healthtec 56221 User manual

User Manual for
Southern Cross Universal Examination
Table
MODEL: 56221
SERIAL:
NEED HELP?
FREECALL
1300 362 923
Page 1. © Healthtec Pty Ltd. 2013 www.healthtec.com.au

Page 2. © Healthtec Pty Ltd. 2018 www.healthtec.com.au
FORWARD
Should you have any questions about the content of this manual or our products in general,
please call us on 1300 362 923
SUPPORTING YOU
DISCLAIMER
TABLE OF CONTENTS ............................................................................................2
FORWARD ................................................................................................................2
DISCLAIMER.............................................................................................................2
PRODUCT SPECIFICATIONS..................................................................................3
UNBOXING AND INSTALLATION ............................................................................4
OPERATING INSTRUCTIONS .................................................................................5
MAINTENANCE.........................................................................................................6
VINYL CARE .............................................................................................................7
TROUBLE SHOOTING GUIDE.................................................................................8
THE HEALTHTEC WARRANTY ...............................................................................9
Congratulations on receiving your quality Healthtec™ equipment, proudly designed and
manufactured in Australia.
This manual contains general information on how to unbox, operate and care for your
equipment. Reading and following the instructions thoroughly will maximize the life and
efficiency of your Healthtec™ equipment and aid in its safe operation.
Healthtec Pty Ltd (Healthtec) prides itself on crafting a quality product, known for its
reliability and safety. Healthtec takes no responsibility for any damage or harm that arises
from improper operation and/or care of the equipment nor for any use for which the
equipment was not intended.
The specifications put forth in this manual were in effect at the time of publication.
However, due to Healthtec’s policy of continuous improvement, changes to these
specifications may be made at any time without any obligation on the part of Healthtec Pty
Ltd.
TABLE OF CONTENTS

Page 3. © Healthtec Pty Ltd. 2018 www.healthtec.com.au
The basic specifications are shown below and include:
•Dimensions in millimeters (mm)
•Range of movement in millimeters (mm) and degrees (º)
•Lifting Capacity is 250KG
•Safe Working Load (SWL) is 400 KG
PRODUCT SPECIFICATIONS

Page 4. © Healthtec Pty Ltd. 2018 www.healthtec.com.au
•Be careful not to cut into the box as damage to the upholstery may occur.
•Lift the product from the metal base of the table assembly rather than the table top.
Notes on unboxing
The table will arrive packaged in two box sections held in place with packing strips.
To unbox follow the following steps.
1. Cut the two plastic strips where shown.
2. Lift the box cover to reveal the table.
3. Lift the table out of the box base and place in a clear space on a level surface.
You may then discard of the packaging.
There is no further assembly required on Healthtec™ tables. The electric actuators are
factory adjusted and do not require any further adjustment.
Plug the power plug into a normal 240v power outlet and test the motor to full height.
UNBOXING AND INSTALLATION

Page 5. © Healthtec Pty Ltd. 2018 www.healthtec.com.au
Pull the locking handle towards the
panel and hold to release the lock.
Do not operate electrical components of the table in the presence of flammable anesthetics
due to the risk of explosive ignition.
WARNING
2
Footswitch operation
for table height adjustment
Place the footswitch with the foot tabs facing
up and look for the indicator arrows.
Press and hold the required foot tab until the
desired height is reached then release your
foot from the tab.
DOWN UP
Support the weight of the
section with your hand.
Allow the panel to lower
to the desired height.
Adjusting head and end sections
Head and end sections are adjustable by
releasing the nearby locking handle.
To lower a section
1. Support the weight of the section with
your hand; and
2. Release the locking handle as shown.
3. Allow the section to lower to the desired
height; then.
4. Return the locking handle to its original
position.
To raise a section
Simply pull the section upwards to the
desired height. There is no need to release
the locking handle to raise a section.
Allow the locking handle to return
to the locked position.
OPERATING INSTRUCTIONS
1
4
3

Page 6. © Healthtec Pty Ltd. 2018 www.healthtec.com.au
3
If the bed is located in an area
where it is subject to extreme
amounts of moisture, humidity or
dust, the pins at pivot points and
sliding surfaces should be
cleaned and lubricated.
Lubrication intervals should be
10–12 weeks depending on use.
Recommended lubricant is
CRC-TAC2 which is available at
most local hardware and
automotive stores.
Lubricate motor pins
with CRC TAC2
Lubricate center pin
with CRC--TAC2
Lubricate side block tracks
with CRC--TAC2
MAINTENANCE
3
1
2
1
1
2
3

Page 7 © Healthtec Pty Ltd. 2013 www.healthtec.com.au
Treatment of specific stains
IMPORTANT
VINYL CARE
The vinyl upholstery requires cleaning with warm soapy water to remove oil from
surfaces, especially around the areas where the face, back or chest comes in contact with
the vinyl.
Cleaning intervals should be once per day depending on use.
Always remember:
• Prompt attention yields to maximum removal.
• Wipe stains from ‘outside–in’ to avoid spreading.
Lipstick, Shoe Polishes, Fatty & Greasy Stains
Remove as much of the stain as possible with edge of spoon, then wipe with cloth
moistened with methylated spirits. Wash with warm soapy water and dry with clean
cloth.
Chewing Gum
Set the gum hard with an ice cube. Then scrape over with the edge of a spoon. Wipe over
with methylated spirits and finally with warm soapy water.
Ball Point Pen Ink
Wiping with methylated spirits is sometimes effective if stain is fresh. If stain is dry, treat
with paste made from Fullers Earth or Light Kaolin (available from local chemist) and a
bleach mixed with a few drops of methylated spirits.
Apply to stain and allow to dry for three hours. More than one application may be needed
if the stain has been present for some time.
Never use furniture polishes, abrasive cleaners, steel wool or cleaners containing solvents
as these items can cause damage to the vinyl surface.
Do not use alcohol or aromatic solvents to clean upholstery.

Page 8 © Healthtec Pty Ltd. 2013 www.healthtec.com.au
TROUBLE SHOOTING GUIDE
PROBLEM:
Electric actuator does not operate.
POSSIBLE SOLUTIONS:
1. Make sure that actuator is getting power. Check power plug to see if it is
securely plugged into the electric outlet and the cord is not severed.
2. Check if circuit breaker or fuse to make sure outlet is receiving power.
3. Check that LED on top of control box is on. When footswitch/hand-switch is
depressed, you should hear a click sound, this indicates that foot-switch/hand-
switch is operating.
PROBLEM:
Head Pad or End Pad moves when weight is applied.
POSSIBLE SOLUTIONS:
1. Clean lock bars with alcohol wipes.
2. Rub around the lock bars with a light grade of sandpaper.
3. Replace lock tabs.
If unit still does not function call 1300 362 923 for service advice.

Page 9. © Healthtec Pty Ltd. 2013 www.healthtec.com.au
WARRANTY REGISTRATION
THE HEALTHTEC WARRANTY
1.
Healthtec Pty Ltd (Healthtec) warrants that the product is free of defects in material
and manufacture when it leaves the factory and will address any defects in material or
workmanship without charge as defined below.
2. Warranty is transferrable to any subsequent owner of the product during the warranty
period.
3. The warranty is valid for five (5) years for electrical functions of motors and foot
switches and three (3) years for vinyl from the date of purchase.
4. The warranty is valid for the lifetime of the product for workmanship of structural
manufacture.
5. The warranty is limited to the repair and/or replacement of defective parts and/or
assemblies. The decision to repair and/or replace will be solely at the discretion of
Healthtec. Repair works will be undertaken at Healthtec’s service facility or that of
a Healthtec approved agent on receipt of the product freighted from the customer.
6. This warranty is valid only for products displaying the Healthtec serial number on its
label. Please register your product with Healthtec to help expedite any warranty
claims.
7. Healthtec does not authorize any person or representative to create for it any other
obligation or liability in connection with the sale of its products. Any representative
or agreement not contained in this warranty shall be void and of no effect.
This warranty does not cover.
8. The cost of freight to or from a Healthtec service facility or Healthtec-authorizedagent.
9. The cost of labor and transport of Healthtec technicians or Healthtec authorized
agents to or from a warranty repair away from a Healthtec service facility.
10. Any replacement parts or labor furnished by anyone other than Healthtec or
a Healthtec authorized agent.
11. Any malfunction or failure in the product that is not caused by a defect in the material
or workmanship or if the malfunction or failure is caused by unreasonable use,
including the failure to provide reasonable and necessary maintenance.
12. The warranty does not extend to or bind or obligate Healthtec to pay any
consequential damage or expenditure to business or property caused as a result of
any defect in the product.
To register your warranty the company, visit our website at
http://www.healthtec.com.au/warranty-registration

Page 10. © Healthtec Pty Ltd. 2013 www.healthtec.com.au
WARRANTY CLAIM PROCESS
To obtain service from Healthtec or an authorised agent under this warranty the owner must
abide by the following process:
STEP 1 —REPORT
A written report of the problem encountered must be made by the customer within seven (7)
days of first becoming aware of the problem; and sent to:
HEALTHTEC PTY LTD
132 Tennyson Memorial Ave, Tennyson QLD 4105,
Australia
or; emailed to [e-mail]
or; register a service request online at http://www.healthtec.com.au/service-request
On receipt of a warranty claim, a Healthtec representative will contact you to discuss the
problem and make arrangements for the product to be returned if applicable.
STEP 2 —RETURN
The product must be returned to Healthtec for assessment and claim resolution and be
transported securely so that no additional damage can occur.
The cost of transportation is the responsibility of the customer.
STEP 3 —RESOLUTION
Healthtec service technicians will assess the reported problem and determine if a repair
and/or replacement is warranted and undertake the applicable course of action. The
resolution of the warranty claim should occur within a period of thirty (30) days from receipt
of the returned product.
.
