounting location of rail including height
(H) and side to side location (L) as shown in Figure 1.Mark
the height and location on the wall for future reference. NOTE:
If accessing the bathroom wall from the backside, transfer the
measurements for the support rail location to the backside
wall as shown in Figure 1b.
2. Find wall support studs & cut hole in wall board to expose
wall studs as shown in Figure 1.Suggested hole size is
height (A) of 18-24" (48-61cm) and width (B) corresponding
to wall stud spacing. Expose half width of each stud to
facilitate re-installation of wall board patch. IMPORTANT:
Avoid any utilities located in wall!
3. Fabricate a support frame structure from suitable wood
pieces as shown in Figure 2a.Support frame width (D) should
fit snugly within wall studs. Support frame height (E) should be
from 24-32" (61-81cm) high or more, depending on material
and stiffness of wall studs. Locate top cross member (F) to
position in line with top rail stem when rail is located at the
height (H). Lower cross member (G) should be spaced at C =
11.75" (30cm) center to center from top cross member. Hold
the support rail against the support frame to confirm the cross
members are in the correct location. Use a generous quantity
of wood screws and glue to hold the support frame structure
together as shown. See alternative to support frame as shown
in Figure 3.
4. Insert support frame structure through hole in wall and
secure uprights to wall studs using a generous amount of
wood screws as shown in Figure 2b.
5. Complete the Invisia™ Wall Toilet Roll Holder installation
instructions on Page 2. Then, patch the wall cutout (if backside
accessto bathroom,considermaking an access panelfor
future servicing) to match the surrounding wall as shown in
Figure 4.
Bathroom Tile Wall
(CAUTION: Do notpuncture
when fastening plywood)
Multi-layers of
3/4" plywood
(approx 24" high)
2" X 2" nom. Stud
(approx 36" high)
Wallboard patch
Generous amounts of
wood screws & glue
Backsideaccess to bathroom
(insert structure from this side)
Wall Stud
FIGURE 3: ALTERNATIVE TO SUPPORT FRAME - MULTI-LAYER
PLYWOOD INSIDE WALL WITH WALLBOARD PATCH (TOP VIEW)
D
C
E
F
G
WOOD
SCREWS
www.ActiveForever.com

WTRH200
Weldment, Handle, WTRH
WTRH104
Bar, Axle, WTRH
WTRH106
Knob, Top, WTRH
HW164
Screw, FHSCS,
#10-32 x 1 in L., 18-8 S/S
WTRH107
Top, Corian, WTRH
WTRH105
Base, Corian, WTRH
WTRH300
Assembly, Top, WTRH
Page 4 of 4
x6
HW225
SnapToggle® Toggle Bolt
9.35"
(23.74cm)
1.75"
(4.45cm)
22.25"
(56.52cm)
4.87"
(12.38cm)
.75"
(1.91cm)
3"
(7.62cm)
10.25"
(26.04cm)
INVISIA™ WALL TOILET ROLL HOLDER
HARDWARE
DIMENSIONAL DRAWINGS
HW122
Washer, Flat Bottom,
SnapCap, 12/12-FB
x6 x6 x6
HW121 / HW123
Cap, SnapCap
Chrome / White
x1
HW322
Hex Key, 5/32", Short Arm
HW177
Washer, Lock,
Split, #10 18-8 S/S
x6
HW175
Screw, PPH WS, #10-24 x 2", S/S
x2
HW358
Screw, FHSCS, 1/4-20 x 1 in. L, 18-8 S/S
x6
HW174
Screw, PPHMS, #10-24 x 2", S/S
www.ActiveForever.com
