HELGI HLG0314-V2.0 User manual

1X4 HDMI Splitter
User manual
Thank you for purchasing this product. For optimum performance and safety, please read the
instructions carefully and keep the manual for future reference.
Important Safety instructions:
1. Use DC 5V power supply only. Make sure the specification matched if using 3rd party DC
adapters.
2. Put product in dry and ventilated place for normal heat dissipation.
3. Keep product away from strong static and magnetic environment.
INTRODUCTION
1x4 HDMI splitter distributes 1 HDMI source to 4 HDMI displays simultaneously. Apply for STB,
DVD, Media Player, Laptop, D-VHS and other HD-Player devices. It's compatible with HDMI 3D
and 4Kx2K.
FEATURES:
1. Distribute 1 HDMI source to 4 HDMI displays
2. Support ultra HD resolution 4K×2K@60Hz
3. Support HDMI 3D
4. Plug and play
5. Good compatibility
6. Metal heat sink design
PACKAGE CONTENTS
（1）HDMI Splitter×1
（2）User Manual×1
（3）DC5V/2A Power Adapter×1
INSTALLATION REQUIREMENT
1. Source: HDMI video source, such as DVD, PS3, STB, PC, Etc.
2. Display: HDTV, projector or other display with HDMI port
3. Cable: High standard HDMI cable (can support 4Kx2K)

INTERFACE SPECIFICATION
HDMI Output HDMI Input HDMI Output Power Input（DC5V/2A）
Output LED power output LED
Indicator Indicator Indicator
INSTALL ATION
1. Connection
1）Connect the HDMI video source output port to the splitter input port
by HDMI cable
2）Connect the splitter output port to HDMI display by HDMI cable
3）Set the TV input to right HDMI channel
4）Power on the splitter (Power indicator led will light on)

FAQ
Q: No image output?
A: 1) Check the power supply of splitter, make sure the power light is on.
2) Check if the HDMI cables connected well.
3) Check and make sure the TV has been set up to the right channel.
4) While connect with PC or notebook via HDMI, please make sure the output mode is mirror
or extend.
Q: Display is unstable, splash screen, snowflakes or audio stuck?
A: 1)Check and make sure all connections are good and correct.
2)Try to directly connect HDMI source to display, if it is the same, please change the source
device.
3)Use high-quality HDMI 1.4 cable and HDMI 2.0 for transmitting 4K×2K UHD signal

SPECIFICATION
Items Specifications
Input ports 1 x HDMI
Output ports 4 x HDMI
Power indicator led
1 xLED
Signal indicator led
4xLED
HDMI Version
Compatible with DVI1.0, HDMI1.4,HDMI2.0
HDCP Version
Compatible with HDCP1.4,HDCP2.2
HDMI Resolution 480i/480p/756i/756p/720p/1080i/1080p/
4K×2K@24/25/30/60Hz
Frequency Range
25MHz~600MHz
Video form
Support 12 bit full HD video, 3D video and
4K×2K@30/60Hz ultra HD video
Input and output
TMDS signal
0.5~1.5Vp-p(TMDS)
Input and output
DDC signal
5Vp-p(TTL)
Audio
Support standard audio and DSD（Direct Stream
Digital）and HD(HBR) audio
Working temperature
0
℃～
60
℃
Power supply
DC5V/2A
Power consumption
<8W
Dimension
158mm(L)x80mm(W)x17mm(H)
Weight 196g
Color Black
Disclaimer
The product name and brand name may be registered trademark of related manufacturers.TM
and ®may be omitted on the user manual. The pictures on the user manual are just for
reference,and there may be some slight difference with the real products.We reserve the rights to
make changes without further notice to a product or system described herein to improve
reliability, function or design.
