heimgard Indoor 360 User manual

Indoor 360°
camera 2
Quick start guide version 1.0
Requires a
Heimgard
smart home
Hub

What is in the box
A. Camera
C. EU USB
power adapter
D. Screws &
wall anchors
B. Micro USB
power cable
E. Mounting bracket F. Positioning map
For wall mounting, you will also need electric drill, as well
as a twist drill bit when using wall anchors.

Device overview
To locate the reset button (I), gently slide the camera lens
(H) up to the top of the camera. The button is located at the
bottom left of the lens housing.
G.
H.
I.
J.
K.
LED-indicator
Camera lens
Join / reset button
Ethernet port
Power input
G.
H. I.
K.
J.

LED indicator status
OFF
Powered o.
Rebooting after reset.
RED LIGHT FLASHING
Network connection failed.
SOLID RED LIGHT
Booting.
Device malfunction.
RED AND GREEN LIGHT FLASHING
Firmware upgrading.
GREEN LIGHT FLASHING
Waiting for network.
SOLID GREEN LIGHT
Operating properly.

1.
3.
2.
Connect the power cable (B) to the power
input (K). Insert the power cable into the USB
power adapter (C). Connect the USB power
adapter to a wall socket.
Manage
Devices
Camera conguration
LED indicator status
Open the Heimgard app and follow these
steps to connect your camera.
Select Indoor 360° camera 2 from the list.
The camera is now
booting. Wait until the
LED-indicator (G) ashes
green before continuing.

4. From the drop-down menu, select the name of
your Wi-Fi network (SSID).
NOTE! Select 2.4 GHz (not 5 GHz) if you have
both options. You can also enter the network
name (SSID) manually.
Remember to distinguish between uppercase
and lowercase letters.
5. On the line below, enter your Wi-Fi password,
then tap Next.
6. Before pressing Next, make sure the LED (G)
on the camera is ashing green.
7. A QR code will now appear on the screen. Turn
the phone screen toward the camera lens (H)
to connect the camera to the Wi-Fi network.
Turn the brightness of the screen on your phone to
maximum for optimal readability of the QR code in front of
the camera.

Hold the phone in front of the
camera lens (H) and slowly move
it away until the QR code is
accepted (LED indicator (G) goes
from ashing calm green to fast
ashes indicating that the camera is
connecting to your Wi-Fi network).
8. When the camera is connected to the network,
the LED indicator (G) on the camera will light
solid green, and you will automatically be taken
to the Congure Devices screen. This might
take up to several minutes.
9. You can now give the camera a name, such
as “Camera hallway” and connect it to a room.
Create a new room if the desired room or area
does not already exist in the overview.
If you have multiple cameras to set up, repeat step 2, 3, and
6 to 9 to add them individually.
If you change the Wi-Fi network or the LED (G) indicates a
fault, reset the camera (see page 12).

The camera starts recording when it detects motion
(records up to ve minutes). If motion is still detected after
ve minutes, the recording continues in a new clip.
Conguration and use
Advanced settings:
The camera can be used for two purposes:
Recording and Generic.
Generic:
The camera does not record when it detects motion.
In the app you can stream and start recording manually.
Recording:
On motion: The camera will record when motion is detected.
On motion when away: The camera will record only when
“Away mode” for the alarm is activated and motion is
detected.

Where to place your camera
Place the camera as high as possible, in a place where it
has a good overview of the area it is to capture and near a
power outlet.

Floor
Wall
Freestanding on
a table / shelf
Wall mounting
Mounting examples

Wall mounting
Before you start: Make sure that the wall material is strong
enough to support 3 times the weight of the camera, and
that you use screws that are suitable for the wall material.
The supplied screws are intended for wood or similar
material and can in combination with the wall anchors
be used for mounting in concrete. For mounting on
plasterboard walls, lightweight concrete or similar, it is
recommended to contact a specialist retailer for advice on
suitable fastening materials and anchors.
1.
2.
3.
When using wall
anchors, use the
enclosed positioning
map when pre-drilling
the holes
Attach the mounting
bracket to the wall.
Connect the device to power and adjust the lens
to the desired position.

1.
2.
3.
To locate the reset button (I), gently slide the
camera lens (H) up to the top of the camera.
The button is located at the bottom left of the
lens housing (see the illustration below).
Press and hold the reset button (I) for 10
seconds to disconnect the camera from your
network. The LED indicator (G) will now turn o.
To re-install the camera, return to “congure
camera” in the manual, and proceed from
step 2.
I.
H.
G.
Factory reset

Factory reset
Need help?
Web: heimgard.com/support
E-mail: [email protected]
Facebook: facebook.com/heimgardnorge/
Phone: [phone]
Visit heimgard.com for more information and tips and
tricks on how to use your Heimgard smart home solution.
Heimgard Technologies AS hereby declares that radio
equipment of the type Indoor 360° Camera 2 is in
accordance to Directive 2014/53 / EU. The full text of the
EU Declaration of Conformity is available at the following
web address: www.heimgard.com

heimgard.com
