Heatmiser TM1-TS WiFi RF User manual

Operating Instructions
TM1-TS WiFi
01/13 Revision 1.1
Ref: TM1-TSWIFI

1
Contents Page
Setting Up Your WiFi Timeclock 2-9
Display Symbols Explained 10
Understanding the Modes 11
Selecting the Mode 11
5/2 Day / 7 Day Programming 12-13
Switching Time Override 13
Countdown Timeclock Programming 14
Locking the Keypad 15
Holiday 15
Clean Screen 16
Factory Reset 16
Optional Feature Setup 17-18
Wiring Diagrams 19

2
Setting up your WiFi Timeclock
Step 1: Download and install the network utility from our
web site: www.heatmiser.co.uk/wi
Step 2: Connect the timeclock to your pc with the USB
cable provided, this will power the timeclock from the USB
port & will allow you to test the Wi-Fi connection.
On the Utility press Read to view the current timeclock
conguration.
Step 3: You should enter the SSID, Security Type and
Security Code of your wireless network. These settings can
be found in your wireless router, consult your router manual
for more information. For more details see security types
below.
Step 4: You need to enter a xed IP address for your Wi-Fi
timeclock outside of the router DHCP range.
It is likely that your network will be congured to operate on
a DHCP basis – this means your router automatically issues
an IP address to a device that successfully connects to the
network.

3
Your Wi-Fi timeclock needs a xed IP address in order for
local and remote access to operate, so you will need to set
this up manually.
Log into your wireless router and navigate to the LAN
settings page. You should see an option for DHCP setup.
This should detail the IP range that can be assigned to
devices connecting to the network.
As an example, you may have an IP starting range
192.168.1.1 and ending 192.168.1.99.
This would mean you can safely provide your Wi-Fi
Timeclock the IP address 192.168.1.100 as no other devices
will be assigned this address by the router.
If your DHCP range is from 192.168.1.1 to 192.168.1.253
you cannot use 254 or above, you will need to change the
DHCP range, taking care not to change any of the rst 3
numbers.
Tip! When setting up an IP address, the rst three sets of
numbers must be the same as the router IP, the fourth set
must not be used elsewhere on the network.
Step 5: Enter the Subnet mask for the network, this
information can be found in your wireless router.

4
Step 6: You need to enter the IP address of your gateway
and DNS. In most cases, this is the IP address of your
wireless router. If you are using the Multi-Link on the system,
the gateway of the timeclock will need to be the IP address
of the Multi-Link.
Step 7: Browser Username & Password
You should now create a username and password that is
used when you access your timeclock from a web browser.
The default username is admin and the default password is
also admin.
Access PIN
The access PIN is required when you are using the iPhone
app and helps secure your system. This PIN should be
entered in the Network Setup screen.
Step 8: Checking Connection
Once you have entered the details of your Wi-Fi network
press Apply and disconnect your timeclock wait 5 seconds
then reconnect it. Once the timeclock has rebooted wait
approximately one minute, you should then see the Wi-Fi
symbol on the display indicating the Wi-Fi Timeclock has
successfully connected to your network. The Wi-Fi symbol is
3 curved lines just below the OFF button.

5
Security Types & Compatability Explained
The Wi-Fi Timeclock operates on the 802.11b standard. If
your router is a G model, you should ensure it is setup to
work in B&G mode otherwise you will not be able to connect
to your timeclock.
There are currently 4 methods of securing your wireless
connection in common use
These are :
OPEN/DISABLED (not recommended )
W.E.P. (lowest security level)
W.P.A. (medium security )
W.P.A.2. (highest security )
Your choice of security settings in the timeclock must match
the setting in your router. Quite often you will nd WPA and
WPA2 as a single option in the router this is perfectly normal
the router knows which one to use, and you can therefore
set the timeclock up using either one. The password can
be up to 63 characters in length including spaces _. / \
characters.
The W.E.P. option is not so simple. Some routers generate a
hidden password from a pass phrase whilst others require a

6
10 or 26 digit hex password and won’t accept anything else.
Your timeclock utility can deal with both options.
The following restrictions apply:
A hex password can only be made up of the numbers 0 to 9
and the letters a to f, lower case only.
Hex passwords can only be 10 characters or 26 characters
in length.
If a passphrase is used it must be either 5 or 13 characters
in length but can be any letter or number.
Your timeclock will automatically calculate the same hidden
password your router creates from the same phrase.
You will nd most routers have these same restrictions.
Remote Connection Setup
In order to connect to your WiFi timeclock remotely, you need
to forward ports within your router to the WiFi timeclock.
This is usually congured in the Port Forwarding section
of the router, as all routers are congured differently,
you will need to consult your router user manual or the
manufacturers website for more information.

As a brief outline, you should rst create a new service
within your router, specifying the port number and the
IP address to forward to, the port numbers needed are
explained below.
Remote access via smartphone/tablet
To access your WiFi timeclock remotely via smartphone or
tablet, you need to forward port 8068 to the IP address of your
WiFi timeclock.
Remote access via web browser
To access your WiFi timeclock remotely via web browser,
you need to forward port 80 to the IP address of your WiFi
timeclock .
7

Connecting to the Timeclck
from your Web Browser
To connect to your timeclock, open your preferred browser
and enter the IP address that you gave the timeclock during
setup and press enter. You will now be asked for a password
and username, these are both “admin” as deafult. We
recommend you change these settings to ensure the
security of your system.
For further information, click the help link within the
browser.
8

Connecting to the Timeclock from your
Smartphone or Tablet application
To connect to your timeclock, launch the app on your smart-
phone or tablet, there are now three sections to ll in.
Lan IP – This is the static IP address you have assigned to
the WiFi timeclock.
WAN IP – This is either your static IP address or Dynamic
DNS address when connecting to your network remotely.
PIN – This is the four digit pin number assigned to the WiFi
timeclock on conguration.
Once this information has been entered the app will store
this for the next time you connect.
9

Wi-Fi Display Guide
Wi-Fi Thermostat Display Guide
V1.0
Shown on the PRT-ETS WiFi Model. Displayed when the floor temperature
rises above the floor limit temperature.
Indicates the current room temperature.
Indicates the current floor temperature (PRT-ETS WiFi Only).
Indicates the thermostat is in Away Mode.
Indicates the thermostat has successfully connected to the Wi-Fi Router.
Indicates the heating output is on.
Indicates the thermostat is locked.
Indicates whether the timed output is on or off.
Temperature Format Display.
Shown when the thermostat is in “Clean Screen Mode” During this mode,
all buttons are disabled to allow for cleaning of the thermostat.
Shown during a holiday to indicate holiday time remaining.
Shown during a hold period to indicate the hold time remaining.
Wake, Leave, Return, Sleep are the 4 comfort settings available.
Time 1-4 are available only on the PRTHW and TM1 versions.
10

11
Understanding the Modes
The TM1-TS WiFi has three modes of operation.
• 5/2 Day Time-clock
(Provides 4 On/Off switching times for the weekday and
4 On/Off switching times for the weekend)
• 7 Day Time-clock
(Provides 4 On/Off switching times for each day of the
week)
• Countdown Timer
(Allows you to enable the output for a countdown period)
Selecting the Mode
• Press PROG and select Setup.
• At the top of the screen you will see and the
number 06. Use the Up arrow and you will see 12.
• In the centre of the screen, use the to set the
desired mode.
• 00 = 5/2 Day 01 = 7 Day 02 = Countdown timer.
• Press Done to store and exit.

12
Setting The Clock
To set the clock, follow these steps:
• Press Prog
• Press Clock
• Enter the Time (In 24hr Format)
• Press Clock
• Enter the day and month
• Press Clock
• Enter the Year
• Press Done
The clock can also be set via the Browser or app.
5/2 Day / 7 Day Programmable Mode
The following switching times are programmed already,
however you can change them easily.
Weekday On Time Off Time Weekend On Time Off Time
Wake 07.00 09.00 Wake 07.00 09.00
Leave 16.00 20.00 Leave 16.00 20.00
Return --.-- --.-- Return --.-- --.--
Sleep --.-- --.-- Sleep --.-- --.--

13
Changing the Switching Times
• Press PROG.
• Select Time 1.
• You will see TIME 1 and ON flash.
• Use to set the on time for the 1st switching time.
• Press Off and then use to set the off switching time.
• You should now repeat for the Times 2-4.
• Press Day to select the next day. In 5/2 day mode the
TM1-TS WiFi will highlight “Sat Sun” prompting you to
program the switching times for the weekend. In 7 day
mode, the TM1-TS WiFi will highlight Tuesday.
• When complete, press Done to Store and Exit.
Switching Time Override
The TM1-TS WiFi has an override function allowing you to
override the output into the opposite state.
• Press Hold.
• If the output is already On – press Off.
• If the output is already Off – press On.

14
You will then see the output status change and the output
indication will flash to show it has been overridden from the
programmed setting. The output will remain in the override
state until the next programmed time. To cancel, repeat the
steps above.
Timeclock Off
To turn the timeclock off completely, press and hold the Off
button. The display and output will be turned off. To turn the
timeclock back on, press the On button.
Count Down Timer Mode
• Use to select the Countdown time.
• Press Done.
The output will be active until the Countdown time expires
and the hold duration will display the time left.
To cancel the Countdown early, repeat the steps above
reducing the time to 00.00.

15
Locking the Keypad
The TM1-TS WiFi has a keylock facility. To enable this press
the bottom right corner of the display and hold for 10 seconds.
When activated, you will see .
To cancel, repeat the steps above.
Holiday
(5/2 Day / 7 Day Programmable Mode Only)
The Holiday function turns the output off for the number of
days programmed. During the holiday, the TM1-TS WiFi will
indicate the number of holiday days left.
Assume you program a holiday on Monday for 1 day, the
holiday will start immediately, but the TM1-TS WiFi will count
the next day (Tuesday) as the holiday. The TM1-TS WiFi will
then revert back to its program at midnight Tuesday.
• Press HOLIDAY.
• Enter the duration of your holiday.
• Press Done.
• To cancel a Holiday, reduce the Holiday time to 00 days.

16
Clean Screen
Pressing Clean Screen will disable all buttons, allowing you
15 seconds to wipe the screen clean.
Factory Reset
The timeclock has a factory reset function. This will reset all
settings back to their factory default.
To perform a factory reset, follow these steps:
Turn off the timeclock by pressing and holding the off
button. Press and hold the bottom left corner of the LCD for
10 seconds. You will see all the icons appear for 2 seconds
and then disappear. You now need to power down the
timer for 5 seconds and then power on again.

17
THE FOLLOWING SETTINGS ARE OPTIONAL
AND IN MOST CASES NEED NOT BE ADJUSTED
Optional Features Explained
Feature 06 - Not used on this model.
Feature 12 – Mode Select: This function allows you to
select between 5/2 Mode, 7 Day mode or Countdown timer.
Adjusting the Optional Settings
To adjust the settings, follow these steps:
• With the timeclock turned on.
• Press PROG.
• Press SETUP.
• Use the at the top of the screen to select the
feature number (shown on page 18) and then use the
keys in the centre to adjust the setting.
• Press Done to accept and Store.

Feature Table
Feature Description Setting
06 Comms # Not used on this model
12 Mode Select 00 = 5/2 Day
01 = 7 Day
02 = Countdown
18
