HedoAjim CT07302010WH User manual

Assembly Instructions
Decorate your home，Brighten wonderful life
[email protected]
SKU:CT07302010WH/CT07302020BK
Decorate your home, Brighten wonderful life

NOTICE:
RETURN/DAMAGE CLAIM INSTRUCTIONS:
Basic precautions should always be followed when using this product. Please read all instructions before using the cabinet and retain the
education for future reference.
Failure to observe all instructions and warnings may cause severe property damage or personal injuries.
When unpacking, please be careful don't cut too deep to damage the products in the box. Just use the blade to scratch the parcel tape.
Check the product and hardware accessories in the box; and confirm whether the instructions are complete.
When installing, please pay attention to the protection of the parts. The soft material must be placed under the product, and please carefully
handle it to avoid surface damage.
After the assembly is completed, please adjust the placement position according to the actual situation.
Keep children away from cabinets, accessories, and installation tools. They are at risk of injury to the child.
Two people are recommended for assembly.
If you need the electronic manual,please contact our customer service to get it.（[email protected]）
HedoAjim product is shipped in a single carton box. If you haven't received the package or need to know the tracking of the package,
get in touch with us immediately via Amazon message or contact us via [email protected].
If the package is damaged, please get in touch with us from the very beginning. Attaching a damaged photo is appreciated.
HedoAjim product accepts returns within 30 days without any reason. If you return this item for personal reasons, you must cover the
return fee and order processing fee (0- 20% restocking fee based on the invoice price). We will cover the freight if the product has quality issues
(not caused by humans).
Please keep the original box if you need to return the goods. Please use our return label and do not return it without permission.
If you return the product after 30 days of receiving it, we are afraid your return application won't be accepted. We appreciate your understanding.
Any damages,defects and parts missings during installation, pls contact us from the very beginning. Replacement, exchange and refund will be
arranged ASAP except of personal reasons.
Customer Service: [email protected].
01 Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
We're just happy cuz you're happy.
If you don't know how to express your new-
found joy, we can get a few suggestions.
Tell your family and friends.
Share your experience by writing a review.
Our friendly customer service team will work
hard to make you have a big smile.
[email protected]
CUSTOMER CARE
HAPPY NOT HAPPY
Here's how to contact us.
02

Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
03 04
E
×1
Part List Hardware List
A
×42
B
×42
C
×30
D
×4
Open the package，and
put the item on the mat with care.
Please install it carefully to ensure
your fingers will not be scratched.
③
①
⑥
③
②
②
⑤
⑤
④
④
Top Panel
Top Right Side Panel
Bottom Right Side Panel
Top Front Fanel
Bottom Front Panel
Top Back Panel
Bottom Back Panel
Top Left Side Panel
Bottom Left Side Panel
Bottom Panel

Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
A
×10
Start...
Step1
05 06
A
Screw the bolt A into the pre-drilled holes on
⑥Panel.
Step2
C
×16
Screw the bolt C into the side holes on panel ④
and panel ⑤.
④
C
C
C
C
④
C
C
C
C
C
C
C
C
⑤
C
C
C
C
⑤
C
A
⑥
A
A
A
A
A
A
A
A
A
A

Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
Step4
07 08
A
A
A
AA
AA
A
A
A
A
A
A
A
A
A
A
A
AA
A
A
A
①
A
A
×24
Screw the bolt A into the pre-drilled holes on
①Panel
Step3
B
×10
Connect the panel ⑥and panel ④and panel ⑤
with bolt B. Then tighten B clockwise as below
shown：
⑥
④
④
B
B
BB
⑤
⑤
Please follow the above prompt,screw the bolt B
from inside of box.

Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
09 10
Step5 Step6
A
A
A
A
C
C
C②
A
A
A
A
C
C
C②
A
×8
Screw the bolt A into the pre-drilled holes on
②Panel；Screw the wooden dowel C into
the side holes on ②Panel.
C
×6
C
C
C
C
③
C
C
C
C
③
Screw the wooden dowel C into the side holes
on ③Panel
C
×8

Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
11 12
Step7 Step8
③
③
③
③
②
②
②
②
Turn it over as below shown( It means that all Wooden
dowel C should be facing down).
②
②
③
③
B
B
B
B
B
B
B
B
×8
Connect the ②Panel and ③Panel with B
（3 in 1 locking）Then tighten them at holes
position clockwise,As below shown：

Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
13 14
Step9 Step10
B
×10
D
×4
Connect the bottom part and the top part with A，
Tighten bottom part with B（3 in 1 locking）at holes
position clockwise.Stick the D（rubber feet pads）
to the coner of ⑥Panel.
③
③
②
②
B
BB
B
B
①
⑥
⑤
④
D
D
D
D
B
③
③
②
②
B
BB
B
B
B
①
B
B
×14
Connect the ②and ③Panel with ①Panel.
Then tighten all panels with B（3 in 1 locking）
at holes position clockwise.As below shown：

Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
15 16
Step11
E
×1
Step12
A
③
③
②
②
①
⑥
⑤
④
E
E
E
Stick the LED Strip to ①Panel. Remove the protective film.

Decorate your home, Brighten wonderful life Decorate your home, Brighten wonderful life
17 18
About HedoAjim LIMITED WARRANTY
HedoAjim furniture team would like to improve customer service quality and make your experience smooth.
Return Policy:HedoAjim accepts returns within 30 days without any significant reason. After we receive the returned item, we will check it and
make sure that it is not damaged, then we will process the refund. For more details, please check the above terms of RETURNDAMAGE CLAIM
INSTRUCTIONS.
Any damages,defects and parts missings during installation, pls contact us from the very beginning. Replacement, exchange and refund will be
arranged ASAP except of personal reasons.
The exceptions or exclusions to this warranty are as follows:
1. HedoAjim does not accept claims outside of a limited period.
2. This warranty does not include the products purchased by mistake.
3. Any damages、brokens、missing parts, HedoAjim will repair or replace them without charging you any cost within a reasonable period.
We reserve the right to require damaged parts to be returned to us upon our request.
If you have any questions concerning this warranty, please get in touch with the HedoAjim Customer Service department via Amazon message
or [email protected]. Be prepared to provide your name, address, daytime phone number, the product's model and purchase order
number, the date of purchase, and the store name. All the information you provided will help us track your order quickly and solve your problem
in the shortest time. This warranty gives you specific rights, and you still possess other rights that vary in each case.
HedoAjim break the traditional monotonous furniture style and give it new meaning through LED lights,
which are both functional and beautiful. Our professional team provides you with innovative and
customized design and attentive service, aiming to meet our customer’s specific needs around the
world, bringing you high quality furniture and colorful and meaningful life. Since now, we have expanded
into the production of a wide variety of LED lighted furniture from living room,bedroom to bathroom.
Your Dream Home is Waiting
Customer Service: [email protected]
