TR8100VGB Thermostat Instructions

ver 1.1

LCD symbols

See overleaf for further setting up information

Setting the clock and day of the week

This thermostat is fitted with a real time clock. It is essential that the clock time and day are set accurately if you require your programmed events

1) Touch the time display and the time will start flashing.Use the up and down arrows to set the time.By holding the arrow down the time will change faster.

2) Press to move to the Day setting and use the up and down arrows to get to the correct day.

3) Press to store and exit.

to start on time. To set follow the steps below:

Page1

The buttons are locked

Heating is turned on

Automatic mode,

Manual mode

executes the programmed schedules

The floor sensor is not being read by the thermostat

Err

Temporary temperature override

Freeze protection activated

AUTO

Override

Symbol SymbolEvent Event

Program number

Economy temperature

Comfort temperature

Configuration Menu

To enter into the setting menu please follow the steps below:

Step 3, Use the up and down arrows to adjust the sensor selection which is Menu 01(Air sensing;Air and Floor, or Floor only)

Step 4, Press to move to the next Menu and once you have all the menu options set,

Setp 5, Press to accept and store.

Step 1, Turn the thermostat off by pressing ;

Step 2, Press , you will then see menu 01.

POWER

DONE

A = Internal sensor

F = External sensor

Menu #

01 Sensor Selection

Switching Differential

Internal Sensor Calibration

External Sensor Calibration

Minimum temperature limit

Maximum temperature limit

Temperature Format

Clock Format

24 (default), 12- hour or 24-hour clock format

Feature Explanation Adjustment

°C, 2°C....10°C ( 1°C by default)

-1

°C

= decrease 1

°C

, 1

°C

= increase 1

°C

...

-1

°C

= decrease 1

°C

, 1

°C

= increase 1

°C

...

°C~

°C

(35

°C

by default)

°C~

°C

by default)

C or F

A / F ( A by default)

(press up & down buttons to adjust)

The number of degrees difference before switching.

The default is 1°C which means the thermostat will switch

the

heating on 0.5°C below the set temperature and will turn

it off 0.5°C above the set temperature.With a 2°C differential

the heating will switch on 1°C below the set temperature

and will switch off 1°C above the set temperature.

This is to recalibrate the temperature reading from internal sensor

This is to recalibrate the temperature reading from external sensor

This gives you the option to change the minimum set temperature

This gives you the option to change the maximum set temperature

This alows the temperautre to be set to show °C or °F.

You can select the clock to show in either 12 or 24 hour time

5+2 / 7 Day Mode

This allows you to program either 5 days at once, then the

2 days of the weekend separately, or a full 7 days at the

same time or 7 days separately

Freeze Protection on= activated, off= deactivated

01 = 5+2 day programmable

02 = 7 day programmable

This is to avoid the temperature from going below 5

°C

(°C by default)

Setting the Program Schedules

This thermostat has the ability to program each individual day of the week separately, or program 7 days of the week at once. You can also program weekdays

Set to the time you would like to wake to and the temperature you want during the morning, until you left for the day.

Press and the day display will start flashing. (If your thermostat is set to 5+2 day programmable mode, the programming will skip to step3)

Use to adjust the day of the week you want to start programming or to the day you wish to edit an existing event / program.

(Press to select all 7 days of the week, and to cancel press again.)

Press

Use and to adjust the time you wish the Program 1 event to commence for the selected day/days.

Press and the temperature will start flashing.

Use and to set the desired temperature to be maintained during Program 1.

Press and the LCD screen will show Program 2 with the time display flashing, this signifies that the second daily event is now ready to be programmed.

Repeat steps 4,5,6 to set the remaining programs/events, then press to store and exit.

Hint: During setting programs, press will clear a program entry and thermostat will maintain the temperature setpoint of the last executed program

Above are default program schedules, to make changes, follow easy steps as below.

Set to the time you leave home and the temperature you wish your home to maintain while you are away at work perhaps.

Set to the time you return home at end of the day and the temperature you want during evening until bed time.

Set to the time you sleep and the temperature you want overnight(usually a comfortable and energy saving temperature).

07:00

22 °C

16:30 22 °C

09:30 16 °C

22:30

16 °C

WAKE

Program Start Time Setpoint Explanation

LEAVE

RETURN

SLEEP

the LCD screen will show Program 1( ) and the time will be flashing.

Page 2

This product should be installed by

a qualified electrician.

Installation and Wiring

Carefully separate the front half of the thermostat from the back plate by placing a small

flat head terminal driver into the slots on the bottom face of the thermostat.

Carefully unplug the ribbon connector which is plugged in to th

e front half of the thermostat.

Place the thermostat front half somewhere safe. Terminate the t

hermostat as shown in

the

diagrams below.

Screw the thermostat back plate on to the flush box

Re-connect the thermostat ribbon cable and clip the two halves together.

Thermostat Instructions

ver 1.1

until the beginning of the next program.

DONE

DELETE

SCHEDULE

ALL DAYS ALL DAYS

Temporary Temperature Override

Touch the temperature display, and it will start to flash. Use up or down

buttons to adjust. Press to accept, and you will see “Override”

above the temperature display. Thermostat will maintain the new set

Lock the Keypad

To lock the keypad, press and hold the top left corner of

display for 5 seconds,

you will see a lock symbol . To unlock, repeat the steps above and the

Reset to Factory Setting

With thermostat turned off,

press and hold OFF for

5 seconds until you can

DONE

RUN

SCHEDULE

see -- : -- on LCD.

temperature until the next programmed event(comfort level). To cancel

the override setting, press

Auto / Manual Mode

Holiday Function

MODE

HOLIDAY

Press to select Auto/Manual mode. In Manual mode( ), the

thermostat maintains

a constant set temperature manually set by the user.

In Auto mode, the thermostat executes the preprogrammed schedules.

Press , enter the duration of your holiday by or .

Press . To cancel a Holiday,reduce the holiday period to 00 days.

The Holiday function will reduce the current temperature to the freeze protection

temperature. The thermostat will maintain this temperature for the duration of the

holiday and will then automatically return to the program mode on your return.

(5 days) to one schedule and then weekends (2 days) to a different schedule. See the Menu information for details on how to set this up.(refer to Menu 10)

lock symbol will disappear.

TR8100VGB

Contact capacity: 3A,250V

External Sensor

COM

FEED

(230VAC)
