Heinner HCF-M362CA+ User manual

CHEST FREEZER
Model: HCF-M362CA+
www.heinner.com
•Chest freezer
•Net capacity: 359L
•Energy class: A+

www.heinner.com
1
Thank you for chosing this product!
Please read this instruction manual carefully before using it and kee it for later information
This manual is conceived for ofering you all of the necessary info regarding instalation, using
and maintenance of the machine. For a correctly and safely use of the machine, please, read
this manual before instalation and using.
I. INTRODUCTION
II. PACKAGE CONTENTS
➢Chest freezer
➢Instruction Manual
➢Warranty card

www.heinner.com
2
III. SAFETY WARNINGS
According to IEC standard
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety.
Keep all packaging away from children as there is risk of suffocation.
If you are discarding the appliance, pull the plug out of the socket, cut the connection
cable (as close to the appliance as you can) and remove the door to prevent children
playing from suffering an electric shock or from closing themselves inside it.
If this appliance, featuring a magnetic door seals, is to replace an older appliance having a
spring lock (latch) on the door or lid, be sure to make the spring lock unusable before you
discard the old appliance. This will prevent it from becoming a death trap for a child.
Children aged from 3 to 8 years are allowed to load and unload refrigerating appliances
(this clause applies only to the EU region).
WARNING —Do not store explosive substances such as aerosol cans with a flammable
propellant in this appliance.
WARNING! The refrigerant and insulation blowing gas are flammable. When disposing of
the appliance, do so only at an authorized waste disposal centre. Do not expose to flame.
WARNING! When positioning the appliance, ensure the supply cord is not trapped or
damaged.
WARNING! Do not locate multiple portable socket-outlets or portable power supplies at
the rear of the appliance.
WARNING! The illuminating lamps must not be replaced by the user! If the illuminating
lamps is damaged, contact the customer helpline for assistance. This warning is only for
refrigerators that contain illuminating lamps.
Refrigerant
The refrigerant (R-290) is contained within the refrigerant circuit of the appliance, a
natural gas with a high level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the appliance, ensure that none of
the components of the refrigerant circuit becomes damaged. The refrigerant (R-290) is
flammable.
WARNING! Refrigerators contain refrigerant and gases in the insulation. Refrigerant and
gases must be disposed of professionally as they may cause eye injuries or ignition. Ensure
that tubing of the refrigerant circuit is not damage prior to proper disposal.

www.heinner.com
3
This appliance is intended to be used in household only.
If the supply cord is damaged, it must be replaced qualified persons in order to avoid a
hazard.
DO not store explosive substances such as an appliance.
The appliance has to be unplugged after use an appliance.
WARNING: Keep ventilation openings, in the appliance enclosure or in the built-in
structure, clear of obstruction.
WARNING: Do not use mechanical devices or other measn to accelerate the defrosting
process, other than those recommendend by the manufacturer.
WARNING: Do not damage the refrigerant circuit.
WARNING: Do not use electrical appliances inside the food strorage compartments of the
appliance, unless they are of the type recommended by the manufacturer.
WARNING: Please abandon the appliance according to local regulators for it use
flammable blowing gas and refrigerant.
WARNING: When positioning the appliance, ensure the aupply cors id not trapped or
damaged.
WARNING: Do not locate multiple portable socket-outlets or prtable power supplies at the
rear of the appliance.
DO not use extension cords or ungrounded (two prong) adapters.
DANGER Risk of child entrapment. Before you throw away the appliance:
- Take off the doors.
-Leave the shelves in place so that children may not easily climb inside.
The appliance must be disconnected from the source of electrical supply before
attempting the installation of accessory.
Refrigerant
The refrigerant (R-290) is contained within the refrigerant circuit of the appliance, a
natural gas with a high level of environmental compatibility, which is nevertheless
flammable. During transportation and installation of the appliance, ensure that none of
the components of the refrigerant circuit becomes damaged. The refrigerant (R-290) is
flammable.
WARNING! Refrigerators contain refrigerant and gases in the insulation. Refrigerant and
gases must be disposed of professionally as they may cause eye injuries or ignition. Ensure
that tubing of the refrigerant circuit is not damage prior to proper disposal.

www.heinner.com
4
WARNING! Risk of fire
If the refrigerant circuit should be damaged:
•Avoid opening flames and sources of ignition.
•Thoroughly ventilate the room in which the appliance is situated.
WARNING! During using, service and disposal the appliance, please pay attention
to symbol similar as left side, which is located on rear of appliance (rear panel or
compressor) and with yellow or orange color. It’s risk of fire warning symbol. There are
flammable materials in refrigerant pipes and compressor. Please be far away fire source
during using, service and disposal.
CHANGING THE LIGHT
WARNING—The illuminating lamps must not be replaced by the user! If the illuminating
lamps is damaged, contact the customer helpline for assistance. This warning is only for
refrigerators that contain illuminating lamps.
Electrical safety
1. The power cord must not be lengthened.
2. Make sure that the power plug is not crushed or damaged. A crushed or damaged
power plug may overheat and cause a fire.
3. Make sure that you can access the main plug of the appliance.
4. Do not pull the main cable.
5. If the power plug socket is loose, do not insert the power plug. There is a risk of
electric shock or fire.
6. You must not operate the appliance without the interior lighting lamp cover.
7. The fridge is only applied with power supply of single phase alternating current of
220~240V/50Hz. If fluctuation of voltage in the district of user is so large that the voltage
exceeds the above scope, for safety sake, be sure to apply A.C. Automatic voltage
regulator of more than 350W to the fridge. The fridge must employ a special power
socket instead of common one with other electric appliances. Its plug must match the
socket with ground wire.

www.heinner.com
5
Meaning of safety symbols
Prohibition symbol
This is a prohibition symbol.
Any incompliance with instructions marked with this symbol may
result in damage to the product or endanger the personal safety
of the user.
Warning symbol
This is a warning symbol. It is required to operate in strict
observance of instructions marked with this symbol, or otherwise
damage to the product or personal injury may be caused.
Note symbol
This is a cautioning symbol. Instructions marked with this symbol
require special caution. Insufficient caution may result in slight or
moderate injury or damage to the product.
Electricity related warnings
•Do not pull the power cord when pulling the power plug of the freezer. Please firmly
grasp the plug and pull out it from the socket directly.
•Do nopt damage the power cord under any condition so as to ensure safety use, do
not use when the power cord is damaged or the plug is worn.
•Worn or damaged power cord shall be replaced in manufacturer-authorized
maintenance stations.
•The power plug should be firmly contacted with the socket or else firs might be
caused. Please ensure that the grounding electrode of the power socket is equipped
with a reliable grounding line.
•Please turn off the valve of the leaking gas and then open the doors and windows in
case of leakage of gas and other flammable gases. Do not unplug the freezer and
other electrical appliances considering that spark may cause a fire.
•To ensure safety, it is not recommended to place regulators, rice cookers, microwaves
ovens and other appliances on the top of the freezer, those recommended by the
manufacturer are not included. Do not use electrical appliances in the food pan.

www.heinner.com
6
IV. PRODUCT DESCRIPTION
Door handle
Shelving basket (2)
Power cord
Shutter
Temperature control
panel
Cabinet
Drainage hole
✓The low temperature of freezer may keep food fresh for a long time and it is mainly
used to store frozen foods and making ice.
✓The freezer is suitable for storage of meat, fish, shrimp, dumplings, rice balls and
other foods not to be consumed in short term.
✓Chunks of meat are preferably to be divided into small pieces for easy access. Please
be noted food shall be consumed within the shelf time.

www.heinner.com
7
HANDLE INSTALLATION STEP 1
Pick out the screws (2) on the freezer cabinet and door by tools, total 7 pices and pick out
the handle base with lock (1) handle cover (3) and lock ring (4)
Step 2 –fix the handle base (1) on the door by driving 5 pices of screws picked
Step 3 –fix the handle cover (3) in the way of handle orbit (1)
Step 4 –fix the lock ring (4) oin the freezer cabinet using the balanced screws (2)
NOTE: if the lock ring failed to hold the lock when installing handle, please unscrew the
round head screws (5) on the back of door and adjust the position of door upper and
lower. Then drive the screw to fix the handle.

www.heinner.com
8
V. USING INSTRUCTIONS
BEFORE USE
•Do not arbitrarily disassemble or reconstruct the freezer, nor damage the refrigerant
circuit, maintenance of the appliance must be conducted by a specialist.
•Damaged power cord must be replaced by the manufacturer, its maintenance
department or related professionals in order to avoid danger.
•The gaps between freezer doors and between doors and freezer body are small, be
noted not to put your hand in thse areas to prevent from squeezing the finger. Please
be gentle when opne the freezer door to avoid falling articles.
•Do not pick foods or containers with wet hands in the freezing chamber when the
freezer is running, especially metal containers in order to avoid frostbite.
•Do not allow children to enter or climb the freezer to prevent that children are
trapped inside or injured by the falling freezer.
•Do not spray or wash the freezer, do not put the freezer in moist places easy to be
splashed with water so as not to affect the electrical insulation properties of the
freezer.
•Do not place heavy objects on the top of the freezer considering that objects may fall
when opne the door and accidental injuries might be caused.
•Please pull out the plug in case of power failure or cleaning. Do not connect the
freezer to power supply within five minutes to prevent damages to the compressor
due to successive starts.
•Do not put flammable, explosive, volatile and higly corrosive items in the freezer to
prevent damaged to the product or fire accidents.
•Do not place flammable items near the freezer to avoid fires.
•This product is household freezer and shall be only suitable for storage of foods.
According to national standards, househols freezer shall not be used for other
purposes, such as storage of blood, drugs or biological products.
•Do not place items such as bottled or sealed container of fluid suhc as bottled beers
and beverages in the freezer to prevent burtst and other losses.

www.heinner.com
9
TEMPERATURE CONTROL
•Connect the freezer to power supply and “Power” indicator (the green light will
shine. “Run” indicator (the red light) will shine when the compressor is running.
•The set temperature is adjusted through the thermostat knob. The number “1,
2,3,4,5,6,7,8 do not mean a specific temperatures, the lower the number ism the
higher the temperature inside will be and vice versa.
•“1-2-3” stands for cooling.
•“4-5-6-7-8” stands for freezing.
•When turn to “SUPER”, the freezer enters into fast freezer mode, and the
compressor will not stop until you turn the knob to the other position.

www.heinner.com
10
PLACEMENT
5. The freezer shall stay for half an hour before connecting 220~240V/50Hz power when
it is firstly started.
6. The freezer shall run 2 to 3 hours before loading fresh or frozen foods; the freezer
shall run for more than 4 hours in summer in advance considering that the ambient
temperature is high.
1. Before using the freezer, remove all packaging
materials including bottom cushions and foam pads
and tapes inside the freezer, tear off the protective
film on the door and the freezer body.
2. Keep away from heat and avoid direct sunlight. Do
not place the freezer in moist or watery places to
prevent rust or reduction of insulating effect.
3. The freezer is placed in a well-ventilated indoor
place; the ground shall be flat, and sturdy.
4. The top space of the freezer shall be greater than
70cm, and the distances from both sides and
backside shall be more than 20cm to facilitate the
opening and closing and heat dissipation. Wipe
the freezer inside and outside with warm moist rag
(add a small amount of detergent in the warm
water and wipe clean finally with clean water).

www.heinner.com
11
Positioning
Energy saving tips
•The appliance should be located in the coolest area of the room, away from heat
producing appliances or heating ducts and out of the direct sunlight.
•Let hot foods cool the rrom temperature before placing in the appliance. Overloading
the appliance forces the compressor to run longer. Foods that freezer too slowly may
lose quality or spoil.
•Be sure to wrap foods properly and wipe containers dry before placing them in the
appliance. This cuts down on frost build-up inside the appliance.
•Appliance storage bin should not be lined with aluminum foil, wax paper or paper
toweling. Liners interfere with cold air circulation, making the appliance less efficient.
•Organize and label food to reduce door openings and extended searches. Remove as
many items as needed at one time and close the door as soon as possible.
To avoid contamination of food, please respect the following instructions:
•Opening the door for long periods can cause a significant increase of the
temperature in the compartments of the appliance.
•Clean regularly surfaces that can come in contact with food and accessible drainage
systems.
•Store raw meat and fish in suitable containers in the refrigerator, so that it is not in
contact with or drip onto other food.
• Two-star frozen-food compartments are suitable for storing pre-frozen food,
storing or making ice cream and making ice cubes.
•One , two and three-star compartments are not suitable for the
freezing of fresh food.
Note: Please store different foods according to the compartments or target storage
temperature of your purchased products.
•If the appliance is left empty for long periods, switch off, defrost, clean, dry, and
leave the door open to prevent mould developing within the appliance.
•When refrigerating food, please be careful not to contact the surface of the inner box
directly.
•When frozen food, in order to prevent moisture loss, prevent the odor, should
separate the different food sealed storage, and can only waterproof sealing material.
•Hot food should be cooled to room temperature first, then put into the freezer,
otherwise it will affect the storage status of other foods and increase the power
consumption.

www.heinner.com
12
Order
Compartments
TYPE
Target storage
temp.[ ℃ ]
Appropriate food
1
(***)*-Freezer
≤-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and
nutrition), suitable for frozen fresh food.
2
***-Freezer
≤-18
Seafood (fish, shrimp, shellfish), freshwater
aquatic products and meat products
(recommended for 3 months, the longer the
storage time, the worse the taste and
nutrition), are not suitable for frozen fresh food.
3
**-Freezer
≤-12
Seafood (fish, shrimp, shellfish), freshwater aquatic
products and meat products (recommended for 2
months, the longer the storage time, the worse the
taste and nutrition), are not suitable for frozen
fresh food.
4
*-Freezer
≤-6
Seafood (fish, shrimp, shellfish), freshwater aquatic
products and meat products (recommended for 1
months, the longer the storage time, the worse the
taste and nutrition), are not suitable for frozen
fresh food.

www.heinner.com
13
➢Cleaning
1. Dusts behind the freezer and on the ground shall be timely cleaned to improve the
cooling effect and energy saving. The interior of the freezer should be cleaned regularly
to avoid odor. Check the door gasket regularly to make sure there are no debris. Clean
the door gasket with mild soap and water. Please turn off the power before cleaning,
remove all food, shelves, drawers, etc. Soft towels or sponge dipped in a solution made
of two tablespoons of baking soda and a quart of warm water and non-corrosive neutral
detergents are suggested for cleaning. The freezer of shall be finally cleaned with clean
water and dry cloth. Open the door for natural drying before the power is turned on.
2. For areas that are difficult to clean in the refrigerator (such as narrow gaps or
corners), it is recommended to wipe them regularly with a soft rag, soft brush, etc. and
when necessary, combined with some auxiliary tools (such as thin sticks) to ensure no
contaminant accumulation in these areas.
3. Do not use soap, detergent, scrub powder, spray cleaner, etc., as these may cause
odors in the interior of the refrigerator
4. Do not use hard brushes, clean steel balls, wire brushes, abrasives, such as
toothpastes, organic solvents (such as alcohol, acetone, banana oil, etc.), boiling water,
acid or alkaline items clean refrigerator considering that this may damage the fridge
surface and interior.
4. Do not rinse with water so as not to affect the electrical insulation properties. Please
use a dry cloth when cleaning temperature control knob and electrical components.
Please unplug the freezer for defrost and cleaning.
➢Defrost
1. Freezer shall be manually defrosted.
Unplug the freezer and open the freezer door, remove foods and drawers before
defrosting; Open the outflow holes and drainage holes (and place water container at
the outflow holes); indoor frost will naturally melt, wipe the defrost water with a dry,
soft cloth. When the frost softens, an ice scraper might be used to accelerate de-icing
process.
2. Please remove the food and put in a cool place when defrosting before removing
accessories.
Other mechanical devices or other means shall not be used to accelerate except those
recommended by the manufacturer. Do not damage the refrigerant circuit.
VI. CLEANING AND MAINTENANCE

www.heinner.com
14
➢Stop using
Foods can be preserved for a couple of hours even in summer in case of power failure; it is
recommended to reduce the frequency of opening door and do not put fresh foods into the
freezer.
Please unplug the freezer left unused for a long time for cleaning. Keep the door open to
avoid the bad odor.
Do not turn upside, horizontally place or vibrate the freezer, the carrying angle can not be
greater than 45°. Please hold the door and hinge when moving.
Continuous operation is recommended when the freezer is started. Please do not move
the freezer under normal circumstances so as not to affect the freezer's service life.

www.heinner.com
15
No operation
Whether the freezer is plugged and connected to power;
Low voltage;
Whether temperature control knob is in the work area;
Failure power or tripping circuit
Odor
Odorous foods should closely wrapped;
Whether foods are rotten;
Whether the interior shall be cleaned
Long-term operation of
compressor
It is normal that freezer operates for longer time in summer when the
ambient temperature is higher;
Do not put too much food in the freezer at one time;
Do not put foods until they are cooled;
Frequent opening of freezer door;
Thick frost layer (defrost is needed)
The freezer door cannot be
properly closed
The freezer door is stuck by food packages;
Too much food;
Unbalanced freezer
Loud noises
Whether the floor is flat, whether the placmenet of freezer is stable;
Whether the freezer accessories are properly placed
Transient difficulty in door
opening
After refrigeration, there will be pressure difference between the inside
and outside of the freezer to result in transient difficulty in door opening.
This is a normal physical phenomenon.
Freezer enclosure heat
condensation
The freezer enclosure may emit heat during operation especially in
summer, this is caused by the radiation of the condenser, and it is a
normal phenomenon.
Condensation: condensation phenomenon will be detected on the
exterior surface and door seals of the freezer when the ambient humidity
is large, this is a normal phenomenon, and the condensation can be wiped
away with a dry towel.
Airflow sound buzz clatter
Refrigerants circulating in the refrigerant lines will produce eruption of
sound and grunts which is normal does not affect the cooling effect.
Buzz will be generated by running compressor specially when starting up
or shutting down.
The solenoid valve or electric switch valve will clatter which is a normal
phenomenon and does not affect the operation.
The following simple issues can be handled by the user. Please call the after-sale service
department if the issues are not settled.
Warm tips:
VIII. TROUBLESHOOTING

www.heinner.com
16
PRODUCT FICHE
CHEST FREEZER HEINNER HCF-M362CA+
Brand
HEINNER
Category
Chest Freezer
Code
HCF-M362CA+
Energy efficiency class
A+
Energy consumption*
kWh/an
304
Total gross volume
litri
359
Total net volume
litri
359
Climate class**
N/SN/ST/T
Freezer rating
****
Freezing capacity
kg/24h
17
Refrigerant
R/g
R290/80
Noise level (max)
dB
44
Control system
Mechanical
Defrost
Manual
Autonomy
h
55
Adjustable thermostat
Yes
Handle
External
Lock
Yes
Accessories
Basket
2
Logistic data
Net dimensions (WxDxH)
cm
125.5 x 74.5x 82.5
Gross dimensions (WxDxH)
cm
128.9 x 77.8 x 88.5
Net weight
kg
51
Gross weight
kg
58
* Energy consumption of 304 kwh per year, calculated on the basis of results in 24 hours under
normalised test conditions. Real energy consumption depends on the conditions in which the
equipment is used as well as where it is placed.
** This appliance is designed for used at an ambient temperature within:
SN - +10 to +32°C;
N - +16 to +32°C;
ST - +16 to +38°C;
T -+16 to +43°C.

www.heinner.com
17
Environment friendly disposal
You can help protect the environment!
Please remember to respect the local regulations: hand in the non-working electrical equipment’s to
an appropriate waste disposal center.
HEINNER is a registered trademark of Network One Distribution SRL. Other brands and
product names are trademarks or registered trademarks of their respective holders.
No part of the specifications may be reproduced in any form or by any means or used to make any
derivative such as translation, transformation, or adaptation without permission from NETWORK
ONE DISTRIBUTION.
Copyright © 2013 Network One Distibution. All rights reserved.
www.heinner.com, http://www.nod.ro
This product is in conformity with norms and standards of European Community.
Importer: Network One Distribution
Marcel Iancu Street, 3-5, Bucharest, Romania
Tel: [phone], www.heinner.com , www.nod.ro

www.heinner.com
18
LADĂ FRIGORIFICĂ
Model: HCF-M362CA+
www.heinner.com
•Ladă frigorifică
•Capacitate netă: 359 L
•Clasa de energie: A+

www.heinner.com
19
Vă mulțumim pentru alegerea acestui produs!
Înainte de a utiliza acest aparat, citiți cu atenție manualul de instrucțiuni și păstrați-l
pentru consultări ulterioare.
Acest manual este conceput pentru a vă oferi toate instrucţiunile necesare referitoare la
instalarea, utilizarea şi întreţinerea aparatului. Pentru utilizarea corectă şi în siguranţă a
aparatului, vă rugam să citiţi cu atenţie acest manual de instrucţiuni, înainte de instalare şi
utilizare.
I. INTRODUCERE
II. CONȚINUTUL PACHETULUI DUMNEAVOASTRĂ
➢Ladă frigorifică
➢Manual de utilizare
➢Certificat de garanție
