Heator HEATOR R 271 C User manual

Edition 2002 - 2003
Strictly for internal use
Transportation Cap
THE 10 MOST IMPORTANT SPARE PARTS
Spare part de scription Model EAN Code
TECHNICAL SPECIFICATIONS
Control
Type heater Control
Brand name Heator
Model no. R 271 C (Type C)
Toyotomi Model Name RS-L27D-HT
Brown 8713508710396
R 271 C
Glass fibre felt wick F 8713508001517
Removable fuel tank D 8713508401607
Fuel tank cap high A 8713508400600
Fuel filter open C 8713508702186
Ignition coil 8713508400402
Wick sleeve 8713508001616
Glass cylinder 8713508020808
Transportation cap U38 8713508402505
Manual fuel pump 8713508400105
Tank lid 8713508000510
BOTTOM LINE ASSORTMENT
Burner type Single Combustion (BL) Dimensions (mm) Width 428
Capacity (W) max. 2900 (including base plate) Depth 295
Tank capacity 4.0 litres Height 455
Burning time tank (hr) 13 hours Fuel consumption (l/hr) Max 0.302
Suitable space (m2)32-42 Fuel consumption (g/hr) Max 242
Suitable space (m3)80-105 Wick height (mm) 9 to 11
Weight heater (kg) 7.5 Internal diameter (mm) 65
Languages manual French Material wick FELT
Accessories Transportation cap, A5 size operating manual
Guarantee 2 years (except ignition coil, glass cylinder(s) and wick)

Control
Strictly for internal use
*Patent Toyotomi
Edition 2002 -2003
FEATURES HEATOR R 271 C
Equipped with a wick-stop mechanism according to NF regulations
No fuel indicator
Grill conform NF regulations
Equipped with a white and cheaper felt wick. This wick will not be ordered as a spare
part because it is interchangeable with the existing felt wick for this heater
No batteries included
No manual fuel pump included
No plastic bag
No plumb bob
New:
- automatic burner switch off 5 sec. after fuel tank removal.
- top plate of the battery compartment will be fastened with a small screw.
- top and bottom end of the carton box will be brown instead of white.
Remarks
Automatic Tip-Over-Switch: The heater is shut off in case of knocking over the heater.
High Efficiency: the heater has a 99.99% heat efficiency with infrared-ray heating.
Great Heating Capacity: The 2.9 kW capacity ensures a capacity to heat an entire
room.
No Installation: This heater needs no wires, no pipes and no flues. This makes the
heater very mobile.
Extinguishing Stop: This heater is equipped with an extinguishing stop. By one simple
push on the stop, the heater will be turned off.
Room Temperature Thermistor: This heater automatically shuts off when used in a
room with too high a room temperature (oxygen shortage).
Made in Japan: Complies with International Quality Control Standard ISO 9000.
Superior quality and finish of top-plate and cabinet.
Wick-Stop: The wick-stop mechanism prevents the consumer to adjust the burner and
therefore limits the exhaust of CO to stay below 50 ppm.
10
Automatic Tip-Over
Switch
Open Filter
Room Temperature
Thermistor
Gross Weight:
Extinguishing stop
340 mm
500 mm
20 ft 376
40 ft 776 Block 7x4=28
Euro 5x4=20
480 mm
