Heinner HCF-H98F+ User manual

CHEST FREEZER
Model:
HCF-H98F+/HCF-H145F+/
HCF-H205F+
www.heinner.ro
•Chest freezer
•Energy class: F
•Net capacity: 95/142/198 L

www.heinner.com
1
Please read the instructions carefully and keep the manual for future information.
This manual is designed to give all necessary instructions concerning installation, use and
maintenance of the unit. In order to operate the unit correctly and safely, please read this
instruction manual carefully before installation and use.
I. INTRODUCTION
II. YOUR PACKAGE CONTAINS
➢Chest freezer
➢User manual
➢Certificate of warranty
Thank you for choosing this product!

www.heinner.com
2
III. SAFETY AND WARNING INFORMATION
For your safety and correct usage before installing and first using the appliance, read this
user manual carefully, including its hints and warnings. To avoid unnecessary mistakes
and accidents, it is important to make sure that all people using the appliance are
thoroughly familiar with its operation and safety features. Save these instructions and be
sure that they remain with the appliance if it is moved or sold, so that anyone using it
throughout its life, will be properly informed on its usage and safety notices.
For the safety of life and property, keep the precautions of these user's instructions as
the manufacturer is not, responsible for damages caused by omission.
Safety for children and others who are vulnerable people
According to EN standard
This appliance can be used by children aged from 8 years and above and persons with
reduced physical, sensory or mental capabilities or lack of experience and knowledge if
they have been given supervision or instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by children without supervision.
According to IEC standard
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning use of the appliance by a
person responsible for their safety.
Keep all packaging away from children as there is risk of suffocation.
If you are discarding the appliance, pull the plug out of the socket, cut the connection
cable (as close to the appliance as you can) and remove the door to prevent children
playing from suffering an electric shock or from closing themselves inside it.
If this appliance, featuring a magnetic door seals, is to replace an older appliance having
a spring lock (latch) on the door or lid, be sure to make the spring lock unusable before
you discard the old appliance. This will prevent it from becoming a death trap for a child.
It is dangerous to alter the specifications or modify this product in any way.
Any damage to the cord may cause a short circuit, fire, and/or electric shock.

www.heinner.com
3
GENERAL SAFETY
WARNING: This appliance is intended to be used in household only.
WARNING —Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
WARNING —If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualified persons in order to avoid a hazard.
WARNING —Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING —Do not use mechanical devices or other means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING —Do not damage the refrigerant circuit.
WARNING —Do not use electrical appliances inside the food storage compartments of
the appliance, unless they are of the type recommended by the manufacturer.
WARNING - The refrigerant and insulation blowing gas are flammable. When disposing
of the appliance, do so only at an authorized waste disposal centre. Do not expose to
flame.
WARNING —When positioning the appliance, ensure the supply cord is not trapped or
damaged.
WARNING —Do not locate multiple portable socket-outlets or portable power supplies
at the rear of the appliance.
WARNING —Damaged supply cord must be replaced by an authorized service.
REPLACING THE ILLUMINATING LAMPS
WARNING - The illuminating lamps must not be replaced by the user! If the illuminating
lamps is damaged, contact the authorized service for assistance.
This warning is only for refrigerators that contain illuminating lamps.
REFRIGERANT
The refrigerant isobutene (R600a) is contained within the refrigerant circuit of the
appliance, a natural gas with a high level of environmental compatibility, which is
nevertheless flammable. During transportation and installation of the appliance, ensure
that none of the components of the refrigerant circuit becomes damaged. The
refrigerant (R600a) is flammable.
WARNING —Refrigerators contain refrigerant and gases in the insulation. Refrigerant
and gases must be disposed of professionally as they may cause eye injuries or ignition.
Ensure that tubing of the refrigerant circuit is not damage prior to proper disposal.
WARNING –RISK OF FIRE/FLAMMABLE MATERIALS
If the refrigerant circuit should be damaged:
-Avoid opening flames and sources of ignition.
-Thoroughly ventilate the room in which the appliance is situated. It is dangerous to
alter the specifications or modify this product in any way. Any damage to the cord may
cause a shortcircuit, fire, and/or electric shock.

www.heinner.com
4
ELECTRICAL SAFETY
1. The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged. A crushed or damaged
power plug may overheat and cause a fire.
3. Make sure that you can access the main plug of the appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power plug. There is a risk of
electric shock or fire.
6. You must not operate the appliance without the interior lighting lamp cover.
7. The fridge is only applied with power supply of single phase alternating current of
220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the
voltage exceeds the above scope, for safety sake, be sure to apply A.C. Automatic
voltage regulator of more than 350W to the fridge. The fridge must employ a special
power socket instead of common one with other electric appliances. Its plug must
match the socket with ground wire.
DAILY USE
Do not store flammable gas or liquids in the appliance, there is a risk of an explosion.
Do not operate any electrical appliances in the appliance (e.g.electric ice cream
makers,mixers etc.).
When unplugging always pull the plug from the mains socket, do not pull on the cable.
Do not place hot items near the plastic components of this appliance.
Do not place food products directly against the air outlet on the rear wall.
Store pre-packed frozen food in accordance with the frozen food manufacture’s
instructions.
The appliances manufactures storage recommendations should be strictly adhered to.
Refer to relrelevant instructions for storage.
Do not place carbonated or fizzy drinks in the freeze compartment as it creates
pressure on the container,which may cause it to explode,resulting in damage to the
appliance.
Frozen food can cause frost burns if consumed straight from the freezer compartment.
Do not place the appliance in direct sunlight.
Keep burning candles,lamps and other items with naked flames away from the
appliance so that do not set the appliance on fire.
The appliance is intended for keeping food stuff and/or beverages in normal
household as explained in this instruction booklet The appliance is heavy.Care should
be taken when moving it.

www.heinner.com
5
Do not remove nor touch items from the freezer compartment if your hands are
damp/wet,as this could cause skin abrasions or frost/freezer burns.
Never use the base,drawers, doors etc. to stand on or as supports.
Frozen food must not be refrozen once it has been thawed out.
Do not consume ice popsicles or ice cubes straight from the freezer as this can cause
freezer burn to the mouth and lips.
To avoid items falling and causing injury or damage to the appliance, do not overload
the door racks or put too much food in the crisper drawers.
Opening the door for long periods can cause a significant increase of the temperature in
the compartments of the appliance.
Clean regularly surfaces that can come in contact with food and accessible drainage
systems.
Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
If the refrigerating appliance is left empty for long periods, switch off, defrost, clean, dry,
and leave the door open to prevent mould developing within the appliance.
CAUTION! CARE AND CLEANING
Before maintenance, switch off the appliance and disconnect the mains plug from the
mains socket.
Do not clean the appliance with metal objects, steam cleaner, ethereal oils, organic
solvents or abrasive cleansers.
Do not use sharp objects to remove frost from the appliance. Use a plastic scraper.
INSTALLATION
For electrical connection carefully, follow the instructions given in this manual.
Unpack the appliance and check if there are damages on it.
Do not connect the appliance if it is damaged. Report possible damages immediately to
the place you bought it. In this case retain packing.
It is advisable to wait at least four hours before connecting the appliance to allow the oil
to flow back in the compressor.
Adequate air circulation should be around the appliance, lacking this leads to
overheating. To achieve sufficient ventilation, follow the instructions relevant to
installation.
Wherever possible the back of the product should not be too close to a wall to avoid
touching or catching warm parts (compressor, condenser) to prevent the risk of a fire,
follow the instructions relevant to installation.
The appliance must not be locate close to radiators or cookers.
Make sure that the mains plug is accessible after the installation of the appliance.

www.heinner.com
6
STORAGE THE FOOD
Note: Children aged from 3 to 8 years are allowed to load and unload refrigerating
appliances. (This clause applies only to the EU region.)
When refrigerating food, please be careful not to contact the surface of the inner box
directly.
Two-star frozen-food compartments are suitable for storing pre-frozen food, storing or
making ice cream and making ice cubes.
One-, two- and three-star compartments are not suitable for the freezing of fresh food.
When frozen food, in order to prevent moisture loss, prevent the odor, should separate the
different food sealed storage, and can only use non-toxic, tasteless, impermeable,
waterproof sealing material.
Hot food should be cooled to room temperature first, then put into the freezer, otherwise it
will affect the storage status of other foods and increase the power consumption.
This appliance is intended to be used in household and similar applications such as:
•staff kitchen areas in shops, offices and other working environments;
•farm houses and by clients in hotels, motels and other residential type
environments;
•bed and breakfast type environments;
•catering and similar nonretail applications;

www.heinner.com
7
Order
Compartments
TYPE
Target storage
temp.[ ℃ ]
Appropriate food
1
Fridge
+2≤+6
Eggs, cooked food, packaged food, fruits and
vegetables, dairy products, cakes, drinks and
other foods are not suitable for freezing.
2
(***)*-Freez
er
≤-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and
nutrition), suitable for frozen fresh food.
3
***-Freezer
≤-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and
nutrition), are not suitable for frozen fresh food.
4
**-Freezer
≤-12
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended for 2 months, the longer the
storage time, the worse the taste and nutrition),
are not suitable for frozen fresh food.
5
*-Freezer
≤-6
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended for 1 months, the longer the
storage time, the worse the taste and nutrition),
are not suitable for frozen fresh food.
SERVICE
Any electrical work required to do the servicing of the appliance should be carried out by
qualified electrician or competent person.
This product must be serviced by an authorized Service center and only genuine spare
parts must be used.
1. If the appliance is Frost Free.
2. If the applaince contains freezer compartment.

www.heinner.com
8
To get the best energy efficiency of this product, please place all shelves, drawers on their
original position as the illustration.
Never touch the interior of the freezer chamber or frozen foods in the compartment with
wet hands as this could result in frostible.
The above image is for reference only, configuration is subject to the actual product.
IV. PRODUCT DESCRIPTION

www.heinner.com
9
V. HOW TO USE
BEFORE USE
Remove shipping package, tape etc. and leave doors open for a while in order to ventilate the
appliance.
The unit is cleaned before shipment. However, it is recommended to clean the compartment
interior once afte delivery.
Please insert power supply plug into the wall outlet, type “grounded single-phase 220-240V”.
Allow the unit to operate for about 1 hour to cool the compartment before placing items into the
appliance.
WAIT 5 MINUTES OR MORE BEFORE RE-STARTING
Restarting the unit immediately after it has been turned off may cause fuses to blow and activate
the circuit-breaker, the compressor may become overloaded and/or another damage may occur.
EFFICIENT USE
Please follow the instructions below in order to save energy consumption:
•To prevent cold air escaping from the appliance open and close the door quickly and keep the
door opened for as short time period as possible.
•Please install the unit in a well-ventilated location.
•Do not use the unit to store water or food that requires water as a storage medium. Never place
fresh seafood containing water directly into the unit.
•All accessories, such as drawers, shelves, door balconies should be kept in original place for
lower energy consumption.
CHECKS
To ensure the safety, perform the following checks after cleaning the unit:
•Is the power cord plug firmly inserted into a dedicated wall outlet? Confirm that the plug is not
abnormally hot.
•Check the power cord for cracks and damage, should the slightest irregularity be observed,
contact the dealer from whom you purchased the unit or the authorisez service.
TEMPERATURE ADJUSTEMENT
-To adjust the temperature inside the freezer compartment, adjust the temperature control dial
on front-bottom side of the chest freezer. Normally use chest freezer with temperature MID. If
the cooling performance is inadequate, turn the temperature control dial in the direction of
MAX. If it is too cold, turn the dial in the direction of MIN.
-When you need the unit to stop running temporally, please turn the temperature control dial in
the direction of Off.

www.heinner.com
10
Appliance description
Installation: Any electrical work that is required to install this appliance MUST be carried
out by a qualified electrician.
Warning: THIS APPLIANCE MUST BE GROUNDED
Before making any electrical connections, ensure the following:
-Electrical connection
-Electrical safety is only guaranteed when the grounding system of your house is in
accordance with the related local regulations.
-Do not damage the refrigerant circuit.
-Do not bend, stretch or pull the supply cable to avoid electric shock.
-Do not use electrical appliances inside the food storage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
-Ensure the power socket is suitable for the maximum power of the machine (fuses in
the power circuit must be 13 amp).
-The supply voltage should be the same as that indicated in the technical specifications
and the appliance rating plate.
-The appliance should be grounded and in compliance with the applicable laws.
-When installed, the power socket must be within easy reach.
-If the socket outlets in your home are not suitable for the plug supplied with this unit
check with a qualified electrician for replacement.
-The use of adapters, multiple connectors or extension cables is not recommended.

www.heinner.com
11
VI. CLEANING AND DEFROSTING
To prevent any electrical shock hazards or injury by the rotating circulation fan,
disconnect the power cord plug from the wall outlet before cleaning.
Exterior
Wipe with a soft, dry cloth. If very soiled, wipe with a cloth that has been moistened with
detergent, then wipe with a cloth that has been dipped in clean water.
Warning:
Do not splash water directly onto the appliance and do not wash with water. A
short-circuit and/or electrical shock could be caused.
•Clean the cooler regularly to keep it clean at all times.
•Never use polishing powder, sopa powder, benzine, oil or hot water as these will
damage the painting and plastic components.
•Keep ventilation openings in the appliance enclosure or in the built-in structure, clear
of obstructions.
•Open the door and wipe clean with a dry cloth.
You should defrost the freezer compartment two or three times a year when the ice is
about 4 mm thick. To defrost, follow these steps :
-Set the thermostat to “MAX” at least 12 hours before defrosting.
-After this period has elapsed, switch off the freezer compartment by removing the
plug from the main power supply.
-Remove all food from the freezer and wrap them in paper and store trhem in a cold
place and leave the door open.
-When the defrosting is finished, the compartment must be cleaned and wiped dry.
-Switch the appliance back on using the thermostat set to “MAX” and wait at least
one hour before replacing the foodstuffs.
-After a few hours the thermostat can be set back to the original position.
WARNING:
Do not use mechanicals devices or other artificial means to accelerate the defrosting
process, other than those recommended by the manufacturer.
WARNING:
Do not use electricals appliances inside the food storage compoartment of the
appliances, unless they are the type recommended by the manufacturer.

www.heinner.com
12
CLEANING BEFORE USE
Before using the appliance for the first time, wash the interior and all internal accessories
with lukewarm water and some neutral soap so as to remove the typical smell of a brand
new product, then dry thoroughly.
Important! It is necessary to have good ventilation around the freezer to allow for the
dissipation of heat, high efficiency, and low power consumption. For this reason,
sufficiently cleared space should be available around the freezer. It is advisable for there
to be 75mm separating the back of the freezer to the wall and at least 100mm of space
on its two sides, a height of over 100mm from its top.
This refrigerating appliance is not intend to be used as a built-in appliance.
Appliances must not be exposed to rain. Sufficient air must be allowed to circulate in the
lower rear section of the appliance, as poor air cisculation can affect performance.
Built-in appliances should be positioned away from heat sources such as heaters and
direct sunlight.
Install this appliance at a location where the ambient temperature corresponds to the
climate class indicated on the rating plate of the appliance:
For refrigerating appliances with climate class:
- extended temperate: this refrigerating appliance is intended to be used at ambient
temperatures ranging from 10 °C to 32 °C (SN);
- temperate: this refrigerating appliance is intended to be used at ambient
temperatures ranging from 16 °C to 32 °C (N);
- subtropical: this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 38 °C (ST);
- tropical: this refrigerating appliance is intended to be used at ambient temperatures
ranging from 16 °C to 43 °C (T);
Leveling
The appliance should be level in order to eliminate vibration. To make the appliance
level, it should be upright and both adjusters should be in stable contact with the floor.
You can laso adjust th elevel by unscrewing the appropiate level adjusment in the front
(use your fingers or a suitable spanner).

www.heinner.com
13
Warning! Before trouble-shooting disconnect the power supply. Only a qualified electrician
or other person must carry out the trouble-shooting that is not in the manual.
Important! Repairs to the appliance may only be performed by competent service engineers.
Improper repairs can give rise to significant hazards for the user. If your appliance needs
repairing, please contact your specialist dealer or your local Customer Service Center.
Power failure
Keep the opening and closing of the door for a minimum time to prevent cold air from
escaping.
Avoid placing new items in the cooler as this will raise the temperature inside the
compartment
In case of a long power suspension, place dry ice in the freezer
Power cord problems
If the supply cord is damaged. It must be replace by a special cord or assembly available
from the manufacturer or the service agent.
The showcase must be positioned so that the plug is accessible to the wall outlet
When not used for a
long period
Remove all items from the compartment and disconnect the power cord plug from the
wall outlet.
Clean the compartment interior and wipe away all water.
To prevent mold formation and foul odors, leave the door open to dry the compartment
completely.
Transportation
Disconnect the power cord plug from the wall outlet.
When moving the appliance, make sure that the feet do not damage the power cord
Do not let the feet hit against floor steps , thresholds, etc
Temporary storage
Put piece of wood or other similar item between , the door and main unit to prevent
complete closing of the door
Be sure not to store the unused chest freezer in a location where children play
Should a child enter the compartment and the door is closed , the child may not be able
to open the door from the inside
Please check the following if you encounter problems with the unit. If the problem continues
after taking the proper remedial actions, disconnect the power cord plug from the wall
outlet.
Transfer the items stored in the cooler to a box or other container. Then contact the dealer
from whom you purchased this unit and be ready to provide information as listed in the
"REQUIRED INFORMATION" below.
To prevent any electrical shock hazards, do not disconnect the power cord plug from the wall
outlet with wet hands.
VII. TROUBLESHOOTING

www.heinner.com
14
No refrigeration at
all
Is the power supply interrupted?
Is the power cord plug disconnected from the wall outlet?
Are the shop's power fuses blown and/or the circuit breaker
activated?
Is the temperature control not turned to OFF?
Inadequate
refrigeration
Is the place of installation ventilated?
Is the freezer exposed to direct sunlight, placed near a heater or
stove?
Are the lids opened and closed frequently?
Are items stocked beyond the load line?
Is the temperature control dial in the direction of MAX.
If it is too cold, turn dial in direction of MIN.
Is a lot of frost forming in the freezer compartment?
Excessive noise
Is the floor underneath the freezer sturdy enough?
Is the unit shaking and/or rattling?
Is the rear panel of the unit in contact with a wall, etc .?
Is there a container or something behind the freezer?
The compressor will generate a rather loud sound for a while
after operation
is started. The noise will cease together with refrigeration.
Condensation on
cooler
exterior
Condensation may condense on the exterior of the unit and
the door during hot and humid days or depending on the
place of installation. This occurs when the humidity is high
and water particles in the cold surfaces. This is normal.
Wipe away condensation with a dry cloth.

www.heinner.com
15
The
circumference of
chest freezer feels
hot
Especially in summer or in the period of starting running, the
circumference of the chest freezer feels hot because the Chest
freezer inside has a pipe for radiating and preventing
condensation. The heat does not affect inside goods.
CUSTOMER CARE AND SERVICE
Always use original spare parts.
When contacting our Authorised Service Centre, ensure that you have the following
data available: Model and Serial Number.
The information can be found on the rating plate. Subject to change without notice.
TECHNICAL DATA
The technical information is situated in the rating plate on the internal side of the
appliance and on the energy label.
The QR code on the energy label supplied with the appliance provides a web link to
the information related to the performance of the appliance in the EU EPREL
database.
Keep the energy label for reference together with the user manual and all other
documents provided with this appliance.
It is also possible to find the same information in EPREL using the link https://
eprel.ec.europa.eu and the model name and product number that you find on the
rating plate of the appliance.
To access information about your product in the EPREL portal, you can scan the codes
below:
Thank you for purchasing this product. If you need support with your product, visit
our website using the links below.
Get User manuals: https://www.heinner.ro
Get Service information: https://www.heinner.ro

www.heinner.com
16
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working electrical equipment’s to
an appropriate waste disposal center.
HEINNER is a registered trademark of Network One Distribution SRL. Other brands and product
names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from NETWORK
ONE DISTRIBUTION.
Copyright © 2013 Network One Distribution. All rights reserved.
www.heinner.com, http://www.nod.ro
http://www.heinner.com, http://www.nod.ro
This product is in conformity with norms and standards of European Community.
Importer: Network One Distribution
Marcel Iancu, 3-5, Bucharest, Romania
Tel: [phone], www.heinner.com , www.nod.ro
